P6F127 Mainboard Manual
Friday,March 02,2001

Copyright Notice
©Copyright 2000
The information contained in this user’s manual and all accompany-
ing documentation is copyrighted and all rights are reserved. This
publication may not, in whole or in part, be reproduced, transcribed,
stored in a retrieval system, translated into any language or com-
puter language, or transmitted in any form whatsoever without the
prior written consent from the manufacturer, except for copies re-
tained by the purchasers for their personal archival purposes.
The manufacturer reserves the right to revise this user’s manual and
all accompanying documentation and to make changes in the con-
tent without obligation to notify any person or organization of the
revision or change.
IN NO EVENT WILL THE VENDOR BE LIABLE FOR DIRECT,
INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE
THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE
VENDOR SHALL NOT HAVE LIABILITY FOR ANY HARDWARE,
SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING,
REPLACING, OR RECOVERING SUCH HARDWARE,
SOFTWARE, OR DATA.
All trademarks mentioned in this document are acknowledged.
The specifications in this manual are subject to change without no-
tice.

Preface
ii
Using This Manual
This manual is designed to help you build a reliable Personal Com-
puter based on the P6F127 platform.
Chapter 1—Quick Reference
This chapter is for advanced users who want to quickly assemble a
system. The mainboard layout along with jumper and switch settings,
and memory configuration are provided.
Chapter 2—Introduction
This chapter includes an introduction, a checklist of the items that
ship with this mainboard, and a summary of the principal features
and components.
Chapter 3—Hardware Installation
This chapter explains how to prepare your mainboard for use and
how to make the various connections to other computer components
and peripheral items.
Chapter 4—BIOS Configuration
This chapter explains how to use the system setup utility that is
stored in the mainboard’s firmware.
Chapter 5—Driver and Utility
This chapter briefly describes the drivers and utility programs that
are packaged with the mainboard.

Preface
iii
Table of Contents
1. P6F127 QUICK REFERENCE 1
1.1. Mainboard Layout ..........................................................1
1.2. I/O Ports (AC97)............................................................2
1.3. I/O Ports (Ensoniq CT5880)...........................................2
1.4. Panel Connector ............................................................2
1.5. Jumpers.........................................................................3
1.6. PCI and AGP Frequency Settings ..................................3
1.7. Connectors ....................................................................4
1.8. Memory Installation........................................................4
2. INTRODUCTION 5
2.1. Overview........................................................................5
2.2. Mainboard Specifications and Features .........................6
2.2.1. Hardware.............................................................................................6
2.2.2. Software...............................................................................................7
2.2.3. Environment........................................................................................7
2.3. Mainboard Layout ..........................................................8
2.4. Microprocessor............................................................ 10
2.5. CPU Packaging ........................................................... 10
2.6. CT5880 Ensoniq Controller (Optional).......................... 10
2.7. Chipset ........................................................................ 11
3. HARDWARE INSTALLATION 12
3.1. Unpacking.................................................................... 12
3.2. Installation ................................................................... 13
3.3. Safety Measures .......................................................... 13
3.4. Connector/Jumper Location......................................... 14
3.5. Attaching Connectors................................................... 15
3.5.1. Front Panel Connectors..................................................................15
3.5.2. Infrared (IR) Connectors................................................................16
3.5.3. CD-ROM Connectors......................................................................16
3.5.4. LAN/Modem Wake Up Connectors...............................................17
3.5.5. Floppy Drive Connector.................................................................17
3.5.6. IDE Connectors................................................................................18
3.5.7. CPU Speed Settings.........................................................................18
3.5.8. Back Panel Connectors...................................................................19
3.6. Installing the CPU........................................................ 24
3.6.1. Before You Begin..............................................................................24
3.6.2. Installation Procedure.....................................................................24

