FRENETIK Core 8 User manual

Dante™ PoE+ 8 x 30 W /
Mid-Span Distributor
V1.1 - 03/2020
User’s manual
Core 8

User’s manual - Core 8 V1.1 03/2020 2/8

User’s manual - Core 8 V1.1 03/2020 3/8
CORE 8 - USER MANUAL Page
1. Carton Contents 4
2. Introduction 4
3. Example of use 4
4. Technical specifications 5
5. LED indicators 6
6. Operation of dip-switches for Power over Ethernet (PoE) function 6
7. Overview 7

User’s manual - Core 8 V1.1 03/2020 4/8
1. Carton Contents
- 1 Dante™ PoE+ Core 8 distributor
- 1 power cord
- 1 rack mounting kit
- 1 user manual
2. Introduction
The Dante™ PoE+ Core 8 distributor offers two 10/100/1000 Mbit/s connection ports as
well as eight 10/100 Mbit/s PoE+ ports on the rear panel. The power activation for each
output is performed by dip-switches on the front panel. The available power on each port
is 30 W. The PoE budget for all ports is 230W. The Dante™ PoE+ distributor is equipped
with overvoltage, overcurrent, overtemperature and short-circuit protection. Several
distributors can be cascaded to create long distance connections, but no more than 100
meters between each distributor.
3. Example of use
Spik 3 Spik 3
Spik Sub
Spik Sub
Spik 3 Spik 3
Spik 3 Spik 3
Adjust
Spik 5 Spik 5
Spik 5 Spik 5
Core 8
Core 4

User’s manual - Core 8 V1.1 03/2020 5/8
4. Technical Specifications
Ref. PS820DP
Standards
IEEE 802.3/u 10/100/1000BaseT/TX
IEEE 802.3x Flow Control
IEEE 802.3 at/af PoE
midspan PoE
Ports
Number of ports: 10
PoE ports: 8
PoE activation (On/Off): Dip-Switches
Ethernet switch features
MAC Address: 8K
Buffer Memory: 128KB
Store and Forward
Packet filtering/transmission
speeds
1000Mbps port - 1,488,000pps
100Mbps port - 148,800pps
10Mbps port - 14,880pps
Network cables 100/1000BaseTx Cat. 5 UTP/STP
10BaseT Cat. 3, 4, 5 UTP/STP
Standard wiring PoE 4, 5, 7, 8
LED indicators
Ports Link 1 à 8: 10/100 Mbits/s, PoE ON/OFF
Ports Uplink 9 et10: 100/1000 Mbits/s
Pour l’appareil: Power
Power Input: 100-240 VAC, 50~60 Hz
Outputs: 56 VDC 4.46 A (250 W)
PoE power on each port 30 W
Dimensions 40 × 480 × 118 mm (H x W x D)
Weight 1,70Kg
Operating temperature range 0°C to 40°C
Storage temperature range -20°C to 90°C
Humidity 10 to 90% (non-condensing)
Certifications FCC Classe A, CE

User’s manual - Core 8 V1.1 03/2020 6/8
5. LED indicators
On the front panel of the Core 8, there are 10 LEDs that give a status on the operation of
the device:
Power SOLID GREEN Indicates that the unit is in operation
Port Link
(1 à 8)
GREEN ON indicates that the corresponding Ethernet port is
connected.
Port Uplink
(9 and 10)
GREEN ON indicates that the corresponding Ethernet Uplink
port is connected with a 1000 Mbps link.
YELLOW ON indicates that the corresponding Ethernet Uplink
port is connected with a 100 Mbps link.
PoE+
GREEN ON ON indicates that the PoE function of the
corresponding port is enabled.
NOT ON indicates that the PoE function of the
corresponding port is not enabled
6. Operation of dip-switches for Power over Ethernet (PoE) function
Ports 1 à 8 DIP ON
Per port PoE+ 30 Watts injected
Actual budget Total PoE 230 Watts
Note that dip-switches can be manipulated at any time. However, it is advisable to activate
them before connecting the cables to the PoE ports. The device will automatically power
off and on again if the total PoE consumption exceeds the available PoE budget. If this
happens, it is advisable to turn off a PoE port.

User’s manual - Core 8 V1.1 03/2020 7/8
7. Overview
1 2 3 4
5 6 7
1. Uplink port operation indicator diodes
2. Mains power indicator diode
3. LEDs for individual indication of PoE power presence and operation of each output port
4. PoE Activation Dip-Switch for each output port
5. Mains power connector
6. Output Connectors
7. Input and copy connectors
