PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC07M5HW1 FFC07M5HW 134A white 115
MARKET
North America
Publication No.
5995349304
010205
-EN/SERVICE /GS
365
FREEZER
Model number
FFC07M5HW
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216372500
OWNER’S GUIDE - # 216768600
SERVICE DATA SHEET - # 216372500
ELECTROLUX HOME PRODUCTS N. AMERICA
P.O BOX 212378, AUGUSTA , GA 30917

03/01 2
Publication No. FFC07M5HW1
5995349304
DOOR

# = Fast-moving Parts 3 03/01
* = Non-Illustrated Parts
FFC07M5HW1 Publication No.
5995349304
DOOR
POS. NO PART NO DESCRIPTION
1 216480901 Gasket-door,white
2 # 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216061600 Panel-inner door/lid,white
10 216141101 Plug button,white
11 216113122 Panel-outer door/lid,white
12 316095402 Label-nameplate,Frigidaire ,white
12A 216373000 Frame-nameplate
18 216205004 Handle,white
23 216212700 Light-signal,amber
27 5303212828 Clip,panel
31 08009392 Gasket,white
35 5303297015 Washer,signal light
44 # 5303017178 Switch-rocker
46 216707800 Screw,PH ,8-32 x 1/2 ,wiring harness
47 216552700 Harness,electrical
53 # 5303208483 Buzzer,alarm
55 216164000 Housing,switch
56 216694200 Sealing cap
93 5303161215 Screw
* 5303917276 Insulation-door,fiberglass ,(bulk)
* 216140200 Handle,recessed ,white

03/01 4
Publication No. FFC07M5HW1
5995349304
CABINET

# = Fast-moving Parts 5 03/01
* = Non-Illustrated Parts
FFC07M5HW1 Publication No.
5995349304
POS. NO PART NO DESCRIPTION
1 216117700 Catch-lock
2 216269500 Adapter-drain
3 216502600 Plug-drain,interior ,interior
4 216073900 Plug-drain,exterior
6 216112800 Breaker-hinge,white
7 216112900 Breaker-lock side
11 216105600 Breaker-ends,white
18 216707200 Knob-control
21 216714500 Control-temperature
27 216337700 Screw,hex washer head ,10-24 x 0.500
28 216478800 Hinge Assy
30 216105500 Breaker-corners,white
59 216078600 Basket
71 131168200 Screw,8-18 x 0.31
75 216329402 Panel-access,white
* 216269500 Adapter-drain
* 5303305324 Paint,touch-up ,white
CABINET

03/01 6
Publication No. FFC07M5HW1
5995349304
SYSTEM

# = Fast-moving Parts 7 03/01
* = Non-Illustrated Parts
FFC07M5HW1 Publication No.
5995349304
POS. NO PART NO DESCRIPTION
1 # 5300120780 Condenser
4 216634500 Drier-filter
5 216552700 Harness,electrical
22 216056400 Clip-spring mtg
27 5308002681 Grommet,compressor
29 216510900 Compressor,R134a ,w/electricals
30 216511200 Starter
31 216100113 Overload Protector
53 216347800 Cover terminal,cover-comp term
86 216707700 Screw,8-18 X ½
* 216478900 Fastener,energy guide
SYSTEM
