Frigidaire GLGQ442CE User manual

Product No. GLGQ442CES0
Series Frigidaire
Market Canada
Color white
Volts 120
Wiring Diagram 134492300
Owner's Guide 134447700
Installation Instructions 134296400
Operating Instructions 134492800
P16L0007.eps P16V0059.eps P16d0028.eps P16C0153.eps P16M0024.eps P16b0015.eps
134492300-1.eps 134492300-2.eps
ELECTROLUX HOME PRODUCTS, INC.
6150 McLaughlin Road
Mississauga, Ontario, Canada L5R 1K6
Publication No.
5995430187
05/02/28
(EN/SERVICE/BJH)
361
GAS DRYER
Model No.
GLGQ442CE
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995430187 GLGQ442CES0
02/05 2
CABINET/DRUM

GLGQ442CES0 Publication No: 5995430187
# Functional Parts 3 02/05
* Non-Illustrated Parts
CABINET/DRUM
POS. NO PART NO. DESCRIPTION
2 131168200 Screw, pan head, 8-18B x 0.31
5 5303281019 Ball, grounding
6 5303281020 Clip, ball, steel, flat nut
7 134121200 Rack, drying
9 131793200 Panel, service access, rear
11 131363200 Cover, terminal block
* # 134101400 Terminal Block, main
12 131825900 Bearing, drum support
13 131724300 Bracket, bearing support
14 131205400 Screw, bracket mtg., 10-16B x 1.375, cr/sq drive
15 # 131600500 Housing, gas heater assy, w/seal
18 131477000 Screw, 10-16AB x 0.375
20 131469100 Bracket, hinge, rear, top panel mtg.
21 134122532 Drum, dryer, galvanized stl., service kit
24 131963900 Glide, drum
25 5303015671 Screw, hex washer head, 8-18 x 0 .375, cup point
29 131382300 Screw, quadrex head, 10-14 x 1.00, vane mtg., special
30 5303201200 Vane, straight
31 # 134102200 Power Cord, electric svce
32 131777700 Shaft, drum support, ballhitch
32* 5303307893 Lubricant, high temp
33 # 5308015399 Thermostat, safety
34 131243700 Screw, pan head, 8-18AB x 0.375, cr/sq drive
37 131952100 Duct, heat
42 134154100 Screw, hex washer head, 10-32 x 0.375, ground
44 134158000 Leveling Leg, screw
64 131704600 Clip, front, cabinet bottom
* 5303937141 Stacking Kit, washer/dryer
* # 5303281153 Rear Bearing Kit, includes 5, 6, 12, 13, 14, 18, 32

Publication No: 5995430187 GLGQ442CES0
02/05 4
FRONT PANEL/LINT FILTER
27
9
8
41
46
P16D0028
2
42
48
42
26
6
1
21
50
50
45
45
22
44
47
25
49
20
42
28 16
58

GLGQ442CES0 Publication No: 5995430187
# Functional Parts 5 02/05
* Non-Illustrated Parts
FRONT PANEL/LINT FILTER
POS. NO PART NO. DESCRIPTION
1 134417000 Seal, air duct
2 131397000 Plug, dome, white
6 131621900 Duct, air
8 # 131845801 Cover, lint housing, w/moist sensor
8* # 131657500 •Wiring Harness, moisture sensor
9 131633200 Plug, white
16 131063700 Clip, wiring
20 134440200 Seal, felt, upper
20* 5308027429 •Adhesive, high temp
21 134134700 Seal, felt, lower
22 131845902 Panel, front, white, with lamp hole
22* 131474700 Insulation
25 131658800 Door Catch
26 # 131843101 Switch, door, with drum light
27 131450300 Trap, lint blade assy
28 134440000 Clip, guide
41 134222900 Hinge, dryer door
42 134156200 Screw, flat head, 8-18AB x 0.44, quad drive
44 131129900 Gasket, door seal
45 134207300 Screw, pan head, 8-18AB x 0.250
46 131644700 Handle, door, white
47 131844104 Panel, inner door, white
48 131789303 Panel, outer door, white
49 5303211430 Door Strike
50 131303300 Screw, pan head, 10-16AB x 0.500, locking
58 # 131843500 Lamp Assy, drum light, w/mtg bracket
58*# 131862800 •Lamp

Publication No: 5995430187 GLGQ442CES0
02/05 6
CONTROLS/TOP PANEL

GLGQ442CES0 Publication No: 5995430187
# Functional Parts 7 02/05
* Non-Illustrated Parts
CONTROLS/TOP PANEL
POS. NO PART NO. DESCRIPTION
1 # 131717300 Timer, dryer
4 134042800 Knob, rotary, white
7 3205821 Clip, top-to-front
10 134398300 Switch, start, turn type
11 131587400 Bracket, pc board mtg., (2)
12 # 134216300 Control Board, moisture sensor
15 # 134398600 Switch, temperature, 4 posn rotary
16 134034300 Screw, pan hd phillips, 8-18B x 0.250
17 134064501 Bracket, control mtg.
21 134042600 Knob, timer, white/gray
23 134491800 Wiring Harness, controls
* # 134006600 Wiring Harness, main
* # 134101400 Terminal Block, main
25 5303015671 Screw, hex washer head, 8-18 x 0 .375, cup point
29 131666976 Console, frame, w/trim & tape
35 # 131243200 Switch, 2 position
38 # 5303210285 Buzzer
53 134086812 Panel, dryer top, white, stackable
* 134296400 Instructions, installation

Publication No: 5995430187 GLGQ442CES0
02/05 8
MOTOR

GLGQ442CES0 Publication No: 5995430187
# Functional Parts 9 02/05
* Non-Illustrated Parts
MOTOR
POS. NO PART NO. DESCRIPTION
4 131435200 Lock, blower housing
7 131451600 Tube, exhaust, rear, w/mtg bracket
7* 131456800 Tube, exhaust, side/bottom, Optional Kit
10 # 131775600 Blower Assy, housing, w/cover & wheel
11 131749800 Spacer, idler
15 # 134048900 Thermostat, control
20 131017900 Screw, hex head, 1/4-20T x 1.25, spacer mtg., thread cutting
22 131601000 Spring, idler arm
23 # 131863004 Idler Arm Assy, w/pulley
25 # 134163400 Belt, dryer
27 134242400 Clamp, motor mtg.
28 # 131560100 Motor & Pulley Assy
34 131243700 Screw, pan head, 8-18AB x 0.375, cr/sq drive
46 134203400 Bracket, motor mtg
47 131633300 Seal, exhaust tube
48 131168200 Screw, pan head, 8-18B x 0.31
52 131202300 Screw, 10-16AB x 0.625

Publication No: 5995430187 GLGQ442CES0
02/05 10
BURNER
