Friedrich VPR VRP07K User manual

Installation & Operation Manual
VRP07 IOM 92000010_00
PRECISION
VRP07K/R
Innovative | Intelligent | Inverter
Variable Refrigerant
Packaged Heat Pump
For Commercial and Residen-
tial Applications
One or more of the following
patents may apply:
10408504
10436457
10488083
Additional patents pending

2
Warnings__________________________________________________________________________________ 3
General
Specications ______________________________________________________________________________ 4
Dimensions ________________________________________________________________________________ 5
Electrical Data _____________________________________________________________________________ 6
Air Flow Data ______________________________________________________________________________ 7
Installation
Minimum Clearances ________________________________________________________________________ 8
Installation Orientations______________________________________________________________________ 9
Rough Opening Dimensions__________________________________________________________________ 10
Preliminary Plumbing ______________________________________________________________________ 12
Wall Plenum Installation ____________________________________________________________________ 13
Drain Pan Installation_______________________________________________________________________ 17
Louver Installation _________________________________________________________________________ 19
Unit Installation ___________________________________________________________________________ 21
Ductwork Installation _______________________________________________________________________ 23
Wall Controller Installation __________________________________________________________________ 24
Electrical Connection _______________________________________________________________________ 26
Return Air Door Installation__________________________________________________________________ 27
FreshAire™ and Basepan Heater Operation _____________________________________________________ 28
Reference
Electrical Wiring Diagrams __________________________________________________________________ 30
Final Installation Checklist___________________________________________________________________ 32
Service and Warranty _______________________________________________________________________ 33
Accessories_______________________________________________________________________________ 34
Diagnostic Error Codes _____________________________________________________________________ 36
VRP Limited Warranty ______________________________________________________________________ 37
Table of Contents

3
Congratulations!
The Friedrich VRP has been carefully engineered and manufactured to provide many years of dependable, efcient operation
while maintaining a comfortable temperature and humidity level. Many extra features have been built into the unit to ensure
quiet operation, optimal circulation of cool, dry air, and the most economic operation.
Please carefully read and follow the installation instructions and safety warnings detailed in this manual. All applicable national
and local mechanical and electrical codes should be followed and take precedence over any Friedrich requirements or recom-
mendations regarding installation applications detailed in this manual.
WARNING
Refrigeration system under high pressure. Do not punc-
ture, heat, expose to ame or incinerate. Only certied
refrigeration technicians should service this equipment.
R410A systems operate at higher pressures than R22
equipment. Appropriate safe service and handling prac-
tices must be used. Only use gauge sets designed for use
with R410A. Do not use R22 gauge sets. Failure to do so
can result in property damage, personal injury, or death.
WARNING
Please read this manual thoroughly prior to equipment
installation or operation. It is the installer’s responsibility
to properly apply and install the equipment. Installation
must be in conformance with the NFPA 70-2008 National
Electric Code or current edition, International Mechanic
code 2009 or current edition and any other applicable local
or national codes.
Your safety and the safety of others are very
important.
We have provided many important safety messages in
this manual and on your appliance. Always read and
obey all safety messages.
This is the safety Alert symbol.
This symbol alerts you to potential
hazards that can kill or hurt you
and others.
All safety messages will follow the
safety alert symbol with the word
“WARNING” or “CAUTION”.
These words mean:
Indicates a hazard which, if not avoided, can result in
severe personal injury or death and damage to product or
other property.
Indicates a hazard which, if not avoided, can result in
personal injury and damage to product or other property.
All safety messages will tell you how to reduce the chance
of injury, and tell you what will happen if the instructions
are not followed.
Indications property damage can occur if instructions
are not followed.
WARNING
CAUTION
NOTICE
WARNING
Electrical shock hazard.
Turn OFF electric power before service or installation.
Unit must be properly grounded.
Unit must have correct fuse or circuit breaker pro-
tection. Unit’s supply circuit must have the correct
wire conductor size. All electrical connections and
wiring must be installed by a qualied electrician and
conform to the National Electrical Code and all local
codes which have jurisdiction. Failure to do so can
result in property
damage, personal injury and/or death.