Preface
iv
3.6.3. Removing the Processor..................................................................25
3.6.4. Installing System Memory...............................................................26
3.6.5. Setting Jumpers................................................................................28
3.6.6. Auto Power On .................................................................................29
4. BIOS CONFIGURATION30
4.1. Entering Setup............................................................. 31
4.2. Standard CMOS Setup ................................................ 33
4.3. BIOS Features Setup................................................... 37
4.4. Chipset Features Setup ............................................... 40
4.5. Integrated Peripherals.................................................. 44
4.6. Power Management ..................................................... 48
4.7. PnP/PCI Configuration................................................. 53
4.8. PC Health Status Option.............................................. 55
4.9. Frequency/Voltage Control .......................................... 56
4.10. Load Optimized Defaults Option............................... 57
4.11. Supervisor/User Password....................................... 58
4.12. Save & Exit Setup .................................................... 58
4.13. Exit Without Saving .................................................. 58
5. DRIVER AND UTILITY59
5.1. Flash Utility .................................................................. 59
5.2. VIA 4-in-1 Driver .......................................................... 59
5.3. System Environment Monitor....................................... 60
5.3.1. Hardware Monitor System Setup...................................................60
5.3.2. Setting the Threshold.......................................................................61
5.4. ATA66/100 Controller Options ..................................... 62
5.5. Ensoniq Installation (optional)...................................... 62
5.6. Online Services............................................................ 64

1. P6F127 Quick Reference
This section is for users to get started using the mainboard straight away.
1.1.Mainboard Layout
LAN WAKE UP
PCI1
PCI2
PCI3
PCI4
PCI5
ISA
BAT
IDE2
IDE1
DIMM1 DIMM2 DIMM3
CPU
FAN
SYSTEMFAN
CD2 CD1
JP19
JP3
MODEM WAKE UP
JP4
AGP
J1
USB2
FDC
POWER1
Parallel
and
serial
ports
USB
ports
PS/2
mouse/keyboard
ports
Game
and
audio
ports
CN1
JP20
1. PGA370 CPU socket (PGA370)
2. ATX power connector (POWER1)
3. DIMM module sockets (DIMM1~3)
4. Floppy drive connector (FDC)
5. CPU fan connector (FAN1)
6. CD-ROM audio connectors (CD1/2)
7. Accelerated Graphics Port slot (AGP)
8. IDE connector (IDE1)
9. IDE connector (IDE2)
10. Ensoniq AC97 controller (optional)
11. USB connector (USB2)
12. LAN wake up connector (JP6)
13. Modem wake up connector(JP5)
14. Infrared (IR) connector (JP4)
15. BIOS controller
16. ISA expansion slot (ISA)
17. PCI expansion slots (PCI1~5)
18. RTC battery (BAT)
19. Front panel connectors (CN1)
20. System fan connector (SYSTEM FAN)

Mainboard User’s Manual
2I/OPorts (AC97)
1.2.I/O Ports (AC97)
PS/2
mouse
PS/2
keyboard
USB
ports
Parallel port (LPT1)
Serial port
COM 1
Line-out
Microphone
Game port Line-in
Serial port
COM 2
1.3.I/O Ports (Ensoniq CT5880)
PS/2
mouse
PS/2
keyboard
USB
ports
Parallel port (LPT1)
Serial port
COM 1
Line-out (front)
Microphone
Game port
Line-in (rear)
Serial port
COM 2
1.4.Panel Connector
The following illustration shows the front panel connector pin as-
signments:
HDD
LED
STANDBY
LED
SPEAKER
Ground
Ground
LED cathode
LED cathode
LED cathode
LED anode
LED anode
LED anode
Keylock
Non
Ground
Ground
Power on/off
Reset Single
+5V
+5V
Speaker-out
POWER LED
& KEYLOCK
RESET
BUTTON
POWER
SWITCH
Pin 1

P6F127 Quick Reference
Jumpers 3
1.5.Jumpers
1-2, 3-4, 5-6, 7-8:CPU ratio = 2X
1-2, 3-4, 7-8:CPU ratio = 2.5X
1-2, 5-6, 7-8:CPU ratio = 3X
1-2, 7-8: CPU ratio = 3.5X
3-4, 5-6, 7-8: CPU ratio = 4X
3-4, 7-8:CPU ratio = 4.5X
5-6, 7-8: CPU ratio = 5X
J1
7-8: CPU ratio = 5.5X
1-2:Normal ModeJP3 2-3:Clear CMOS RAM
Short:System detects FSB speedJ17 Open:133 FSB speed only
1-2: Suspend to RAM disabledJP19 2-3: Suspend to RAM enabled
1-2: OnChip sound enabledJP20 2-3: OnChip sound disabled
1.6.PCI and AGP Frequency Settings
The PCI and AGP frequency settings are automatically set by the
system.

Mainboard User’s Manual
4Connectors
1.7.Connectors
FAN1 CPU FAN Connector: This 3-pin header is used for con-
necting the CPU fan.
CD1/2 CD Connectors: These 4-pin headers are used for con-
necting the CD ROM audio input to the sound card.
USB2 USB Connector:This 8-pin.
JP4 Infrared (IR) Connector: This 5-pin header is used to
connect an infrared (IR) port for use of IR devices.
JP5 Modem Wake UP Connector:This 3-pinheaderisused
for remote wake up of the computer through a modem.
JP6 LAN Wake Up Connector:This 3-pinheaderis used for
remote wake up of the computer through a network card.
SYSTEM
FAN System Fan Connector:This 3-pin header is for con- necting the case fan that keeps the system cool.
1.8.Memory Installation
168-Pin DIMM SDRAM Memory Configuration
Bank 0 (DIMM1) 8, 16, 32, 64, 128, 256, 512 MB
Bank 1 (DIMM2) 8, 16, 32, 64, 128, 256, 512 MB
Bank 2 (DIMM3) 8, 16, 32, 64, 128, 256, 512 MB
Total 8 MB to 1.5 GB
This concludes Chapter 1. Chapter 2 covers the mainboard’s specifi-
cations and features.

2. Introduction
2.1.Overview
The P6F127 is a high quality, high performance, enhanced function
mainboard that supports 64-bit Intel Celeron/Cyrix Socket 370 proc-
essors. This mainboard is designed around the latest and fastest
Apollo Pro133A chipset in a standard ATX form factor.
The mainboard delivers workstation-level performance with an inte-
grated AGP (Accelerated Graphics Port), bus mastering EIDE
(Enhanced IDE) controller, concurrent PCI bus, and an Ensoniq digi-
tal controller (optional). The mainboard accommodates SDRAM
(Synchronous DRAM) memory and supports ATA33/66/100.
The mainboard achieves the highest reliability by supporting ECC
(Error Checking and Correction) memory protection, enabling the
mainboard to achieve superior data integrity and fault-tolerance in re-
spect to memory errors while running applications.
In addition to superior hardware capabilities, features like bus mas-
tering EIDE driver, Plug and Play, Soft-off, APM (Advanced Power
Management), ACPI (Advanced Configuration and Power Interface),
Keyboard Turn On, External Modem Ring On, LAN wake up,
Watchdog timer wake up, Fan Off in sleeping state and BIOS up-
gradability are provided with this platform.

Mainboard User’s Manual
6Mainboard Specifications and Features
2.2.Mainboard Specifications and Features
2.2.1. Hardware
CPU Celeron/Cyrix Socket 370 processors
VRM Onboard Voltage Regulator Module
Provides 1.3V to 3.5V operating voltage
Coprocessor CPU has built-in floating point unit
Speed System bus clock 66/100/133 MHz
AGP 1x/2x/4x
PCI bus clock 33 MHz
ISA bus clock 8.33~9.35 MHz
Chipset Apollo Pro133A:
VT82C694X system controller
VT82C686A/VT82C686B PCI to ISA bridge
DRAM Three 168-pin DIMM sockets
Supports 8 MB to 1.5 GB memory
Supports FP, EDO, SDRAM, ESDRAM, and VCM
SDRAM memory types
EIDE
Controller Supports four IDE devices in two channels
Supports PIO mode 0 through mode 4 drives
Supports Bus Mastering DMA mode 2 drives
Supports Bus Mastering Ultra DMA-66/100 drives
Supports Iomega ZIP or LS-120 removable drives
Sound Chip
(optional)CT5880 Ensoniq digital controller
Enhanced
I/O One floppy disk controller
One Standard/EPP/ECP parallel port connector
Two 16550 compatible serial port connectors
Two USB (Universal Serial Bus) ports
I/O Options One IrDA compatible infrared (IR) connector
One connector for front panel USB ports 3/4
Mouse and
Keyboard PS/2 mouse connector
PS/2 keyboard connector
Expansion
Slots One AGP-4x (V2.0) slot
Five 32-bit PCI slots
One 8/16-bit ISA slot

