Frigidaire RC30DG60PS Owner's manual

TABLE OF CONTENTS
Gas Cooktop
Use&Care
318203683 (March 2013) Rev. A
IMPORTANT SAFETY INSTRUCTIONS .......................2-3
Product Record.................................................................. 4
Serial Plate Location.......................................................... 4
Grounding Instructions ...................................................... 4
Liquefied Petroleum (Propane) Gas Conversion............... 4
Setting Surface Controls.................................................5-6
Surface Cooking................................................................ 7
Setting the Downdraft Vent System................................... 8
Setting Surface Burner Controls.....................................8-9
General Care & Cleaning ........................................... 10-12
Cleaning Various Parts of Your Cooktop..................... 10
Porcelain Enamel Cooktop Cleaning Instructions ...... 10
Cleaning the Burner Grates.........................................11
Cleaning the Burner Caps...........................................11
Cleaning the Burner Heads.........................................11
Cleaning the Vent Grate............................................. 12
Cleaning the Vent Seal............................................... 12
Cleaning the Grease Filter.......................................... 12
Before You Call................................................................ 13
Major Appliance Warranty ............................................... 14

22
• Remove all tape and packaging wrap before
using the cooktop. Destroy the carton and
plastic bags after unpacking the cooktop.
Never allow children to play with packaging
material. DO NOT remove the model/serial plate
attached to the cooktop.
• ProperInstallation—Besureyourapplianceis
properlyinstalledandgroundedby aqualified
technician in accordance with the National
Fuel Gas Code ANSI Z223.1 latest edition and
CAN/CGA B149.2, and the National Electrical
Code ANSI/NFPA No. 70—latest edition, and
local code requirements. Install and/or adjust
only per installation instructions provided in the
literature package for this cooktop.
Askyourdealertorecommendaqualifiedtechnician
andanauthorizedrepair service. Know howtoshut
off gas supply at the meter and disconnect the
electricalpowertothecooktopatthecircuitbreaker
or fuse box in case of an emergency.
•User Servicing—DO NOT repair or replace
any part of the appliance unless specifically
recommended in the manuals. All other
servicing should be done only by a qualified
technician to reduce the risk of personal injury
and damage to the cooktop.
• Never modify or alter the construction of a
cooktop by removing panels, wire covers, or
any other part of the product.
• Air curtain or other overhead hoods, which
operate by blowing a downward air flow on
to a range, shall not be used in conjunction
with gas ranges other than when the hood
and range have been designed, tested and
listed by an independent test laboratory
for use in combination with each other.
This type of ventilation system may cause
ignition and combustion problems with the gas
cooking appliance resulting in personal injury or
unintended operation.
Stepping or leaning on this cooktop
can result in serious injuries and may also cause
damage to the cooktop. DO NOT allow children to
climb or play around the cooktop.
• Storage on Appliance—Flammable materials
should not be stored on the cooktop, near
surface burners. This includes paper, plastic
and cloth items, such as cookbooks, plasticware
andtowels,aswellasflammableliquids.DONOT
store explosives, such as aerosol cans, on the
cooktop. Flammable materials may explode and
result in fire or property damage.
DO NOT store items of interest to
children in the cabinets above the cooktop.
• DO NOT leave children alone—Children
should not be left alone or unattended in the
area where an appliance is in use. They should
never be allowed to sit or stand on any part of the
appliance.
• DO NOT TOUCH SURFACE BURNERS,
GRATES,ORAREASNEARTHESEBURNERS.
Surface burners may be hot even though the
flamesarenotvisible.Areasnearsurfaceburners
may become hot enough to cause burns. During
and after use, DO NOT touch or let clothing or
otherflammablematerialstouchtheseareasuntil
theyhavehadsufficienttimetocool.Amongthese
areasare the cooktopand the surfacesfacingthe
cooktop.
• WearProperApparel—Loose-fittingor hanging
garmentsshouldneverbe worn while using the
appliance.DONOTletclothingorotherflammable
materials contact hot surfaces.
If the information in this manual
is not followed exactly, a fire or explosion
may result causing property damage,
personal injury or death.
FOR YOUR SAFETY:
— DO NOT store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• DO NOT try to light any appliance.
• DO NOT touch any electrical switch; DO
NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor’sphone.Followthegassupplier’s
instructions.
• If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
servicer or the gas supplier.
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this appliance. Save these instructions for future reference.
This manual contains important safety symbols and instructions. Please pay attention to these
symbols and follow all instructions given.
This symbol will help alert you to situations that may cause serious bodily harm, death
or property damage.
This symbol will help alert you to situations that may cause bodily injury or property damage.

