VarTech Systems VT170W User manual

VT170 Series
17.0” Flat Panel Series LCD Monitors
VT170W · VT170 WX · VT170P ·
VT170PSS · VT170R · VT170RX
User’s Guide
Read these instructions completely before attempting to operate your new Color Display.
VarTech Systems Inc.
Solutions for Demanding Applications
Industrial CRT and Flat Panel Displays

Table Of Contents
Section 1 Section 5
Introduction Touch screen 5.0
About LCD Monitors 1.0 Touch Screen Introduction 5.1
Product Safety Precautions 1.1 Touch Screen Definition 5.2
Section 2 Touch Screen Serial Interface 5.3
Display Setup 2.0 Setting up the Touch Interface 5.4
Display Features 2.1 Installing Windows NT 4.0 Touch Drivers 5.5
Unpacking The Display 2.2 Installing Windows 95/98 Touch Drivers 5.6
Included Parts 2.2.1 Installing Windows 2000 Touch Drivers 5.7
Connecting Your Display 2.3 Section 6
Signal Connections 2.4 Frequently Asked Questions 6.0
Section 3 Section 7
Getting Started 3.0 Troubleshooting Tips 7.0
Adjusting the Display 3.1 Section 8
Adjustment 3.1.1 Cleaning & Maintenance 8.0
Color Adjustment 3.1.2 Section 9
Setup Adjustment 3.1.3 Display Specifications 9.0
Section 4
Mounting Instructions 4.0
Chassis Mount Procedure 4.1
Chassis Mount Drawing 4.1.1
Panel Mount Procedure 4.2
Panel Mount Drawing 4.2.1
Rack Mount Procedure 4.3
Rack Mount Drawing 4.3.1

LCDs
Introduction
1
Section
About LCD Monitors
What you gain by using an LCD monitor in your industrial controls
are the future of display technology. CRTs although they have dropped
in cost significantly, do not offer the performance, reliability, and
mounting options available with LCDs. LCD monitors consist
primarily of an LCD, Video Board and a Back Light video. The LCD
determines to a large extent the viewing angle, brightness and contrast. Beyond that it is the function of
the video board which converts the analog RGB (Red, Green, Blue) signals from a standard video card
to a high quality, digital RGB that the LCD can display.
Recently the video card has taken on a new role. It is the responsibility of this device to “scale” a
particular video resolution to the “native” resolution of the LCD. Simply, consider that a computer is
putting out a VGA [640x480] resolution signal, yet the LCD that is connected is an XGA [1024x768]
display. The displayed picture would be in the center 1/3 of the LCD. With the introduction of the
scaling engine. The converter will mathematically recalculate the 640x480 to 1024x768. This may sound
simple but it is in fact a complex algorithm that adjusts for different aspect ratios and pixel alignment,
essentially smoothing text and graphics to produce a picture that is pleasant to the eye.
All Vartech displays from 12.1” (800x600) to 23.1 (1600x1200) incorporate scaling engines in the
converter card.
1.0
1

Product Safety Precautions
⇒ Ensure that sufficient space is available around the display to provide the circula-
tion necessary for cooling.
⇒ Ensure that the ambient air temperature will not exceed the specified maximum
temperature.
⇒ Do not attempt to service this display yourself. The rear chassis has a seal so that
non qualified personal will not expose themselves to dangerous voltages or other
risks.
⇒ To protect from electrical shock, unplug the display power supply from the wall
before moving.
⇒ Do not expose the display to direct sunlight or heat.
⇒ Do not use this display near water
⇒ Do not place any heavy objects on the power cords. Damage may cause electrical
shock.
⇒ Unplug the power supply from the wall or unit if one of the following conditions
exists.
⇒ Power cord or plug is damaged or frayed
⇒ Liquid is spilled into the display or the display is exposed to rain or
water.
⇒ The display does not operate normally when the operating instruc-
tions are followed.
⇒ The display has been dropped or the enclosure has been damaged.
⇒ The display exhibits a distinct change in performance, indicating a
need for service.
1.1
2

