Frigidaire FFC20C4CW User manual

Product No. FFC20C4CW1
Series 134A
Color white
Volts 115
Wiring Diagram 216804000
Owner's Guide 216960000
Market North America
Energy Guide 216794404
P08F0060.eps P08D0365.eps P08C0623.eps P08S0310.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995408431
04/04/27
(EN/SERVICE/MLR)
365
FREEZER CHEST
Model No.
FFC20C4CW
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995408431 FFC20C4CW1
04/04 2
DOOR
5
2
47
27
34
16
15
9
1
10
11
P08D0365
40
40
18
57
14

FFC20C4CW1 Publication No: 5995408431
# Functional Parts 3 04/04
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216481401 Gasket, lid seal, white
2 5303925107 Lock Assy
5 # 216702900 Key, lock
9 216829504 Panel-inner door, frzr
10 216923001 Plug button, 1/4", white
11 216130122 Panel-outer lid, white
14 216822900 Switch, light/lamp, ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket, light/lamp, 25 W
18 216897600 Handle, white
27 5303212828 Clip, panel mtg
* 5303161215 Screw, ph truss head, 8-18AB x 0.500
34 5303296969 Shield, lid lamp
40 216922700 Fastener, .330 dia stud, handle, (2)
47 # 216898800 Harness-lid
57 216899503 Overlay, white
* 5303917276 Insulation-door, fiberglass, (bulk)

Publication No: 5995408431 FFC20C4CW1
04/04 4
CABINET

FFC20C4CW1 Publication No: 5995408431
# Functional Parts 5 04/04
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 216909800 Catch-lock, white
1A 216818900 Support, lock catch clip
3 216502600 Plug, drain, interior
4 216073905 Plug-drain, exterior
6 216111200 Breaker, hinge side
7 216111800 Breaker, lock side
11 216110800 Breaker, chest end, (2)
18 216707200 Knob, temp control
21 # 216714600 Control-temperature
27 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
28 216035300 Hinge
30 216110700 Breaker, corners
59 216916200 Basket, upper, (2)
62A 131420300 Screw, cr truss head, 8-18AB x 0.750
75 216034301 Panel, access, white
* 216794404 Energy Guide
* 5303305324 Paint, touch-up, white

Publication No: 5995408431 FFC20C4CW1
04/04 6
SYSTEM

FFC20C4CW1 Publication No: 5995408431
# Functional Parts 7 04/04
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 5303280307 Condenser
4 216634500 Drier-filter
5 216806900 Harness-main
22 216056400 Clip, compressor mtg, SPRING
27 5308002681 Grommet, compressor
28 5303212615 Support, compressor
29 # 216784700 Compressor, w/o electricals
30 216649300 Controller-regulator LP
32 216649100 Clamp, elec cont mtg, compressor
42 216232700 Washer, flat, 1"OD x 0.531"ID
43A 5303212614 Clip, harness mount
47 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
55 218909913 Capacitor-run, 220 VAC, 15 microfarad
86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
* 5303298960 Spacer-tube, 0.237" ID
