Franke Crystal User manual

EN Installation and user manual Microwave oven
DE Installations- und Gebrauchsanweisung Mikrowellengerät
FR Manuel d‘installation et mode d‘emploi Four Micro-ondes
IT Manuale per l‘installazione e l‘uso Forno a microonde
ES Manual del usuario y de instalación Horno microondas
PT Manual de instalação e do utilizador Forno micro-ondas
NL Installatie- en gebruikershandleiding Magnetron
EL Εγχειρίδιο εγκατάστασης και χρήστη Φούρνος μικροκυμάτων
FMW 45 CR C
CRYSTAL

– 3 –
FMW 45 CR C XS / FMW 45 CR C BK EN
ABOUT THIS MANUAL
This user manual applies to several models of
the device. Thus it may be possible that some
of the described features and functions are not
available on your specific model.
The explanatory images and figures, described
in the various sections, are available at the end
of the manual.
 Carefully read the user manual before using
the device.
 Keep the user manual.
 Use the device described in this user
manual only according to the intended use.
Franke reserves the right to make modifications
to the product without prior notice. All
information correct at time of issuance.
Symbol Meaning
Warning symbol. Warning against risks of injury.
Actions in safety and warning notes to avoid injury or damage.
Action step. Specifies an action to be done.
Result. Result of one or more action steps.
TABLE OF CONTENTS
About this manual 3
Intended use 4
Safety Information 4
Proper installation and fitting 6
Proper use 6
Maintenance and cleaning 7
Repair 7
Taking out of service 7
Overview 8
Display 9
Control panel 9
Cooking programs 10
Installation 11
Configuring the display 12
Operation 12
Cleaning and care 15
Maintenance and repair 16
Disposal 16
Customer service 17
Technical data 17
Function suitability tests 17

FMW 45 CR C XS / FMW 45 CR C BK
– 4 –
EN
INTENDED USE
The oven was developed exclusively for non-
professional, domestic use in the household.
The oven is designed to offer professional
performance in the household.
It is a highly versatile appliance enabling safe
and easy selection of different cooking methods.
SAFETY INFORMATION
 READ THE USER MANUAL
AND THE SAFETY
INFORMATION CAREFULLY
BEFORE USING THE OVEN.
 Keep the manual for future
reference.
The manufacturer can not
be made liable for possible
damage which may occur
due to incorrect installation
and incorrect, improper or
unreasonable use of the device.
The electrical safety of the
oven is guaranteed only when
it is connected to an earthing
system in compliance with the
valid regulations.
To ensure safe and efficient
operation of this electrical
device:
 Only contact authorised
service centres.
 Do not modify any features
of the device.
Children of 8 years or
older and persons with restricted
physical, sensory or mental
abilities, or with limited
experience or knowledge, may
not use or clean the device,
except when they are supervised
and instructed by a person
responsible for their safety.
Children under 8 years may not
use or clean the device even
when supervised.
This device is not a toy.
 Keep children away from the
device and the packaging
material.
 Do not leave children near
the device unattended.
 Do not let children play with
the device.
 Do not allow children
to touch the device or
its controls during and
immediately after using it.
 Ensure that the device is
installed in a way that allows
to disconnect it from the
power supply, either using
a plug or by fitting a switch
on the fixed wiring system in
accordance with installation
rules, with a contact opening
distance that ensures
complete disconnection

– 5 –
FMW 45 CR C XS / FMW 45 CR C BK EN
in category III overvoltage
conditions.
WARNING: In order to avoid
overheating, the appliance
must not be installed behind
decorative door.
 Only use utensils suitable for
use in microwave ovens.
 While heating food items in
plastic or paper containers,
monitor the microwave’s
contents, since there is a risk
of spontaneous combustion.
 If smoke appears, stop or
unplug the oven and keep
the door closed to smother
any flames.
 Heating beverages in the
microwave oven can cause
the sudden and/or delayed
splattering of boiling liquid,
so care must be taken when
handling their containers.
 Do not use any metallic
containers or aluminium trays.
 It is not recommended to
heat eggs in their shells and
whole hard-boiled eggs in a
microwave ovenas they may
explode even after cooking
has ended.
 The microwave oven is
intended for heating food
and drinks.
 Only use the oven to prepare
and cook food.
 Do not use flammable liquids
near the oven.
 Only use the temperature
probe recommended for
this oven.
The drying of food
products or linen and the
heating of heating pads,
slippers, sponges, damp
clothes and the like can cause
injury, inflammation or fire.
Risk of overheating and
malfunction of the oven due
to blocked ventilation!
 Never cover the inside walls
of the oven with aluminium
foil, especially the lower part
of the oven cavity.
 Do not block the ventilation of
the fan or the cooling openings
above the oven door.
WARNING: Liquids and other
foods must not be heated in
sealed containers, as they may
explode.
Risk of burns!
 Accessible parts may
become hot during use.
Young children should be
kept away.
 If the door or door seal is
damaged, the oven must not
be operated until it has been
repaired by an authorised
person.
Before maintenance or cleaning:
 Disconnect the device from
the power supply, e.g., switch
off the fuse in the fuse box.

FMW 45 CR C XS / FMW 45 CR C BK
– 6 –
EN
 Do not use coarse abrasive
materials or sharp metal
scrapers to clean the glass
parts of the oven door,
as they could scratch the
surface and cause the glass
to shatter.
 Do not use steam cleaners
or direct jets of water.
 Do not use pressurised
steam to clean the device.
 It is dangerous for anyone
other than a qualified
person to perform
maintenance or repairs that
requires the removal of the
cover providing protection
against exposure to
microwave power.
Proper installation and fitting
If the oven is to be permanently connected to
the power supply:
 Ensure that the device is installed only
by the customer service, an electrician
or trained personnel with the appropriate
knowledge/education.
 Ensure that the device is connected
directly to the main socket.
 Ensure that no adapters, no multi-sockets
and no extension cables are used to
connect the device.
 Ensure that the device is not exposed to
atmospheric agents (rain, sun).
Proper use
 The contents of baby bottles and baby food
pots should be stirred or shaken and the
temperature should be checked before
consumption so as to avoid burns.
 This appliance has been designed for
closed door cooking.
 Use oven gloves when placing containers
in the oven or when taking containers out
of the oven.
 Observe only the manuals that are used
with the oven when it is in function.
 Do not place power cables of other electric
appliances on hot parts of the oven.
 Do not use the oven cavity to store any
objects.
 Damage to the enamel in the oven due to
wrong handling of pots or containers!
 During cooking, never place pots or
containers directly on the floor of the
oven cavity.
 Place pots and containers only on the racks
or enamel trays provided in the oven cavity,
on one of the three shelves available.
Risk of burns!
 The end of the door handle may be hotter
due to hot air being vented.
 When opening or closing the door, always
hold the door handle in the middle.
 Always make sure that the control knobs
are in the off position when the oven is not
in use.
Risk of electric shock due to
damaged device!
 Do not switch on a damaged device.
 Switch off the fuse in the fuse box.
 Contact the customer service.
Risk of electric shock!
 Do not touch the device with wet parts of
your body.
 Do not use the device when barefoot.
 Do not pull on the device or power cable to
unplug it from the socket.

– 7 –
FMW 45 CR C XS / FMW 45 CR C BK EN
Maintenance and cleaning
The oven uses a special enamel which is easy
to keep clean. However, Franke recommends
to clean it frequently in order to avoid baking
on grime and previous cooking residues.
If the appliance is not cleaned regularly, its
surface could become damaged, permanently
affecting the appliance’s lifespan and possibly
causing a safety hazard.
Risk of electric shock due to
entering liquid!
The device contains electrical components.
 Make sure that no liquid enters the interior
of the device.
 Do not use a wet cloth to clean the
operating elements.
Repair
 Do not allow anyone except qualified
personnel to install or repair the appliance.
 Contact a service centre authorized by the
manufacturer or qualified personnel in the
following cases:
– Immediately after unpacking, in the event
of doubts regarding the integrity of the
device
– During installation (according to the
manufacturer‘s instructions)
– Doubts regarding the correct operation of
the device
– Malfunction or poor operation
– Replacing the power socket if incompatible
with the power plug of the device
– Damage to the power cable or need of
replacing the power cord or plug
Taking out of service
 If the oven is no longer to be used, call the
service centre or qualified personnel to
disconnect it from the power supply.

