Founten FS-REPEATER-XR User manual
Status Indicator Lights
There are 2 green lights on the repeater. The one labeled
STATUS give an indication of the operational state of the unit.
The one labeled SIGNAL indicates the strength of the
wireless signal detected by the repeater.
STATUS
ff – No Power
Fast Blink – Power Up (1 second)
Short Blink – Trying to Join Wireless Network
Slow Blink – Trying to Reach Cloud Servers
Solid n – Fully Active (Forwarding Wireless Traffic)
SIGNAL
ff – No Active Wireless Network Detected
Short Blink – Weak Signal Detected (Not Usable)
Slow Blink – Marginal Signal Detected (Partially Usable)
Solid n – Good Signal Detected (Fully Usable)
09/01/2014
Installation Guide
FS-REPEATER-XR Wireless Repeater
The Wireless Repeater is used to extend the range of your Founten
wireless network by bridging the distance between Founten devices.
This unit only requires a power connection for operation and should
be installed in a location approximately halfway between devices
which are unable to reach each other directly.
Wall Mounting
The Wireless Repeater is designed to be wall mounted using
the included 3M Command Removable Strip or using the
screw mount on the rear of the unit.
Find a suitable location which is:
Within 4 feet of an electrical outlet
At least 4 feet away from other wireless devices
Away from large metal objects which may interfere
with the wireless signal
Above office equipment which may interfere with the
wireless signal
Installation Steps
1. Attach the Command Strip to the back of the Wireless
Repeater.
2. Insert the power cable from the included power adapter
into the Wireless Repeater.
3. Plug the power adapter into an electrical outlet.
4. Attach the Wireless Repeater to the wall using the
Command Strip you attached to the back of the unit.
nce the unit has been powered up it will automatically join
the wireless network and begin forwarding wireless
messages. No further installation steps are required.
09/01/2014
