Frigicoll BSX Series Instruction manual

INSTALLATION, OPERATION
& MAINTENANCE MANUAL
“BSX” Series Water Heater Tanks

2
Contents
Introduction 3
Technical Features 3
Symbols 3
Accessories 3
Installation Guidelines 4
Specifications 5
Recommendations 6
Expansion Tank Installation 7
Before Commissioning 7
Commissioning 7
BSX Heat Pump Single Coil Tanks Installation 8
Maintenance 8
Checklist For Troubleshooting 9
Domestic Water Standards 10
Installatıon of optıonal electrıcal backup heater 11

3
Introduction
• In order to guarantee a safe and efficient operation of your device, we recommend you to
follow the instructions provided in this guide.
• Your device installation, operation and maintenance should be performed as described in
this guide otherwise device will not be covered by the guarantee.
• Please keep this manual for future reference
• Features mentioned in this document may be updated without prior notice for
improvements on products and service.
Proper installation of a safety valve is mandatory according to the given diagram.
Important notice: The safety valve that will be used on the product varies according to the system
pressure. (Max. 8 bar - Min. 6 bar)
Technical Features
• Water heater tanks are manufactured in accordance with TS EN 12897:2015 and TS
736:2015 standards.
• Tank’s inner surface is enameled in accordance with DIN4753 standards. Protection
against corrosion is provided by a sacrificial magnesium anode bar positioned inside the
tank.
• In order to check water temperature inside the device, there is a thermostat sensor
housing that can be connected through the thermal sensor.
• Water heaters have connection sleeves for electric heaters and thermostat.
Symbols
2 way valve
Pressure relief
valve
One-way valve
Twin pump
Space heating
system
3 way
modulating valve
Pressure gauge
Safety
thermostat
Ball valve
Thermometer
Anti scald 3 way
valve
Drain valve
Solar collector
Expansion
vessel
Dirt seperator
3 way valve
Buffer tank
Air seperator
Filter
Ball valve
Pressure release
valve
By-pass valve
Air vent
Pump
Underfloor
heating system
Accessories
Important notice: please note that below given accessories or fittings are not supplied with the tank
package. Necessary accessories and fittings must be supplied seperately to continue guarantee
coverage.
Safety accessories:
Safety and control equipments should be installed and operated according to parts mentioned below
in order to limit the domestic water temperature maximum 95°C

4
• Thermostatic control device
• Energy cut-off device (safety cut-off functioned thermostat)
• Temperature reducing valve, pressure reducing valve or safety relief valve
All equipments which are necessary to limit the water temperature under 95°C, must compliant with
the local regulations.
Safety Valve : In case of high pressure in the tank, discharges the overpressure.
Expansion Vessel : Absorbs pressure fluctuations that may occur in the system.
One-way Valve : Allows fluid moving inside the system on desired direction and avoids the flow back
to the opposite direction.
Filter : Used to block dirts from the water.
Valve : Used to allow or stop the flow of domestic water into the system
Pump : Enables the circulation of fluid used in the system.
Manometer : Used to measure the pressure of the system.
Thermometer : Used to measure the temperature of the liquid in the system.
Pressure Reducer : In case the water pressure in the system exceeds the allowed pressure of the
device, an appropriate pressure reducer must be installed to decrease the pressure of water.
Installation Guidelines
• Products are delivering on wooden pallets. Please remove the pallet before installation to
avoid any move after installation.
• Installation must be performed by a qualified installer in accordance with local regulations
and laws.
• Installation should be done according to the diagrams given in this manual.
• The device must be placed on a proper, non-inclined, smooth grounding strong enough to
carry the load of the tank plus water content weight. The area of installation should be
chosen according to the maintenance and service requirements.
• The device must be placed in a room or covered area as it is an indoor unit, must be
protected against direct sunrays, wet and windy weather conditions and freezing risk.
• In order to ensure an efficient operation of the device, it is impotant to make connections
according to the installation schemes. Heating device should be chosen according to hot
water supply needs.
• If the installation guidelines are not followed and damages occur during the installation
process, product will be out of any warranty.
• If a proper safety valve is not assembled or incorrectly installed, the product will be out of
any warranty.
• The place of installation should be protected against fire and flood risk. The warranty
does not cover any product failure caused by external effects.