FMW 45 CR C XS / FMW 45 CR C BK
– 8 –
EN
OVERVIEW
Oven Runners for racks and glass drip tray
1
2
3
1000W
...W
OK
1
2
3
°C/W
3 3
22
1 1
1 Control panel
2 Front door glass
3 Front door handle
2 shelf supports allow you to use the rack at
3 heights.
Accessories Description
Glass Drip Pan
It can be used half filled with water for boiling food with
convection heat. It can serve as a cooking dish.
Grill Rack
Allows you to toast, brown or grill. The grill rack
must never be used with other metal containers
in microwave, grill + microwave or convection +
microwave mode. However, you can heat food in an
aluminium tray by isolating it from the rack using a plate.
Turntable
The turntable plate allows even cooking of the food
without having to handle it. It rotates in both directions. If
it does not rotate, verify that all components are properly
positioned. It can be used as a cooking dish. To remove
it, take hold of it by using the access areas in the cavity.
The turntable allows the glass plate to turn.
 If you remove the turntable, avoid getting water in
the motor shaft hole.
 Do not forget to put the turntable, the roller frame
and the glass turntable plate back in.
 Do not attempt to manually turn the glass plate
as this may damage the drive system. If it does
not turn properly, check that there is nothing
underneath the plate stopping it from turning.
 If the plate is set to the stop position, large dishes
can be placed on the entire surface of the oven.
In this case you will need to manually turn the
container or mix its contents mid-program.

– 9 –
FMW 45 CR C XS / FMW 45 CR C BK EN
Display
Right-hand screen Left-hand screen
Cooking time
°C
Temperature indicator
End of cooking
W
Power indicator
Keypad lock Cooking guide indicator
Minute Minder Stopping the turntable
Weight indicator
Control panel
1000 W... W
OK
°C/W
1
2
3
Key Function
Power On/Off Up
Set cooking time Down
Confirm / Run / Stop / Pause
°C/W
Temperature and Power indicator
1
2
3
Cooking functions

FMW 45 CR C XS / FMW 45 CR C BK
– 10 –
EN
COOKING PROGRAMS
Program Description
1000 W
1000W
For quickly heating drinks, water and dishes containing a large amount of liquid.
For cooking food containing lots of water (soups, sauces, tomatoes, etc.).
... W
900W / 100W
800W / 700W: For cooking fresh or frozen vegetables.
600W: To melt chocolate.
500W: For cooking fish and shellfish. 2 level reheating. For cooking dried vegetables over low heat.
Reheating or cooking of delicate egg-based foods.
400W / 300W: For cooking dairy products or jams at low heat.
200W: Manual defrost. To soften butter or ice cream.
100W: For defrosting pastries containing cream.
DEFROST
In this case, the air driven by the fan inside the oven concentrates around the food, thus speeding up the
natural defrosting process.
MICROWAVE & FAN
This combined function combines microwave and convection cooking, saving you considerable time.
The following microwave power levels are available: 100W-200W-300W. The cooking temperature can
be adjusted from 50°C to 200°C.
FULL POWER GRILL
This combined function lets you use the grill + the microwave at the same time, allowing you to cook
more quickly. You can combine any of the grill levels (1 to 4) with any of the microwave power levels
available (from 100W to 700W).
MEDIUM POWER GRILL
This combined function lets you use the grill + the microwave at the same time, allowing you to cook
more quickly. You can combine any of the grill levels (1 to 4) with any of the microwave power levels
available (from 100W to 700W).
MEMORY FUNCTION
The memory function allows you to store 3 common cooking (or defrosting) programs, which you can
then use thanks to quick selection.
PULSED GRILL
The pulsed grill function allows you to get crispy roasts and poultry and cook your legs of lamb, ribs of
beef without preheating. The cooking is done, alternately, by the upper element and by the air stirring
propeller. The cooking temperature can be adjusted from 50°C to 200°C.
GRILL
The grill function allows you to cook and brown food such as gratins and meat. It can be used before or
after cooking, depending on the recipe. There are 4 grill levels: from 1 to 4, going from light grilling to
strong grilling.
FAN OVEN
The convection function allows you to cook and brown food like in a traditional oven. Cooking is done by
the heating element located at the bottom of the oven and by the air stirring propeller.
The cooking temperature can be adjusted from 50°C to 220°C.
COOKING GUIDE
The “Flavour guide” function selects the appropriate cooking parameters according to the food to be
prepared and its weight.
AUTOMATIC DEFROSTING
Automatic defrosting function by weight
You will save a lot of time when you use your microwave oven to defrost frozen food.