Introduction
Mainboard Specifications and Features 7
Power
Management Compliant with EPA, APM 1.2 and ACPI
ATX soft-off power control
Power –on by keyboard and PS/2 mouse
Power –on by external modem ring
Power –on by alarm
Power –on by LAN wake up
Fan off in sleep mode
System
Management CPU temperature warning and system temperature detection
CPU and system voltage detection
CPU and secondary fan RPM detection
Voltage
Regulator Switching regulator
CPU voltage auto-detection
Form Factor ATX form factor 20 cm x 30.5 cm (7.9-inch x 12.0-inch)
2.2.2. Software
BIOS AWARD AGP/PCI BIOS
2M-bit Flash BIOS with ESCD (Extended System
Configuration Data) block
Supports APM, Plug and Play, Multi-Boot, DMI and
EIDE devices
Supports ACPI
Supports high-capacity LS-120 and ZIP removable
media drive
Driver and
Utility IDE Bus mastering Ultra DMA driver
Flash utility for BIOS upgrade
System Environment Monitoring Utility
CT5880-5V Ensoniq driver
Operating
System Operates with MS_DOS, Windows 3.x/95/98/2000/NT, OS/2, Novell Netware/UnixWare 1.1, and SCO Unix 4.2
2.2.3. Environment
Ambient Temperature 0ºC to 50ºC (operating)
Relative Humidity 0 to 85% (operating)
Vibration 0 to 500 Hz
DC Voltage 4.9V to 5.2V
DC Voltage 1.3V to 3.50V
DC Voltage -5V, +12V, -12V, +5VSB 5% tolerance

Mainboard User’s Manual
8Mainboard Layout
2.3.Mainboard Layout
1
3
4
5
6
7
8
10
11
12
13
14
15
16
17
18 9
20
Note: Because of optional items and design changes, your
mainboard may not be identical to the one shown in the illus-
tration.

Introduction
Mainboard Layout 9
Key to Mainboard Components
No. Name Function
1PGA370 CPU socket
2POWER1 ATX power connector
3DIMM1~3 Memory module slots
4FDC Floppy drive connector
5CPU FAN CPU cooling fan connector (FAN1)
6AGP Accelerated Graphics Port (AGP) slot
7IDE1 IDE1 connector (white)
8IDE2 IDE2 connector (black)
9USB2 Front panel USB connector
10 BAT RTC battery
11 JP5 Modem wake up connector
12 JP4 IrDA compliant Infrared (IR) connector
13 CN1 Front panel connectors
14 SYSTEM FAN Secondary case fan connector
15 ISA ISA expansion slot
16 BIOS BIOS controller
17 JP6 LAN wake up connector
18 PCI1~5 32-bit PCI expansion slots
19 CT5880 Ensoniq digital controller (optional)
20 CD1/2 CD-ROM audio signal input connectors

Mainboard User’s Manual
10 Microprocessor
2.4.Microprocessor
The mainboard is designed to operate with the following processors:
ProcessorType Speed FSB
IntelCeleron
IntelCoppermine
IntelCoppermine
466~766+MHz
500~850+MHz
533~933+MHz
66MHz
100MHz
133MHz
VIACyrixIII
VIACyrixIII 500+MHz 533+MHz 100MHz 133MHz
An onboard switching voltage regulator provides the required 1.3 to
3.5 volts for the processor. The processor sends five VID (Voltage
Identification) signals to the switching voltage regulator. The switch-
ing regulator generates the correct voltage for the processor.
2.5.CPU Packaging
PGA370 CPUs are packaged in a FC-PGA or PPGA (Flip Chip or In-
tegrated Circuit-Plastic Pin Grid Array) configuration.
2.6.CT5880 Ensoniq Controller (Optional)
This mainboard offers the option of a built-in CT5880 Ensoniq digi-
tal controller. The CT5880 provides the next generation of audio
performance to the Sound Blaster AudioPCI product line.
•CD Audio over the PCI Bus
•PCI Bus Master for fast DMA
•AC97 interface/Microsoft PC97/98 compliant
•Multimedia PC Level II/III compliant
•Supports multiple sample rate
•Supports Aureal A3D API for 3D Positional Audio
•CD Audio over the PCI Bus

