FRC FROG-D 3P User manual

FDA300 Rev0306
1
FIRE RESEARCH CORPORATION
www.fi reresearch.com
26 Southern Blvd., Nesconset, NY11767
TEL ( 631 ) 724-8888 FAX ( 631 ) 360-9727 TOLL FREE 1-800-645-0074
FROG-D 3P
THREE PHASE GENERATOR DISPLAY
FREQUENCY READOUT OF GENERATOR
MODEL FDA300
Document Number:
XE-FDA3PM-R0A
FOR DELTA WINDINGS
FOR STAR WINDINGS

FDA300 Rev0306
2
CONTENTS
Table of Contents
CONTENTS ................................................................................................................ 2
INTRODUCTION ...................................................................................................... 3
Overview ................................................................................................................ 3
Features .................................................................................................................. 3
Specifications ......................................................................................................... 3
GENERAL DESCRIPTION ....................................................................................... 4
Components ........................................................................................................... 4
Controls and Indicators .......................................................................................... 5
INSTALLATION ........................................................................................................ 6
Install Display Module .......................................................................................... 6
Install Current Sensor ............................................................................................ 8
Install Voltage Transformer .................................................................................... 9
Install Optional Hydraulic Oil Temperature Sensor .............................................. 9
Install Optional Buzzer .......................................................................................... 9
OPERATION ............................................................................................................ 10
WIRING .................................................................................................................... 12
Star Winding Connections ................................................................................... 14
Delta Winding Connections ................................................................................. 15
List of Figures
Figure 1. Controls and Indicators ............................................................................... 5
Figure 2. Display Module Mounting Dimensions ..................................................... 7
Figure 3. Current Sensor ............................................................................................ 8
Figure 4. Transformer ................................................................................................ 9
Figure 5. Wiring ...................................................................................................... 12
Figure 6. Star Winding Connections ........................................................................ 14
Figure 7. Delta Winding Connections ...................................................................... 15
List of Tables
Table 1. Line Displays ............................................................................................. 11

FDA300 Rev0306
3
INTRODUCTION
Overview
The Fire Research FROG-D is a three phase generator output display panel for
50/60 Hz generators rated from 10 to 135 kW with delta or star windings.
The ultra-brite LED displays on the FROG-D will show the operator generator
frequency, current on each lines, and AC line voltage (phase to neutral or phase to
phase. When the generator is off line the display will show total accumulated generator
hours.
The FROG-D built in safety features include current overload, voltage fluctuation,
and high hydraulic oil temperature warnings.
Features
Generator Hourmeter
Audible Alarm Buzzer (Optional)
Hydraulic Oil Temperature Sensor (Optional)
Specifications
Display Module
Supply Power: 12 VDC
Supply Current: 1.25 Amps
Dimensions: 4.25" Wide by 4.25" High
LED Displays
Frequency: 0 - 99.9 Hz
Current: 0 - 150 Amps Each Line
Voltage: 0 - 300 AC volts
Hourmeter: 0 - 9999 (1 Hour Increments)
Hydraulic Oil Temperature: 0 - 230 °F

FDA300 Rev0306
4
GENERAL DESCRIPTION
Components
The FROG-D 3P consistof the following components:
Display Module
3 Current Sensors
3 Voltage Transformer
Engine Oil Temperature Sensor (Optional)
Audible Alarm Buzzer (Optional)
Cables
Display Module
The display module is waterproof and can be mounted anywhere on the electrical
panel. The FROG-D 3P display module has a square flange with overall dimensions
of 4.25" X 4.25". A cutout hole of 3.75" in diameter is required.
Current Sensors
Three current sensors are supplied with the FROG-D 3P. The current sensors are
identical and they can be used either to measure line 1, line 2, or line 3 current draw
Run the wires from the main circuit breaker to the current sensors; one wire through
each current sensor.
Voltage Transformer
The voltage transformers supplied will work for 120 or 240 volt AC systems. The
transformers should be securely mounted inside the electrical box.
Hydraulic Oil Temperature Sensor (Optional)
The optional hydraulic oil temperature sensor has a 1/8 NPT male threads and is
installed as required.
Audible Alarm Buzzer (Optional)
The optional buzzer is installed as required.
Cables
The cables to connect power and the sensors are provided. Refer to the Wiring
Section.

FDA300 Rev0306
5
Controls and Indicators
All controls and indicators are located on the front of the display module.
FREQUENCY HZ Display
Shows generator frequency in hertz.
LINE Displays
Shows the selected line to view voltage or current. See Operation Section for
complete description.
AC VOLTS Display
Shows the generator output voltage on the selected line.
AMPS Display
Shows the current in ampers on selected line.
MODE Button
Press to show total generator hours and hydraulic oil temperature.
LINE Button
The LINE button allows the operator to select the individual line voltage and
current to show in the display. There are 7 selections for the LINE button. See Operation
Section for complete description.
Figure 1. Controls and Indicators
LINE
Button
MODE
Button
FREQUENCY
Display
AMPS
Displays
AC VOLTS
Display
VOLTS Line
Display
AMPS Line
Display

FDA300 Rev0306
6
INSTALLATION
The FROG-D 3P must match the rated output of the generator. It is factory set
from 10 to 135 kW in 5 kW increments. Ensure that the generator power rating and
the FROG-D rating match.
Install Display Module
1. Measure and mark mounting location for display module panel cutout and
mounting screw holes. Make sure there is clearance behind the panel for
the module and cables before cutting holes. Refer to Figure 2 for layout and
dimensions.
2. Cut out a 3.75" mounting hole in panel.
3. Drill four holes, clearance or tapped, for 10-32 mounting screws.
4. Place control module in position and secure with screws.
5. Connect cables at rear of the display module. (Refer to Wiring section.)

FDA300 Rev0306
7
Figure 2. Display Module Mounting Dimensions
Mounting holes are clearance
or tapped for 10-32 screws.
4.25"
4.25"
3.5"
3.5"
2.38"
.75"
3.72"
Panel Cutout
A 3.75" hole is
recommanded.

FDA300 Rev0306
8
Install Current Sensor
Three current sensors are supplied. It is best to mount the sensors in the circuit
breaker box. For each line that is to be monitored, run the wire from the generator
through the current sensor to the input side of the circuit breaker. (Refer to Wiring
section.)
Figure 3. Current Sensor
Current Sensor
Ratio: 150 : 5
A = 1.13"
B = 2.46"
C = 1.05"

FDA300 Rev0306
9
Figure 4. Transformer
Install Voltage Transformer
The voltage transformers suppplied will work for 120 or 240 volt AC systems. The
transformers should be securely mounted inside the electrical box.
Each transformer will be connect to show line voltage phase and neutral or phase
to phase for star or delta windings of the generator. (Refer to Wiring section.)
Install Optional Hydraulic Oil Temperature Sensor
The hydraulic oil temperature sensor (FRC part number XE-FDT2) has 1/8-27
NPT male threads. (Refer to Wiring section.)
Install Optional Buzzer
Install the buzzer close to the control module so the audible warning is easily
associated with the visual warning on the display. The optional buzzer provided by
FRC requires a cutout hole of 1-1/8” (1.125”). (Refer to Wiring section.)
Voltage Transformer
Input: 120/240 VAC
Output: 12/24 VAC @ 0.2A
D = 1 1/2”
H = 1 3/8”
W = 2 3/8”
MW = 2”
Note: Refer to Wiring section, Star or Delta Windings for
generator connections.

FDA300 Rev0306
10
OPERATION
MODE Button
During normal operations the mode button is used to display the accumulated
hours and hydraulic oil temperature if this option is installed.
The first time the MODE button is pressed, the FROG-D 3P will display the
generator hours.
Generator Operating Time is:
50 hours
Over Current Warning
When the generator is operating outside the range of its rated capacity, the current
display will start to flash. When line 4, 5, or 6 is selected, the display will flash ‘OC’ to
indicate Over Capacity since no current draw reading is display when line 4, 5, or 6
are selected. An optional audible buzzer can also be connected for audio warning.
Voltage Out-Of-Range Warning
If the output voltage is below 200 VAC or above 270 VAC, the VOLTS readout
will begin to flash. This will give the operator an indication that the generator output
falls outside the safe operating level. There is no audible alarm for the voltage out of
range warning.
Hydraulic Oil Temperature (Optional )
This warning will be activated if the oil temperature rises above 180 deg. F. The
frequency readout will flash “OIL“ to warn the operator and the optional audio alarm
will also be activated.
Pressing the MODE button again will switch the display to show the engine oil
temperature.
Hydraulic Oil Temperature is:
150 degrees F
Pressing the MODE button again will return the display to normal operations.

FDA300 Rev0306
11
Table 1. Line Displays
LINE Displays and Button
On power up the LINE displays will be set to Auto.
In Auto mode, the displays will scroll continuously through all six selectable options
and show the corresponding voltages and currents in the display windows.
To read the voltage and current for a specific line press and hold the LINE button
until the number corresponding to the desired selection shows in the LINE window.
(Refer to the chart next to the LINE window.)
Note: When line selections 4, 5, and 6 are active the AMPS window will
show 3 dashes.
Leave the display in Auto during normal operations to monitor voltages and
currents on all lines.
LINE WINDOW CHART DESCRIPTION
1.A-N Shows Voltage Phase A to Neutral
2.B-N Shows Voltage Phase B to Neutral
3.C-N Shows Voltage Phase C to Neutral
4.A-B Shows Voltage Phase A to Phase B
5.B-C Shows Voltage Phase B to Phase C
6.C-A Shows Voltage Phase C to Phase A
7.Auto Scroll Continuously Through All Six
Selectable Options
1.A Shows Current on Phase A Line
2.B Shows Current on Phase B Line
3.C Shows Current on Phase C Line

FDA300 Rev0306
12
Figure 5. Wiring
(Sheet 1 of 2)
WIRING
The following figures include the schematics, wiring diagrams, block diagrams,
and cables for the FROG-D 3P.
Power
Supply Options
B
Connector Key
A 6-Pin Deutsch
B 2-Pin Deutsch
Current Sensors
(See Sheet 2)
Black
Plug
Options Cable Connector
Pin/Wire Description
1/Red Temp Sensor Red
2/Black Temp Sensor Black
3/White Temp Sensor Green
/Green Buzzer GND
/Blue Buzzer +12V
Current
Sensors
A
Current Sensor Cable
Connector
Pin/Wire Description
1/Red Line 1 Sensor WHT
2/Black Line 1 Sensor BLK
3/White Line 2 Sensor WHT
4/Green Line 2 Sensor BLK
5/Blue Line 3 Sensor WHT
6/Brown Line 3 Sensor BLK
A
Power Supply Cable
Connector
Pin/Wire Description
A/Red +12 VDC
B/Black Ground
Transformers
A
Transformer Cable
Connector
Pin/Wire Description
1/Red Transformer 1 BLU
2/Black Transformer 1 BLU
3/White Transformer 2 BLU
4/Green Transformer 2 BLU
5/Blue Transformer 3 BLU
6/Brown Transformer 3 BLU
AC Transformer
(See Sheet 2)
Gray
Plug

FDA300 Rev0306
13
Transformers
Transformer
Cable
(See Sheet 1)
Secondary AC Output
12/24 VAC
To FROG
Primary AC Input
120/240 VAC
From Generator
Black
Wires
Blue
Wires
Black Wire
Red Wire
Current Sensors
Current
Sensor Cable
(See Sheet 1)
Figure 5. Wiring
(Sheet 2 of 2)
Red Wire
Black Wire
White Wire
Green Wire
Blue Wire
Brown Wire
Line 2
Line 3
White Wire
Black Wire
White Wire
Black Wire
White Wire
Black Wire
Line 1
Note: Refer to Star or Delta windings diagrams for generator connections.

FDA300 Rev0306
14
Figure 6. Star Winding Connections
NCB A
Transformers
Current
Sensors
From Generator
6-Pin Deutsch Receptacle
to Transformer Cable
6-Pin Deutsch Receptacle
to Current Sensor Cable
Refer to Figure 5 for pin
number and wire color.
A
BC
N
240v
240v
240v
120v
120v
120v
Star Circuit
Star Winding Connections

FDA300 Rev0306
15
Figure 7. Delta Winding Connections
NCB A
Transformers
Current
Sensors
From Generator
A
BC
N
240v
240v
240v
208v
120v
Delta Circuit
120v
6-Pin Deutsch Receptacle to
Transformer Cable
6-Pin Deutsch Receptacle
to Current Sensor Cable
Refer to Figure 5 for pin
number and wire color.
Delta Winding Connections
