FPG INLINE GN Series User manual

Inline GN Series
Refrigerated Well

Part No.21967 Rev. M June 2017 - 2 - Refrigerated Well GN Series
Copyright © June 2017 Future Products Group Limited.
All rights reserved.
No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior
written permission of Future Products Group Ltd.

IN-GNC03/4/5/6 - 3 - © Future Products Group
Table of Contents
INTRODUCTION .................................................................................................................7
Welcome........................................................................................................................................................... 7
Future Products Group (FPG).................................................................................................................... 7
Guidance and Help..................................................................................................................................... 7
Warranty ........................................................................................................................................................... 7
Warranty Period.......................................................................................................................................... 7
Liability Exceptions..................................................................................................................................... 8
Specific Exclusions..................................................................................................................................... 8
Assessment................................................................................................................................................ 8
Time Limit................................................................................................................................................... 8
Caution ....................................................................................................................................................... 8
OPERATION .......................................................................................................................9
Configuration ................................................................................................................................................... 9
Mechanical Features.................................................................................................................................. 9
Food Display Options................................................................................................................................. 9
Operating Temperature.............................................................................................................................. 9
Condensate and Drain ............................................................................................................................... 9
Optional Lighting......................................................................................................................................... 9
Controls.......................................................................................................................................................... 10
Control Panel............................................................................................................................................ 10
Power Switch............................................................................................................................................ 10
Refrigeration Switch ................................................................................................................................. 10
Temperature Controller ............................................................................................................................ 10
Display Mode.................................................................................................................................................. 11
Choice of Mode ........................................................................................................................................ 11
Display Trays............................................................................................................................................ 11
Gastronorm Dishes................................................................................................................................... 11
Component Locations .............................................................................................................................. 11
Preparation..................................................................................................................................................... 12
Power Supply ........................................................................................................................................... 12
Turn on Refrigeration................................................................................................................................ 12
Pre-chilled Food ....................................................................................................................................... 12
Loading Restrictions................................................................................................................................. 12
Draughts................................................................................................................................................... 12
Defrost Cycle............................................................................................................................................ 12
Operating Routines ....................................................................................................................................... 13
Monitor Food Temperature....................................................................................................................... 13
After Hours ............................................................................................................................................... 13
Cleaning ................................................................................................................................................... 13
De-frost Cycle........................................................................................................................................... 13
Storage and Display Basics ......................................................................................................................... 14
Food Temperature.................................................................................................................................... 14
Display Time............................................................................................................................................. 14
Unsuitable Food Type .............................................................................................................................. 14

Part No.21967 Rev. M June 2017 - 4 - Refrigerated Well GN Series
TROUBLE SHOOTING .....................................................................................................15
CLEANING........................................................................................................................16
Cautions ......................................................................................................................................................... 16
Power ....................................................................................................................................................... 16
Water........................................................................................................................................................ 16
Exterior ........................................................................................................................................................... 16
Metal Surfaces.......................................................................................................................................... 16
Glass (Optional Hood).............................................................................................................................. 16
Louvers..................................................................................................................................................... 16
Interior............................................................................................................................................................. 17
Cabinet Well Layout ................................................................................................................................. 17
Deck Trays and Dishes ............................................................................................................................ 17
Air Louvers ............................................................................................................................................... 17
Side Grills ................................................................................................................................................. 17
Fan Cover................................................................................................................................................. 17
Stainless Steel Items................................................................................................................................ 18
Well Cleaning ........................................................................................................................................... 18
Cooling Coil .............................................................................................................................................. 18
Removal of Fan Deck............................................................................................................................... 19
Temperature Probes................................................................................................................................. 19
Cleaning Routines ......................................................................................................................................... 20
Schedules................................................................................................................................................. 20
Louvers..................................................................................................................................................... 20
Condenser Radiator ................................................................................................................................. 20
Inspection ................................................................................................................................................. 20
Correction................................................................................................................................................. 20
INSTALLATION ................................................................................................................21
Regulations .................................................................................................................................................... 21
Compliance with Local Requirements...................................................................................................... 21
Setting Up....................................................................................................................................................... 21
Unpacking................................................................................................................................................. 21
Transport .................................................................................................................................................. 21
Site Preparation........................................................................................................................................ 21
Well Assembly Preparation ...................................................................................................................... 21
Grounding................................................................................................................................................. 21
Power Supply ........................................................................................................................................... 22
Isolation .................................................................................................................................................... 22
Protection ................................................................................................................................................. 22
Drain......................................................................................................................................................... 22
Vapour Extraction Warning ...................................................................................................................... 22
Control Panel............................................................................................................................................ 22
Control Panel Mounting............................................................................................................................ 23
Location.......................................................................................................................................................... 23
Ventilation................................................................................................................................................. 23
Air Louvers ............................................................................................................................................... 23
Access...................................................................................................................................................... 23
Fumes and Odours................................................................................................................................... 23