33
Please carefully read and save these instructions
This Use & Care Manual contains general operating instructions for your appliance and feature
information for several models. Your product may not have all the described features. The graphics
shown are representative. The graphics on your appliance may not look exactly like those shown.
Common sense and caution must be practiced when installing, operating and maintaining any
appliance.
IMPORTANT SAFETY INSTRUCTIONS
NEVER use this appliance as a
space heater to heat or warm the room. Doing
so may result in carbon monoxide poisoning.
• DO NOT Use Water or Flour on Grease
Fires—Smother the fire with a pan lid, or use
baking soda, a dry chemical or foam-type
extinguisher.
• When heating fat or grease, watch it closely.
Fat or grease may catch fire if allowed to become
too hot.
• Use Only Dry Potholders—Moist or damp pot
holders on hot surfaces may result in burns
fromsteam.DONOTletthepotholderstouchthe
flame or burners. DO NOT use a towel or other
bulky cloth instead of a pot holder.
• DO NOT Heat Unopened Food Containers—
Buildup of pressure may cause container to
burst and result in injury.
• Know which knob controls each surface
burner. Always turn the knob to the LITE position
when igniting the burners. Visually check that the
burner has lit. Then adjust the flame so it does not
extend beyond the edge of the utensil.
Use Proper Flame Size—Adjust
flame size so it does not extend beyond the
edgeoftheutensil.Theuseofundersizedutensils
will expose a portion of the burner flame to direct
contactandmayresultinignitionofclothing.Proper
relationship of utensil to flame will also improve
efficiency. DO NOT use stove top grills on your
sealed gas burners. If you use a stove top grill
on a sealed gas burner, it will cause incomplete
combustion and can result in exposure to carbon
monoxidelevelsaboveallowablecurrentstandards.
This can be hazardous to your health.
Useproperpansize—Thisappliance
is equipped with one or more surface burners of
different sizes. Select utensils having flat bottom
large enough to cover the surface burner. The use
of undersized utensils will expose a portion of the
surface burner to direct contact and may result in
ignition of clothing. Proper relationship of utensil to
the surface burner will also improve efficiency.
• Clean the appliance regularly to keep all parts
freeofgreasethatcouldcatchfire.Exhaustfan
ventilationhoodsandgreasefiltersshouldbekept
clean. DO NOT allow grease to accumulate on
filter. Greasy deposits in the fan could catch fire.
• Utensil Handles Should Be Turned Inward
from Edges of Cooktop and Not Extend Over
Adjacent Surface Burners—To reduce the
risk of burns, ignition of flammable materials,
and spillage due to unintentional contact with
the utensil, the handle of the utensil should be
positioned so that it is turned inward, and does
not extend over adjacent surface burners.
•Never Leave Surface Burners Unattended at
High Heat Settings—Boilovers cause smoking
and greasy spillovers that may ignite, or a pan
that has boiled dry may melt.
• Protective Liners—DO NOT use aluminum foil
to line surface burner pans. Protective liners or
aluminum foil may interfere with heat and air
distribution, and combustion. Damage to the
cooktop or personal injury may result.
• Glazed Cooking Utensils—Only certain types
of glass, glass/ceramic, ceramic, earthenware,
or other glazed utensils are suitable for cooktop
service without breaking due to the sudden
changeintemperature.Checkthemanufacturer's
recommendations for cooktop use.
• DO NOT Use Decorative Surface Burner
Covers. If a burner is accidentally turned on, the
decorative cover will become hot and possibly
melt. You will not be able to see that the burner is
on. Burns will occur if the hot covers are touched.
Damage may also be done to the cooktop
or burners because the covers may cause
overheating. Air will be blocked from the burner
and cause combustion problems.
IMPORTANT SAFETY NOTICE
The California Safe Drinking Water and Toxic
EnforcementActrequirestheGovernorofCalifornia
to publish a list of substances known to the state
to cause cancer, birth defects or other reproductive
harm, and requires businesses to warn customers
of potential exposure to such substances.