Section
2
Display Setup
VT170 Series Display Features
⇒ Capable of displaying unlimited colors in a continuous spectrum. The high contrast LCD enhances
the image with no geometric distortion.
⇒ The VT170 Series directly accepts an analog 5 wire RGB with separate H/V sync or 4 wire RGB
with separate combined sync. (3 wire SOG is available as optional)
⇒ The VT170 Series is auto synchronous adjusting the display to the appropriate input between VGA,
SVGA,XGA, and SXGA.
⇒ The VT170 Series is available in Panel Mount, Rack Mount, Wall Mount or Chassis Mount industrial
packages..
⇒ The VT170 Series is supplied with a Anti-Reflective Screen unless equipped with an optional Touch
System.
⇒ The VT170 Series has an integrated 115/220VAC supply as standard on all models except the
chassis model. The chassis model has a +12V jack. The 115/220VAC supply is optional.
⇒ The V7170RX Extreme Series has V-Bonded Glass.
⇒ The V7170RX Extreme Series has Conformal Coating on all circuit boards.
⇒ The V7170RX Extreme Series has ruggedized Amphenol Connectors.
⇒ The V7170RX Extreme Series has a Thermostat controlled heater installed.
2.1
3

2.2 Unpacking and setting up your display
Your LCD monitor package will consist of the components listed below. Open shipping container
and lay all components on a flat clean surface.
⇒ VT170R or VT170P, or VT170C or VT170W LCD Monitor
⇒ 5 ft Video Cable
⇒ Chassis model only has a +12V power connection. (115/220VAC Power Supply is optional)
⇒ 10-32 Mounting Hardware. (For use with Panel Mount only)
⇒ 6 ft RS232 Touch Interface Cable (Optional when touch is installed)
⇒ CD ROM with Touch Screen Drivers (Optional when touch is installed)
⇒ Users Manual
1. Connect all cables to the computer first. This would include the VGA cable and the optional
RS 232 serial touch screen connection.
2. After connecting the cables between the LCD monitor and the computer, plug the customer
supplied +12VDC source to the 12V connection on the rear (Chassis model only) . All other
models have a integrated 115/220VAC power supply.
3. Once the +12V or the 115/220VAC connection is made, the display is active.
4. If your computer was off, turn on your computer.
5. Your display should now operate as a normal computer display showing your windows or
whatever video is being sent to the flat panel.
Note: If for any reason the display goes blank and gives an “out of Range” or “No Input Signal”,
your computer or video source is putting out a signal that is out of range of the LCD’s video
board. If this happens, reboot the computer or video source and make sure you are inputting the
correct signal. If the display doesn’t work properly, it may be because:
(a) The resolution is to high or low for the LCD.
(b) The refresh rate is set to high. Refresh on an LCD is different than a CRT. Set the refresh to
60Hz. CRT’s need a high refresh rate to avoid flicker. The refresh rate has no impact on
LCD’s.
(c) The power source is incorrect.
(d)The unit is malfunctioning. If you believe this to be true, disconnect the video cable from the
rear of the LCD and connect to a known good computer CRT display. If the computer display is
working satisfactory and the video is within the appropriate range, then contact Vartech
Customer service for a RMA number.
2.2.1 What is included with your display
2.3 Connecting the Display
2.4 Signal Connections
To avoid irregular operation and /or damage to the display, please insure correct video is being
supplied as shown on the following page.
4

