Frigidaire FDBB2840E User manual

P30L0069.eps P30C0144.eps P30B0039.eps P30U0021.eps P30M0036.eps P30F0022.eps
P30R0087.eps
Product No. FDBB2840EC0
Series Built-in 24"
Color stainless
Owner's Guide English 154493801
Owner's Guide Spanish 154493901
Owner's Guide French 154494001
Service Data Sheet 154493101
Energy Guide 154540024
Installation Instructions 154427301
Market North America
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995435194
05/04/22
(EN/SERVICE/ECL)
821
24-INCH BUILT-IN
DISHWASHER
Model No.
FDBB2840E
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995435194 FDBB2840EC0
04/05 2
CONTROL PANEL

FDBB2840EC0 Publication No: 5995435194
# Functional Parts 3 04/05
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
1 # 154486103 Panel, control, black
2 154483503 Insert, control panel, stainless, w/switch memb.
3 154555005 Board, control
3* 154200401 Screw, 6-10 x 3/8, pan plask
4 154460601 Cover, control
4* 154478901 Gasket, cover
8 154474801 Board, segment display
8* 5303318719 Screw, mtg.
8A 154486201 Shield, tactile switch
20 154423601 Vent assy, active dry, w/actuator
20* 154436201 Screw, dry duct, (3)
27 154433501 Actuator, active dry vent
28 154474401 Adapter, vent
* # 154468901 Harness, wiring
* 154540024 Energy guide label

Publication No: 5995435194 FDBB2840EC0
04/05 4
DOOR

FDBB2840EC0 Publication No: 5995435194
# Functional Parts 5 04/05
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 154430601 Spring, door, (2)
1A 154325201 Linkage, door spring, (2)
2 154093301 Screw, armassy, (4)
3 154325302 Arm Assy, LH
3A 154325301 Arm Assy, RH
* 154529101 Pin, arm assy
5 154079601 Nut, arm assy, and handle mtg.
7 154494601 Liner, door assy.
9 154452704 Dispenser, det/rinse aid, w/reed
9* 154294701 Screw, #7 plas .375, (6), disp. assy.
10 154103702 Screw, latch mtg, (2)
12 154529403 Latch assy, black
20 154533202 Door, stainless
20* 154253201 Insulation, door
20* 5304428306 Screw, door mtg., (2)
41 154470405 Towel bar assy, stainless
49 154297603 Gasket, door, bottom
50 154211401 Support, door hinge
51 154320301 Clamp, drip loop, wire
53 154425001 Nut, Keps, (2), handle mtg.
* 154200601 Screw, #10-16 x 3/8

Publication No: 5995435194 FDBB2840EC0
04/05 6
TUB

FDBB2840EC0 Publication No: 5995435194
# Functional Parts 7 04/05
* Non-Illustrated Parts
TUB
POS. NO PART NO. DESCRIPTION
1 # 154534701 Tub assy, w/frame parts
2 154429101 Strike, door
3 # 154211801 Gasket, tub
4 154200602 Screw, 10-16 x 3/8, hex
5 154333902 Roller, tub
6 5303943103 Screw, w/washer, (8)
22 154446002 Tubing, water inlet
23 5303318539 Clamp, tubing, (2)
24 # 154525301 Hose, drain
25 # 154209701 Float
28 154408701 Switch Assy, float
29 # 154290204 Thermostat, re-settable
30 154241101 Retainer, thermostat
30* 154297701 Screw, retainer-thermo
* 154447102 Insulation, blanket
* 154447301 Insulation, tub back
* 154041001 Screw, plask #1, 10-10 x 9/16
* 5300807270 Screw, (2), countertop mtg.

Publication No: 5995435194 FDBB2840EC0
04/05 8
MOTOR & PUMP

FDBB2840EC0 Publication No: 5995435194
# Functional Parts 9 04/05
* Non-Illustrated Parts
MOTOR & PUMP
POS. NO PART NO. DESCRIPTION
1 # 154482901 Heater, round
1* 154106201 Nut, heater, (2)
1* 154289801 Shield, heater terminal
2 154465101 Bracket, heater, (2)
10 154245501 Cover, volute
13 154246801 Gasket, sump
14 154461902 Housing, sump
16 154246502 Retainer, sump
24 154467702 Spray arm, grey, lower
24A 154468502 Spray arm, grey, center
24B 154478201 Spray arm, 3rd level
32 154464101 Tube, delivery
32* 154491101 Screw, delivery tube
32A 154406401 Gasket, delivery tube
40 154348401 Clamp, red, pump
40 154348502 Clamp, red, pump
40* 154106801 Clamp, hose, (2)
40* 154380601 Clamp, hose, (1)
54 154234401 Hose, connector
55 154362301 Bracket, motor, askoll
55* 5303316032 Screw, truss ss, 8 .625
58 154246402 Check ball
59 154246901 O-ring, rear
59A 154247001 O-ring, front
60 154491301 Pump, drain
61 154463402 Grommet, delivery tube
62 154294102 Support, spray arm, grey, lower
63 154252201 Base, soil director
64 154252302 Filter, soil director, grey
65 154283005 Filter Assy, grey
66 154252702 Trap, glass, grey
70 # 154536101 Motor assembly, circulation, w/o o'rings
71 # 154473901 Sensor, turbidity
71* 154376001 O-ring, turbidity
* 154200601 Screw, #10-16 x 3/8

Publication No: 5995435194 FDBB2840EC0
04/05 10
FRAME

FDBB2840EC0 Publication No: 5995435194
# Functional Parts 11 04/05
* Non-Illustrated Parts
FRAME
POS. NO PART NO. DESCRIPTION
3 # 154476101 Valve, water
4 154208701 Brace, front frame
8 154322903 Toeplate, adjustable, black
9 154397203 Kickplate Assy, black, w/foam
10 5300808658 Screw, #8A x .375", black
11 154200701 Screw, #10-32 x 3/8
11A 154200601 Screw, #10-16 x 3/8
15 154419301 Screw, leveling
20 154209601 Cover, junction box
* 154412301 Baffle, sound
* 154290101 Guard, sound baffle, wire
* 154041001 Screw, plask #1, 10-10 x 9/16
* 154200602 Screw, 10-16 x 3/8, hex
* 154409401 Screw, #8-18 x .375

Publication No: 5995435194 FDBB2840EC0
04/05 12
RACKS

FDBB2840EC0 Publication No: 5995435194
# Functional Parts 13 04/05
* Non-Illustrated Parts
RACKS
POS. NO PART NO. DESCRIPTION
1 154432604 Rack assy, lower, grey
2 154424002 Basket, silverware, grey, main
2A 154424102 Basket, silverware, grey, (2), side
3 154494404 Rack assy, upper, grey
4 154494502 Wheel assy., upper rack, (4)
5 5304440996 Cap, slide, (4)
6 154232701 Slide, rack, (2)
7 154174503 Wheel & bracket assy, grey, lower rack, (8)
10 154488802 Tray, utility, grey, w/knife holder
10A 154452502 Holder, knife, grey
11 154436104 Shelf, cup, half width, grey
13 154425503 Fence, fold down, grey, lower rack, (2), full length
13A 154480403 Fence, multi, 4 wire, LH, upper rack
13B 154480503 Fence, multi, 4 wire, RH, upper rack
14 154428402 Bracket, fold down fence, grey, lower rack, (6)
14A 154242002 Bracket, multi fence, white, upper rack, (4)
14A* 154242102 Bushing, multi fence, upper rack, (4)
16 154424203 Cover, main basket, grey, silverware
16A 154424303 Cover, side basket, grey, (2), silverware
20 154530702 Handle, pull, grey, front, upper rack
21 154530902 Handle, pull, grey, rear, upper rack
30 154481402 Bracket, adjustment, LH, upper rack, assembly
30* 154481702 Bracket, adjustment, RH, upper rack, assembly
