Frigidaire GLEQ942C User manual

P16L0037.e
p
s P16V0075.e
p
s P16d0028.e
p
s P16C0165.e
p
s P16M0024.e
p
s
134200300e.eps
Product No. GLEQ942CS0
Series Frig Gallery
Market North America
Color white
Volts 230
Wiring Diagram 134200300
Owner's Guide 134306300
Installation Instructions 134306200
Operating Instructions 134306100
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995399754
03/12/05
(EN/SERVICE/KC)
361
ELECTRIC DRYER
Model No.
GLEQ942C
Copyright 2003 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995399754 GLEQ942CS0
12/03 2
CABINET/DRUM

GLEQ942CS0 Publication No: 5995399754
# Functional Parts 3 12/03
* Non-Ilustrated Parts
CABINET/DRUM
POS. NO PART NO. DESCRIPTION
2 131168200 Screw, pan head, 8-18B x 0.31
4 131785200 Bracket, elec power cord, knock out
5 5303281019 Ball
6 5303281020 Clip, ball, steel, flat nut
7 134121200 Rack, drying
9 131793201 Panel, access, rear
11 5303211428 Cover, terminal block
12 131825900 Bearing, drum support
13 131724300 Bracket, bearing support
14 131205400 Screw, bracket mtg., 10-16B x 1.375, cr/sq drive
15 # 131553900 Heater Assy, w/housing/felt
17 3204254 Baffle, heater shield
18 131477000 Screw, 10-16AB x 0.375
19 131205300 Screw, 10-16 x 0.750
20 134166500 Bracket, top panel mtg., rear
21 134122532 Drum, dryer, galvanized stl., service kit
24 131963900 Glide, drum
25 5303015671 Screw, hex washer head, 8-18 x 0 .375, cup point
29 131382300 Screw, quadrex head, 10-14 x 1.00, vane mtg., special
30 5303201200 Vane, straight
32 131777700 Shaft, drum support, ballhitch
32* 5303307893 Lubricant, high temp
33 # 3204267 Thermostat, safety
34 131243700 Screw, pan head, 8-18AB x 0.375, cr/sq drive
35 131892100 Screw, 6-20B x 0.230
36 # 134120900 Thermal Limiter
42 134154100 Screw, hex washer head, 10-32 x 0.375, ground
44 134158000 Leveling Leg, screw
51 131472100 Insulator, heater housing
52 # 134101400 Terminal Block, main
* # 134198900 Wiring Harness, main
52A# 3202786 Terminal Block, heater housing
64 131704600 Clip
* # 5303281153 Rear Bearing Kit, includes 5, 6, 12, 13, 14, 18, 32

Publication No: 5995399754 GLEQ942CS0
12/03 4
FRONT PANEL/LINT FILTER
27
9
8
41
46
P16D0028
2
42
48
42
26
6
1
21
50
50
45
45
22
44
47
25
49
20
42
28 16
58

GLEQ942CS0 Publication No: 5995399754
# Functional Parts 5 12/03
* Non-Ilustrated Parts
FRONT PANEL/LINT FILTER
POS. NO PART NO. DESCRIPTION
1 134063300 Seal, air duct
2 131397000 Plug, dome, white
6 131621900 Duct, air
8 # 131845801 Cover, lint housing, w/moist sensor
8* # 131657500 •Wiring Harness, moisture sensor
9 131633200 Plug, white
16 131063700 Clip, wiring
20 134036400 Seal, felt, upper
20* 5308027429 Adhesive, high temp
21 134134700 Seal, felt, lower
22 131845902 Panel, front, white, with lamp hole
22* 131474700 Insulation
25 131658800 Door Catch
26 # 131843101 Switch, door, with drum light
27 131450300 Trap, lint blade assy
28 5303281074 Clip, guide, (3)
41 131627500 Hinge, door
42 131209600 Screw, flat head, 8-18AB x 0.44, cr/sq drive
44 131129900 Gasket, door seal
45 134207300 Screw, pan head, 8-18AB x 0.250
46 134213800 Handle, door, white
47 131844104 Panel, inner door, white
48 131789303 Panel, outer door, white
49 5303211430 Door Strike
50 131303300 Screw, pan head, 10-16AB x 0.500, locking
58 # 131843500 Lamp Assy, drum light, w/mtg bracket
58*# 131862800 •Lamp

Publication No: 5995399754 GLEQ942CS0
12/03 6
CONTROLS/TOP PANEL
10:00
P16C0165
23
17
19
29
61
39 1
53

GLEQ942CS0 Publication No: 5995399754
# Functional Parts 7 12/03
* Non-Ilustrated Parts
CONTROLS/TOP PANEL
POS. NO PART NO. DESCRIPTION
1 # 134208151 Control Board, printed circuit, with display
17 134195700 Bracket, control mtg.
19 134205400 Screw, pan head, 6-19 x 0.500, type p
23 # 134199000 Wiring Harness, controls
23*# 134198900 Wiring Harness, main
29 # 134208350 Frame, control console, with membrane
39 134178900 Screw, Quad, 8-18AB x 0.455
53 134164202 Panel, dryer top, white, top
61 134167300 Drip Rail, dryer console

Publication No: 5995399754 GLEQ942CS0
12/03 8
MOTOR

GLEQ942CS0 Publication No: 5995399754
# Functional Parts 9 12/03
* Non-Ilustrated Parts
MOTOR
POS. NO PART NO. DESCRIPTION
4 131435200 Lock, blower housing
7 131451600 Tube, exhaust, rear, w/mtg bracket
7* 131456800 Tube, exhaust, side/bottom, Optional Kit
10 # 131775600 Housing, blower assy, cover & wheel
11 131749800 Spacer, idler
15 # 134216500 Thermistor, control
20 131017900 Screw, hex head, 1/4-20T x 1.25, spacer mtg., thread cutting
22 131601000 Spring, idler arm
23 # 131863000 Idler Arm
25 # 134163400 Belt, dryer
27 134242400 Clamp, motor mtg.
28 # 131560100 Motor, main drive, w/pulley
34 131243700 Screw, pan head, 8-18AB x 0.375, cr/sq drive
46 134203400 Bracket, motor mtg
47 131633300 Seal, exhaust tube
48 131168200 Screw, pan head, 8-18B x 0.31
52 131303100 Screw, hex washer head, 10-16AB x 0.625

Publication No: 5995399754 GLEQ942CS0
12/03 10
WIRING DIAGRAM