– 11 –
FMW 45 CR C XS / FMW 45 CR C BK EN
INSTALLATION
Unpacking
 When you receive the appliance, unpack it
or have it unpacked immediately.
 Check its general appearance.
 Make a note of any reservations on the
delivery slip and keep a copy.
 Remove all protective packing.
 Check and follow the appliance’s
specifications which are listed on the
data plate.
Nr
SERVICE: TYPE:
CC
XXXXXXXXX
XXXXXXXXX
XXXX
XXXXX
XXXXXXXXX
XXXXXXXXX
XXXXX XXX
XXXXX
XX XX XXXX
Choice of location and fitting
This appliance can be installed in a cabinet
column as shown in the images below.
550
>=550
<=70
560
450
>=460
550
>=550
<=70
560
450
>=460
550
>=550
<=70
560
450
>=460
 Do not use your appliance immediately (wait
approximately 1 to 2 hours) after transferring
it from a cold place to a warm place, as
condensation may cause a malfunction.
 Centre the oven in the cabinet so as to ensure
a minimum distance of 10 mm between the
appliance and the surrounding unit.
 The material of the cabinet supporting
the appliance must be heat resistant (or
covered with a heat-resistant material).
 For greater stability, attach the oven to
the unit with 2 screws through the holes
provided on the side panels.
Electrical connection
Installation should only be performed
by installers and qualified technicians.
 The appliance must be recess-fitted
correctly to ensure electrical safety.
 The electrical connections should be made
before the appliance is installed in its
housing.
 Ensure that the circuit has sufficient power
(16 Amps).
 The safety wire (green-yellow) is connected
to the appliance’s ground terminal and
must be connected to the installation’s
earth.
 If the oven malfunctions in any way, unplug
it or remove the fuse for the circuit where
the oven is installed.
 We cannot accept liability for any accident
or incident resulting from non-existent,
defective or incorrect grounding.
If the electrical installation of your
home requires a modification to connect the
appliance, call a qualified electrician.
During maintenance, the appliance must be
disconnected from the mains, the fuses must
be switched off or removed.
600 ext.
560
550 int.
592
18
447
450 int.
547
22
x 2

FMW 45 CR C XS / FMW 45 CR C BK
– 12 –
EN
CONFIGURING THE DISPLAY
Setting the clock
 When switching on the display flashes at
12:00. Set the clock with or
 Confirm by pressing
Changing the clock
 The oven must be off. Press twice
 The time of day flashes and you can
now set it.
 Adjust the clock setting with or
 Press to confirm.
Timer
This function can only be used when the oven
is off.
 Press
 The minute minder flashes.
 Set the minute minder with the or
buttons.
 Press to confirm.
 Once the time has lapsed, there is a
sound signal. To stop it, press any key.
Note: You can modify or cancel the timer at
any time. To cancel, return to the timer’s menu
and set to 00:00. If you do not confirm, it will
be saved automatically after 60 seconds.
Keypad locking
 When the oven is off, press or at the
same time until the symbol appears on
the screen. Do the same to unlock.
Stopping the turntable plate
 If you think the size of your dish is too large
to turn properly, select a cooking function
and then select the turntable stop option.
 Press the
°C/W
and keys at the same
time to stop the turntable turning.
 The turntable’s stopping is confirmed
by a beep.
 To restart it, press the
°C/W
and keys at
the same time.
Note: You must rotate the container and stir its
content mid-program when the turntable stop
option is activated.
The stop turntable function cannot be used
with the defrosting modes.
OPERATION
 For best use of your Franke oven, consult
the cooking programs table.
Operating principles
Microwaves used for cooking are
electromagnetic waves. They are commonly
found in our environment in the form of
radio waves, light, or infrared radiation. Their
frequency is in the 2450 MHz band.
This is how they work:
– They are reflected by metals.
– They pass through any other material.
– They are absorbed by water, fat and sugar
molecules.
When food is exposed to microwaves, this
results in a rapid agitation of its molecules,
which makes the food heat up.
The depth of penetration of the waves into the
food is about 2.5 cm. If the food is thicker,
cooking at its centre occurs by conduction just
like traditional cooking.
In essence, microwaves are simply causing
a thermal change inside the food and are
therefore not harmful to health.

