Frigidaire FFC20C4CW0 User manual

CHEST FREEZER
Model number:
FFC20C4CW0
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216804000
OWNER’S GUIDE - # 216802800 / ENERGY GUIDE - # 216794404
SERVICE DATA SHEET - # 216804000
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC20C4CW0 FFC20C4CW 134A white 115
MARKET
North America
Publication No.
5995392585
030708
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

07/03 2
Publication No FFC20C4CW0
5995392585
5
2
47
27
34
16
15
9
1
10
11
P08D0365
40
40
18
57
14
DOOR

# = Fast-moving Parts 3 07/03
* = Non-Illustrated Parts
FFC20C4CW0 Publication No.
5995392585
DOOR
POS. NO PART NO DESCRIPTION
1 216481401 Gasket,lid seal ,white
2 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216829504 Panel-inner door,frzr
10 216141101 Plug button,white
11 216130122 Panel-outer lid,white
14 216822900 Switch,light/lamp ,ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket,light/lamp ,25 W
18 216897600 Handle,white
27 5303212828 Clip,panel mtg
34 5303296969 Shield,lid lamp
40 5309948647 Fastener,handle
47 # 216898800 Harness-lid
57 216899503 Overlay,white
* 5303917276 Insulation-door,fiberglass ,(bulk)

07/03 4
Publication No FFC20C4CW0
5995392585
CABINET

# = Fast-moving Parts 5 07/03
* = Non-Illustrated Parts
FFC20C4CW0 Publication No.
5995392585
POS. NO PART NO DESCRIPTION
1 216909800 Catch-lock,white
1A 216818900 Support,lock catch clip
3 216502600 Plug,drain ,interior
4 216073905 Plug-drain,exterior
6 216111200 Breaker,hinge side
7 216111800 Breaker,lock side
11 216110800 Breaker,chest end ,(2)
18 216707200 Knob,temp control
21 # 216714600 Control-temperature
27 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
28 216035300 Hinge
30 216110700 Breaker,corners
59 216916200 Basket,upper ,(2)
62A 131420300 Screw,cr truss head ,8-18AB x 0.750
75 216034301 Panel,access ,white
* 216794404 Energy Guide
* 5303305324 Paint,touch-up ,white
CABINET

07/03 6
Publication No FFC20C4CW0
5995392585
SYSTEM

# = Fast-moving Parts 7 07/03
* = Non-Illustrated Parts
FFC20C4CW0 Publication No.
5995392585
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5303280307 Condenser
4 216634500 Drier-filter
5 216806900 Harness-main
22 216056400 Clip,compressor mtg ,SPRING
27 5308002681 Grommet,compressor
28 5303212615 Support,compressor
29 # 216784600 Compressor,w/o electricals
30 216649315 Controller
32 216649100 Clamp,elec cont mtg ,compressor
42 216232700 Washer,flat ,1"OD x 0.531"ID
43A 5303212614 Clip,harness mount
47 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
55 218909913 Capacitor-run,220 VAC ,15 microfarad
86 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming
* 5303298960 Spacer-tube,0.237" ID