Introduction
Chipset 11
2.7.Chipset
The P6F127 supports the VIA 82C694X Apollo Pro-133A chipset.
The chipset comes in pairs—the North Bridge chip and the South
Bridge chip.
North Bridge •CPU interface controller (66/100/133 MHz FSB)
•AGP interface controller (AGP 1x/2x/4x)
•Integrated DRAM controller
(Synchronous 66/100/133 MHz SDRAM)
•Fully synchronous PCI 2.2 bus interface
•Data buffering:
♦CPU-to-AGP
♦CPU-to-DRAM
♦CPU-to-PCI
♦AGP-to-DRAM
♦AGP-to-PCI
♦PCI-to-AGP
♦PCI-to-DRAM
South Bridge •Interface between the PCI and ISA buses
•Power Management Logic
•USB controller
•EIDE controller (ATA33/66/100)
•Seven DMA channels
•One timer/counter
•Two 8-channel interrupt controllers
•NMI logic and SMI interrupt logic
•PCI/ ISA bus arbitrator
•SMBus interface
•Power management Logic
•Realtime clock (RTC)
•ACPI controller
This concludes Chapter 2. Chapter 3 covers hardware installation.

3. Hardware Installation
This chapter explains how to use your mainboard to build a powerful
computer system. At a minimum, you will need the following com-
ponents in order to build a fully functioning system.
•Computer case with ATX power supply
•PGA370 Processor
•One SDRAM memory module
•One floppy disk drive
•One UDMA-66 IDE hard disk drive
•One CD-ROM drive
•One display monitor
•One PS/2 mouse
•One PS/2 keyboard
•One set of loudspeakers
Of course, you can use the system I/O ports and expansion slots to
add many more features and components to your system than the
items listed above.
3.1.Unpacking
The P6F127 mainboard package contains the following items:
qOne mainboard
qOne IDE 40-pin ribbon cable
qOne floppy 34-pin ribbon cable
qDriver and utility CD
qUser's manual
After removing the mainboard from its anti-static bag, place it on a
grounded or anti-static surface (component side up). Inspect the
mainboard and contact your vendor immediately if it is damaged.

Hardware Installation
Installation 13
3.2.Installation
The P6F127 is designed to fit into a standard ATX form factor chas-
sis. The pattern of the mounting holes and the position of the back
panel connectors meet the ATX system board specification. The
chassis comes with various mounting fasteners, which are made of
metal or plastic. It is highly recommended to use as many metal fas-
teners as possible to mount the mainboard in the chassis for better
grounding.
To install the mainboard you need to install the CPU and DIMM
memory modules, attach the connectors, and set the correct CPU
speed in the CMOS setup.
3.3.Safety Measures
Computer components and electronic circuit boards can be damaged
by discharges of static electricity. Working on computers that are still
connected to a power supply can be extremely dangerous. Follow the
simple guidelines below to avoid damaging your computer:
•Always disconnect the mainboard from the ATX power
supply, and disconnect the computer from the power outlet
whenever you are working inside the computer case.
•If possible, wear a grounded wrist strap when you are in-
stalling the mainboard or working inside the computer case.
Alternatively, discharge any static electricity by touching
the bare metal chassis of the computer case, or the bare
metal body of any other grounded appliance.
•Hold electronic circuit boards by the edges only. Do not
touch the components on the board unless it is necessary to
do so. Do not flex or stress the circuit board.
•Leave each component inside the static-proof packaging
that it ships with until you are ready to use the component
for the installation.

Mainboard User’s Manual
14 Connector/JumperLocation
3.4.Connector/Jumper Location
LAN WAKE UP
PCI1
PCI2
PCI3
PCI4
PCI5
ISA
BAT
IDE2
IDE1
DIMM1
DIMM2 DIMM3
CPU
FAN
SYSTEMFAN
CD2 CD1
JP19
JP3
MODEM WAKE UP
JP4
AGP
J1
USB2
FDC
POWER1
CN1
JP20