44
Product Record
In this space below, record the date of purchase, model and
serial number of your product. You will find the model and
serial number printed on the serial plate. This serial plate is
located under the cooktop. See bottom of this page for the
serial plate location.
Model No. _____________________________________
Serial No.______________________________________
Date of purchase _______________________________
Save these instructions and your sales receipt for future
reference.
Serial Plate Location
Please see the illustration for exact location. Remember to
record the serial number for future reference.
Serial plate is
located under
the burner box. Grates for
illustration
purpose only
For personal safety, the cooktop must be properly grounded. For maximum
safety, the power cord must be plugged into an electrical outlet that is
correctly polarized and properly grounded.
DO NOT operate the cooktop using a 2-prong adapter or an extension
cord. If a 2-prong wall receptacle is the only available outlet, it is the
personal responsibility of the consumer to have it replaced with a properly
grounded 3-prong wall receptacle installed by a qualified electrician.
See the INSTALLATION INSTRUCTIONS packaged with this cooktop for
complete installation and grounding instructions.
Grounding Instructions
Avoid fire hazard or electrical shock. DO
NOT use an adapter plug, an extension cord, or remove
grounding prong from electrical power cord. Failure to follow
this warning can cause serious injury, fire or death.
This appliance is equipped with a 3-prong
grounding plug for your protection against shock hazard
and should be plugged directly into a properly grounded
receptacle. DO NOT cut or remove the grounding prong
from this plug.
DO NOT, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
Power supply
cord with 3-prong
grounding plug
Grounding
type wall
receptacle
Conversion to Liquefied Petroleum Gas (or L.P. Gas)
This natural gas appliance is designed to allow for
conversion to Liquefied Petroleum (L.P.) Gas.
Only a qualified service agent should perform the L. P.
conversion. Contact the local gas provider for conversion.
The L. P. Conversion Kit is supplied with this unit and
is located in the literature package. The kit contains
installation instructions which must be read before and
followed carefully when installing the kit.
To avoid serious injury, any additions,
changes or conversions required in order for this appliance
to satisfactorily meet the application needs must be made
by a qualified service agent.
4

55
OFF
MED
HI
LITE
LO
OFF
MED
HI
LITE
LO
OFF
MED
HI
LITE
LO
OFF
MED
HI
LITE
LO
OFF
MED
HI
LITE
LO
OFF
MED
HI
LITE
LO
OFF
MED
HI
LITE
LO
OFF
MED
HI
LITE
LO
Control Locations of the Gas Surface Burners
Your cooktop is equipped with gas surface burners with different BTU ratings. The ability to heat food quicker and in larger
volumes increases as the burner size increases.
The small• SIMMER burner is best used for simmering delicate sauces, etc.
The• REGULAR burners can be used for most surface cooking needs.
The large• QUICK BOIL burner is best used for bringing large quantities of liquid rapidly up to temperature or when
preparing larger quantities of food.
The• BRIDGE burner is best suited when using rectangular or long shaped cookware. The rear and middle burners are
combined and controlled by the same control knob. The front burner may also be added for a total of 3 burners.
The large• POWER burner is best used when preparing larger quantities of food and it quickly bring liquids up to a
rolling boil.
Regardless of size, always select cookware that is suitable for the amount and type of food being prepared. Select a
burner and flame size appropriate to the pan. Never allow flames to extend beyond the outer edge of the pan.
Setting Surface Controls
Figure 1 - 30" Model
Figure 2 - 36" Model
Q
U
I
C
K
B
O
I
L
S
I
M
M
E
R
P
O
W
E
R
S
I
M
M
E
R
R
E
G
U
L
A
R
B
R
I
D
G
E
5
Q
U
I
C
K
B
O
I
L