4
General Specications
Nomenclature
V R P 0 7 K 2 5 S S D S A -A00
Series
VRP Heat Pump
Marketing
Revision
Engineering
Revision
S= Standard
L= Basepan Heat
Nominal Capacity (Btu /Hr.)
07 = 3800 - 10000 Operating Range
Plenum and Louver Configuration
D= Standard (VRP07 Only)
Voltage
K = 230/208 V
R = 265 V
Heater Watts
25 = 2.5 kW
34 = 3.4 kW
S= Standard
R= Reheat
Outdoor Air/ Ventilation
S= Standard No FreshAire™
F= Single OA Fan 35 CFM
Model VRP07K / VRP07R
Cooling Performance Data (Cooling Standards: 95°F DB/75°F WB outdoor, 80°F DB/67°F WB indoor)
Voltage 230/208 265
Cooling Btu (Rated) 7000
Cooling Btu (Min. - Max) 3800 - 10000
Outdoor Operating Range (°F ) 55 - 115
Power (W) 636
EER 11.0
IEER* 19.1
Sensible Heat Ratio 0.77
Cooling Amps 3.2
Heat Pump Performance Data
Voltage 230/208 265
Heating Btu ( Rated @ 47° F ) 7000
Heating Btu ( @ 17° F ) 3500
Heating Btu (Min. - Max.) 2800 - 9000
Heat Pump Outdoor Operating Range (°F ) 0 - 70
COP 3.3
Heating Power (W) 621
Heat Pump Amps 3.2
*Integrated Energy E󰀩ciency Ratio (IEER) is calculated based on AHRI Standard 390 - 2021

5
Dimensions
Model VRP07K/R VRP07K/R With Reheat
Dimensions (W x D x H) 22 15/16" x 22 13/16" x 44 15/16"
Shipping Dimensions (W x D x H) 25" x 25" x 48 1/4"
Net Weight (lbs.) 161
Shipping Weight (lbs.) 165
R410A Charge (oz.) 31.0 33.0
23in
211/4in
1in
23/4in
44in
291/2in
43in
5in
21in
311/8in
313/8in
95/8in

6
Electrical Data
MCA = Minimum Circuit Ampacity
MOP / MOCP - Maximum Overcurrent Protection / Breaker Size
Minimum Circuit Amps (MCA) and MOCP values in the above table are calculated in accordance with The NEC.Article 440
Electrical Requirements
Wire Size Use ONLY wire size recommended for
single outlet branch circuit.
Fuse/Circuit
Breaker
Use ONLY type and size fuse or HACR cir-
cuit breaker indicated on unit’s rating guide.
Proper over current protection to the units is
the responsibility of the owner.
Grounding Unit MUST be grounded from branch circuit
to unit, or through separate ground wire
provided on permanently connected units.
Ensure that branch circuit or general pur-
pose outlet is grounded.
Wire Sizing Use recommended wire size given in tables
and install a single branch circuit. All wiring
must comply with local and national codes.
NOTE: Use copper conductors only.
Electrical Rating Table
NOTE: Use copper conductors ONLY. Wire sizes are per NEC.
Recommended Branch Circuit Sizes*
Nameplate Maximum Circuit Breaker Size AWG Wiring Size**
15A 14
20A 12
AWG - American Wire Gauge
* Single circuit from main box.
** Based on 100’ or less of copper, single insulated conductor at 60˚ C
NOTE: All eld wiring must comply with NEC and local codes. It is the installer’s responsibility to ensure that the electrical codes are
met.
VRP Model Voltage
Electric
Heater
Watts
Electric
Heating
Btu
ID Blower
Amps
OD Blower
Amps
Total
Electric
Heating
Amps
MCA MOP / MOCP
VRP07K
230 0 0 0.7 0.5 3.2 8.1 15
208 0 0 0.7 0.5 3.2
230 2500 8530 0.7 0.5 11.5 14.4 15
208 2045 6980 0.7 0.5 10.6
230 3400 11600 0.7 0.5 15.4 19.3 20
208 2780 9490 0.7 0.5 14.1
VRP07R 265
0 0 0.5 0.5 4.8 7.9 15
2500 8530 0.5 0.5 9.9 12.5 15
3400 9490 0.5 0.5 13.3 16.7 20

7
Air Flow Data
Condenser CFM & External Static Pressure
VRP07 is designed to install through an exterior wall with a plenum (VPAWP1-8, VPAWP-14) and a Friedrich external louver .
If the Friedrich designed plenum and louver combinations are not used, the selections and design must be evaluated by Friedrich to ensure the
total pressure drop does not exceed the maximum allowable limits.
Condenser External Static Pressure
Design Max
CFM ESP ("WC) ESP (“WC)
VRP 7000 Btu 550 0.02 0.08
Indoor CFM & External Static Pressure
Air Flow Data
Model Speed
Select
Airow
Setting
Static Pressure (in. WC)
0.00 0.05 0.10 0.15 0.20
VRP07K/R*
1High 380 360 340 310 280
Low 330 305 285 255 230
2High 380 360 340 310 280
Low 350 320 300 270 230
3High 380 360 340 310 280
Low 365 335 310 280 230
4High 380 360 340 310 280
Low 375 345 320 290 265
5High 380 360 340 310 280
Low 380 360 340 310 280
* Rated to 0.1” ESP High and includes factory provided lter
VRP Congurator
All units are shipped with Speed Select 1 High as the default airow. In higher static applications, it is necessary to increase the airow
to a higher Speed Select setting. Using the VRP Congurator tool and associated instructions, the speed settings can be changed on
units with a rmware 3.7.0.0 or later.

