FREEWAY MT500-22T Assembly instructions
INTRODUCTION
Thank you for purchasing Freeway Med-Tech’s Battery Powered Computer. With a 22-inch display and
optional integrated batteries, the Battery Powered Computer offers optimal combinations of performance and
power savings. With fully-integrated point-of-care modules within an elegant, space-saving design, the Battery
Powered Computer is the optimum solution to enhance workow and service.
Please take a few moments to review the contents of this document to ensure that the setup and startup
proceed smoothly. The Battery Powered Computer is ready for use, out of the box, in its default conguration
when powered by the power source provided. The following documentation offers guidance on the hardware
elements and features of the monitor. Please refer to your device provider for information pertaining to the
software operating system or software applications.
The MT500-22T supports VESA standard (100x100mm) mounting brackets and arms. Attach the bracket or
BASIC
OPERATION
GUIDE
MT500 -22T
Battery Powered Computer
Package contents
1 MT500-22T Battery
Powered 22in Touch
Screen AIO Monitor/PC
1-3 MT202 Li-ion batteries
(qty dependant on
order spec)
1 Medical Grade AC-DC
power adapter with
orange curly power cord
1 Basic Operation Guide
the arm to the back of MT500-22T, then use screws (4 x M4x12mm) to fix the VESA bracket or arm.
BASIC FEATURES
The Battery Powered Computer integrates a bright 22in display with a high performance system, USB
ports, and integrated options such as capacitive touch, hot-swappable batteries, and smart card reader for a
comprehensive point-of-healthcare solution.
Powering ON and OFF
If your Battery Powered Computer comes with the battery packs, please open the battery slot caps and
then put in the battery packs one by one. If not, please use the AC-DC adapter with the Battery Powered
Computer for the power supply. To activate the Battery Powered Computer, push and quickly release the
Power Button and the display will come on in a few seconds. To put in Standby mode, push and quickly release
the Power Button. To turn off for extended storage, power off the device safely using any software function
that “shuts down computer” provided in the software operating system.
PRECAUTIONS
• Always exercise care when operating and handling
the Battery Powered Computer.
• Never disassemble any portion of the enclosure, as
this will void any product warranty on the Battery
Powered Computer.
• Do not use any AC/DC adapter other than the
one provided with the device or a replacement
acquired from the manufacturer.
• In the unlikely event that smoke, abnormal noise or
strange odour is present, immediately power down
the Battery Powered Computer and disconnect all
power sources. Please report the problem to your
device provider immediately.
IMPORTANT NOTES
1. The battery packs (optional) shipped with your
device may be low in power - please use the AC-
DC adapter with the Battery Powered Computer
when setting up the device for the rst time to fully
charge the battery packs. You may charge the battery
packs with them attached to the Battery Powered
Computer or with the optional battery charger kit.
2. When the battery packs are charging, the blue-
coloured Battery LED should blink slowly. If plugging
in the AC-DC adapter does not trigger this blinking
activity and the LED stays dark, the battery pack(s)
may have been drained substantially. Try unplugging/
plugging in the AC-DC adapter to the Battery
Powered Computer a few times to activate the
charging process.
3. To conserve power, use (push and quick release)
the Power Button to put the device in “Standby”
mode while not in use. Pushing briey on the same
button will wake up the system within seconds.
4. Avoid using the Power Button (“hold 4+ seconds”
feature) to turn off the device—this form of
hardware shutdown is intended to be a means of
recovery from device lockups, and not as normal
operation.
5. If connecting an external monitor to the Battery
Powered Computer (via HDMI port), you must
power the Battery Powered Computer with the
provided AC-DC power adapter.
freewaymedtech.com
Power/Battery LED Status
• Blue indicates the battery is 25% to 100% charged
• Blinking blue indicates the battery is charging
• Orange indicates that the battery is between 11% to25%
• Blinking Orange indicates that the battery is below 10%
Wireless Networking
Wireless LAN
The Battery Powered Computer is often delivered with an embedded (user-inaccessible) 802.11ax WLAN
adapter equipped with a hidden custom antenna.
• Through the support of typical WLAN adapters, the Battery Powered Computer should be able to detect
all 802.11 access points in the vicinity for you to select the access point of your choice for connection.
• The SSID and WEP/WPA/WPA2 (if enabled) parameters on the Battery Powered Computer and the access
points have to match. The SSID is case-sensitive and it is recommended that you enable WEP/WPA/WPA2
encryption (or advanced alternatives) for secure access.
• When WEP/WPA/WPA2 is enabled, you may need to consult your network administrator or your
networking equipment literature to properly congure associated settings such as Authentication mode, etc.
• Refer to the access point operating manuals for setting up the 802.11 access points.
Bluetooth
The Battery Powered Computer features a built-in Bluetooth adapter that operates on the Microsoft Windows
Bluetooth protocol. The Bluetooth conguration application is invoked from the System Tray or from the
Control Panel. Follow the instructions and options provided within the application to congure and invoke
Bluetooth connectivity with the corresponding peripherals.
CLEANING THE MT500-22T AIO PC
You can clean the MT500-22T as often as required. All health care institutions will have a recommended
minimum frequency for routine cleaning of various items within their facility. This may be weekly, daily or after
each use depending on the risk involved.
The screen
• An antibacterial cleaning solution (70% alcohol) that is non-abrasive can be used to clean the touch screen.
• Cleaning with a micro-ber cloth is recommended.
• Please spread the solution onto the cloth and then clean the touch screen.
• It is recommended to wipe the screen in a top to bottom motion and nish across the bottom to minimise
streaking and to prevent excess moisture running down off the bezel.
The anti-microbial enclosure
• Use a soft/non-abrasive cloth moistened with cleaning solution (70% alcohol) to clean the enclosure.
• To prevent scratching the anti-microbial coating, please wipe gently.
MT500-22T Basic operation guide
Battery status LEDs
Battery packs (optional)
FRONT REAR
100x100 VESA mounting
F
TOUCH
SCREEN
I/O PORTS
The MT500-22T Battery Powered Computer has a comprehensive set of I/O ports. The following ports
are located along the lower rear edge of the unit.
v1 0123freewaymedtech.com
Caution: Disposal of a battery into re or a hot oven, or mechanically crushing or
cutting of a battery, that can result in an explosion. Leaving a battery in an extremely
high temperature surrounding environment that can result in an explosion or the
leakage of ammable liquid or gas.
A C G
JH I JLK
EB D
*The AIO enclosure may look
different to production models.
ADC-in GUSB 3.0
BDC-out (optional) HPower button
CEthernet port (RJ45) IFunction buttons
DCOM Ports JStereo speaker
EHDMI (1.4a) KReading light on/off button
FUSB 2.0 LLED reading light