2.4 Signal Connections Cont.
Pin assignments for the HD15 video connector.
Pin 1 Red Video Pin 9 No Connection
Pin 2 Green Video Pin 10 Sync Ground
Pin3 BlueVideo Pin11 NotUsed
Pin 4 Not Used Pin 12 Bi-Directional Data
Pin 5 Return Pin 13 Horizontal Sync
Pin 6 Red Video Ground Pin 14 Vertical Sync
Pin 7 Green Video Ground Pin 15 Data Clock (SCL)
Pin 8 Blue Video Ground
Standard Resolutions Supported
⇒ 640 x 480 (VGA)
⇒ 800 x 600 (SVGA)
⇒ 1024 x 768 (XGA)
⇒ 1280 x 1024 (SXGA)
Pin assignment for 9 Pin Optional Touch Screen Connector.
Pin 1 DCD Data Carrier Detect
Pin 2 RD (Rx) Receive Data
Pin 3 SD (Tx) Transmit Data
Pin 4 DTR Data Terminal Ready
Pin 5 SB Signal Ground
Pin 6 DSR Data Set Ready
Pin 7 RTS Request to Send
Pin 8 CTS Clear to Send
Pin 9 NC No Connection
You can use an HD-15 connector cable or a BNC adapter cable to connect the flat panel monitor
to the host computer. The HD-15 video cable (supplied in the kit) you use with this monitor is
equipped with a conventional HD-15 connector at each end.
Note: The following figure is the view looking into the pin end of the male connector or solder
term end of the female connector.
HD-15 Video Connector
The following table provides the pin numbers and corresponding pin
assignments for the HD-15 video connector.
5

Optional BNC Adaptor Cable
A 5-BNC-to-HD-15 adapter cable is available. The functions of the cables are described below.
⇒ R, B, and G: Red, Green, and Blue input connectors to establish color.
These are used for RS-343 analog signals.
⇒ HS/CS: Separate horizontal/composite sync signal from the video
source.
⇒ VS: Separate vertical sync signal from the video source.
BNC Adapter Cable
This table describes the signal types you can use with the connectors:
BNC Signal Types
BNC Signal Type Description R G B HS/ VS
CS
Sync-on-Green Use the three video connectors.
(optional) Horizontal and vertical syncs are X X X
supplied on the green video line.
Composite Sync Use the three video connectors plus the X X X X
horizontal sync/composite sync input.
Separate Horizontal Use the three video connectors plus the
and Vertical Sync. horizontal sync/composite sync and X X X X X
vertical sync input.
2.4 Signal Connections Cont.
6

Vartech Displays, Inc
Menu Select Down Up Source
Getting Started 3
Section
3.1 Adjusting the display
The VT170 Series display has an embedded microprocessor in the converter card. Once you
have the unit displaying the resolution you desire for your application do the following:
In order to navigate to the appropriate adjustments, press Menu and the OSD layout chart will
appear as indicated as shown below.
Definition of OSD (on screen display) Adjustments
There are seven membrane buttons (as shown above) located on the rear of the unit. They will
activate the OSD and allow navigation to all adjustments if your unit requires adjustment.
Press MENU and a major adjustment category will appear. Press DOWN or UP and you will
see the remaining adjustment categories. The actual adjustment categories are listed under each
major category (bold) as shown below.
ADJUSTMENT
Brightness, Contrast, Clock, Phase, H Position, V Position, Auto
COLOR ADJUSTMENT
User, 6500, 9300
SETUP
Language, Image Size, OSD H Position, OSD V Position, Transparency, Zoom
PIP (Not available on this model)
On/Off, PIP Source, PIP Size, PIP H Position, PIP V Position, PIP Image
AUDIO (Not available on this model)
Volume, Bass, Treble, Mute, Sound
7

