Frigidaire FPHD2481KF - Professional 24" -Built Installation instructions

frigidaire.com
24" Built-In
Signature Features
Product Dimensions
Height (Adjustable) 33-1/2"– 35"
Width 24"
Depth (Including Door) 25"
More Easy-To-Use Features
PowerPlus™ Cycle
For an extra-heavy wash performance.
Largest Silverware Basket3
There's room for over 180 items
in our largest, multicompartment
silverware basket.
Energy Saver Plus Cycle
Eco-friendly cycle uses less energy
without compromising cleaning
performance.
DishSense™ Technology
Sensors select the cycle for you
based on your cleaning needs.
Quick Clean
Clean dishes faster with Quick Clean.
Pro-Select™ Controls
Easily select options with the touch
of a button.
Professional / Solid Dish Racks
Adjustable Upper Dish Rack
Flexible racking system lets you adjust
the top rack to fit taller items.
Stay-Put Door
The door stays put at whatever
angle you open it.
Most Adaptable Delay Start
1- to 24-hour options.
Low-Rinse Aid Indicator
ENERGY STAR®
NSF® International
Certification
Available in:
1
Based on industry standard dryability testing
using PowerPlus™ Dry.
2 Based on published manufacturer specifications
for plastic interior dishwashers.
3 Among leading brands.
Stainless
(F)
Quietest Dishwasher
in Its Class2
A quiet performance every time.
Best Drying Performance1
Our PowerPlus™ dry cycle offers the
best drying performance.1
Real Stainless Steel
Real stainless steel with a protective
coating that reduces fingerprints and
smudges so it’s easy to clean.
SpaceWise™
Organization System
Our SpaceWise™ Organization system
features adjustable racks and the
Largest Silverware Basket3so there’s
a place for virtually anything.
Dishwasher
FPHD2481K F

Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FPHD2481K 08/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Dishwasher
FPHD2481K F 24" Built-In
Product Dimensions
A - Height (Adjustable)
B - Width
C - Depth (Including Door)
D - Depth (To Tub Flange)
Depth with Door Open 90˚
33-1/2"– 35"
24"
25"
22-1/2"
49-1/4"
Cutout Dimensions
Height (Min.)
Height (Max.)
Width (Min.)
Depth (Min.)
34-1/4"
35-1/4"
24"
24"
NOTE: For planning purposes only. Always consult local and national electric and plumbing codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
24" Built-In Dishwashers with Integrated Controls
Frigidaire Professional
B
A
D
C
Meets requirements
of ASSE 1006
1 For use on adequately wired 120V, dedicated circuit having 2-wire service
with a separate ground wire. Appliance must be grounded for safe operation.
Features
Control Design
Digital Display
Door Latch / Stay-Put Door Hinge Design
Low Rinse-Aid Indicator Light
Interior Design / Interior Color
Wash System
Wash Levels / Wash Speeds
DishSense™ Technology
Sound Package
Filter / Filter Trap
Soft Food Disposer
dB Level
Drying System
Cycles
Number of Cycles
Heavy
Normal
Light
Quick
Favorite
China Crystal
Rinse Only
Energy Saver Plus
Upper Rack Wash Only
Cycle Indicator Light / Control Lock
Options
Heat / No Heat Dry
Hi-Temp Wash
NSF® Certified Sanitize Rinse
Delay Start
Rack System
Rack Design
Rack Coating
Upper Rack –
Rack Handles
Stemware / Champagne Glass Holders
Fold-Down Tines
Cup Shelves
Utensil Tray
Adjustable Rack Height
Lower Rack –
SpaceWise™ Silverware Basket
Fold-Down Tines
Small Items Cover
Certifications
ENERGY STAR®
NSF® International Certification
Specifications
Water Inlet Location
Water Usage (Gallons)
Water Pressure (PSI)
Integral Air Gap on Supply
Leveling Legs
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating) @ 120 Volts 1
Amps @ 120 Volts
Shipping Weight (Approx.)
Fully-Integrated
Pro-Select™
Yes
Yes / Yes
Yes
Tall Tub / GraniteGrey™
Direct
5 / 5
Yes
SilentDesign™
S. Steel / Removable
Yes
52
PowerPlus™ Dry
7
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No / Yes
Yes
Yes
Yes
1–24 Hour
Maximum
Nylon TufRacks™
Yes
Yes
Yes
2
Yes
Yes
3-Piece Split
2 Full Rows
3
Yes
Yes
Left Bottom Front
4.9 – 8.5
20 – 120
Yes
4
Right Bottom Front
120V / 60 Hz / 15A
1.44
10
83
