Fox Spirit PGM490 V2 User manual

PGM490 V2
USER’S GUIDE
Curved Monitor 49''

Preface
Every effort has been made to ensure that the information in this document is accurate.
However, the manufacturer and the distributor of this product assume no responsibility for
any error, omission.
Please preserve this manual for the life of the equipment.
Congratulations on your purchase!

DECLARATION OF CE CONFORMITY MARKING
Product in accordance with the applicable regulations on the European territory, with the
requirements EMC 2014/30/EU and LVD 2014/35/EU.
This product is RoHS (Restriction of Hazardous Substances) compliant.
INFORMATION ABOUT RECYCLING
This product bears the selective sorting symbol for waste electrical and
electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive in
order to be recycled or dismantled to minimize its impact on the environment.
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially dangerous
fors the environment and human health due to the presence of hazardous substances.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United
States and other countries.

TABLE OF CONTENT
SAFETY NOTICE
PRECAUTIONS
MAINTENANCE AND CLEANING
SPECIAL NOTES ON LCD MONITORS
PACKAGE CONTENT
PRODUCT OVERVIEW
MONITOR BUTTONS
MONITOR PORTS
STAND INSTALLATION
REMOVING THE STAND
WALL MOUNTING
CONNECTIVITY OPTIONS
POWER SUPPLY
AUDIO OUTPUT
VIDEO OUTPUT
BASIC OPERATION
ADAPTATIVE SYNC
INDICATOR LIGHT
OSD MENU
PRESENTATION
OSD MENU FUNCTIONS
SWITCH TO GAMEPLUS AND ECO MODE
PIP (PICTURE IN PICTURE) INPUT INFORMATION
PBP (PICTURE BY PICTURE) RESOLUTION INFORMATION
TECHNICAL SPECIFICATIONS

SPECIAL NOTES ON LCD MONITORS
The following symptoms are normal with LCD monitor and do not indicate a problem.
⚫Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the
Power Switch and then turn it on again to make sure the flicker disappears.
⚫You may find slightly uneven brightness on the screen depending on the desktop pattern you use.
⚫Due to the nature of the LCD screen, an afterimage of the previous screen may remain after
switching the image, when the same image is displayed for hours. In this case, the screen is
recovered slowly by changing the image or turning off the Power Switch for hours.
⚫If the screen suddenly flashes erratically or the backlighting fails, please contact your dealer. Do
not attempt to repair the monitor itself.

PACKAGE CONTENT
Note: 3x PM5*15 screws are needed to
fasten stand stem and base. 1x screw is
provided as spare part.
DP CABLE 1.4 1.8m x1
HDMI CABLE 2.0 1.5m
(100-240V~,50/60Hz, 2.0A, 1.8m)

PRODUCT OVERVIEW
MONITOR PORTS
Audio DP HDMI1(2.0) HDMI2 (1.4) HDMI3 (1.4)

STAND INSTALLATION
2. Take out main parts of accessory bags.
3. Use 3x PM5*15 screws to fasten stem and base.
4. Place the assembled stand into rotation shaft. Please make sure a tighten assembling, when
hearing an audible click from the locking button.

5.Use both hands to stand the assembled machine on a flat desktop.
Note: do not directly press and hold the LCD screen with your hand during the whole machine’s
erection to prevent the screen from breaking
6. After the installation is completed, the monitor needs to be connected with wires. As shown
on the below picture, follow the direction of the arrow, and then remove the rear shell
decorative cover in order to access to the monitor ports.

7. Hold the display screen, rotate the display screen, and plug in the signal cable when you see the port
of the machine sideways.
Pay attention to holding the machine with both hands to prevent the machine from falling.
8. For a neat management, run the cables through the hole intended for this purpose, from the
outside to the inside, before repositioning the rear shell.
Rear shell
Cable gland

REMOVING THE STAND
1. Remove the rear shell cover
2. Press the unlocking button, located under the shell, to unlatch the stand
Make sure to place your monitor safely on a flat surface or on a table before unlocking the
stand.
Unlocking button

WALL MOUNTING
1. Open the carton, remove the foam, remove the upper foam.
2. Remove the original screws x4 ( 1 ) from the opening in the back of the monitor. Follow the
directions received with your mount, stand, or accessory and install the monitor on the
wall or fixture as desired. Remember to use the included screws when attaching anything
to the back of the monitor. Refer to the image ( ) for correct screw placement.
Original Screws x 4
a. Only use the screws (35 mm x 2 pcs, 17mm x 2 pcs) provided with this type of
installation.
b. Do not discard the original screws as these may be needed for future use.
2

3. Your monitor is now ready to be attached to a wall-mounting bracket. To avoid damages,
please do not pinch the screen during bracket installation.
Do not place or hang any objects on the wall bracket. Do not put the monitor higher than 2m
from the ground.
CONNECTIVITY OPTIONS
POWER SUPPLY
Connect the supplied power adapter to the power cable, connect the power adapter to the dedicated
port of the monitor, and then plug the remaining end of the power cable into a wall outlet to power
your monitor.
AUDIO OUTPUT
Plug in your earphones to receive audio signals from your monitor. If your earphones are connected
to the monitor and audio devices are connected to your computer at the same time, the audio devices
will not produce sound.