Adjustment
NOTE: The following adjustments are all under the ADJUSTMENT category. The outlined
procedure covers the sequential adjustments under this category. If you desire to move to an-
other category, press MENU and the UP or DOWN button and proceed to the desired
category.
All adjustments are graphically illustrated in yellow along with a digital value.
Brightness
Press MENU.Press the UP or DOWN button until you reach the ADJUSTMENT
Category. Next press the SELECT button. Press the UP or DOWN button until you reach
BRIGHTNESS. Now press the UP/DOWN arrow to obtain the desired brightness level.
When complete press UP/DOWN button and you can select the next desired adjustment.
Contrast
Press MENU.Press the UP or DOWN button until you reach the ADJUSTMENT
Category. Next press the SELECT button. Press the UP or DOWN button until you reach
CONTRAST. Now press the UP/DOWN arrow to obtain the desired contrast level.
When complete press UP/DOWN button and you can select the next desired adjustment.
Clock
Press MENU.Press the UP or DOWN button until you reach the ADJUSTMENT
Category. Next press the SELECT button. Press the UP or DOWN button until you reach
CLOCK. Now press the UP/DOWN arrow until the screen image is sharp and there is no
screen “jitter”. When complete press UP/DOWN button and you can select the next desired
adjustment.
Phase
Press MENU.Press the UP or DOWN button until you reach the ADJUSTMENT
Category. Next press the SELECT button. Press the UP or DOWN button until you reach
PHASE. Now press the UP/DOWN arrow until the screen image is sharp and there is no
screen “jitter”. NOTE: You may desire to readjust Clock and Phase alternately
When complete press UP/DOWN button and you can select the next desired adjustment.
H Position
Press MENU.Press the UP or DOWN button until you reach the ADJUSTMENT
Category. Next press the SELECT button. Press the UP or DOWN button until you reach
H Position. Now press the UP/DOWN arrow until the screen is centered in the horizontal
direction. When complete press UP/DOWN button and you can select the next desired
adjustment.
V Position
Press MENU.Press the UP or DOWN button until you reach the ADJUSTMENT
Category. Next press the SELECT button. Press the UP or DOWN button until you reach
V Position. Now press the UP/DOWN arrow until the screen is centered in the vertical
position. When complete press UP/DOWN button and you can select the next desired
adjustment.
3.1.1
8

3.1.2 Color Adjustments
NOTE: The following adjustments are all under the ADJUSTMENT category. The outlined
procedure covers the sequential adjustments under this category. If you desire to move to an-
other category, press MENU and the UP or DOWN button and proceed to the desired
category.
All adjustments are graphically illustrated in yellow along with a digital value.
RED
Press MENU.Press the UP or DOWN button until you reach the COLOR
ADJUSTMENT category. Next press the SELECT button. Press the UP or DOWN arrow
until you reach USER. This will display the RED, GREEN and BLUE controls.
Press SELECT and RED adjustment will appear. Press the UP or DOWN arrow to adjust
RED to the desired level. When complete press UP/DOWN button and you can select the
GREEN adjustment.
GREEN
Press the UP or DOWN button until you reach GREEN. .
Press the UP or DOWN arrow to obtain the desired level of green. When complete press
UP/DOWN button and you can select the BLUE adjustment.
BLUE
Press the UP or DOWN button until you reach BLUE. .
Press the UP or DOWN arrow to obtain the desired level of blue. When complete press UP/
DOWN button if you desire to readjust any colors again.
COLOR TEMPERATURE (6500K)
If you desire a fixed color temperature of 6500K proceed as follows.
Press MENU.Press the UP or DOWN button until you reach the COLOR
ADJUSTMENT category. Next press the SELECT button. Press the UP or DOWN arrow
until you reach 6500K. This will display in yellow. Press SELECT if you desire the colors to
emulate 6500K. Press MENU to return to another adjustment.
COLOR TEMPERATURE (9300K)
If you desire a fixed color temperature of 9300K proceed as follows.
Press MENU.Press the UP or DOWN button until you reach the COLOR
ADJUSTMENT category. Next press the SELECT button. Press the UP or DOWN arrow
until you reach 9300K. This will display in yellow. Press SELECT if you desire the colors to
emulate 9300K. Press MENU to return to another adjustment
9

