Frigidaire FDB510CF User manual

P30L0055.eps P30C0140.eps P30B0032.eps P30U0018.eps P30M0033.eps P30F0022.eps
P30R0089.eps
Product No. FDB510CFB0 FDB510CFS0
Series 24" Built-in 24" Built-in
Color black white
Owner's Guide English 154575201 154575201
Owner's Guide Spanish 154575203 154575203
Owner's Guide French 154575202 154575202
Service Data Sheet 154465801 154465801
Energy Guide 154540013 154540013
Installation Instructions 154427301 154427301
Market Canada Canada
Electrolux Major Appliances
North & Latin America
5855 TERRY FOX WAY
MISSISSAUGA, ONTARIO, CANADA L5V
3E4 Publication No.
5995464921
06/04/11
(EN/SERVICE/ECL)
821
24-INCH BUILT-IN
DISHWASHER
Model No.
FDB510CF
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995464921 FDB510CF
04/06 2
CONTROL PANEL

FDB510CF Publication No: 5995464921
# Functional Parts 3 04/06
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFDB510CF (FDB510CFS0)
BFDB510CF (FDB510CFB0)
POS. NO PART NO. DESCRIPTION
1 154454201 A - Panel, control, white
1 154454203 - B Panel, control, black
2 154465301 A - Insert, control panel, white
2 154465303 - B Insert, control panel, black
3 # 154465901 A B Timer
3* 154095701 A B Screw, thread rolling, (2), timer
3* 154131203 A B Shield, timer
8 # 154466001 A B Switch, selector, 4 button
8* 154248601 A B Shield, switch
8* 5303318719 A B Screw, mtg.
13 154426901 A - Knob, timer, white
13 154426903 - B Knob, timer, black
20 154433001 A B Vent assy, static dry
20* 154436201 A B Screw, dry duct, (3)
* 154546201 A B Wiring Harness
* 154540013 A B Energy guide label

Publication No: 5995464921 FDB510CF
04/06 4
DOOR

FDB510CF Publication No: 5995464921
# Functional Parts 5 04/06
* Non-Illustrated Parts
DOOR
Model Index: AFDB510CF (FDB510CFS0)
BFDB510CF (FDB510CFB0)
POS. NO PART NO. DESCRIPTION
1 154430501 A B Spring, door, (2)
1A 154325201 A B Linkage, door spring, (2)
2 154093301 A B Screw, arm assy, (4)
3 154558102 A B Arm Assy, LH
3A 154558502 A B Arm Assy, RH
* 154529101 A B Pin, arm assy
5 154079601 A B Nut, arm assy, and handle mtg.
7 154299004 A B Door, inner assy
9 154230103 A B Dispenser, det/rinse aid, includes #22
9* 154294701 A B Screw, #7 plas .375, (6), disp. assy.
10 154103702 A B Screw, latch mtg, (2)
12 # 154537301 A - Latch assy, white
12 # 154537303 - B Latch assy, black
20 154359105 A - Door, white
20 154359107 - B Door, black
20* 5304428306 A B Screw, door mtg., (2)
22 154388801 A B Cap, Rinse aid
49 154297603 A B Gasket, door, bottom
50 154211401 A B Support, door hinge
51 154320301 A B Clamp, drip loop, wire
* # 154227806 A B Thermostat, temp boost, hi temp rinse

Publication No: 5995464921 FDB510CF
04/06 6
TUB

FDB510CF Publication No: 5995464921
# Functional Parts 7 04/06
* Non-Illustrated Parts
TUB
Model Index: AFDB510CF (FDB510CFS0)
BFDB510CF (FDB510CFB0)
POS. NO PART NO. DESCRIPTION
1 # 154209301 A B Tub assy, w/frame parts
2 154429101 A B Strike, door
3 # 154561001 A B Gasket, tub
4 154200602 A B Screw, 10-16 x 3/8, hex
5 154333902 A B Roller, tub
6 5303943103 A B Screw, w/washer, (8)
22 154446001 A B Tubing, water inlet
23 5303318539 A B Clamp, tubing, (2)
24 # 154525301 A B Hose, drain
25 # 154209701 A B Float
28 154408701 A B Switch Assy, float
29 # 154290204 A B Thermostat, re-settable
30 154241101 A B Retainer, thermostat
30* 154297701 A B Screw, retainer-thermo
* 154457002 A B Insulation, blanket
* 154041001 A B Screw, plask #1, 10-10 x 9/16
* 154200601 A B Screw, #10-16 x 3/8
* 5300807270 A B Screw, (2), countertop mtg.