8
VRP®Required Minimum Clearances
Grill Clearance Requirements
Where obstructions are present use the
following guidelines for proper spacing from
the VRP exterior louvered grill. Friedrich
recommends that ALL obstructions are a
minimum of 72” from the exhaust.
For minor obstruction(s) such as lamp poles
or small shrubbery, a clearance of 24” from
the outdoor louver must be maintained.
For major obstructions such as a solid
fence, wall, or other heat rejecting devices
like a condensing unit, a minimum distance
of 72” must be kept.
The the example pictured above is for reference only and does not represent all possible installations. Please contact Friedrich
Air Conditioning for information regarding effects of other installation arrangements.
Building Exterior Unit Opening Requirements
VRP units must be installed on an outside wall. Conned spaces and/or covered areas should be avoided. Units must
be installed no closer than 12” apart when two units are side by side. If three or more units are to operate next to one
another, maintain a minimum of 60” between units or pairs of units (Figure B). If more than two units are sharing a oor
with adjacent, outset units, a minimum distance of 64” must be kept between units (Figure C). Also, a vertical clearance of
60” must be maintained (Figure A) between units. Units installed on the bottom oor must be mounted at least 6” off of the
ground. If two units are facing each other, a minimum distance of 108” must be kept between units (Figure D).
6"
60"60"
60"
60"
60"
60"
60"
60"
60"
6"
6"
12"
60"
60"
64"
160 “
32 “
Figure A Figure B Figure C Figure D
108 “
108 “
Figure E
BUILDING
24"
VVV
POLE
SHRUB
FENCE
MAJOROBSTRUCTIONS
OUTDOOR
CONDENSING
UNIT

9
Installation Orientations

)URQW,QVWDOODWLRQ7RS9LHZ
/HIW,QVWDOODWLRQ7RS9LHZ
5LJKW,QVWDOODWLRQ7RS9LHZ


 

 
 
 








 
 

3










 

 
23 1/8"
23 1/8"
23 1/8"
23 1/8"
23 1/8"
23 1/8"
31 1/8"
31 1/8"
30 5/8"
30 5/8"
3"
26 1/8"
29 1/8"
27"
27"
27"

10
Exterior Wall Opening Dimensions
Exterior Wall Rough Opening Dimensions
Unit Width Heigth
VPAWP1-* 24 5/8" 30 7/8"
*8 or 14
NOTE: The distance between the rough opening and
the nished oor/platform must be 3/4”.
3/4”

11
Interior (Closet) Wall Opening Dimensions
Return Air Access Door Wall Cut-Out
27”
55 3/4”
NOTE: To maintain ease of removal and serviceability, if the unit is installed on a platform ensure that the total height of
the unit from the oor does not exceed the height of the interior rough opening.

12
Preliminary Plumbing
Standard (Front Install)
The image to the right shows the installation
closet for the standard (Front Install) conguration
(where the wall plenum is opposite the service
access door).
A drainage system is required, and should provide
a “P-trap” to prevent undesirable waste gas
from entering into the residential area. This is
represented by a vertical standpipe in the image
shown (Detail A), but other solutions are possible
and are at the discretion of the building designer
and contractor.
The near wall has been trimmed away at the door
centerline to permit full view of the installation.
Detail A

13
Wall Plenum Installation
Field Supplied Parts:
Sealant, attachment screws, and ashing
are eld supplied. Silicone sealant is recommended.
VPAWP1-8 adjusts for walls up to 4”- 8” thick.
VPAWP1-14 adjusts for walls up to 8” - 14” thick
All installations are similar.
Flashing
1”-3” Screws to
attach the plenum
assembly to the wall
studs
Sealant
Shim
A
B
Parts included in Plenum kit:
Outside Plenum Half (Part A)
Inside Plenum Half (Part B)

14
Wall Plenum Installation
Note: The wall plenum is not designed to carry any structural load. A load bearing header must be built above
the rough opening.
1) Prepare the rough opening. The rough opening should be lined with metal or wood. The plenum will warp if
sealed against concrete or brick.
2) Dry t the outside plenum half into the rough opening and check the t and level.
3) Remove the outside plenum half, ash the rough opening to ensure proper t and level.
4) Pre-installing the exterior louver (VPAL2) as shown above is optional (See Page 18).
5) Apply sealant to the outside plenum half and insert into the rough opening to ensure a water-tight seal.
Ensure that the oustide plenum half is securely attached to the framed opening.
Step 1 - Outside Wall Plenum Half