Setting Surface Controls
Burner Cap
Burner Head
Fig. 1
Fig. 4
Correct Burner Cap
Placement
Fig. 2
Incorrect Burner Cap
Placement
Fig. 3
Burner Cap Lip
Check Burner Cap Placement Before
Operating the Surface Burners
To prevent flare-ups and avoid creation of harmful by-
products, DO NOT use the cooktop without all burner caps
properly installed to ensure proper ignition and gas flame
size.
It is very important to be sure that all surface burner caps
and burner grates are properly installed and in the correct
locations BEFORE operating the cooktop burners.
Remember:
• Always keep surface burner caps in place whenever
using a surface burner.
• When placing the burner caps, be sure that all burner caps
are seated firmly and rest level on top of burner heads.
• For proper flow of gas and ignition of burners DO NOT
allow spills, food, cleaning agents or any other material to
enter the gas orifice port opening.
Round Style Burners
The burner cap lip (See Fig. 1) should fit snug into the
center of burner head and rest level. Refer to Figs. 2 & 3
for correct and incorrect burner cap placement. Once in
place, you may check the fit by gently sliding the burner
cap from side to side (Fig. 4) to be sure it is centered and
firmly seated. When the burner cap lip makes contact inside
the center of the burner head you will be able to hear the
burner cap click. Please note that the burner cap SHOULD
NOT move off the center of the burner head when sliding
from side to side.
Fig. 5
Bridge Burner Head
Bridge
Burner
End
Cap
Bridge
Burner
End
Cap
Bridge
Burner
Center
Cap
Igniter
Hole
Igniter
Hole
Bridge Style Burners
Install Burner Caps, these include one Bridge Burner
Center Cap (rectangular shaped) and the two Bridge Burner
End Caps (The Bridge Burner End Caps will fit either the
front or rear Bridge Burner Head locations). Make sure
that the lips located under the Bridge Burner Caps fall into
the slots located in the Bridge Burner Head (See arrows in
Figure 5) and that all the Bridge Burner Caps lie flat and
evenly on the Bridge Burner Head.
6

Surface Cooking
Use Proper Cookware
Cookware should have flat bottoms that
*Specialty pans such as lobster pots, griddles and pressure cookers
may be used but must conform to the above recommended cookware
requirements.
CORRECT
• Flat bottom and straight
sides.
• Tight fitting lids.
• Weight of handle does not tilt
pan. Pan is well balanced.
• Pan sizes match the amount
of food to be prepared.
• Made of material that
conducts heat well.
• Easy to clean.
INCORRECT
• Curved and warped pan bottoms.
• Pan overhangs unit by more than
1" (2.5 cm).
• Heavy handle tilts pan.
• Flame extends beyond unit.
Figure 2
Figure 1
DO NOT use a wok if it is equipped
withametalringthatextendsbeyond
the burner unit. Because this ring
traps heat, the surface unit and
cooktop surface could be damaged.
Using a Wok (not supplied) Woks with flat bottoms suitable for use
on your cooktop are available in most
cookshop or hardware stores. Round-
bottomed woks (with a support ring that
does not extend beyond the burner unit)
may also be used. The metal ring was
designed to support the wok safely when
it is filled with large amounts of liquids
(soup making) or fat (frying).
Wire trivets: DO NOT use wire trivets.
Cookware bottoms must be in direct
contact with the grates.
make good contact with
the entire surface heating
element. Check for flatness
by rotating a ruler across
the bottom of the cookware
(See Figure 1). Be sure to
follow the recommendations
for using cookware as
shown in Figure 2.
Note: The size and type of cookware used will
influence the setting needed for best cooking
results.
Note: Always use a utensil for its intended
purpose. Follow manufacturer's instructions.
Some utensils were not made to be used in the
oven or on the cooktop.
7
Grates for
illustration
purpose only
Grates for
illustration
purpose only

