Frigidaire Gallery FGHD2455LF User manual

frigidaire.com
Signature Features
24" Built-In
Product Dimensions
Height (Adjustable) 34"–35"
Width 23-3/4"
Depth (Including Door) 25-3/8"
More Easy-To-Use Features
Real Stainless Steel3
Real stainless steel with a protective
coating that reduces fingerprints and
smudges so it’s easy to clean.
DishSense™ Technology
Sensors select the cycle for you
based on your cleaning needs.
Energy Saver Plus Cycle
Eco-friendly cycle uses less energy
without compromising cleaning
performance.
Express-Select™ Controls
Easily select options with the touch
of a button.
Multiple Cycle Options
Features easy-to-use cleaning cycle
options including Rinse Only and
Heavy Wash.
Adjustable Upper Dish Rack
Flexible racking system lets you adjust
the top rack to fit taller items.
Most Adaptable Delay Start
1- to 24-hour options.
Stay-Put Door
The door stays put at whatever
angle you open it.
Low-Rinse Aid Indicator
ENERGY STAR®
NSF® International
Certification
Available in:
1
Based on published manufacturer specifications.
2 Among leading brands.
3 Select model only.
Stainless
(F)
White
(W)
Black
(B)
Quietest Dishwasher
in Its Class1
A quiet performance every time.
SpaceWise™
Organization System
Our SpaceWise™ Organization system
features adjustable racks and the
Largest Silverware Basket2so there’s
a place for virtually anything.
Stainless Steel Interior
Premium stainless steel interior
for maximum durability.
Largest Silverware Basket2
There’s room for over 180 items in our
multicompartment silverware basket.
Dishwashers
FGHD2455L F/W/B

Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
1 For use on adequately wired 120V, dedicated circuit having 2-wire service
with a separate ground wire. Appliance must be grounded for safe operation.
Features
Control Design
Digital Display
Door Latch/Stay-Put Door Hinge Design
Low Rinse-Aid Indicator Light
Interior Design/Interior Color
Wash System
Wash Levels/Wash Speeds
DishSense™ Technology
Sound Package
Filter/Filter Trap
Soft Food Disposer
dB Level
Drying System
Cycles
Number of Cycles
Heavy
Normal
Light
Quick
Favorite
China Crystal
Rinse Only
Energy Saver Plus
Upper Rack Wash Only
Cycle Indicator Light/Control Lock
Options
Heat/No Heat Dry
Hi-Temp Wash
NSF® Certified Sanitize Rinse
Delay Start
Rack System
Rack Design
Rack Coating
Upper Rack –
Rack Handles
Stemware/Champagne Glass Holders
Fold-Down Tines
Cup Shelves
Utensil Tray
Adjustable Rack Height
Lower Rack –
SpaceWise™ Silverware Basket
Fold-Down Tines
Small Items Cover
Certifications
ENERGY STAR®
NSF® International Certification
Specifications
Water Inlet Location
Water Usage (Gallons)
Water Pressure (PSI)
Integral Air Gap on Supply
Leveling Legs
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating)@120 Volts1
Amps @ 120 Volts
Shipping Weight (Approx.)
Slimline Express-Select™
Yes
Yes/Yes
Yes
Tall Tub/Stainless Steel
Direct
5/1
Yes
SilentDesign™
S. Steel/Removable
Yes
51
Eortless™ Dry
5
Yes
Yes
Yes
Yes
Yes
No/Yes
Yes
Yes
Yes
1–24 Hour
Premium
Nylon TufRacks™
Yes
Yes
Yes
2
Yes
3-Piece Split
2 Full Rows
3
Yes
Yes
Left Bottom Front
4.9 – 8.5
20 – 120
Yes
4
Right Bottom Front
120V/60Hz/15A
1.44
10
90
Product Dimensions
A-Height (Adjustable)
B-Width
C-Depth (Including Door)
D-Depth (To Tub Flange)
Depth with Door Open 90˚
34"–35"
23-3/4"
25-3/8"
23"
50-3/8"
Cutout Dimensions
Height (Min.)
Height (Max.)
Width (Min.)
Depth (Min.)
34-1/4"
35-1/4"
24"
24"
NOTE: For planning purposes only. Always consult local and national electric and plumbing codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
B
A
D
C
24" Built-In Dishwashers
Frigidaire Baseline
Meets requirements
of ASSE 1006
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGHD2455L 09/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Dishwashers
FGHD2455L F/W/B 24" Built-In
