Frigidaire Affinity FAQE7001LW Installation instructions

Signature Features
frigidaire.com
Optional SpaceWise® Pedestal Drawer Shown
Product Dimensions
Height 36"
Width 27"
Depth 30-5/16"
More Easy To Use Features
SilentDesign™
for quiet operation.
Moisture Sensor
Optional SpaceWise®
Pedestal Drawer
Reversible Door
Available in:
1Based on I.E.C. std. 60456 4th Edition for dryers
37" or less in height and 27" or less in width.
Ultra-Capacity Dryer
The largest in its class1, so you can
finish more laundry, even faster.
DrySense™ Technology
Dries your clothes more precisely,
reducing wrinkles.
Express-Select® Controls
Easily select options with the touch of
a button.
Wrinkle Release Technology
Front Load Dryers
FAQE7001L B / W
6 Dry Cycles
7.0 Cu. Ft. Electric
Classic
Black
(B)
Classic
White
(W)

Front Load Laundry - Dryers (E & G)
Frigidaire Affinity (L models)
BC
A
C
B
A
Specifications
subject to change.
NOTE: For planning purposes only. Always consult local and national
electric and plumbing codes. Refer to Product Installation Guide for
detailed installation instructions on the web at frigidaire.com.
Product Dimensions
A - Height (Single)
Height (Stacked)
B - Width
C - Depth
Depth with Door Open 90˚
Pedestal Dimensions
A - Height
B - Width
C - Depth
36"
71-1/2"
27"
30-5/16"
51-7/16"
15-1/4"
27"
26-1/4"
Features
Total Capacity (Cu. Ft.)
Controls
Dryer Drum Interior
Interior Light
Door Trim
Ready Steam™
DrySense™ Technology
Wrinkle Release Technology
TimeWise™ Technology
Moisture Sensor
Time Remaining Indicator
Cycle Status Lights
Cycle Signal
Cycle Signal “On/O ”
Cycle Signal Volume Control
Control Lock
Start / Pause / Cancel Buttons
Energy Saver Option
Delay Start
Tumble Speed (RPM)
Reversible Door
Lint Screen
Sound Package
Adjustable Leveling Legs
Cycles
Dry Cycles
Specialty Cycles
Options
Temperature Selections
Dryness Level Selections
Timed Dry
Optional Accessories
Dryer Stacking Kit
15" Frigidaire Anity® Pedestal Drawers
Classic Red (R)
Classic Blue (N)
Classic Silver (A)
Classic Black (B)
Classic White (W)
Mobile Home Installation Kit
Drying Rack
Certifications
NSF® Certified Sanitize
Specifications
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating) @ 240 Volts
Amps @ 240 Volts
Heating Element @ 240 Volts (Watts)
Shipping Weight (Approx.)
Accessories information available
on the web at frigidaire.com
7.0
Express-Select®
Painted Steel
Yes
Color-Coordinated
Yes
Yes
Yes
Yes
Yes
Yes
Chime
Yes
Yes
Yes
Yes
50
Yes
Yes
SilentDesign™
Yes
6
0
5
4
15, 30, 60, 90
PN # STACKIT4X
(B) PN # CFPWD15B
(W) PN # CFPWD15W
PN # 137067200
PN # 137067300
Right Bottom Rear
240V / 60Hz / 30A
5.0
24
4,500
140 Lbs.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FAQE7001L 12/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Front Load Dryers
FAQE7001L B / W 7.0 Cu. Ft. Electric
