FRADAN PB-5.5BS User manual

WARNING DANGER
Read instructions carefully and follow rules for safe operation.
Failure to do so could result in serious injury.
OPERATOR
MANUAL
Fradan Manufacturing Corp.
www.fradanpower.com
FRADAN POWER BLOWERS
Part No. 888-011-222-0

2

WELCOME TO THE FRADAN FAMILY
CONGRATULATIONS! You are now the owner of a quality FRADAN POWER BLOWER.
FRADAN manufactures a family of high performance, reliable power equipment. Our designs are based on years
of personal use of landscape equipment.
We at Fradan have revolutionized the landscaping industry, offering modern, reliable, high performance equipment
designed to meet today’s environmental demands and exceed tomorrow’s.
FRADAN built means durability, quality, maximum performance and non-obsolescence. With proper care and
maintenance of your unit, we assure you years of service-free operation. This booklet refers to the information
which you should learn in order to take advantage of its outstanding performance.
FRADAN manufacturing would like to thank you for choosing our product and hope that you continue to enjoy the
quality and pride that we built into our products.
Always use the proper machine for the job, use a FRADAN.
CONTENTS
Introduction / Technical Data..................................................................................................................................4
Graphic Warnings ....................................................................................................................................................5
Safety Rules & Precautions.................................................................................................................................6-7
Assembly ..................................................................................................................................................................8
Fuel & Oil .................................................................................................................................................................9
Preparing for Operations ........................................................................................................................................9
Operations ..............................................................................................................................................................10
Maintenance & Care...............................................................................................................................................11
Trouble Shooting....................................................................................................................................................11
WARNING DANGER
Toreduce the potential for accidents, comply with the safety instructions in this manual.
Failure to comply may result in serious personal injury and/or equipment and property damage.

4
INTRODUCTION
The FRADAN Push Blower model is a ruggedly built, high performance gasoline powered unit specially designed
for blowing leaves and debris. Proper maintenance and use of the FRADAN Blower will guarantee years of safe,
service-free, reliable operation.
We wish for you to gain sufficient knowledge from this booklet before operating your Fradan, and make the best
use of it in the future. We urge you to follow these instructions to assure safe and reliable operation.
TECHNICAL DATA
Engine Briggs & Stratton Kohler Honda Briggs & Stratton Kohler Honda Briggs & Stratton
5.5HP 8.5HP 9HP 10HP 12.75HP 13HP Vanguard14HP
Overhead Valve Overhead Overhead Valve Overhead Valve Overhead Valve Overhead Valve Overhead Valve
Displacement 206 cm3301 cm3270 cm3305 cm3360 cm3389 cm3480cm3
12.6 in318.37 in316.48 in318.6 in322 in323.74 in329.3 in3
Spark Plug Champion NGK NGK Champion NGK DENSO Champion
RC12YC BPR4ES BPRGES RC12YC BPR4ES W20EPR-U RC12YC
Tank 3qt. 7.3 qt. 6.4 qt. 4 qt. 7.3 qt. 6.9 qt. 9 qt.
Capacity 2.85 Liter 6.9 Liters 6 Liters 3.78 Liters 6.9 Liters 6.5 Liters 8.5 Liters
Operating
Engine Speed 3300 RPM 3300 RPM 3300 RPM 3600 RPM 3300 RPM 3300 RPM 3600 RPM
Tire Pressure 15-20 PSI 15-20 PSI 15-20 PSI 15-20 PSI 15-20 PSI 15-20 PSI 15-20 PSI
Starter Recoil Recoil Recoil Recoil Recoil Recoil Recoil
Starter Starter Starter Starter Starter Starter Starter
Weight 90 lbs. 125 lbs. 123 lbs. 110 lbs. 139 lbs. 150 lbs. 150 lbs.
Model PB-5.5BS PB-8.5KY PB-9HD PB-10 IC PB-13KY PB-13HP PB-14VG

5
GRAPHIC WARNINGS
Because a power blower uses gasoline and blows air and debris at a high speed, safety precautions must be
observed to reduce the risk of personal injury. Read this manual carefully. Be familiar with the controls and the prop-
er use of the machine.
WARNING DANGER
The engine exhaust from this product contains chemicals known to the
State of California to cause cancer, birth defects, or other reproductive harm.
Specifications, descriptions and illustrative material in this manual are as accurate as known at the time of publi-
cation, but are subject to change without notice. Ilustrations may include optional equipment and accessories, and
may not include all standard equipment.
CAUTION
Removal of this cover can result in
serious bodily injuries, and
will cause heavy damage
to the machine.
FRADAN
POWER EQUIPMENT
This graphic accompanied by the words WARNING and DANGER calls
attention to an act or a condition which can lead to SERIOUS INJURY.
WHEN YOU SEE THIS SYMBOL, HEED ITS WARNING!
STAY ALERT!
READ & UNDERSTAND Operator’s Manual and Safety Manual.
ALWAYS WEAR EYE AND EAR PROTECTION.
KEEP HANDS & FEET AWAY FROM AIR DISCHARGE AREAS.
ROTATING FAN BLADES WILL CAUSE SERIOUS INJURY.
C
CA AU UT TI IO ON N
Removal of this cover can result in serious bodily injuries,
and will cause heavy damage to the machine.