5
Specifications
Description (dimensions in mm)
Letter
BSX190
BSX270
BSX475
Diameter
øD
590
700
750
Height
H
1320
1209
1800
Thermometer connection
L1
1080
940
1520
Flange
L2
280
290
340
Domestic cold water inlet
L4
160
150
250
Coil inlet
L5
240
230
330
Circulation
L6
590
500
750
Coil outlet
L7
940
940
1290
Domestic hot water outlet
L8
1080
1020
1520
Sacrificial anode connection
L9
11/4”
11/4”
11/4”
Stand distance from the center
L12
102
102
154
Minimum free dimension for electrical heater service
L13
1125
1125
1125
Minimum free dimension for sacrificial anode service
L14
350
600
1050
Minimum ceiling height
L15
1920
1810
2850
Insulation type / thickness
t
PU/50
PU/50
PU/50
Tipping measure
R
1466
1418
1970
N1
Thermometer connection
N2
Flange
N3
Electrical heating element connection
N4
Domestic cold water inlet
N5
Coil outlet
N6
Circulation
N7
Coil inlet
N8
Domestic hot water outlet
N9
Sacrificial anode connection

6
Recommendations
Warning: THE MOST IMPORTANT POINT IS INSTALLING THE SAFETY VALVE, DURING INSTALLATION OF
A WATER HEATER TANK.
Domestic water inside the tank expands when it is heated. The expansion rate of water according to
the temperature is given at the chart below. E.g. water expands 2,88% at 80˚C. This extra volume of
water should be removed from the water heater tank as water is incompressible. If the expanded
water is not removed from the tank, this will increase pressure inside the tank which can cause
damages on the weakest point of the tank.
T
d
V
%
e
%
(
o
C)
(kg/lt)
(kg/lt)
E
x
p
a
n
s
i
o
n
0
0.9998
1.0002
0
0.0002
10
0.9996
1.0004
0.02
0.0004
20
0.9982
1.0018
0.16
0.0018
30
0.9956
1.0044
0.42
0.0044
40
0.9922
1.0079
0.77
0.079
50
0.9880
1.021
1.19
0.0121
60
0.9832
1.071
1.67
0.0171
70
0.9777
1.0228
2.26
0.0228
80
0.9718
1.0290
2.88
0.0290
90
0.9635
1.0359
3.57
0.0390
100
0.9583
1.0435
4.33
0.0435
110
0.9519
1.0515
5.13
0.0515
120
0.9431
1.0603
6.01
0.0608

7
Expansion Tank Installation
There must be a closed membrane type proper expansion tank installed in the system together with
wter heater tank. It should be selected as minimum 10% volume of the water heater tank volume. E.g.
together with a 1000 lt water heater tank, a 100 lt expansion tank must be installed in the system.
Expansion tank can be used under 8 bar pressure and initial pressure should be set to %10 lower then
the operation pressure. The most important protection precaution is to install a proper safety valve
and expansion tank in the system. Always install the expansion tank and the safety valve between the
water heater tank domestic cold water inlet and the valve of the main water line.
Before Commissioning
• Tank must be installed by a qualified staff by taking all safety measures and precautions
according to the local and general regulations.
• The domestic water used in the system must conform standards defined in the last page
of this manual. The warranty does not cover cases where the domestic water does not
conform these standards.
• Make sure that all hydraulic and electrical connections are done properly.
• Check all hydraulic connections against leakage.
• Make sure to take precautions against leak, electric shock, damages because of the
movement of tank, etc.
• If an electric heater installed, it must be grounded. While working on electric connections
take all measures and cut the electric current to avoid injuries or risk of death because of
electric shock.
Commissioning
• Make sure that water heater is completely filled with water before start operation of your
water heater and cold water inlet must be connected to main water supply continuously.
• After completely filling the tank with water, in order to release remaining air inside the
tank, open the domestic hot water tap.
• Electric connections of the device must be done by a qualified electrician.

8
• Check the cable cutaway, voltage value and grounding and then set the regulation
thermostat if available.
• Do not turn on the electric heater before completely filling the water heater tank,
otherwise electrical heater will blow and damage as produced just inside the water.
• It is important to install a residual current device to the power supply when you use
electrical products on the tank.
BSX Heat Pump Single Coil Tanks Installation
Important notice: maximum 8 bar safety valve must be installed.
Maintenance
• It is suggested to clean inside the water heater through the cleaning flange in order to
remove dirts that may exist in the water.
• If the product have electrical heater or instruments, please disconnect all electric
connections and turn-off completely before any maintenance or cleaning operation.
• Gaskets on the product will be damaged after removing them. In case they are removed
for any reason, they should be replaced with a new one.
• Cleaning the device by chemicals is not recommended. Hazardous chemicals will damage
the enamel coating and also harmful to human health if not well cleaned.
• Please be sure that the accessories e.g. valves, one-way valve, strainer, safety valves,
expansion tank and thermometer are in always in operation, to avoid any damage on tank
and system.
• Please remove and clean the filter of the strainer periodically.
• The magnesium anode bar should be checked annually. The substitution frequency can be
determined after the first check. The quality and contaminents of water is important for
the life of the anode.
• If the magnesium anode bar diameter is less than 12 mm it should be replaced with a new
one with a minimum diameter of 26 mm.
• The magnesium anode bar is a sacrificial part therefore it is out of warranty.
• Tanks operated without magnesium anode bar or operated with magnesium anode bar
less than 12 mm are out of warranty.
• When the water heater tank is out of operation, please be sure that the water discharged
completely and tank is empty to protect the tank against freezing.

9
• While cleaning the interior of the tank, please be sure about not damaging the enamel
coating inside.
• After cleaning the interior of the tank, please be sure that flange, sensor(s) and
thermostat connections are not leaking.
Checklist For Troubleshooting
Problem: electrical heater (optional) is not working;
Possible reasons:
• Electric connection might be not connected,
• The switch might be off,
• The building’s main fuse might be switched off.
Problem: no domestic hot water at the tap;
Possible reasons:
• The hot-cold water valve might be turned-off.
• Main water supply might be off
• The strainer might be blocked and out of order.
Problem: domestic water at the hot side of the tap is not hot;
Possible reasons:
• Heating system or solar collector loop might be out of order,
• Circulation pump might be switched-off or out of order.
Problem: there is not enough hot water supply from the water heater tank;
Possible reasons:
• The tank/system capacity might not be adequately selected,
• The hot water might return back to the system if a one-way valve is not being used,
• There might be a problem with the controller.
Problem: safety valve on water heater is leaking;
Possible reasons:
• The main water line pressure might be above 6 bar,
• Safety valve gasket might be blocked and remain open because of dirt/limescale.

10
Domestic Water Standards
This manual suits for next models
3
Table of contents
Popular Water Heater manuals by other brands

Kenmore
Kenmore 153.582400 Use & care guide

STIEBEL ELTRON
STIEBEL ELTRON Eltronom SHU 5 S Operating and installation instructions

clage
clage E-Mini Series Operating and installation instructions

Toyotomi
Toyotomi Oil Miser OM-180 installation manual

Bradford White
Bradford White EF Series Service manual

Eccotemp
Eccotemp 40-H Use & care manual

Dimplex
Dimplex ECSd125-580 Installation and user instructions

Dux
Dux 32FCR6N installation manual

Noritz
Noritz N-132M Owner's guide and installation manual

TESY
TESY GCV7/4S 10047 Instructions for use and maintenance

A.O. Smith
A.O. Smith Gphe 50 instruction manual

Toyotomi
Toyotomi Oil Miser OM-148 (Type D) Operation and maintenance instructions
