FE-TEL-48G Android Video Phone Admin Guide

FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina | www.ip-integra.ba |
[e-mail] | Tel. [phone]
Content
1. Product Overview...........................................................................................................................................................................1
1.1. Instruction ...............................................................................................................................................................................1
1.2. Equipment Appearance And Interface Description..................................................................................................................2
1.2.1. Interface Description......................................................................................................................................................4
1.2.2. Keypad Description........................................................................................................................................................5
1.3. Pendant(Optional)...................................................................................................................................................................7
1.4. Indicator..................................................................................................................................................................................7
1.4.1. Indicator of 48G.............................................................................................................................................................7
1.4.2. Indicator of Pendant.......................................................................................................................................................8
2. Installation ....................................................................................................................................................................................10
2.1. Equipment Packaging...........................................................................................................................................................10
2.2. Connecting Video Phone ......................................................................................................................................................11
2.3. Installation Considerations....................................................................................................................................................13
3. Daily Use.......................................................................................................................................................................................14
3.1. Call........................................................................................................................................................................................14
3.1.1. Make A Call..................................................................................................................................................................14

FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina | www.ip-integra.ba |
[e-mail] | Tel. [phone]
3.1.2. Dial Out Directly........................................................................................................................................................15
3.1.3. Dialing Out From Contact List......................................................................................................................................16
3.1.4. Receive A Call..............................................................................................................................................................17
3.1.5. Call Options.................................................................................................................................................................18
3.1.6. Multiple Calls ...............................................................................................................................................................20
4. Basic Setting ................................................................................................................................................................................21
4.1. Main Screen Instruction ........................................................................................................................................................21
4.2. Status And Notifications Instruction.......................................................................................................................................22
4.2.1. Using The Touchscreen ...............................................................................................................................................24
4.2.2. Startup And Shutdown .................................................................................................................................................25
4.2.3. View / Turn Off Notifications.........................................................................................................................................26
4.3. Connecting To Network And Wi-Fi.........................................................................................................................................27
4.3.1. Configuring Static IP ....................................................................................................................................................27
4.3.2. Configuring DHCP .......................................................................................................................................................29
4.3.3. Configuring Wi-Fi.........................................................................................................................................................30
4.4. SIP Account Configuration ....................................................................................................................................................33
4.4.1. Add Account.................................................................................................................................................................34

FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina | www.ip-integra.ba |
[e-mail] | Tel. [phone]
4.4.2. SIPAccount ON/OFF...................................................................................................................................................35
4.4.3. Modify/Remove SIP Account .......................................................................................................................................36
4.5. Sound & notification..............................................................................................................................................................36
4.5.1. Volumes.......................................................................................................................................................................37
4.5.2. Interruptions.................................................................................................................................................................38
4.5.3. Phone ringtone ............................................................................................................................................................39
4.5.4. Default notification ringtone .........................................................................................................................................40
4.5.5. Other Sounds...............................................................................................................................................................40
4.6. Audio Settings.......................................................................................................................................................................41
4.7. Video Settings.......................................................................................................................................................................41
4.8. Call Settings..........................................................................................................................................................................42
4.8.1. Always forwarding & Forwarding Number....................................................................................................................42
4.8.2. Call forwarding busy & Forwarding Number ................................................................................................................42
4.8.3. No Answer Forwarding & Forwarding Number.............................................................................................................43
4.8.4. Time out.......................................................................................................................................................................44
4.8.5. Do Not Disturb.............................................................................................................................................................44
4.8.6. Call Waiting..................................................................................................................................................................45

FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina | www.ip-integra.ba |
[e-mail] | Tel. [phone]
4.8.7. Playtone.......................................................................................................................................................................45
4.8.8. Intercom.......................................................................................................................................................................46
4.8.9. Hotline..........................................................................................................................................................................46
4.9. Dial Plan................................................................................................................................................................................47
4.10. Auto Provision ..................................................................................................................................................................48
4.11. Personalize..........................................................................................................................................................................48
4.11.1. Log Level ...................................................................................................................................................................48
4.11.2. Hook Mode.................................................................................................................................................................48
4.12. Reboot Manager .................................................................................................................................................................49
4.12.1. Reboot time ...............................................................................................................................................................49
4.12.2. Status of time.............................................................................................................................................................49
4.12.3. Status of active ..........................................................................................................................................................49
4.12.4. Reboot settings..........................................................................................................................................................50
4.13. Date & Time ........................................................................................................................................................................50
4.14. Personalization Settings......................................................................................................................................................53
4.14.1. Wallpaper...................................................................................................................................................................53
4.14.2. Widgets......................................................................................................................................................................54

FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina | www.ip-integra.ba |
[e-mail] | Tel. [phone]
4.14.3. Shortcuts....................................................................................................................................................................56
4.14.4. Ringtone ....................................................................................................................................................................59
4.14.5. Backup & Reset.........................................................................................................................................................60
5. Function........................................................................................................................................................................................61
5.1. Call Records .........................................................................................................................................................................61
5.1.1. View Call Records...................................................................................................................................................61
5.1.2. Call From Call Records................................................................................................................................................62
5.2. Contacts................................................................................................................................................................................64
5.2.1. Local Phone Book........................................................................................................................................................65
5.2.2. Broadsoft Phone Book.................................................................................................................................................67
5.2.3. Remote Phone Book....................................................................................................................................................67
5.2.4. LDAP ...........................................................................................................................................................................68
5.2.5. Group...........................................................................................................................................................................69
5.3. RF Number(Optional)............................................................................................................................................................71
5.4. BLF .......................................................................................................................................................................................72
5.5. Intercom................................................................................................................................................................................74
5.6. Call Return............................................................................................................................................................................75

FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina | www.ip-integra.ba |
[e-mail] | Tel. [phone]
5.7. BLFList..................................................................................................................................................................................76
5.8. Pickup & Group Pickup.........................................................................................................................................................76
5.9. ACD ......................................................................................................................................................................................77
5.10. Hot Desking ........................................................................................................................................................................78
5.11. Conference..........................................................................................................................................................................78
5.11.1. Create 3-way conference...........................................................................................................................................79
5.12. Transfer............................................................................................................................................................................80
5.12.1. Blind Transfer.............................................................................................................................................................80
5.12.2. Attended Transfer ......................................................................................................................................................80
5.13. Keypad Input.......................................................................................................................................................................81
5.14. Webpage Browser...............................................................................................................................................................82
5.14.1. Open The Webpage...................................................................................................................................................82
5.14.2. Open The Webpage...................................................................................................................................................83
5.15. Camera...............................................................................................................................................................................84
5.15.1. Photograph Mode ......................................................................................................................................................84
5.16. Gallery.................................................................................................................................................................................87
5.16.1. View Photo & Picture & Video....................................................................................................................................87

FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina | www.ip-integra.ba |
[e-mail] | Tel. [phone]
5.17. Bluetooth.............................................................................................................................................................................88
5.17.1. Turning Bluetooth On /Off..........................................................................................................................................89
5.17.2. Changing Bluetooth Device Name.............................................................................................................................90
5.17.3. Paring FE-TEL-48G With A Bluetooth Device............................................................................................................91
5.17.4. Un-pairing A Bluetooth Device ...................................................................................................................................92
5.18. USB.....................................................................................................................................................................................93
5.19. Calendar .............................................................................................................................................................................94
5.19.1. Add An Account .........................................................................................................................................................94
5.19.2. View Calendar............................................................................................................................................................95
5.19.3. NewActivities.............................................................................................................................................................96
5.19.4. Edit Activities..............................................................................................................................................................96
5.19.5. Delete Activities .........................................................................................................................................................96
5.20. Clock...................................................................................................................................................................................97
5.20.1. Alarm .........................................................................................................................................................................97
5.20.2. Countdown Timer..................................................................................................................................................100
5.20.3. Stopwatch..............................................................................................................................................................101
5.21. Gmail.................................................................................................................................................................................102

FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina | www.ip-integra.ba |
[e-mail] | Tel. [phone]
5.21.1. Add A New Gmail Account .......................................................................................................................................102
5.22. Music.................................................................................................................................................................................103
5.23. Explorer.............................................................................................................................................................................104
5.24. Video Player......................................................................................................................................................................105
5.25. Others...............................................................................................................................................................................106
5.25.1. Apk Install................................................................................................................................................................106
6. Software Upgrade.......................................................................................................................................................................107
6.1. Immediate Update...............................................................................................................................................................107
6.1.1. Select Other Upgrade Package.................................................................................................................................108
6.1.2. Local Update..............................................................................................................................................................109
6.1.3. Remote Update..........................................................................................................................................................110
6.2. Auto Update Period.............................................................................................................................................................111
6.3. Upgrade on the web............................................................................................................................................................112
6.4. Check Update After System Power On ...............................................................................................................................113
7. System Maintenance..................................................................................................................................................................114
7.1. System State Inspection......................................................................................................................................................114
7.2. IP Query..............................................................................................................................................................................115

FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina | www.ip-integra.ba |
[e-mail] | Tel. [phone]
7.3. SIP Account Registration Query..........................................................................................................................................116
7.4. Backup & Reset..................................................................................................................................................................117
7.5. Failure Process...................................................................................................................................................................117
8. Web Interface..............................................................................................................................................................................120
8.1. Web login............................................................................................................................................................................120
8.2. Status->Basic......................................................................................................................................................................121
8.3. Account->Basic...................................................................................................................................................................122
8.4. Account->Advanced............................................................................................................................................................125
8.5. Network ->Basic..................................................................................................................................................................133
8.6. Network->Advance..............................................................................................................................................................133
8.7. Phone->Time ......................................................................................................................................................................134
8.8. Phone->Preference.............................................................................................................................................................135
8.9. Phone ->Call Feature..........................................................................................................................................................136
8.10. Phone->Audio...................................................................................................................................................................143
8.11. Phone->Video ...................................................................................................................................................................145
8.12. Phone->Ext Key................................................................................................................................................................147
8.13. Phone-> Tone....................................................................................................................................................................148

FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina | www.ip-integra.ba |
[e-mail] | Tel. [phone]
8.14. Phone->Replace Rule.......................................................................................................................................................149
8.15. Phone->Dial Now..............................................................................................................................................................150
8.16. Phone->Action URL..........................................................................................................................................................151
8.17. Phone->Multicast..............................................................................................................................................................154
8.18. PhoneBook->Local Book ..................................................................................................................................................155
8.19. PhoneBook->Remote Book...............................................................................................................................................157
8.20. PhoneBook->Call Log.......................................................................................................................................................158
8.21. PhoneBook->LDAP...........................................................................................................................................................159
8.22. PhoneBook->Broadsoft.....................................................................................................................................................160
8.23. Upgrade->Basic................................................................................................................................................................161
8.24. Upgrade->Advanced.........................................................................................................................................................162
8.25. Security->Basic.................................................................................................................................................................165
8.26. Security->Advanced..........................................................................................................................................................166

1
1. Product Overview
1.1. Instruction
FE-TEL-48G is an Android-based multimedia terminal with a 7-inch
touch screen and a 1.3M CMOS sensor camera. It supports
H.264/H.263 codecs with adaptive bandwidth adjustment. The 7-inch
touch screen offers excellent user experiences such as high-quality
videophone, smooth internet surfing, variousAndroid Apps and daily
information.
FE-TEL-48G provides 2 Ethernet ports, 1USB, 1HDMI, and one 3.5mm
headset/audio port.

2
1.2. Equipment Appearance and Interface Description
USB
HDMI
Headset

3

4
1.2.1. Interface Description
Interface
Description
Camera
Adjustable camera shooting angle, rotate down the camera to "off" angle.
USB interface
External USB storage device
Headset
Connect to 3.5mm stereo headphone, headset device
HDMI
Use HDMI cable to output the video to a TV screen
LAN
Network interface can be connected to a hub, switch or other network access device also supports
POE.
PC
Share the network access from LAN port, and for PC and other equipment connection
Power
Connect to 12V adapter, Power supply. Note: If Power over Ethernet is being used, do not plug in
the AC adapter.
Handset
Connect to handset
Lock
Lock the video phone with a Laptop lock

5
1.2.2. Keypad Description
Interface
Description
Power
Turn on/off the LCD, Reboot, Silent mode
Suspend
Turn on/off the LCD, Reboot, Silent mode
Volume
Press + or –for the phone volume adjustment
Standard
Keypad
Input the number or symbol
Function Key
Delete
Delete a character before the cursor
OK
Same function with soft keyboard "Enter" key
Message
Optional
Contact
Enter Into the contacts list, you can view the local
contact
Conferenc
The first party is held in the case, according to a

6
e
conference key, the first party can be combined to
achieve a tripartite meeting
Hold
To hold a call during the call
Transfer
To transfer the current call to the third party
Mute
The other party cannot hear the voice during the call
Home
Return to the main screen, and long press, it will
display recently used applications
Menu
To call up the System or program setup menu
Back
Return to the previous menu
Speaker
Speaker

7
1.3. Pendant (Optional)
48G supports 2 frequency pendants - 433 and 869. Pendant is used to
call out the emergence number when you need help. However, users
can choose whether the pendant is needed, based on your own needs.
1.4. Indicator
1.4.1. Indicator of FE-TEL-48G
Indicator Name
Icon
Status
Description
Power
ON
System is under working
OFF
System is not working
Network
Connection
ON
Network（LAN Port）is connected
OFF
Network（LAN Port）is disconnected
Information
Flashing
Contains Miss Calls or Unread Message
OFF
Normal status

8
1.4.2. Indicator of Pendant
Indicator Status
Description
Notes
Flashing Yellow
The pendant is in low battery power
status.
The pendant powers on again.
User need to replace the battery.
Alternate Flashing
Green and Red
(1) The pendant in factory-test
mode.
(1) If user long press the
pendant button meanwhile
install the battery, it will enter
testing mode. User need to
install the battery again and do
not press the push button during
the installation.
Before the pendant matches with
(1) User need to match the

9
Flashing Red
the phone, press pendant button.
Press the pendant to make a call
over 200 meters after it matched
with the phone.
pendant with the phone.
(2) The maximum distance
between the matched phone
with the pendant is about 200
meters. User need to use it in
this range.
Flashing Green
(1) In the process of the RF
Learning. press the pendant button.
The phone will prompt RF Key
Learned.
(2) Press pendant button to make a
call after it matched with the phone.
Light off
The battery runs out of power.
Idle status.
(1) User need to replace a new
battery.