Publication No: 5995464921 FDB510CF
04/06 8
MOTOR & PUMP

FDB510CF Publication No: 5995464921
# Functional Parts 9 04/06
* Non-Illustrated Parts
MOTOR & PUMP
Model Index: AFDB510CF (FDB510CFS0)
BFDB510CF (FDB510CFB0)
POS. NO PART NO. DESCRIPTION
1 # 154247601 A B Heater
1* 154106201 A B Nut, heater, (2)
1* 154289801 A B Shield, heater terminal
2 154479601 A B Bracket, heater, (2)
10 154245501 A B Cover, volute
13 154246801 A B Gasket, sump
14 154365902 A B Housing, sump
16 154246502 A B Retainer, sump
24 154414101 A B Spray arm, lower, w/heat shield
24A 154313601 A B Spray arm, center
24A* 154252001 A B Nut, spray arm, center
32 154406601 A B Tube, delivery
32A 154406401 A B Gasket, delivery tube
40 154348401 A B Clamp, red, pump
40 154348502 A B Clamp, red, pump
40* 154106801 A B Clamp, hose, worm/drain
40* 154380601 A B Clamp, hose, worm/gear
54 154234401 A B Hose, connector
55 154362301 A B Bracket, motor
55* 5303316032 A B Screw, truss ss, 8 .625
58 154246402 A B Check ball
59 154246901 A B O-ring, rear
59A 154247001 A B O-ring, front
60 154474101 A B Drain Pump Assy
60* 154426201 A B Bracket, motor, drain
60* 5303318719 A B Screw, mtg.
61 154406701 A B Nozzle, 2nd level, spray arm
62 154294101 A B Support, spray arm, lower
63 154252201 A B Base, soil director
64 154252301 A B Filter, soil director, white
65 154252401 A B Filter, polypro
66 154252701 A B Trap, glass
70 # 154574701 A B Motor & Pump Assy
* 154200601 A B Screw, #10-16 x 3/8

Publication No: 5995464921 FDB510CF
04/06 10
FRAME

FDB510CF Publication No: 5995464921
# Functional Parts 11 04/06
* Non-Illustrated Parts
FRAME
Model Index: AFDB510CF (FDB510CFS0)
BFDB510CF (FDB510CFB0)
POS. NO PART NO. DESCRIPTION
3 # 154476101 A B Valve, water
4 154208701 A B Brace, front frame
8 154322901 A - Toeplate, adjustable, white
8 154322903 - B Toeplate, adjustable, black
9 154397201 A - Kickplate Assy, white, w/foam
9 154397203 - B Kickplate Assy, black, w/foam
10 154371301 A - Screw, phillips head, white
10 5300808658 - B Screw, #8A x .375", black
11 154200701 A B Screw, #10-32 x 3/8
11A 154200601 A B Screw, #10-16 x 3/8
15 154419301 A B Screw, leveling
20 154209601 A B Cover, junction box
* 154041001 A B Screw, plask #1, 10-10 x 9/16
* 154200602 A B Screw, 10-16 x 3/8, hex
* 154409401 A B Screw, #8-18 x .375

Publication No: 5995464921 FDB510CF
04/06 12
RACKS

FDB510CF Publication No: 5995464921
# Functional Parts 13 04/06
* Non-Illustrated Parts
RACKS
Model Index: AFDB510CF (FDB510CFS0)
BFDB510CF (FDB510CFB0)
POS. NO PART NO. DESCRIPTION
1 154336009 A B Rack assy, lower, w/rollers
2 5300808994 A B Basket, silverware
3 154331502 A B Rack assy, upper
4 154522901 A B Wheel & bushing assy, upper rack, (8)
5 5300809927 A B Cap, slide, (4)
6 154232701 A B Slide, rack, (2)
7 154174502 A B Wheel & bracket assy, lower rack
8 154304001 A B Base, funnel
9 154251801 A B Funnel