15
Wall Plenum Installation
Step 2 - Inside Wall Plenum Half
Caulk all 8
Flange Corners
and Unused
Holes
Detail A
1) Apply sealant to all 4 ange corners and unused holes. See Detail A.
2) Flash the inside of the rough opening to ensure the proper t and level.
3) Insert inside plenum half (Part B) into Outside Plenum Half (Part A). Ensure that Part A does not back out of
the rough opening.
4) Remove the inside plenum half.
5) Apply sealant to the outside plenum half and insert into the rough opening to ensure a water-tight seal.

16
Wall Plenum Installation
B
Detail B
Step 3 - Inside Wall Plenum (cont.)
Note: Do not place any screws, fasteners, or penetrating holes through the top or bottom of the plenum
assembly.
1) Drill pilot holes on the interior of the inside plenum half (Part B) as show in Detail B. Pilot holes should be
located approximately 4” from the top and bottom of the inside plenum half, on both the left and right sides.
2) Install fasteners through each pilot hole. Fastener must pass through both Part A and Part B. If the inside
and outside plenum halves do not overlap at fastening point, be certain to drill extra holes where needed to
secure both Part A and Part B to the rough opening.

17
VPDP2 Drain Kit Installation
Note: VRP07 models require installation of the VPDP2 drain kit. Please reference the VPDP2 installation
manual for more detailed instructions.
1) Cut away gasket from the of the base of the inside wall plenum half the length of the drain kit beginning
from the bottom right corner.
2) Place the VPDP2 where the gasket has been removed as shown above.
3) Ensure that the back lip of the VPDP2 is inserted no deeper than 1.5” into the exterior opening.
4) Secure the VPDP2 to the nished oor or platform.

18
Final Drain Installation
NOTE: Failure to follow the following procedures may result in serious property damage. A eld supplied secondary
condensate pan may be required. Check with local codes. In case of drainage system blockage, the unit base will allow
excess water to ow out of the unit through the plenum and the architectural louver. It is critical to ensure that the
drainage path is not blocked or obstructed in any way during installation.
1) Ensure the drain pan is not inserted beyond 1.5 inches into the sleeve.
2) Attach the drain pan to the closet oor with the appropriate eld supplied hardware.
3) Use the supplied drain plug to plug the unused port on the VPDP2. Proper sealant must be applied to prevent
leaks.
4) Use one of the rst three options above for routing of the drain line.
5) Check the system for leaks.
Option 1
Run condensate line
to left of unit
Option 3
Run condensate line
to right of unit
Option 2
Run condensate line
beneath unit platform
Option 4
Do not run
condensate line
back toward unit

19
Louver Installation
Installation of the louver PRIOR to Wall Plenum Installation
Hold the louver up to the Outside Wall Plenum Part A and line up the louver top with the very top edge of the 3/4” flange. Line up
the Wall Plenum holes with the threaded holes in the louver, install and tighten the 8 screws.
Attach louver with 8
screws provided
Louver
SIDE
Wall Plenum
NOTE: Louvers & Drip Ledge orientation is down Optional Pre-assembled Outside
Element (Grill and Plenum)
Installation of the louver PRIOR to Wall Plenum Installation
1) Hold the louver up to the outside plenum half (Part A) and line up the louver top with the very top edge of the
¾” ange.
2) Line up the wall plenum holes with the threaded holes in the louver and securely tighten fasteners.
Installation of the louver AFTER the installation of wall plenum on
elevated oors
From the interior of the utility closet:
1) Tie a rope or tether to the architectural louver and the divider in
the wall plenum to prevent it from falling if dropped.
3) Turn the louver sideways and push the louver out below the
divider in the wall plenum.
4) Pull the louver back against the wall plenum and align the holes.
5) Insert and tighten all eight provided fasteners. When the louver
is secured, remove the safety tether.

20
Final Wall Plenum and Architectural Louver Installation
NOTE: Ensure that the weather strip is undamaged and provides a continuous
seal around the inner perimeter of the plenum.
Apply silicone grease or other non-petroleum-based lubricants to the weather strip to enhance the sealing
capability of the weather strip and ease installation of the air conditioner chassis.
1) Loosen the two set screws located on the top side of the divider.
2) Slide the top part of the divider toward the outside until the sealing strip makes contact with the exterior
louver.
3) Tighten the set screws to complete the adjustment.
NOTE: Let all ashing cure completely before installing the chassis.
Louver