– 13 –
FMW 45 CR C XS / FMW 45 CR C BK EN
Using the microwave function
In manual mode you are cooking by setting
a program, the temperature and duration
according to your preferences.
 Select the
1000
Wfunction with the button
1
2
3
 A time is displayed by default (1.30
minutes) and the maximum power
(1000 W) is preprogrammed.
 To modify this time, press then adjust
with the buttons and
 Press to confirm.
 Your oven starts.
 Select the
...
Wfunction with the button
1
2
3
.
 To modify the power level, press
°C/W
key,
adjust the power with the and keys.
 You may also set the time by pressing the
key adjust the time with the and
keys.
 Press to confirm.
 Your oven starts.
Using the combined microwave function
 Select the function with the button
1
2
3
 A time is displayed by default (30
minutes) on the right-hand screen.
 The pre-programmed power (300 W)
and temperature (200°C) are displayed
on the left-hand screen.
 To modify this time, press and adjust
with the buttons and
 Press to confirm.
 Your oven starts.
 To modify the microwave power level or the
temperature, press
°C/W
and then adjust
the settings with and
 Press to confirm.
 Your oven starts.
Using the classic cooking functions
 Press
1
2
3
and select a classic cooking
function.
Your oven will recommend a temperature which
can be modified with and
 Press to confirm.
 Cooking starts immediately.
 The temperature indicator flashes until
the temperature has been reached.
 To set the temperature, press
°C/W
 Adjust the temperature with and
 Press to confirm.
 The oven starts to heat; the cooking
function flashes.
 A series of beeps sounds when
the oven has reached the selected
temperature.
 Press
 The cooking time display flashes to
indicate that it can be set.
 Press and to adjust the cooking
time.
 Press to confirm.
Your oven has the SMART ASSIST function
which, when programming a cooking time, will
suggest a cooking time which can be modified
depending on the selected cooking mode. See
the table below:
Cooking mode Cooking time
recommendation
Pulsed grill 15 min
Medium grill 7 min
Fan oven 30 min
End of cooking
 Proceed as for programmed cooking.
 After setting the cooking time, press
 The cooking end time indicated with
the symbol flashes.
 Adjust the cooking end time with and
 Press to confirm.
 The cooking end time display stops
flashing.
Memo active function
If the same cooking function has been used
during the last three cooking sessions, it will be
memorised and automatically suggested at the
next cooking session.
For each cooking function, if you modify three
times the recommended temperature with the
same information, it will be memorised as the
new recommended temperature.
Note: This function is disabled by default.
To activate it, go to the settings menu (see
Settings paragraph).

FMW 45 CR C XS / FMW 45 CR C BK
– 14 –
EN
Cooking guide function
The Cooking guide function selects the
appropriate cooking parameters according to
the food to be prepared and its weight.
 Select . You must choose a
preprogrammed food from the following
list:
P01 Ready-to-cook frozen food
P02 Ready-to-cook chilled food (combined function)
P03 Frozen pizza (combined function)
P04 Frozen pizza (traditional cooking)
P05 Fresh pizza
P06 Quiche
P07 Savoury tart
P08 Poultry
P09 Beef
P10 Pork
P11 Ready-to-cook chilled food (microwave)
P12 Fish
P13 Fresh fibrous vegetables
P14 Fresh vegetables
P15 Frozen vegetables
 Select the function with
1
2
3
 Choose your food with and
 Press to confirm.
 Depending on the food selected, a
weight (or a cooking time) is suggested
and flashes on the screen.
 Modify the required setting with
and
 Press to confirm.
Note: Duration cannot be modified for P06
and P 07.
 By pressing , you access the cooking
end time setting (delayed start ).
 Modify it if required with and
 Press to confirm.
 The oven starts.
Automatic defrost functions
The automatic defrost functions select the
appropriate cooking parameters according to
the food to be prepared and its weight.
Select a pre-programmed food from the list
below:
P01 Defrosting meat, poultry and ready-to-cook dishes
P02 Defrosting fish
P03 Defrosting bread
 Select the automatic defrost function
 Select a programme and enter the weight
of the food with and (in 50g steps).
 Press to confirm.
 The delayed start cannot be used with
these positions.
Memory function
The memory function allows you to store 3
common cooking (or defrosting) programs,
which you can then use thanks to quick
selection.
Programming a memory key
 First programme a cooking mode of your
choice with
1
2
3
(e.g. fan).
 Adjust the temperature and the power
(e.g.: 220°C) and then the cooking time
(e.g.: 25 minutes).
 Save your cooking program by holding
down the OK button until MEMO -1- flashes
in the display.
 Select one of the available memory
programs: 1 – 2 or 3 with and to go
from one to the next.
 Press to confirm.
 A beep will confirm that the
programme has been saved.
Using a memory programme
 Select the function with
1
2
3
 MEMO will appear in the display.
 Choose the required MEMO 1 – 2 or 3 with
and to go from one to the next.
 Press to confirm.
 The programmed memory will be
displayed.
 Press the button again; the oven
will turn on and the program will start.
Note: Follow the same procedure to replace
the previous programming. You can store all
functions except automatic programs.

