Frigidaire FFC13K1AW1 User manual

CHEST FREEZER
Model number:
FFC13K1AW1
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216803900
OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216794101
SERVICE DATA SHEET - # 216803900
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC13K1AW1 FFC13K1AW 134A white 115
MARKET
North America
Publication No.
5995378196
020916
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

09/02 2
Publication No FFC13K1AW1
5995378196
DOOR

# = Fast-moving Parts 3 09/02
* = Non-Illustrated Parts
FFC13K1AW1 Publication No.
5995378196
DOOR
POS. NO PART NO DESCRIPTION
1 216481101 Gasket-door,white
9 216057406 Panel-lid
10 216141101 Plug button,white
11 216129800 Panel-outer door/lid,white
18 216140200 Handle,recessed ,white
27 5303212828 Clip,panel mtg
31 08009392 Gasket,white
* 5303925098 Insulation

09/02 4
Publication No FFC13K1AW1
5995378196
CABINET

# = Fast-moving Parts 5 09/02
* = Non-Illustrated Parts
FFC13K1AW1 Publication No.
5995378196
POS. NO PART NO DESCRIPTION
6 216110900 Breaker
11 216110800 Breaker,chest end ,(2)
12 240415201 Label-nameplate,white
18 216707200 Knob,temp control
21 # 216714601 Control temperature
27 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
28 216039600 Hinge
30 216110700 Breaker,corners
59 216080300 Basket
71 5303302714 Screw,8-18x3/4 ,(2)
75 216034301 Panel,access ,white
94 216140400 Lens,frost indicator ,blue
* 5303305324 Paint,touch-up ,white
CABINET

09/02 6
Publication No FFC13K1AW1
5995378196
SYSTEM

# = Fast-moving Parts 7 09/02
* = Non-Illustrated Parts
FFC13K1AW1 Publication No.
5995378196
SYSTEM
POS. NO PART NO DESCRIPTION
1 5303925238 Condenser
4 216634500 Drier-filter
5 216551600 Wiring Harness
22 216056400 Clip,compressor mtg ,SPRING
27 5308002681 Grommet,compressor
28 5303212615 Support,compressor
29 # 216856700 Compressor,w/o electricals
30 216649319 Controller
32 216694500 Clip,controller
42 216232700 Washer,flat ,1"OD x 0.531"ID
43A 5303212614 Clip,harness mount
47 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
55 # 218909901 Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad
85 216533500 Wire,ground
86 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming
