CHEST FREEZER
Model numbers:
FFC13C3AW
FFC15C3AW
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216908200
OWNER’S GUIDE - # 216802800
SERVICE DATA SHEET - # 216908200
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC13C3AW2 FFC13C3AW 134A white 115
FFC15C3AW3 FFC15C3AW 134A white 115
MARKET
North America
Publication No.
5995387569
030318
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917
09/02 2
Publication No FFC13C3AW2, FFC15C3AW3
5995387569
DOOR
# = Fast-moving Parts 3 09/02
* = Non-Illustrated Parts
FFC13C3AW2, FFC15C3AW3 Publication No.
5995387569
DOOR
A = FFC13C3A (FFC13C3AW2)
B = FFC15C3A (FFC15C3AW3)
POS. NO PART NO DESCRIPTION
1 216481101 A - Gasket-door,white
1 216481201 - B Gasket-door,white
2 # 5303925107 A B Lock Assy
5 # 216702900 A B Key,lock
9 216056904 A - Panel-inner lid,white
9 216057804 - B Panel-inner lid,white
10 216141101 A B Plug button,white
11 216129821 A - Lid,white
11 216129920 - B Lid,white
12A 216816801 A B Nameplate
18 216446600 A B Handle
23 5308002706 A B Light-signal,amber
27 5303212828 A B Clip,panel mtg
40 5309948647 A B Fastener,handle
47 216823700 A B Harness-lid/defrost
56 216694200 A B Cap,sig light seal
* 5303925098 A B Insulation
* 5309948955 A - Clip-panel
09/02 4
Publication No FFC13C3AW2, FFC15C3AW3
5995387569
CABINET
# = Fast-moving Parts 5 09/02
* = Non-Illustrated Parts
FFC13C3AW2, FFC15C3AW3 Publication No.
5995387569
A = FFC13C3A (FFC13C3AW2)
B = FFC15C3A (FFC15C3AW3)
POS. NO PART NO DESCRIPTION
1 5303208488 A B Latch,lid catch
3 216502600 A B Plug,drain ,interior
4 216073905 A B Plug-drain,exterior
6 216110900 A - Breaker
6 216111000 - B Breaker
7 216111500 A - Breaker,lock side
7 216111600 - B Breaker,lock side
11 216110800 A B Breaker,chest end ,(2)
18 216707200 A B Knob,temp control
21 # 216714601 A B Control temperature
27 216629600 A B Screw,hex washer head ,10-16 x 0.500 ,tapping
28 216039600 A - Hinge
28 216035200 - B Hinge
30 216110700 A B Breaker,corners
59 216867300 A B Basket,upper
71 5303302714 A B Screw,8-18x3/4 ,(2)
75 216034301 A B Panel,access ,white
* 5303305324 A B Paint,touch-up ,white
* 216794104 A - Energy Guide
* 216794206 - B Energy Guide
CABINET
09/02 6
Publication No FFC13C3AW2, FFC15C3AW3
5995387569
SYSTEM
# = Fast-moving Parts 7 09/02
* = Non-Illustrated Parts
FFC13C3AW2, FFC15C3AW3 Publication No.
5995387569
SYSTEM
A = FFC13C3A (FFC13C3AW2)
B = FFC15C3A (FFC15C3AW3)
POS. NO PART NO DESCRIPTION
1 5303925238 A B Condenser
4 216634500 A B Drier-filter
5 # 216906200 A B Harness-main
22 216056400 A B Clip,compressor mtg ,SPRING
27 5308002681 A B Grommet,compressor
28 5303212615 A B Support,compressor
29 # 216888100 A B Compressor,w/o electricals
30 216596800 A B Starter,relay
31 # 216100106 A B Overload Protector
42 216232700 A B Washer,flat ,1"OD x 0.531"ID
43 5303212614 A B Clip,harness mount
47 216629600 A B Screw,hex washer head ,10-16 x 0.500 ,tapping
53 216347800 A B Cover terminal,cover-comp term
86 216036600 A B Screw,ph washer head ,8-32CA x 0.500 ,thread forming