88
RIGHT
WRONG
Setting Surface Burner Controls
Setting the Downdraft Vent System
DO NOT place plastic
items such as salt and pepper
shakers, spoon holders or plastic
wrappings on top of the range when
it is in use. These items could melt
or ignite. Potholders, towels or wood
spoons could catch fire if placed too
close to a flame.
Manual Lighting
In the event of an electrical power
outage, the surface burners can be lit
manually. To light a surface burner, hold a
lit match to the burner head, then slowly
turn the surface control knob to LITE.
After burner lights, turn knob to desired
setting. Use caution when lighting
surface burners manually.
Your appliance is equipped with an integrated downdraft vent system that may be turned
on at any moment. This system helps remove smoke, odors and vapors from food
prepared on your cooktop.
To activate the downdraft vent system, simply turn the knob to the desired fan power
setting.
When you are finished operating the downdraft vent system, turn back the knob to the Off
position.
IMPORTANT: For best performance, the grease filter must be properly installed and often
cleaned. See the "General Care and Cleaning" section for more information.
Figure 2
Figure 1
Improper
flame size
Proper
flame size
Flame Size* Type of Cooking
High Flame Start most foods; bring water to a boil; pan broiling.
Medium Flame Maintain a slow boil; thicken sauces, gravies; steaming.
Low Flame Keep foods cooking; poach; stewing.
Setting Proper Surface Burner Flame Size
For most cooking, start on the highest control setting and then turn to a
lower one to complete the process. Use the recommendations below as a
guide for determining proper flame size for various types of cooking. The
size and type of utensil used and the amount of food being cooked will
influence the setting needed for cooking.
*These settings are based on using medium-weight metal or aluminum
pans with lids. Settings may vary when using other types of pans.
The color of the flame is the key to proper burner adjustment. A good flame
is clear, blue and hardly visible in a well-lighted room. Each cone of flame
should be steady and sharp. Clean burner if flame is yellow-orange.
Regardless of size, always select cookware that is suitable for the amount
and type of food being prepared. Select a burner and flame size appropriate
to the pan. Never allow flames to extend beyond the outer edge of the pan.
NEVER extend the flame beyond the outer edge of the
utensil. A higher flame wastes heat and energy and increases your risk
of being burned by the flame (Figure 2).
For deep fat frying,use a thermometer and adjust the surface control knob
accordingly. If the fat is too cool, the food will absorb the fat and be greasy.
If the fat is too hot, the food will brown so quickly that the center will be
undercooked. DO NOT attempt to deep fat fry too much food at once as the
food will neither brown nor cook properly.

99
OFF
LITE
HI
HI
LO
LO
Setting the Simmer / Regular / Power / Turbo Boil Burners
Setting the Bridge Burner
Setting Surface Burner Controls
Operating the Regular Burner:
1. Place cooking utensil on surface burner.
2. Push the surface control knob down and turn counterclockwise out of the OFF
position (See Figure 1).
3. Release the knob and rotate to the LITE position.
Note: All four (or five) electronic surface ignitors will spark at the same time. However,
only the burner you are turning on will ignite.
4. Visually check that the burner has a flame.
5. Once the burner is lit, continue to turn counterclockwise to the desired flame size.
The control knobs DO NOT have to be set at a particular setting. Use the knob indicator
settings to adjust the flame as needed. DO NOT cook with the surface
control knob in the LITE position (The electronic ignitor will continue to spark if the knob is
left in the LITE position).
Figure 1
Regular Burner Knobs
Figure 2 - Bridge Burner
Setting the Bridge Burner
The Bridge Burner should be used with rectangular shaped cookware.
Cookware like a cast-iron Griddle is designed specifically for best results
with the Bridge Burner.
The Bridge Burner feature may be used to combine the cooking power of 2
or if needed 3 gas surface Burners located along the left-hand side of the
cooktop. The left rear and left center Burners are controlled by the left rear
surface Control Knob. In addition the left front Burner may be added to the
Bridge Burner with the left front gas Control Knob.
Operating the Bridge Burner
1. Push the left rear surface control knob in and turn counterclockwise
out of the OFF position (See Figure 2).
2. Release the knob and rotate to the LITE position (See Figure 2). Note:
All electronic surface ignitors will spark at the same time. However, only
the selected surface Burner will lite.
3. Visually check that the rear Burner has lit.
4. Continue to rotate the gas control knob counterclockwise past the first
LO.
5. Visually check that both the rear and center Burners are lit.
6. When both Burners are lit, continue to turn the control knob
counterclockwise to adjust to the desired flame size for both Burners
together. Note: The markings between bridge HI and bridge LO
settings on the control knob are used for adjusting the flame size for
both burners.
7. Add the front Burner if needed. Once lit, visually adjust the flame size of
the front Burner to match the flame size of the Bridge Burner.
DO NOT cook with any of the surface control knobs in the
LITE position (The electronic ignitor will continue to spark if the knob is left in
the LITE position).
Note: If only the rear surface Burner is needed, adjust the settings between
the 1st HI and LO.
Note: The front Burner may be added to the Bridge Burner by setting the left
front gas Control Knob.
OFF
MED
HI
LITE
LO

1010
General Care & Cleaning
Cleaning Various Parts of Your Cooktop
Before cleaning any part of the cooktop, be sure all controls are turned OFF and the cooktop is COOL. REMOVE
SPILLOVERS AND HEAVY SOILINGAS SOON AS POSSIBLE. REGULAR CLEANINGS NOW WILL REDUCE THE
DIFFICULTY AND EXTENT OF A MAJOR CLEANING LATER.
Surfaces How to Clean
Control Knobs For general cleaning, use hot soapy water and a cloth. For more difficult soils and built-up
grease, apply a liquid detergent directly onto the soil. Leave on soil for 30 to 60 minutes. Rinse
with a damp cloth and dry. DO NOT use abrasive cleaners on any of these materials; they can
scratch or dull the finish.
Control Panel Wipe the control panel clean after each use. Before cleaning the control panel, turn all controls
to OFF and remove the control knobs. To remove, pull each knob straight off the shaft. Clean
using hot, soapy water and a cloth. Be sure to squeeze excess water from the cloth before
wiping the panel; especially when wiping around the controls. Excess water in or around the
controls may cause damage to the appliance. To replace knobs after cleaning, line up the flat
sides of both the knob and the shaft; then push the knob into place.
Stainless Steel Clean with hot, soapy water and a dishcloth. Rinse with clean water and cloth. DO NOT use
cleaners with high concentrations of chlorides or chlorines.DO NOT use harsh scrubbing
cleaners. Only use kitchen cleaners that are especially made for cleaning stainless steel.Always
be sure to rinse the cleaners off from the surface as bluish stains may occur during heating that
cannot be removed.
Porcelain Enamel
Burner Grates, Cooktop
Surface
Gentle scouring with a soapy scouring pad will remove most spots. Rinse with a 1:1 solution of
clear water and ammonia. If necessary, cover difficult spots with an ammonia-soaked paper towel
for 30 to 40 minutes. Rinse with clean water and a damp cloth, and then scrub with a soap-filled
scouring pad. Rinse and wipe dry with a clean cloth or paper towel. Remove all cleaners or the
porcelain may become damaged during future heating. DO NOT use spray oven cleaners on the
cooktop.
Grease Filter For general cleaning, the grease filter can be cleaned in the dishwasher.
Grate Seal Clean with a mild solution of soap and warm water. Rinse clean and dry before use. The grate
seal may be cleaned in a dishwasher, TOP RACK ONLY.
Porcelain Enamel Cooktop Cleaning Instructions (some models)
The cooktop is designed to make cleaning easier. Because the gas burner are sealed, cleanups are easy when spillovers
are cleaned up immediately. Correct and consistent cleaning is essential to maintaining your porcelain enamel cooktop.
If food spills and grease spatters are not removed, they may burn onto the surface of the cooktop and cause permanent
discoloration.
DO NOT use
a cooktop cleaner on a hot
cooktop. The fumes can be
hazardous to your health, and
can chemically damage the
cooking surface.
Before cleaning
the surface cooktop, be sure the
controls are turned to OFF and
the cooktop is cool.
DO NOT use
commercial oven cleaners on
the cooktop
DO NOT remove any parts from the cooktop until they have
completely cooled and are safe to handle.
Daily Cleaning
For normal soil:
1. Allow cooktop surface to cool.
2. Wipe off spills and spatters using a clean paper towel or a clean cloth with warm,
soapy water.
3. If needed, use mild household cleaners or a soap-filled steel wool pad.
4. Be sure to rinse off all cleaning solutions or the porcelain may become damaged
during future heating.
For heavy, burned-on soil:
1. Allow cooktop surface to cool.
2. Use a soap filled scouring pad with warm water or cover heavily soiled spots with a
solution of clear water and ammonia. Scour gently. Rinse and wipe dry with a clean
cloth.
DO NOT use harsh abrasive cleaners on the cooktop. They can scratch the
stainless steel / porcelain.
10

1111
Cleaning the Burner Grates
The burner grates are dishwasher safe and may be cleaned in the dishwasher. Remove any excessive soils before
placing in the dishwasher.
IMPORTANT
●For proper gas flow and ignition of the burners — DO NOT allow spills, food, cleaning agents or any other material to
enter the gas orifice opening.
●The cooktop is not removable. DO NOT attempt to remove or lift the cooktop.
To avoid possible burns use care when cleaning the cooktop. DO NOT attempt to clean the cooktop
whenever the cooktop or burner heads are still hot.
To avoid possible burns DO NOT attempt any of the following cleaning instructions provided before turning
OFF all of the surface burners and allow them to cool.
To avoid possible burns DO NOT attempt to operate the surface burners without the burner caps
Before using your gas appliance be sure to:
●Follow installation instructions before operating.
●Remove all packing tape from cooktop area.
●Properly install the bridge burner and burner caps (See page 6).
Cleaning the Burner Caps
Should you ever need to remove the burner caps for cleaning, lift the burner cap off the burner head. Clean heavy soils
with an absorbent cloth. Rinse with a clean, damp cloth and immediately thoroughly dry including the bottom and inside of
the cap. DO NOT use harsh abrasive cleaners. They can scratch the porcelain on the cap. DO NOT clean burner caps in
dishwasher.
IMPORTANT - When placing the burner caps on the cooktop, be sure the burner caps are seated firmly on top of burner
heads. Improper flame size and uneven heating may result when any surface burners are turned ON and the burner caps
are not seated correctly.
Cleaning the Burner Heads
Lift the burner cap from the burner head. The surface burner heads are secured to the cooktop and must be cleaned in
place (except for the bridge burner, which is removable. See bridge burner assembly section for proper installation).
For proper gas flow it may be necessary to clean the burner heads and slots. To clean, first use a clean DAMP cloth to
soak up any spills. Remove any food from between the burner slots using a small nonabrasive brush like a toothbrush and
afterwards wipe using a damp cloth. For stubborn soils located in the slots, use a small-gauge wire or needle to clean.
Should you experience ignition problems it may be that an ignition port hole is partially blocked with soil (see Fig. 1). With
the burner head in place, use a small wire gauge needle or the end of a paper clip to clear the ignition port or ports.
General Care & Cleaning
Figure 1- Cooktop regular burner head
Slots Ignition port
Orifice port
11

General Care & Cleaning
Figure 3A - 30" Model
Figure 1A - 30" Model
Figure 1B - 36" Model
Figure 2
Figure 3B - 36" Model
Vent Filter
Vent Chamber
Cleaning the Vent Grate
Remove the vent grate (Fig. 1) from the cooktop by lifting it
off. The vent grate is dishwasher safe and may be cleaned
in the dishwasher. Remove any excessive soils before
placing in the dishwasher. Use mild detergent.
Cleaning the Grease Filter
Remove the grease filter (Fig. 3) from the vent chamber
by lifting it off. The grease filter can be cleaned using hot
soapy water. Rinse with clean water and dry thoroughly. The
grease filter is dishwasher safe. When cleaned, replace the
filter diagonally in the vent chamber as shown on Figure 4.
DO NOT operate the downdraft vent system
without the filter in place.
Cleaning the Vent Seal
Remove the vent seal from the cooktop by unscrewing it
(figure 2) and by lifting it off. The vent seal can be cleaned
using warm soapy water and may be cleaned in the
dishwasher, TOP RACK ONLY. Remove any excessive soils
before placing in the dishwasher. Use mild detergent.
Cleaning the vent
chamber
Use a cloth with hot
soapy (mild detergent)
water to clean the
chamber. Rinse with
clean water and dry
thoroughly.
Be sure to turn off the downdraft vent system
before cleaning any of its parts.
To avoid possible burns use care when
cleaning the downdraft system, DO NOT attempt to clean
the cooktop whenever the grates are still hot.
12
Vent Grate
Grease Filter
Grease Filter
Vent Grate
Vent Grate
Seal
Vent
Chamber
Vent
Chamber
Vent Grate
Seal
Figure 4