3.1.3 Setup Adjustments
NOTE: The following adjustments are all under the ADJUSTMENT category. The outlined
procedure covers the sequential adjustments under this category. If you desire to move to an-
other category, press MENU and the UP or DOWN button and proceed to the desired
category.
All adjustments are graphically illustrated in yellow along with a digital value
LANGUAGE
Press MENU.Press the UP or DOWN button until you reach the SETUP
ADJUSTMENT category. Next press the SELECT button. Press the UP or DOWN
button until you reach LANGUAGE. Press the UP or DOWN arrow to select ENGLISH,
ITALIANO, ESPANOL or DEUTSCH.
IMAGE SIZE
Press MENU.Press the UP or DOWN button until you reach the SETUP
ADJUSTMENT category. Next press the SELECT button. Press the UP or DOWN
button until you reach IMAGE SIZE. Press SELECT for full picture size.
OSD H POSITION
Press MENU.Press the UP or DOWN button until you reach the SETUP
ADJUSTMENT category. Next press the SELECT button. Press the UP or DOWN
button until you reach OSD H POSITION. Press SELECT . Press the UP or DOWN
arrow to adjust the horizontal position of the OSD window. Press the UP or DOWN button
to OSD V POSITION.
OSD V POSITION
Press MENU.Press the UP or DOWN button until you reach the SETUP
ADJUSTMENT category. Next press the SELECT button. Press the UP or DOWN
button until you reach OSD V POSITION. Press SELECT . Press the UP or DOWN
arrow to adjust the vertical position of the OSD window. Press the UP or DOWN button to
proceed to the next adjustment.
TRANSPARENCY
Press MENU.Press the UP or DOWN button until you reach the SETUP
ADJUSTMENT category. Next press the SELECT button. Press the UP or DOWN
button until you reach TRANSPARENCY. Press SELECT . Press the UP or DOWN
arrow to adjust the transparency to the desired level . Press the UP or DOWN button to
proceed to the next adjustment.
ZOOM
Press MENU.Press the UP or DOWN button until you reach the SETUP
ADJUSTMENT category. Next press the SELECT button. Press the UP or DOWN
button until you reach ZOOM. Press SELECT . Press the UP or DOWN
arrow to adjust zoom as desired. NOTE: The H and V zoom positions are fixed.
10

Mounting Instructions
Mounting instructions for chassis mount
The chassis mount contains a simple frame with mounting holes. Traditionally captive hard-
ware would be used to secure the display against a panel with the proper hole size based on
the mechanical drawing. The chassis display is supplied with a piece of Plexiglas material
sealed to the front for protection. If the display is equipped with a touch screen, the touch
screen takes the place of the Plexiglas for protection of the LCD.
The unit is normally supplied for +12V operation, however it is available with a 115/220VAC
supply.
4
4.1 Chassis Mount Procedure
11

4.1.1 Chassis Mounting Drawing
THIS OPTION NOT AVAILABLE
12

Panel Mounting Procedure
1. Cut and drill the panel (refer to panel mount drawing). Measurements are in inches.
Panel Mounting Cutout
2. If access to the side of the monitor is not available following installation, attach the power
and video cables to the side of the monitor at this time.
3. Install the monitor in the prepared cutout.
4. Install the lock nuts and washers, supplied with the monitor, behind the holes running along
the sides and top/bottom of the cutout in the panel. Extra lock nuts and washers are provided.
Note: Use #10-32 nuts for mounting.
5. Tighten all mounting nuts evenly to a torque of 24 inch-pounds.
ATTENTION: Mounting nuts must be tightened to a torque of 24 inch-pounds to provide
panel seal and avoid potential damage. Vartech Displays assumes no responsibility for water or
chemical damage to the monitor or other equipment within the enclosure due to
improper installation.
6. Attach the power and video cables to the side of the monitor if you
have not already done so. .
4.2 Panel Mount Procedure
13

4.2.1 Panel Mount Dimensions and Mounting Drawing
14

Rack Mounting Procedure
1. Carefully remove the monitor from its packaging.
2. Locate holes in the cabinet front mounting rails corresponding to the holes in the monitor
front panel. Install clip nuts behind the holes in the rails if threaded rails are not provided.
Note: The mounting rails that run vertically along the inside edges of the front opening of an
EIA rack cabinet can be of two types:
· “Wide” rails have holes spaced 0.5"(12.7 mm) and 1.25"(31.8 mm) on centers, in a repeating
pattern. Wide rails are prevalent in Europe. · “Universal” rails have holes spaced 0.5"(12.7 mm),
0.625"(31.8 mm), and 0.625"(31.8 mm) on centers, in a repeating pattern. Thus, the universal
rails have a hole pattern that contains the wide pattern but provides an additional hole at the
midpoint of the pattern. Universal rails are most prevalent in the US.
3. Install the monitor into the cabinet from the front.
4. Secure the monitor chassis to the cabinet by installing panel mounting screws through the
holes in the monitor front panel and into the rails behind.
4.3 Rack Mount Procedure
15