IN-GNC03/4/5/6 - 5 - © Future Products Group
SERVICING.......................................................................................................................24
Control Gear................................................................................................................................................... 24
Location.................................................................................................................................................... 24
Mains Lead ..................................................................................................................................................... 24
Lead Replacement ................................................................................................................................... 24
Refrigeration .................................................................................................................................................. 24
Caution ..................................................................................................................................................... 24
Access to Compressor etc. ...................................................................................................................... 24
Louver Panels........................................................................................................................................... 25
Condenser Radiator ................................................................................................................................. 25
Temperature Probes................................................................................................................................. 25
Fan Deck .................................................................................................................................................. 25
Temperature Regulator XR40CX ............................................................................................................. 26
FPG Settings............................................................................................................................................ 30
Dixell Default Settings .............................................................................................................................. 30
Optional ACR Assembly ............................................................................................................................... 33
Condensate Disposal ............................................................................................................................... 33
ACR Fault Finding Guide ......................................................................................................................... 33
SPECIFICATIONS.............................................................................................................34
Mechanical ..................................................................................................................................................... 34
Electrical......................................................................................................................................................... 34
Controller Settings ........................................................................................................................................ 35
Changes from Dixell Defaults................................................................................................................... 35
XR40CX Settings...................................................................................................................................... 35
Compliance .................................................................................................................................................... 36
Safety Aspects.......................................................................................................................................... 36
Operational Safety.................................................................................................................................... 36
Performance Aspects............................................................................................................................... 36
Improvements ................................................................................................................................................ 36
Ongoing Development.............................................................................................................................. 36

Part No.21967 Rev. M June 2017 - 6 - Refrigerated Well GN Series
ELECTRICAL CIRCUIT DIAGRAMS................................................................................37
Model: IN-GNC03..................................................................................................................................... 37
Model: IN-GNC03 (Remote)..................................................................................................................... 37
Model: IN-GNC04..................................................................................................................................... 38
Model: IN-GNC05..................................................................................................................................... 38
Model: IN-GNC05 (Remote)..................................................................................................................... 39
Model: IN-GNC06..................................................................................................................................... 39
SPARE PARTS .................................................................................................................40
Assembly Serial Number.......................................................................................................................... 40
MECHANICAL DRAWINGS..............................................................................................41
Dimensions .................................................................................................................................................... 41
IN-GNC03................................................................................................................................................. 41
IN-GNC04................................................................................................................................................. 41
IN-GNC05................................................................................................................................................. 42
IN-GNC06................................................................................................................................................. 42
Bench Cut-outs.............................................................................................................................................. 43
Over Mount Installation ............................................................................................................................ 43
Flush Mount Installation ........................................................................................................................... 44
Under Mount Installation .......................................................................................................................... 45
Control Panel Mounting ................................................................................................................................ 46
Over Mounting.......................................................................................................................................... 46
Flush Mounting......................................................................................................................................... 46
Under Mounting........................................................................................................................................ 46
Ventilation Requirements ............................................................................................................................. 47
Basic Air Flow........................................................................................................................................... 47
Side Louver Option................................................................................................................................... 48
Toe Kick Vent Option................................................................................................................................ 48

IN-GNC03/4/5/6 - 7 - © Future Products Group
INTRODUCTION
Welcome
GN SERIES REFRIGERATED WELL - INTRODUCTION
Future
Products
Group (FPG)
Welcome to the world of FPG! Our products are designed and engineered to
give you the optimal performance that you deserve with innovative visual
merchandising appeal.
We are confident that you will be delighted with your state of the art inline food
service cabinet, and that it will become a valued appliance.
Guidance and
Help
Any new appliance can seem very complex and confusing at first glance. To
ensure you receive the utmost benefit from your new inline cabinet, there are
two things you can do.
Before operating the cabinet, please read the instruction book carefully and
follow its recommendations. The time taken will be well spent. These
instructions both general and technical tell you how to install, operate and
look after your inline food service cabinet so that you can receive the full
benefits that this cabinet has to offer.
These instructions cannot, however, cover all eventualities. If you are
unsure of any aspect of the installation, instructions or performance of your
cabinet, contact your dealer promptly or contact us via email to
[e-mail].
Warranty
GN SERIES REFRIGERATED WELL - INTRODUCTION
Warranty
Period
Future Products Group Limited warrants, to the original purchaser of an FPG
manufactured food service cabinet that for ONE YEAR (12 months), from the
date of purchase, any defect in workmanship or material resulting in the product
malfunctioning while under correct use will be rectified.
Liability under this warranty is limited to replacing or repairing a part, without
charge.
Continued on next page