Before you call for service, review this list. It may save you time and expense. The list includes common occurrences
that are not the result of defective workmanship or materials in this appliance.
Before You Call
Solutions to Common Problems
OCCURRENCE POSSIBLE CAUSE/SOLUTION
Surface burners DO NOT light. Surface Control knob has not been completely turned to LITE. Push in and turn
the Surface Control knob to LITE until burner ignites and then turn control to
desired flame size.
Be sure gas supply valve is open.
Gas-air mixture needs a straight line to travel. Be sure burner is properly seated
in its support (models with open burners only).
Burner ports or slots are clogged. With the burner off, use a small-gauge wire
or needle to clean ports or slots.
Power cord is disconnected from outlet (electric ignition models). Be sure cord
is plugged securely into outlet.
Electrical power outage (electric ignition models). Burners can be lit manually.
See Setting Surface Controls in this Use & Care Guide.
Surface burner flame burns half way
around. Burner ports or slots are clogged. With the burner off, clean ports with a small- gauge wire or needle to clean ports or slots.
Moisture is present after cleaning. Lightly fan the flame and allow burner to
operate until flame is full. To avoid this occurrence dry the burners thoroughly
following instructions under General Care & Cleaning.
Surface burner flame is orange. Dust particles in main line.Allow the burner to operate a few minutes until flame
turns blue.
In coastal areas, a slightly orange flame is unavoidable due to salt air.
Surface burner flame is too high or
too low. Surface burner valves are not adjusted properly. Refer to your LP conversion instructions for guidance on how to adjust the valves.
Blower motor not running No power to the appliance. Check steps under “Entire Cooktop Does Not
Operate” in this Before You Call checklist
Reduced performance of the
ventilation system Check that grease filter has been properly cleaned and installed.
Check that no foreign objects are present in the ventilation chamber.
Checkthatthepropercontrolsetting is selected to match the cooking conditions
on the cooktop.
Rattling noise during ventilation
operation Verify that the mounting nuts on the blower housing have been properly tightened.
Verify that the external ductwork has been mounted and secured properly.
Verify that there are no foreign objects in the external ductwork.
Reduced performance of the
ventilation system. Verify that the vent grate seal and vent grate have been properly installed on the cooktop.
Surface burner flame extinguishes
when ventilation system is ON. Verify that the vent grate seal and vent grate have been properly installed on the cooktop.
13

1414
Notes

1515
Notes

1616
MAJOR APPLIANCE WARRANTY
This warranty does not cover the following:
1Products with original serial numbers that have been removed, altered or cannot be readily determined.
2Product that has been transferred from its original owner to another party or removed outside the USA or
Canada.
3Rust on the interior or exterior of the unit.
4Products purchased "as-is" are not covered by this warranty.
5Food loss due to any refrigerator or freezer failures.
6Products used in a commercial setting.
7Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances not
in ordinary household use or used other than in accordance with the provided instructions.
8Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc.,
which are not a part of the appliance when it is shipped from the factory.
10 Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumable, or knobs,
handles, or other cosmetic parts.
11 Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip
charges, or mileage expense for service calls to remote areas, including the state of Alaska.
12 Damages to the finish of appliance or home incurred during installation, including but not limited to floors,
cabinets, walls, etc.
13 Damages caused by: services performed by unauthorized service companies; use of parts other than genuine
Electrolux parts or parts obtained from persons other than authorized service companies; or external causes
such as abuse, misuse, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIES WARRANTIES; LIMITATION OF REMEDIES
Customer’s sole and exclusive remedy under this limited warranty shall be product repair or replacement
as provided herein. Claims based on implied warranties, including warranties of merchantability or fitness
for particular purpose, are limited to one year or the shortest period allowed by law, but not less than one
year. Electrolux shall not be liable for consequential or incidental damages such as property damage and
incidental expenses resulting from any breach of this written limited warranty or any implied warranty. Some
states and provinces do not allow the exclusion or limitation of incidental or consequential damages, or
limitations on the duration of implied warranties, so these limitations or exclusions may not imply to you.
This written warranty gives you specific legal rights. You may also have other rights that vary from state to
state.
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period should
service be required. If service is performed, it is in your best interest to obtain and keep all receipts. Service under
this warranty must be obtained contacting Electrolux at the addresses or phone numbers below.
Exclusions
If You
Need
Service
USA
1.800.944.9044
Electrolux Major Appliances
North America
P.O. Box 212378
Augusta, GA 30907
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
Your appliance is covered by a one year limited warranty. For one year from your original date of
purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove
to be defective in materials or workmanship when such appliance is installed, used and maintained in
accordance with the provided instructions.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances
North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada
Corp. Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service
and parts under this warranty must be performed by Electrolux or an authorized service company. Product features or
specifications as described or illustrated are subject to change without notice.
16