4.3.1 Rack Mount Dimensions and Mounting Drawing
16

Touch Screen
5
Section
Touch Screen Introduction
Touch screen interfaces have become the standard interface in the past 5 years. They are, rugged,
reliable, extremely flexible and easier than ever to implement! Over 90% of the display packages
Vartech Systems builds are touch screen systems. If you are uncertain about using a touch screen,
or are having difficulty, please call us. The universal acceptance of the Windows GUI [Graphical
User Interface] along with the extensive use of a mouse interface has significantly accelerated the
use of touch interface. Basically think of your touch screen as if it were a mouse.
Quite simply, Vartech Systems touch systems are a mouse emulator. By installing a software driver
and connecting to a serial port, the touch screen will support all the primary mouse functions:
Our standard touch screen interface, is a high resolution analog resistive. Following is a quick
explanation of what all this means.
High Resolution: The touch screen resolution is 400 ppi [points per inch]
Analog Resistive: The actual touch glass is an analog device. Meaning there is a very low voltage
applied to the X and Y axis of the touch screen. This current is applied to ITO [Iridium Tin Oxide]
that is sputtered onto a polyester membrane. When you touch the screen you are changing the
resistance on both the X and Y axis, producing an analog value that references a particular location.
This type of screen can be activated with a gloved finger or mechanical stylus.
The touch screen itself is connected to electronics that provide the Analog to Digital conversion.
When the screen is touched, the electronics convert the analog voltage to a digital value and add a
“Mouse Click”, then sends the data to the serial port that the driver is loaded to. When the touch is
released the new XY location is sent along with a “Mouse Up Click”.
This system requires no special software knowledge, and can be installed and set up in minutes.
The following section gives a detailed explanation of the software setup and configuration.
Since the touch screen interface is RS-232, the recommend maximum distance from the PC is 50
feet. In reality, every application is different. The touch driver default baud rate is 9600, and we
have tested the driver and interface with good quality cables to 50 feet.
With RS-232 line drivers this can be extended almost indefinitely.
5.1
Touch Screen Definition
5.2
17

Touch Screen Definition Cont.
5.2
Connecting the touch screen
1. Make sure all optional cables have been received.
2. Connect one end of the 6 foot touch screen serial cable to the touch screen port D9 connec-
tor on the side of the monitor.
3. Connect the other end to any communications port on the host computer.
4. Tighten the captive screws on the cable connector to secure it.
5.3 Touch Screen Serial Interface
All touch controllers are configured by default to provide serial communications at 9600 baud, 8 data
bits, 1 stop bit, no parity. For Vartech flat panels equipped with touch screens, a serial
communications cable is required. This 6 foot cable comes with the unit in the accessory kit.
The cable is a straight wired serial (RS-232) cable with a male DE-9 D-shell connector on the
monitor end. The cable provides a communications channel between the touch screen
controller, which is mounted inside the monitor, and an RS-232 serial port on the host computer.
Because the touch controller obtains power from the monitor's power supply, no external touch power
connections are necessary.
Software supplied with the touch screen must be loaded on the host computer to handle
communications with the touch controller over the channel.
Because the touch screen emulates a mouse, there may be compatibility issues involving how the touch
screen emulates mouse buttons, especially multiple buttons.
5.4 Setting up the Touch Screen Interface
Enabling the Touch Screen Interface
The Flat Panel Monitor provides a female DE-9 connector for the touch interface. This connector pro-
vides the serial interface for the touch controller.
Interconnecting wiring to the host serial port connection is shown in the
following table.
Touch screen Interface
Monitor
(DCE Device) Host (DTE Device)
DE-9 (Female) Signal Description DE-9 (Male) DB-25 (Male)
1 Not Connected (DCD) 1 8
2 Transmit Data (TXD) 2 3
3 Receive Data (RXD) 3 2
4 Data Terminal Ready (DTR) 4 20
5 Common Signal Return (SG) 5 7
6 Not Connected (DSR) 6 6
7 Request To Send (RTS) 7 4
8 Clear To Send (CTS) 8 5
9 Not Connected 9 22
18