– 15 –
FMW 45 CR C XS / FMW 45 CR C BK EN
Settings
You can adjust different settings on your oven.
To do so:
 Press until you get to the MENU
display then press again to select the
different settings.
 Activate or de-activate the different
parameters with and ; see table
below.
 To exit MENU mode, press until you
get to the clock display.
Activate/de-activate the beeping
sound of the buttons
Activate/de-activate demonstration
setting
Activate/de-activate memo mode
Keep warm function:
Position ON, function activated.
Position OFF, function de-activated.
Keep warm function
If the door is not opened after the cooking
process, after 2 minutes the oven switches to
keep warm function for 15 minutes and HH is
displayed on the screen.
CLEANING AND CARE
Before performing any cleaning and care:
 Read the general safety information
about cleaning in the chapter “SAFETY
INFORMATION“.
 Turn the oven off.
– Depending on how the oven is installed:
Unplug the oven or disconnect the power
at the main electrical system switch,
e.g., switch off the fuse of the oven in
the fuse box.
General recommendations
Stains on the base of the oven from various
cooking products (sauces, sugar, proteins and
fat) are always caused by spills and splashes.
Splashes occur during cooking and are usually
the result of cooking at too high temperatures.
Spills occur when using cooking dishes which
are too small, or due to an incorrect estimate
of increases in volume during cooking. These
problems can be avoided by using deep
cooking receptacles or by using the rack with
the glass drip tray.
The oven will remain as good as new if cleaned
regularly with water or special detergents.
 Ensure that the oven is cold before you
start cleaning.
 Do not use steam cleaners or direct jets
of water.
 Do not use coarse abrasive materials or
sharp metal scrapers to clean the glass
parts of the oven door.They could scratch
the surface and cause the glass to shatter.
 Never use scouring pads, steel wool,
muriatic acid or other products which
could scratch or mark the surface.
 Only use hot water and non-abrasive
detergents when cleaning the enamelled
surfaces and the oven chamber.
 Use a branded glass cleaner for the glass.
 Use a wet and soapy sponge.
Cleaning the oven chamber
It is easier to remove any stains while the oven
is still warm and while the stains are still new.
 Ensure the oven is cool to the touch, to
avoid burns.
 Clean the enamelled surfaces and the oven
chamber with hot water and non-abrasive
detergents.
 If the oven smells bad or is dirty, boil a cup
of water with lemon juice for 2 minutes
and clean the walls with a small amount of
washing up liquid.
 Dry all parts of the oven thoroughly after
cleaning.

FMW 45 CR C XS / FMW 45 CR C BK
– 16 –
EN
MAINTENANCE AND REPAIR
You may resolve certain little problems yourself:
The oven is not heating
 Check that the oven is correctly connected
and that your installation’s fuse is not out
of service.
 Check that the oven is not set to demo
mode (see settings menu).
The oven light is not working
 Replace the bulb or the fuse.
 Check that the oven is correctly
connected.
 If the oven light still doesn‘t work contact
the After Sales Department or a qualified
professional accredited to work on the
brand.
The cooling fan continues to operate after
the oven stops
This is normal; the fan may continue running
until a maximum of 1 hour after cooking to lower
the temperature inside and outside the oven.
 If the fan runs for over an hour, contact the
After Sales Department.
 Make sure that maintenance on electrical
components is carried out only by the
manufacturer or the customer service.
 Make sure that damaged cables are
changed only by the manufacturer or the
customer service.
 When contacting the customer service,
please provide the following information:
– type of fault
– appliance model (Art.)
– serial number (S.N.)
This information is given on the data plate.
DISPOSAL
The symbol on the product or on the
packaging indicates that the device
must not be disposed of in the
domestic waste.
By disposing of the device in a proper way
you help to avoid harmful consequences to
environment and health.
Further information about recycling the device
is available from the competent authority, the
local refuse disposal service or the vendor of
the device.
 Dispose of the device, which is to be
discarded, via a specialised waste collection
point for electronic and electrical devices.
In accordance with the Directive 2012/19/
EU, regarding the reduction of the hazardous
substances used in electrical and electronic
appliances, and waste disposal.
The barred dustbin symbol on the appliance
indicates that at the end of its working life the
product must not be disposed of as household
waste.
Consequently, when the appliance has reached
the end of its working life the user must take
it to a suitable recycling centre for electronic
and electrotechnical waste, or return it to the
dealer when purchasing a new appliance of
equivalent type.
Proper separate waste collection of the
scrapped appliance for subsequent recycling,
treatment and environmentally-friendly
disposal helps prevent a potentially negative
impact on the environment and health and
facilitates recycling of the materials used in
appliance construction.

