CHEST FREEZER
Base Model:
FFC15C8CW
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216908200
OWNER’S GUIDE - # 216802800 / ENERGY GUIDE - # 216794213
SERVICE DATA SHEET - # 216908200
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC15C8CW0 FFC15C8CW 134A white 115
MARKET
North America
Publication No.
5995393096
030723
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

07/03 2
Publication No FFC15C8CW0
5995393096
DOOR

# = Fast-moving Parts 3 07/03
* = Non-Illustrated Parts
FFC15C8CW0 Publication No.
5995393096
DOOR
POS. NO PART NO DESCRIPTION
1 216481201 Gasket-door,white
2 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216829104 Panel-lid
10 216141101 Plug button,white
11 216129938 Panel-outer door,white
14 216822900 Switch,light/lamp ,ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket,light/lamp ,25 W
18 216897600 Handle,white
27 5303212828 Clip,panel mtg
34 216578502 Shield,light
40 5309948647 Fastener,handle
47 # 216889600 Harness-lid
57 216899500 Overlay,white
79 # 216898700 Control Board,electronic
* 216905300 Screw,control board ,#3-24 x .25
* 5303917276 Insulation-door,fiberglass ,(bulk)

07/03 4
Publication No FFC15C8CW0
5995393096
CABINET

# = Fast-moving Parts 5 07/03
* = Non-Illustrated Parts
FFC15C8CW0 Publication No.
5995393096
POS. NO PART NO DESCRIPTION
1 216909800 Catch-lock,white
1A 216818900 Support,lock catch clip
3 216502600 Plug,drain ,interior
4 216073905 Plug-drain,exterior
6 216111000 Breaker,Plain ,white
7 216111600 Breaker,lock side
11 216110800 Breaker,chest end ,(2)
18 216707200 Knob,temp control
21 # 216844500 Control-temperature
27 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
28 216035200 Hinge
30 216110700 Breaker,corners
59 216916200 Basket,upper ,(2)
59A 216867400 Basket,lower ,(2)
62A 131420300 Screw,cr truss head ,8-18AB x 0.750
75 216034301 Panel,access ,white
93 5303161215 Screw,ph truss head ,8-18AB x 0.500
100 216654400 Track-basket
* 216794213 Energy Guide
* 5303305324 Paint,touch-up ,white
CABINET

07/03 6
Publication No FFC15C8CW0
5995393096
5
86
86 86
4
28
43
29
47
27
1
P08S0348
22
42
53
30
31 78
SYSTEM

# = Fast-moving Parts 7 07/03
* = Non-Illustrated Parts
FFC15C8CW0 Publication No.
5995393096
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5303925238 Condenser
4 216634500 Drier-filter
5 # 216920400 Harness-main
5 * 216890200 Harness,low voltage- ,w/thermistor
22 216056400 Clip,compressor mtg ,SPRING
27 5308002681 Grommet,compressor
28 5303212615 Support,compressor
29 # 216888100 Compressor,w/o electricals
30 216596800 Starter,relay
31 # 216100106 Overload Protector
42 216232700 Washer,flat ,1"OD x 0.531"ID
43 5303212614 Clip,harness mount
47 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
53 216347800 Cover terminal,cover-comp term
78 216912700 Assy-High Voltage
86 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming
