Franklin LT70B User manual

LT70B Smart Locator
User Guide

2
Introduction
The following topics describe the basics of using this guide and your new tracker device.
Before You Begin
Thank you for purchasing your new LT70B Tracker!
The following topics explain how best to use this guide to get the most out of your device.
Before Using Your Device
Read Safety and Notices thoroughly for proper usage.
Accessible services may be limited by subscription contract conditions.
Guide Usage Notes
Note that most descriptions in this guide are based on your device's default settings at the time of
purchase.
Screenshots and Key Labels
Screenshots and Key labels are provided for reference only. Actual windows, menus, etc. may differ in
appearance.
Other Notations
In the user guide, the device may be referred to either as "Smart Locator," "Tracker,"
Package Contents
See below for details on everything you will find in the box for your LT70B.
Smart Locator
Key ring
Belt clip
USB Charger

3
Get Started
The following topics give you all the information you need to set up your device and wireless service for
the first time.
Device Parts and Functions
Learn your device's primary parts and functions.
Device and Charger Layout
The following illustration outlines your device's primary external features and buttons.
Charge the Battery
Follow these instructions to charge your device's embedded battery using the included
USB Cable.
1. Plug USB cable into USB port of PC
2. Connect the USB cable with 4 pogo pins in backside of device
Power Button
LED

4
Battery Charging Cautions
Charging Conditions: Under low temperatures charging performance decreases. Charge your
device in temperatures between 0°C –40°C. Do not charge in places where there is high humidity.
Use Supplied Accessories: Always use the supplied USB cable.
Precaution for Extended Use: Your device may become hot when used for a long time or while
charging, especially in high temperatures. Prolonged contact with skin may cause low-temperature
burn injuries.
Turn Your Device On
Press 1 second, LED turns ON once device powers ON and is GREEN for 2 sec
Turn Your Device OFF
Press the button .for 7 seconds
After 7 seconds, LED blinks Amber every 500 milliseconds to imply action needed. Quick button press
within 2-3 seconds stops LED blinking and confirms power down. LED shuts off. Also sends a location
update with shut off status.

5
.How to Download the APP
Step 1: Power UP the device and Activate
By pressing the button for 1 sec. device turns on with green LED and beeper
When device is power on, the device will be activated automatically for next 2 ~ 3 min.
Step 2: Download the App
Visit your App store on your smartphone.
Search for “Smart Locator"
Find the App, download and install.
Create Username and Password
Step 3: Begin registering your tracker device
Register your IMEI of the device via Bluetooth.
a. If not successful via Bluetooth, scan the IMEI 2D barcode number located in the device or
on the packaging box.
b. If not successful via IMEI barcode scan, you can enter 15 digit IMEI number manually
Step 4: Create a profile and Virtual Geo-Fence
Create your profile during the setup
Create your Geo-fence by drawing your own fence boundary either circular format or free format
Create your Geo-fence by selecting home Wi-Fi SSID.

6
Device and Battery Charger LED Scenario
Function
Button Press
Duration
LED Color
Device Behavior
Sound
Power ON
1 sec press
GREEN
LED turns ON once device
powers ON and is GREEN
for 2 sec
2-tone rising
beep
Power OFF
7 second long-
press, button
release, followed
by quick button
press.
AMBER
After 7 seconds, LED blinks
Amber every 500
milliseconds to imply action
needed. Quick button press
within 2-3 seconds stops
LED blinking and confirms
power down. LED shuts off.
Also sends a location
update with shut off status.
2-tone
decending
beep
Power Cycle
HARD RESET
15 or more
seconds long
press ignoring
LED behavior,
then release.
There will be no
LED or buzzer
behavior if device
is stuck or not
responding.
blink green
after 2 sec,
then blink
Amber after
7 sec,
None if
device is
not
responding.
LED continues to blink
Amber until device powers
back On. There will be no
location update and no
status update to server.
Device will just shut off and
turn back on
No LED blinking if device
not responsive
2-tone
decending
beep when
powering off
and then 2-
tone
ascending
beep when
powering on
Power Cycle
(before
pairing)
Tracker Button
behavior
BEOFRE
PAIRING (User
will receive
instruction in the
app after the MDN
is provisioned
during SA flow):
1. User presses
and holds Button
press for 3
seconds
2.Tracker Power
Cycles and
follows existing
requirements for
power down and
power on
LED/Sounds
LED
"Double-
blinks"
Amber
User is instructed in-app to
release button when hearing
tone and seeing LED blink
Amber, and Tracker ONLY
power cycles upon release
of the button
If the Tracker Button is
released between 3 seconds
and 7 seconds, the Tracker
will power cycle. If the
Tracker button is held for 7
seconds, the Tracker shall
follow existing requirements
(above) for power down
Single-tone
beep like
when device
enters ready-
to-pair mode
Power off and
Power on
sound as per
requirements

7
Factory Reset
Device must be
placed on and
connected to
charging dock,
then 4 short
button presses, 2
second pause,
followed by quick
button press.
Blinks
Amber for 5
sec after 4
presses
After 4 presses, alert sound
starts and plays for 2
seconds, during which time
user pauses for 2 seconds -
then LED blinks Amber
every 500 milliseconds to
imply action needed. Then
user makes quick 5th button
press. The 5th button press
should happen within 5
seconds after pause, else
action is cancelled.
After 4
presses, Alert
sound starts
for 2 seconds.
Location
Update/Report
Long-press (must
be longer than 2
seconds).
GREEN,
blinks 3
times
or
RED, blinks
3 times
LED blinks GREEN after 2
sec, user should release
button when it starts blinking
LED blinks RED if device is
"not connected" to LTE or in
"No service" state
LT70B Tracker Device Specifications
Item
Description
Model name
LT70B Smart Locator
Dimensions1
50.3mm (L) x 35.3mm (W) x 15.3mm (H)
Weight
49g (including Battery Pack)
Compatible networks
LTE Band 13
LED
1bi-color LED (3 different Colors)
SIM
4FF Nano SIM
Battery
3.8V 400mAh
Rechargeable Lithium-ion
Modem Processor
Qualcomm MDM9206

8
Item
Description
GPS
Qualcomm WTR2965
WIFI/BT
Qualcomm QCA9377
Memory
RAM –256MB
Flash - 256MB
Operating System
Linux

9
Product Safety and Warranty
Information
The following topics outline your device's warranty and service information.
General Precautions
• It is normal that your wireless device may get hot when you use it.
• Use your device and accessories with care and in a clean environment.
• Keep your device away from open flames,fire or lit cigarettes.
• Protect your device and accessories from water and vapor and keep them dry.
• Do not drop, throw or bend your device.
• Clean your device with a damp and soft antistatic cloth.
• Do not use any chemical agents (such as alcohol and benzene), chemical detergents or
abrasive powders to clean your device.
• Do not leave your device or accessories in a place with extreme low or high temperatures (e.g.,
direct sunlight for any extended length of time).
• Use only accessories for your device that have been approved by the manufacturer.
Trademarks and Copyright Information
The names of companies, products, and services used in this guide are registered trademarks or
trademarks of the respective companies.
Franklin Wireless logo is trademarks or registered trademarks of Franklin Wireless Corporation in
US. Copyright © 2017 Franklin Wireless Corporation. All rights reserved.

10
Safety and Notices
The following topics address important safety precautions, general notes, and required RF exposure
information for your mobile broadband device.
Safety Precautions
The following topics outline important safety precautions that must be observed when using your device.
Important Notice
Due to the nature of wireless communications, transmission and reception of data can never be
guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant
delays or losses of data are rare when wireless devices are used in a normal manner with a well-
constructed network, your device should not be used in situations where failure to transmit or receive data
could result in damage of any kind to the user or any other party, including but not limited to personal
injury, death, or loss of property. Franklin Wireless accepts no responsibility for damages of any kind
resulting from delays or errors in data transmitted or received using your device, or for failure of your
device to transmit or receive such data.
Safety and Hazards
Do not operate your device under the following conditions.
●In areas where blasting is in progress
●Where explosive atmospheres may be present
●Near medical equipment
●Near life support equipment, or any equipment that may be susceptible to any form of radio
interference.
In such areas, your device MUST BE POWERED OFF. Your device can transmit signals that could
interfere with this equipment.
Do not operate your device in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, your
device MUST BE POWERED OFF. When operating, your device can transmit signals that could interfere
with various onboard systems.
Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground. Your device
may be used at this time if allowed by airlines.
The driver or operator of any vehicle should not operate the device while in control of a vehicle. Doing so
will detract from the driver or operator’s control and operation of that vehicle. In some jurisdictions,
operating such communications devices while in control of a vehicle is an offense.

11
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.