– 17 –
FMW 45 CR C XS / FMW 45 CR C BK EN
CUSTOMER SERVICE
 Refer to the contact address for your
country on the back page or on our
website: www.franke.com
TECHNICAL DATA
Function suitability tests
Functional suitability tests in accordance
with IEC/EN/NF EN 60705 standards. The
International Electrotechnical Commission,
SC.59K, has established a standard for
comparative performance tests conducted on
various microwave ovens.
We recommend the following for this appliance:
Test Load Approx. time Power selector Cookware/Tips
Egg cream
(12.3.1)
1000 g
750 g
16-18 min
13-15 min 500 W
Pyrex 227
On the turntable plate
Pyrex 220
On the turntable plate
Savoy cake
(12.3.2) 475 g 6-7 min 700 W Pyrex 827 On the turntable plate
Meat loaf
(12.3.3) 900 g 14 min 700 W
Pyrex 838
Cover with cling film.
On the turntable plate
Defrosting meat
(13.3) 500 g 11-12 min 200 W On the turntable plate
Defrosting strawberries
(B.2.1) 250 g 6-7 min 200 W On a flat plate On the turntable plate
Potato gratin
(12.3.4) 1100 g 23-25 min Medium grill + 700 W
Pyrex 827
On the turntable plate
Chicken
(12.3.6) 1200 g
24-26 min High grill
+ 500 W
Place on the two grill rack + drip
pan
Insert at level 1 from the bottom
Turn midway through
35-40 min
Fan-assisted
200°C
+200 W
In an enamelled earthenware dish
Place on the grill rack inserted at
level 1 (from the bottom)
Cake
(12.3.5) 700 g 20 min
Fan-assisted
200°C
+200 W
Pyrex 828
Place on the grill rack at level 1
The manufacturer provides continuously product enhancements.
For this reason, the text and the illustrations in this manual may be changed without notice.
Further information on technical data is available on: www.franke.com

FMW 45 CR C XS/FMW 45 CR C BK
– 18 –
DE
ZU DIESER BEDIENUNGSANLEITUNG
Diese Bedienungsanleitung gilt für
verschiedene Modelle des Geräts. Auf
diese Weise ist es möglich, dass einige der
beschriebenen Merkmale und Funktionen an
Ihrem spezifischen Modell nicht verfügbar sind.
Die erklärenden Abbildungen, die in den
verschiedenen Abschnitten beschrieben
werden, stehen am Ende der Anleitung zur
Verfügung.
 Lesen Sie die Bedienungsanleitung durch,
bevor Sie das Gerät benutzen.
 Bewahren Sie die Bedienungsanleitung auf.
 Benutzen Sie das in dieser
Bedienungsanleitung beschriebene Gerät
nur gemäß der bestimmungsgemäßen
Verwendung.
Franke behält sich das Recht vor, Änderungen
am Produkt ohne vorherige Ankündigung
vorzunehmen. Alle Informationen waren zum
Zeitpunkt der Veröffentlichung korrekt.
Symbol Bedeutung
Warnzeichen. Warnung vor Verletzungsgefahren.
Maßnahmen in Sicherheits- und Warnhinweisen zur Vermeidung von Schäden und Verletzungen.
Handlung. Hier müssen Sie etwas tun.
Resultat. Ergebnis einer oder mehrerer Handlungen.
INHALTSVERZEICHNIS
Zu dieser Bedienungsanleitung 18
Bestimmungsgemäße Verwendung 19
Sicherheitshinweise 19
Korrekte Installation und Verbindung
mit der Stromversorgung 22
Richtige Verwendung 22
Pflege und Reinigung 22
Reparatur 23
Außerbetriebsetzung 23
Überblick 23
Anzeige 25
Bedienfeld 25
Garprogramme 26
Installation 27
Konfigurieren der Anzeige 28
Bedienung 29
Reinigung/Instandhaltung 32
Wartung und Reparatur 32
Entsorgung 33
Kundendienst 33
Technische Daten 34
Gebrauchstauglichkeitsprüfungen 34

– 19 –
FMW 45 CR C XS/FMW 45 CR C BK DE
BESTIMMUNGSGEMÄSSE VERWENDUNG
Der Multifunktionsofen wurde ausschließlich
für den nicht gewerblichen, privaten Gebrauch
im Haushalt entwickelt.
Der Ofen sorgt für Profileistungen im Haushalt.
Mit diesem äußerst vielseitigen Gerät lassen
sich verschiedene Garmethoden sicher und
einfach auswählen.
SICHERHEITSHINWEISE
 GEBRAUCHSANWEISUNG
UND SICHERHEITSHINWEISE
VOR DER VERWENDUNG
DES OFENS AUFMERKSAM
LESEN.
 Gebrauchsanweisung
sorgfältig aufbewahren,
um auch zu einem
späteren Zeitpunkt darauf
zurückgreifen zu können.
Der Hersteller haftet nicht für
etwaige Schäden, die durch
fehlerhafte Installation und
falschen, unsachgemäßen oder
unangemessenen Gebrauch
entstehen können.
Die elektrische Sicherheit des
Ofens ist nur gewährleistet, wenn
er an eine vorschriftsgemäße
Erdungsanlage angeschlossen ist.
Für den sicheren und
effizienten Betrieb dieses
Elektrogeräts:
 Kontaktieren Sie
nur autorisierte
Kundendienststellen.
 Nehmen Sie keine
Änderungen an den
Gerätefunktionen vor.
Kinder ab 8 Jahren und
Personen mit
eingeschränkten physischen,
sensorischen oder psychischen
Fähigkeiten oder mit mangelnden
Erfahrungen oder Kenntnissen
dürfen das Gerät nicht bedienen
und nicht reinigen, es sei denn,
sie werden von einer für ihre
Sicherheit verantwortlichen
Person beaufsichtigt oder
angeleitet.
Kinder unter 8 Jahren dürfen
das Gerät nicht bedienen und
nicht reinigen, auch wenn sie
beaufsichtigt werden.
Dieses Gerät ist kein Spielzeug.
 Halten Sie Kinder
vom Gerät und vom
Verpackungsmaterial fern.
 Lassen Sie Kinder in der
Nähe des Geräts nicht
unbeaufsichtigt.
 Kinder nicht mit dem Gerät
spielen lassen.
 Kinder dürfen das Gerät
oder die Bedienelemente
während des Betriebs oder
unmittelbar danach nicht
berühren.

FMW 45 CR C XS/FMW 45 CR C BK
– 20 –
DE
 Das Gerät muss so
eingebaut werden, dass die
vollständige Trennung von
der Stromquelle mit einem
Kontaktöffnungsabstand
ermöglicht wird (gemäß
Überspannungskategorie
III). Zu diesem Zweck ist
entweder ein Stecker
erforderlich, oder es muss
ein Schalter in das ortsfeste
Verdrahtungssystem
unter Einhaltung der
Installationsregeln
eingebaut werden.
WARNUNG: Das Gerät darf
nicht hinter einer Dekortür
installiert werden, um
Überhitzung zu vermeiden.
 Verwenden Sie
ausschließlich Utensilien,
die zur Verwendung
in Mikrowellengeräten
geeignet sind.
 Wenn Sie Speisen
in Kunststoff- oder
Papierbehältern erwärmen,
überwachen Sie den Inhalt
der Mikrowelle, da die Gefahr
spontaner Entflammung
besteht.
 Sollte sich Rauch
bilden, schalten Sie das
Mikrowellengerät aus oder
ziehen Sie den Netzstecker
ab und halten Sie die Tür
geschlossen, um eventuelle
Flammen zu ersticken.
 Wenn Sie Getränke im
Mikrowellengerät erhitzen,
kann kochende Flüssigkeit
unvermittelt und/oder
verzögert aus dem Behälter
herausspritzen. Gehen Sie
vorsichtig vor, wenn Sie den
Behälter aus dem Gerät
nehmen.
 Verwenden Sie weder
Metallbehälter noch
Aluminiumschalen.
 Es empfiehlt sich nicht,
Eier in ihrer Schale und
hart gekochte ganze Eier
in einem Mikrowellengerät
zu erhitzen, da sie auch
noch explodieren können,
nachdem der Garprozess
beendet ist.
 Das Mikrowellengerät ist
zum Erhitzen von Speisen
und Getränken vorgesehen.
 Verwenden Sie den Ofen nur
zum Kochen und Zubereiten
von Speisen.
 Keine brennbaren
Flüssigkeiten in der Nähe
des Ofens verwenden.
 Nur das für diesen
Ofen empfohlene
Bratenthermometer
verwenden.