6
SAFETY RULES & PRECAUTIONS
Proper safety precautions must be observed. Like all power equipment this unit must be handled carefully.
DO NOT EXPOSE YOURSELF OR OTHERS TO DANGER. Follow these general rules. Do not permit others to use
this machine unless they are thoroughly responsible and have read, and understand the machine manual and are
trained in its operation.
• Always wear safety goggles for eye protection. Dress properly, do not wear loose clothing or jewelry that could
become caught in moving parts of the unit. Safe, sturdy, nonskid footwear should always be worn. Long hair
should be tied back. It is recommended that legs and feet be covered to protect from flying debris during opera-
tion.
• Inspect the entire machine for loose parts (nuts, bolts, screws, etc.) and any damage. Repair or replace as nec-
essary before using the machine.
•DO NOT USE any attachment with this Power Blower other than the ones recommended by FRADAN. Serious
injury to the operator or bystanders could result as well as damage to the machine.
• Keep the handles free from oil and fuel.
• Do not smoke while handling fuel or filling tank.
• Do not fuel machine in an enclosed room or near open flames. Assure adequate ventilation.
• Always store the fuel in a properly marked container that is approved by local codes and ordinances for such
usage.
• Never remove the fuel tank cap while the engine is running.
• Never start or run the engine inside a closed room or building. Fumes from the exhaust contain dangerous car-
bon monoxide.
•Never attempt to make engine adjustments while the unit is running. Always make engine adjustments with the
unit resting on a flat, clear surface.
• Do not use the unit if it is damaged or poorly adjusted. Never remove the machine’s guard and front air intake
cover.
• Keep children away. Onlookers should be kept at a safe distance from the work area, at least 100 FEET/130
METERS.
• Never leave the machine unattended.
• Do not use this unit for any job other than those for which it is intended as described in this manual.
• Do not overreach. Keep proper footing and balance at all times. Do not run the unit on very hilly areas or on any
unstable footing location.
• Do not use the unit when you are tired or under the influence of medication, drugs or alcohol.

7
SAFETY RULES & PRECAUTIONS
• Do not store in a closed area where fuel vapors can reach an open flame from hot water heaters, furnaces, etc.
Store in a locked, well ventilated area only.
• Use only FRADAN original equipment parts when servicing the unit. This will ensure safe and proper performance
of your product. These parts are available from your dealer. The use of any other accessories or attachments may
cause a potential hazard or injury to the user, damage to the machine and void this warranty.
• Clean the machine completely, especially, the fuel tank, its surroundings, and the air cleaner.
• When refueling, be sure to stop the engine and confirm that it is cooled down. Never refuel when the engine is
running hot. When gasoline spills, be sure to wipe it up completely and properly dispose of those materials before
starting the engine.
• Stay clear of the other workers or bystanders by at least 100 feet / 30 meters.
• When ever approaching an operator of the machine, carefully call his attention and confirm that the operator stops
the engine. Be careful not to startle or distract the operator which can cause an unsafe situation.
WARNING - KEEP CHILDREN, PETS, and BYSTANDERS AWAY - Do not permit children to contact blow-
er. Keep children a safe distance from work area. Never allow a person mentally ill, under influence of alcoholic
drinks or drugs or too young in age, to operate the blower.
• Pay attention to loosening and overheating of parts. If there is any abnormality of the machine, stop operation
immediately and check the machine carefully. If necessary, have the machine serviced by an authorized FRADAN
dealer. Never continue to operate a machine which may be malfunctioning.
•In start-up or during operation of the engine, never touch hot parts such as the muffler, the high voltage wire or
the spark plug.
•After the engine has stopped, the muffler is still hot. Never place the machine in any places where there are flam-
mable materials (dry grass, etc.), combustible gases or combustible liquids.
• Pay special attention to operation in the rain or just after the rain as the ground may be slippery.
•Be careful not to drop the machine or hit it against obstacles.
• Before proceeding to adjust or repair the machine, be sure to stop the engine and detach the spark plug cap from
the spark plug.
• When the machine is placed in storage for a long time, drain fuel from the fuel tank and carburetor, clean the parts,
move the machine to a safe place and confirm that the engine is cooled down.
•Make periodic inspections to assure safe and efficient operation. For a thorough inspection of your machine,
please contact a FRADAN dealer.
•Keep the machine away from fire or sparks.
• Never blow leaves and debris into highways and roadways.
• DO NOT POINT THE BLOWER OUTLET in the direction of people, cars, glass, or other similar items which could
be injured or damaged by blown debns.

8
ASSEMBLY INSTRUCTIONS
•Remove blower unit from box and inspect for
shipping damage.
• Position unit to rest on front cover.
• Remove wheel nuts and wheels with a 15/16
wrench.
Handle Assembly (Refer to figure 1).
1. Insert lower handle (B) into upper handle
(A) making sure that throttle guides are
both in line.
2. Insert lower handle (C) into upper handle
(A).
3. Install handle plate using four 5/16 x 1 1/4
bolts washers and lock nuts, ensuring that
all bolts are properly tightened.
• Install handle assembly to the blower frame
using two 5/16 x 1 1/2 bolts, washers and
lock nuts, and two 5/16 x 1 1/4 bolt, washer
and lock nuts.
• Ensure that all bolts are properly tightened.
• Reinstall wheels. Ensure that all bolts are
properly tightened.
• Install throttle cable using two #10 screws,
washers and lock nuts.
• Fill up crank case with proper engine oil.
Refer to engine manufacturing manual.
• Ensure that all nuts, screws and bolts,
installed are properly tightened.
• Check wheel for proper inflation - 15-20 PSI
all models. Do not over inflate.
• Start unit.
————— C A U T I O N : —————
Check Governed Speed
PB-5.5BS 3300 R.P.M. (maximum)
PB-8.5KY 3600 R.P.M. (maximum)
PB-10IP 3600 R.P.M. (maximum)
PB-9HD 3600 R.P
.M. (maximum)
PB-13HD 3300 R.P.M. (maximum)
PB-16VG 3600 R.P
.M. (maximum)
PB-13KY 3300 R.P.M. (maximum)
Handle Assembly
FIGURE 1
BE SURE BLOWER IS FULLY ASSEMBLED!
Never operate blower without all guards and deflectors in place.
Ensure that all nuts, bolts, screws are installed and properly tightened.

9
FUEL & OIL
PREPARING FOR OPERATIONS
WARNING
• Never fill the fuel tank to the very top.
• Never add fuel to the tank in a closed non-ventilated area.
• Do not add fuel to this unit close to an open fire or sparks.
• Be sure to wipe off spilled fuel before attempting to start engine.
• Do not attempt to refuel a hot engine.
WARNING
All Fradan Blowers are shipped
WITHOUT OIL.
When filling oil, refer to
engine manufacturers’ Instruction Manual.
WARNING
The engine exhaust from this product contains chemicals
known to the State of California to cause
cancer, birth defects, or other reproductive harm.
When preparing fuel, use only the amount needed for the job you are to do. Do not use fuel that has been stored
longer than two months. Fuel stored longer than this will cause hard starting and poor performance. If fuel has been
stored longer than this time, it should be removed and filled with fresh fuel.
CHECK POINTS BEFORE OPERATION
1. Check for loose bolts, nuts and fittings.
2. Check the air cleaner for dirt. Clean the air filter of all dirt, etc. before operation.
3. Check to be sure that air intake screen is securely in place.
WARNING
Handle fuel with care. It is highly flammable. Fueling a hot engine or
an engine near an ignition source can cause fire and result in serious
personal injury and/or property damage.

10
OPERATING INSTRUCTIONS
For best performance, be sure engine recoil starter assembly, front air intake cover and air discharge are clear
and free of leaves or other debris.
Air stream can be directed by simply maneuvering the unit and directing the flow of air accordingly.
Each unit is also fitted with an air deflector. Slight change in deflector will have a big effect on air flow. By mov-
ing the air deflector downward, this will allow wet leaves and heavy debris to move more efficiently.
WARNING DANGER
Never attempt to remove leaves or other debris
from any part of the power blower while it is running.
WARNING DANGER
Never attempt to move or adjust deflector
while engine is running!
WARNING DANGER
• Do not smoke while handling fuel.
• Do not refuel a hot or running engine.
• Do not fill tank indoors.
• CAUTION - Do not start or run engine indoors as poisonous carbon monoxide is emitted.
• Do not operate in un-ventilated area.
WARNING DANGER
IN ORDER TO AVOID ENGINE DAMAGE DUE TO OVER-HEATING OR OVER-REVVING,
KEEP ENGINE RECOIL STARTER ASSEMBLY, THE BLOWER INTAKE AND DISCHARGE
AREAS CLEAR AND FREE OF LEAVES OR OTHER DEBRIS.
BEFORE ATTEMPTING TO REMOVE ANY LEAVES OR DEBRIS FROM THESE AREAS,
THE MACHINE MUST BE TURNED OFF.

11
MAINTENANCE INSTRUCTIONS
1. Keep all nuts, bolts, and screws tight.
Never store the blower with fuel in its fuel tanK inside a building or in a confined space where fumes may reach
an open flame or sparks.
3. Always refer to the instruction manual for ımportant details if the product is to be stored for an extended period.
4. Engine - 4 cycle. (Refer to engine manufacturer's operating instructions for fuel recommendations and addition-
al information.)
5. Tires - Inflate to air pressure of 15-20 P.S.I.
6. Labels should be inspected before each use. Replace damaged labels immediately.
STORE BLOWER INDOORS:
When not in use, store blower indoors in a sheltered area (a dry place) where it’s not accessible to children.
The blower, as well as fuel, should not be stored in a house. Keep throttle in the stop position.
TROUBLESHOOTING
• Refer to manufacturer’s Owners Engine Manual.

Fradan Manufacturing Corp.
www.fradanpower.com
