CHEST FREEZER
Model number:
FFC07C4CW0
FFC09C4CW0
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216787900, SERVICE DATA - # 216787900
OWNER’S GUIDE - # 216802800
ENERGY GUIDE - (07) # 216793913, (09) # 216794008
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC07C4CW0 FFC07C4CW 134A white 115
FFC09C4CW0 FFC09C4CW 134A white 115
MARKET
North America
Publication No.
5995390332
030509
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917
05/03 2
Publication No FFC07C4CW / FFC09C4CW
5995390332
DOOR
# = Fast-moving Parts 3 05/03
* = Non-Illustrated Parts
FFC07C4CW / FFC09C4CW Publication No.
5995390332
DOOR
A = FFC07C4CW (FFC07C4CW0)
B = FFC09C4CW (FFC09C4CW0)
POS. NO PART NO DESCRIPTION
1 # 216480901 A - Gasket,door seal ,white
1 216481001 - B Gasket-door,white
2 5303925107 A B Lock Assy
5 # 216702900 A B Key,lock
9 216829700 A - Panel-lid
9 216829800 - B Panel-lid
10 216141101 A B Plug button,white
11 216113130 A - Lid,white
11 216117935 - B Lid,white
12A 216816801 A B Insert-nameplate
14 # 216822900 A B Switch,light/lamp ,ramp
15 216846400 A B Light Bulb/Lamp
16 # 216817600 A B Socket,light/lamp ,25 W
18 216446600 A B Handle
27 5303212828 A B Clip,panel mtg
34 5303296969 A B Shield,lid lamp
40 5309948647 A B Fastener,handle
46 216707800 A B Screw,PH ,8-32 x 1/2 ,wiring harness
47 # 216915300 A B Harness-lid
* 5303917276 A B Insulation-door,fiberglass ,(bulk)
05/03 4
Publication No FFC07C4CW / FFC09C4CW
5995390332
CABINET
# = Fast-moving Parts 5 05/03
* = Non-Illustrated Parts
FFC07C4CW / FFC09C4CW Publication No.
5995390332
A = FFC07C4CW (FFC07C4CW0)
B = FFC09C4CW (FFC09C4CW0)
POS. NO PART NO DESCRIPTION
1 216117700 A B Catch-lock
3 216502600 A B Plug,drain ,interior
6 216112800 A - Breaker-hinge,white
6 216117500 - B Breaker-hinge side,white
7 216112900 A - Breaker-lock side
7 216117600 - B Breaker-lock side
11 216105600 A B Breaker-ends,white
18 216707200 A B Knob,temp control
21 # 216787700 A B Control-temperature
23 06594648 A B Light-signal,amber
27 216337700 A B Screw,hex washer head ,10-24 x 0.500
28 216478800 A B Hinge Assy
30 216105500 A B Breaker-corners,white
59 216848200 A B Basket,(2)
71 131168200 A B Screw,pan head ,8-18B x 0.31
75 216782000 A B Panel-access,white
* 216793913 A - Energy Guide
* 216794008 - B Energy Guide
* 5303305324 A B Paint,touch-up ,white
CABINET
05/03 6
Publication No FFC07C4CW / FFC09C4CW
5995390332
SYSTEM
# = Fast-moving Parts 7 05/03
* = Non-Illustrated Parts
FFC07C4CW / FFC09C4CW Publication No.
5995390332
SYSTEM
A = FFC07C4CW (FFC07C4CW0)
B = FFC09C4CW (FFC09C4CW0)
POS. NO PART NO DESCRIPTION
1 # 5300120780 A - Condenser
1 # 5300120781 - B Condenser
4 216634500 A B Drier-filter
5 # 216915400 A B Harness-main
22 216056400 A B Clip,compressor mtg ,SPRING
27 5308002681 A B Grommet,compressor
29 # 216820500 A - Compressor,w/o electricals
29 # 216784200 - B Compressor,w/o electricals
30 216649305 A - Controller
30 216649314 - B Controller
32 216694500 A - Clip,controller
32 216649200 - B Clip,controller
55 216696700 A - Capacitor-run,180 VAC ,15 microfarad
55 # 216787800 - B Capacitor,run ,50/60 Hz ,220 VAC ,12 microfarad
85 216818300 A B Wire-ground
86 216707700 A B Screw,8-18 X 1/2