Part No.21967 Rev. M June 2017 - 8 - Refrigerated Well GN Series
Warranty cont.
GN SERIES REFRIGERATED WELL -INTRODUCTION
Liability
Exceptions
Liability under this warranty does not include:
Any loss, or damage or expenses directly or indirectly arising from use or
inability to use the product or from any other cause.
Any part of the cabinet which has been subject to misuse, neglect,
alteration, incorrect installation, accident, or damage caused by
transportation, use of abrasive or caustic chemicals, flooding, fire or acts of
God.
Damage, resulting from failure to have the cabinet regularly serviced every
three months by a refrigeration engineer. NB: You will be required to
provide copies of service records in the event of compressor failure.
Damage resulting from maladjustment of the electronic refrigeration
controller, by an unqualified person.
Any damage or malfunction resulting from the use of non-FPG supplied
spare parts.
Specific
Exclusions
The following are specifically excluded from warranty:
Breakage of glass or plastic components or the replacement of lamps or
gaskets.
Failure resulting from incorrect assembly after cleaning.
Fair wear and tear.
Assessment
The liability under this warranty is dependent on an assessment by FPG, to
determine the defect in workmanship or materials.
Time Limit
FPG does not guarantee that any service to be performed under this warranty
will be carried out within any particular time limit.
Caution
No warranty claim will be accepted unless authorised by FPG prior to
commencement of service.

IN-GNC03/4/5/6 - 9 - © Future Products Group
OPERATION
Configuration
GN SERIES REFRIGERATED WELL - OPERATION
Mechanical
Features
The drop-in well consists of a main assembly,
with integral refrigeration equipment, in which
trays and gastronorm dishes of various sizes
can be mounted.
The control panel is located on the main
assembly, but since it is connected by a two
metre cable, it can be easily re-located onto the
joinery.
Food Display
Options
This versatile refrigerated well can be configured to display food in a variety of
ways:
On adjustable height trays, using dishes or platters
On trays of ice, for fresh fish or similar
In gastronorm dishes of various sizes
Operating
Temperature
The operating temperature of the well is governed by a digital controller.
This is pre-set to maintain the correct chilled air temperature of 2°C to 4°C.
Care must be taken to load the well correctly, to ensure correct product
temperature.
Condensate
and Drain
Condensate water will be released during defrost cycles.
Ideally this should be routed to an external drain, but a removable container
could be used.
An integral boil-off unit is available, as an optional extra, at the time of ordering.
However, unless really good forced ventilation is provided, integral boil-
off trays are not recommended due to potential moisture damage to the
joinery.
Optional
Lighting
An optional lighting gantry is available.
The well assembly has provision for easily mounting the gantry and is pre-wired
to supply power for the overhead LED lighting.
The lighting switch is on the gantry.

Part No.21967 Rev. M June 2017 - 10 - Refrigerated Well GN Series
Controls
GN SERIES REFRIGERATED WELL - OPERATION
Control Panel
A control panel, mounted on the joinery, provides
for all operational adjustments.
The refrigeration Controller
The Main Switch
The Refrigeration Switch
If an overhead lighting gantry is fitted, the light
switch is mounted on the gantry.
Power Switch
To turn the power on, rotate the switch in a clockwise
direction.
Note that the cabinet and condenser fans will operate as
soon as the power is turned on.
Refrigeration
Switch
To start refrigeration, rotate the refrigeration switch in a
clockwise direction.
Temperature
Controller
Only to be
adjusted by a
qualified service
technician.
The controller regulates the cabinet
temperature and controls the automatic
defrost cycles.
The display indicates the exit air temperature
from the cooling fins, below the deck trays.
The temperature of the condenser is also monitored, to protect the compressor
from damage resulting from a blocked radiator or ventilation louvers.
Continued on next page