VIDEO OUTPUT
For the monitor to receive HDMI signals from the computer, use the HDMI cable to connect the
monitor to the computer.
For the monitor to receive DP signals from the computer, use the DP cable to connect the
monitor to the computer.
DP Cable 1.4 1.8m (included)

BASIC OPERATION
Insert one end of the DP cable into your PC’s graphics card. A HDMI cable may also
be used.
1. Connect the other end of the cable to the corresponding connector on your monitor.
DP Connector
Audio Output HDMI Connectors Power Connector
2. Connect the power cable to your monitor then connect the other end to your power source.
It is recommended that you use a surge protector with adequate voltage if a wall outlet cannot
be reached directly.
3. Locate the power button on the monitor and press it to turn the monitor on.
ADAPTATIVE SYNC
The feature itself is off by default. In order to use this feature, please note to set the Adaptive
sync function in the OSD menu to ON. You must have hardware with Adaptive sync capability,
a DP/HDMI cable, and the latest graphic drivers.
To use this feature, connect your computer and monitor with a DP cable. After connecting, you
may receive a prompt to enable the feature on your computer. If you do not receive the prompt,
you may need to enable the function in your graphics card menu. See your graphics card
manufacturer’s documentation for instructions on how to turn on and/or enable Adaptive sync.
INDICATOR LIGHT
Indicator Light

Solid blue light indicates power is on and the monitor is operating normally. Flashing blue light
indicates no video source, no horizontal or vertical signal has been detected or voltage is low. Please
ensure your computer is on and all video cables are fully inserted and/or connected.
OSD MENU
The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on
screen after turning on the monitor and pressing the Mbutton.
2.Press Mbutton to enter the OSD screen (Figure 2).

OSD MENU FUNCTIONS
Main Menu
Sub-Menu
Options
Description
Input Source
HDMI 1 (2.0)
HDMI 2 (1.4)
HDMI 3 (1.4)
NONE
Switch to HDMI signal input
DP
NONE
Switch to DP signal input
Brightness/
Contrast
Brightness
0~100
Adjust display brightness
Blacklevel
0~100
Adjust display blacklevel
Contrast
0~100
Adjust display contrast
DCR
On
Turn on DCR function
Off
Turn off DCR function
Color Setting
Gamma
1.8
Set Gamma add-in
2.0
2.2
2.4
2.6
Picture Mode
Standard, Photo,
Movie, Game,
FPS, RTS
Set visual mode according to activity
Color
Temperature
Warm, Cool, User
Select color temperature
Red
0~100
Green
0~100
Blue
0~100
Low Blue Light
0~100
Hue
0~100
Adjust hue levels
Saturation
0~100
Adjust saturation levels
Quality
Setting
Sharpness
0~100
Set display sharpness
Response Time
Off, High, Middle,
Low
Adjust response time
Noise
Reduction
Off, High, Middle,
Low
Reduce the interference of image noise caused by signal source
interference
Super-
Resolution
Off, High, Middle,
Low
When the resolution of the display screen is low, this function can be
turned on to enhance the image resolution
Dynamic
Luminous
Control
On, Off
Compensate for gray scale display screen and strengthen the expression
of gray scale
Display
Aspect Ratio
Wide Screen, 4:3,
1:1, Auto
Select on-screen aspect ratio
Audio
Mute
On, Off
Turn mute mode on/off
Volume
0-100
Adjust audio volume
Audio Source
HDMI 1
HDMI 2
HDMI 3
DP
Select audio signal input via HDMI or DP
Multi-Window
Multi-Window
Off, PIP Mode,
PBP 2Win
Select PIP/PBP modes according to the number of input signals etc.
Sub Win2 Input
DP, HDMI1,
HDMI2,
HDMI3
Select according to input signal for PIP/
PBP mode

PIP Size
Small,
Medium,
Large
Adjust the PIP/PBP display window size
PIP Position
TopRight, TopLeft,
BottomRight,
BottomLeft
Adjust the PIP/PBP window position
Swap
NONE
Swap the two-channel signal source of only the PIP/PBP 2 screens
function
OSD
Language
English,
简体中文， 한국어,
Русский, Español,
日本語,
Français
Set OSD language
OSD
H-Position
0-100
Adjust the OSD’s horizontal position
OSD V-Position
0-100
Adjust the OSD’s vertical position
OSD
Transparency
0-100
Set the OSD’s overall transparency
OSD Time Out
5-100
Set how long the OSD remains open after non-use
OSD Rotation
Normal, 90, 180,
270
When the user ips the display, this function can also ip the OSD to
achieve the best display angle
Other
DP Version
DP 1.1;
DP 1.2
Adaptive Sync
On, Off
Turn the Adaptive Sync function on/off
HDR
On, Off; Auto
Detect
Turn the HDR mode on/off
Reset
None
PIP (Picture in Picture) Input Information
Mode
Home Screen
Input Source
Picture in Picture
Additional Input Source
Interchange
Window
Picture Mode
DP
HDMI
Mode 1
DP
X
O
O
O
Mode 2
HDMI
O
X
O
O
Note:” O” means this feature is supported while “X” means it is not supported.
PBP (Picture by Picture) Resolution Information
While using this feature and in order to obtain an optimal viewing experience, it is recommended
to set both panels to the same resolution.
1
2
It is recommended to set the
second panel to 1080p @
60Hz resolution.
At this resolution, tearing and visual deformation should be minimized.
It is recommended to set the
resolution.
