Frigidaire EFRB200 User manual

TABLE OF CONTENTS
Important Safety Instructions.....................1
Unpacking and Setup................................4
Features at a Glance.................................5
Assembly and Installation..........................6
Door Removal Instructions........................12
Temperature Controls................................13
Helpful Hints.................................................14
Energy Saving Tips.......................................15
Vacation and Moving Tips.............................15
Normal Operating Sounds and Sights..........15
Care and Cleaning........................................16
Before You Call.............................................17
BEER COOLER
170L
6.1CU FT
USERMANUAL
EFRB200,EFRB200C

IMPORTANT SAFETY INSTRUCTIONS
1
WARNING:
Please read all instructions before using this unit.
FOR YOUR SAFETY
• DO NOT store or use gasoline, or other flammable liquids in the vicinity of this or any other
appliance. Read product labels for warnings regarding flammability and other hazards.
• DO NOT operate the appliance in the presence of explosive fumes.
• Remove all staples from the carton. Staples can cause severe cuts, and also destroy finishes
if they come in contact with other appliances or furniture.
DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey
all safety messages that follow this symbol to avoid possible injury or death.
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious minjury.
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
IMPORTANT indicates installation, operation or maintenance information
which is important but not hazard-related.
INSTALLATION CHECKLIST
Electrical Power
House power turned on
Appliance plugged in
Final Checks
Shipping material removed
Appliance temperatures set
Registration card sent in
Doors
Door seals completely to cabinet on all sides
Door is level across the top
Leveling
Unit is level, side-to-side and tilted 1/4” (6 mm)
front-to-back
Cabinet is setting solid on all corners
CHILD SAFETY
Destroy or recycle the carton, plastic bags, and any exterior wrapping material immediately after
the appliance is unpacked. Children should NEVER use these items to play. Cartons covered
with rugs, bedspreads, plastic sheets or stretch wrap may become airtight chambers, and can
quickly cause suffocation.

2
WARNING These guidelines must be followed to ensure that safety
mechanisms in this unit will operate properly.
IMPORTANT Turning the Temperature Control to
“OFF” turns off the compressor and prevents your
appliance from cooling, but does not disconnect the
power to the other electrical components. To turn off
power to your appliance you must unplug the power
cord from the electrical outlet.
PROPER DISPOSAL OF YOUR APPLIANCE
ELECTRICAL INFORMATION
RISK OF CHILD ENTRAPMENT
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous – even if they will sit for “just a few days.” If you are getting rid of
your old appliance, please follow the instructions below to help prevent accidents.
PROPER DISPOSAL OF APPLIANCE
We strongly encourage responsible appliance recycling/disposal methods. Check with your
utility company or visit www.energystar.gov/recycle for more information on recycling your old
appliance.
BEFORE YOU THROW AWAY YOUR OLD APPLIANCE:
• Remove doors.
• Leave shelves in place so children may
not easily climb inside.
• Have refrigerant removed by a qualified
service technician.
• The appliance must be plugged into its own dedicated 115 Volt, 60 Hz., AC only electrical
outlet. The power cord of the appliance is equipped with a three-prong grounding plug for
your protection against electrical shock hazards. It must be plugged directly into a properly
grounded three prong receptacle. The receptacle must be installed in accordance with local
codes and ordinances. Consult a qualified electrician. Avoid connecting keg cooler to a Ground
Fault Interruptor (GFI) circuit. Do not use an extension cord or adapter plug.
• If the power cord is damaged, it should be replaced by an authorized service technician to
prevent any risk.
• Never unplug the appliance by pulling on the power cord. Always grip the plug firmly, and pull
straight out from the receptacle to prevent damaging the power cord.
• Unplug the appliance before cleaning and before replacing a light bulb to avoid electrical shock.
• Performance may be affected if the voltage varies by 10% or more. Operating the appliance
with insufficient power can damage the compressor. Such damage is not covered under your
warranty.
• Do not plug the unit into an electrical outlet controlled by a wall switch or pull cord to prevent
the unit from being turned off accidentally.

3
WARNING
CO2CANISTER SAFE HANDLING
• CO2canisters must be handled with extreme care. They contain potentially
hazardous high pressure compressed gas. Make sure you read and understand all of
these instructions before installation.
• Never attempt to refill a CO2cylinder yourself. They can be refilled at locations such
as welding supply shops, party stores, fire supply shops, or where kegs are purchased.
• ALWAYS connect CO2gas canisters to a pressure regulator.
• NEVER drop or throw the CO2canister.
• NEVER connect gas canister directly to keg.
• ALWAYS keep CO2canisters in a cool place (21.5°C（70°F）or less) and away from heat.
• In case of CO2leakage, ventilate and evacuate the area immediately.
• ALWAYS keep canister secured in an upright position.
• Check the Department of Transportation (D.O.T.) test date on the canister neck and do
not use if older than five (5) years.
• Return outdated canister to your gas supplier for one that is within the time limit.

UNPACKING AND SETUP
4
This Use and Care Manual provides specific assembly, operating and maintenance instructions
for your model. Use the keg cooler only as instructed in this Use and Care Manual. Before
starting the keg cooler, follow these important first steps.
PARTS
Your keg cooler comes with several small boxes that contain all the required parts and
accessories. Check to make sure that you have received all of the components listed below.
BEVERAGE DELIVERY KIT BOX
(1) Drip Tray
(2) Casters and Washers
(3) Retaining Strap
(4) Hole Plug
(5) Faucet Knob
(6) CO2Regulator (with plastic washer)
(7) Keg Coupler
(8) Small Hose (Gas Line)
(9) Rubber Gasket (Black)
(For bottom of Dispensing Tower)
(10) Guard Rail
(11) Dispenser Tower (with faucet)
(12) CO2Canister (Empty)
(13) Bag of spare parts
(replacement seals and washers)
Casters and
Washers
Faucet Knob
Drip Tray Retaining Strap
C0 Regulator
2
Hole Plug
Keg Coupler
Spare Parts
Rubber Gasket
1
5
2
6
9
3
7
11
4
8
10
13
Dispenser
Tower C0 Canister
2
11 12
Guard Rail
1 piece
4 pieces
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 bag
The box comes with a “D System” type Keg Coupler (7). Depending on your choice of beer,
you may require a different Keg Coupler (7). Check with your local beer distributor to
determine which type of system you need, and order additional Keg Couplers as needed.
NOTE
Small Hose

FEATURES AT A GLANCE
5
Features may vary according to model
Dispensing Tower
Drip Tray
Casters (x4)
Faucet Handle
Faucet
Top Rail
Temperature Control
Standard Keg Sizes for this Cooler
35.2 cm
(13-7/8 in.)
59.4 cm
(23-3/8 in.) 59.4 cm (23-3/8 in.)
41.0 cm (16-1/8 in.) 41.0 cm (16-1/8 in.) 28.3 cm (11-1/8 in.) 23.5 cm (9-1/4 in.)

ASSEMBLY AND INSTALLATION
6
LOCATION
• Choose a place that is near a grounded electrical outlet. Do not use an extension cord or an
adapter plug.
• If possible, place the unit out of direct sunlight and away from the range, dishwasher or other
heat sources.
• For optimum performance, this product should only be used indoors under normal ambient
conditions.
• The appliance must be installed on a floor that is level and strong enough to support a fully
loaded unit.
• If the appliance has been placed in a horizontal or tilted position for any period of time, please
wait at least 24 hours before plugging the unit in.
INSTALLING THE CASTERS
Follow the steps below to install the casters.
1. Empty the inside of the cabinet completely and lay the Keg Cooler down on its side.
We recommend that you place a piece of cardboard or cloth underneath the cabinet to prevent
dents or scratches.
2. Insert the casters into the holes on the bottom corners of the cabinet. Tighten each caster by
turning the head of the bolts clockwise with a wrench (not provided in the kit).
3. Once all four casters have been tightened, stand the cabinet in its upright position.
INSTALLING THE BEER TAP
There are notches on the bottom of the dispensing tower that line up with grooves inside the
opening on the top of the Keg Cooler. Align the dispensing tower with the opening on the top of
the unit, then place inside and twist clockwise until secure. Use four screws to fasten the beer tap.
Pay attention to use the thin black gasket (9) for assembly (see illustration). If you find this to be
a tight fit, apply some soapy water to the gasket to make the tower easier to twist into place.
Also see illustration showing hose connections to CO2regulator to the beer tap.
This Use and Care Guide provides specific operating instructions for your model. Use this unit
only as instructed in this Use and Care Guide. Before starting the unit, follow these important
first steps.
NOTE: Two of the casters include locking mechanisms to ensure the unit does not
slide on hard floors. These two locking casters should be fastened at the front end
of the unit, with the unlocked casters fastened on the rear end.

7
INSTALLING THE GUARDRAIL
Follow the steps below to install the guardrail.
1. Place the guard rail on top of the cabinet.
2. Align all support feet of the guardrail with the holes on the top of the unit and press down into
place.
INSTALLATION
Installation clearances
• Allow the following clearances for ease of installation, proper air circulation, and electrical
connections:
Sides and Top 12.7 cm (5 inches)
Back 12.7 cm (5 inches)
LEVELING
All four casters of your unit must rest firmly on a solid floor. Use adjustable wrench to adjust
leveling screws.
REGULATOR INSTALLATION
• Check to ensure plastic washer is inside the hex nut.
• Fasten the CO2 regulator (6) to the CO2 canister (12). Place
the regulator to the right of the tank.
• Tighten the hex nut securely. DO NOT over tighten. Over-
tightening may damage the gasket in the nut of the regulator.
SMALL CO2HOSE TO REGULATOR CONNECTION
• Attach wing nut on end of small hose (8) to fitting at bottom of regulator (6).
CAUTION: Do not install the unit where the temperature will drop below 13°C
(55°F) or rise above 32°C (90°F). The compressor will not be able to maintain
proper temperatures inside the unit.
NOTE: If your unit is placed with the door hinge side against a wall, you may have
to allow additional space so the door can be opened wider.
CAUTION: do not attempt to move or relocate the keg cooler with a keg inside.

SMALL CO2HOSE TO COUPLER CONNECTION
• Secure other end of small hose (8) to the threaded
end of keg coupler (7) as shown. Be sure to fully
tighten fitting.
CLEAR HOSE TO COUPLER CONNECTION
Place one of the supplied rubber washers inside
the wing nut on the one end of the clear hose
(beverage delivery line) and attach to keg coupler
(7). Be sure to tighten the nut securely to prevent
leakage. DO NOT overtighten. Overtightening may
damage the gasket in the nut.
COUPLER TO KEG INSTALLATION
• Align locks on keg coupler (7) with housing on
top of keg and push down on the keg coupler (7).
Make sure top handle is in the up position.
• Turn the tap head handle clockwise 1/4 turn. The
tap head is now secured to the keg.
• Pull the tap handle out and push down until it locks
into place to open the port in the keg.
DELIVERY HOSE PRESSURIZATION
• Open the CO2canister valve all the way by turning
counterclockwise until it stops. This valve seals
at both the fully open and fully closed positions.
Failure to completely open or close the valve could
result in premature loss of CO2pressure.
• Open the regulator shut-off valve by moving it to
the 6 o’clock position.
• Check gauge pressure. Adjust the regulator
adjustment knob Knob as necessary until the pressure
reads between 12 to 14 psi. You may first need to
loosen set screw located behind knob. After setting
regulator to correct pressure, set screw may be retightened
to lock knob in place.
NOTE: Depending on your choice of beer, you may require a
different keg coupler (7). Check with your local beer
distributor to determine which type of system you need, and
order additional keg couplers as needed.
8

CO2CANISTER TO CABINET INSTALLATION
• Lift and place the CO2 canister (12) with the CO2 regulator (6) on the shelf at rear right hand
corner of cabinet. It is important that the canister be kept in an upright position to operate
efficiently. Hook one end of retaining strap (3) over metal bracket at rear, then stretch around
canister and hook other end over front bracket.
KEG TO CABINET INSTALLATION
• Place the keg on the support shelf and push
back next to the CO2 canister (12) (See TIPS ON
INSTALLING KEG TO THE CABINET) inside the
cabinet as shown.
WARNING
SAFE KEG HANDLING
• Installing the keg to the cabinet is a two-person team effort. NEVER lift a full keg alone.
Doing so may cause severe injury.
• With the door fully open and the help of another person, lift the keg vertically on both
sides until the keg is higher than the keg support shelf.
• Set the edge of the keg on top of the plastic protective plate located on top of keg
support shelf. Slide the keg back until it is fully inside the cabinet.
• Care must be taken to avoid damage to the temperature control and shelf tower located
in the cabinet.
NOTE: The above illustration does not show the tap installed for clarity of installation.
9

OPERATING YOUR KEG COOLER
• Make sure that the keg cooler is plugged in properly to a 115V, 60Hz AC only electrical outlet.
• Make sure that the drip tray and sump are secured under the faucet.
• Start with a clean beverage glass that has been wetted in cold water. Place the glass at a 45º
angle, 2.5 cm (1 in.) below the faucet. Do not let the glass touch the faucet. Open the faucet
all the way.
• After the glass has reached half full, gradually bring the glass to an upright position.
• Let the remaining beverage run straight down the middle. This insures proper release of CO2
by producing a 1.9 to 2.5 cm (3/4 to 1 in.) foam head.
• Close the faucet completely and quickly.
DELIVERY HOSE ARRANGEMENT
NOTE: Failure to route hoses properly may cause the hose to become kinked or
caught in door.
NOTE: It is normal to see condensation forming around the faucet. This
condensation is caused by the temperature difference between the cold beverage
and the inner surfaces of the faucet when beverage is being drawn through the line.
10

HOW TO REPLACE AN EMPTY CO2CANISTER
• Remove hoses from routing clips.
• Remove the keg, then remove CO2canister.
• Close the canister valve of the empty canister by turning clockwise until it stops.
• Close the regulator shut-off valve by moving it to the 9 o’clock position.
• Carefully remove regulator from the empty CO2canister by loosening the nut with an
adjustable wrench. Check the condition of the gasket inside the nut and replace if necessary.
• Return canister to your local carbonic gas source for filling. (We suggest looking in your yellow
pages under “Carbonic Gas.” Sources of CO2vary from community to community but it is often
available at welding supply stores and beverage distributors.)
• Remove dust cap from new canister nut, if any.
• With the canister valve still in closed position, reattach the regulator to the new canister using
an adjustable wrench. Ensure the plastic washer is inside of the nut. Tighten nut until it feels
snug but be careful not to overtighten as you will damage the gasket inside the stem nut.
• Check to make sure that the braided gas line hose is still securely attached to the regulator.
• Open the canister valve all the way by turning counter-clockwise until it stops. This valve seals
at both the fully open and fully closed positions. Failure to completely open or close the valve
could result in premature loss of CO2pressure.
• Open the regulator shut-off valve by moving it down to the 6 o’clock position.
• Check gauge pressure. Adjust the regulator adjustment screw as necessary until the pressure
reads between 12 to 14 psi. Tighten the adjustment lock nut.
• Replace keg and route hose clips.
11

DOOR REMOVAL INSTRUCTIONS
DOOR REMOVAL AND REVERSAL INSTRUCTIONS:
1 Remove dispensing tower from unit.
2 Remove three (3) screws at rear edge of top cover, then lift up at rear and slide forward to
remove cover (see Figure A).
3 Remove two (2) screws from top door hinge and lift up out of door bushing (see Figure B).
6 Re-install door with LH bushing placed over hinge pin.
7 Re-install top hinge on opposite corner of cabinet and then assemble top cover in reverse
order of Step 2.
NOTE: The direction in which your unit door opens (door swing) can be reversed,
from left to right or right to left, by moving the door hinges from one side to the
other. Reversing the door swing should be performed by a qualified person.
IMPORTANT: Before you begin, turn the unit temperature control to “OFF” and
remove the electrical power cord from the wall outlet. Remove any food from door
shelves.
12

TEMPERATURE CONTROLS
COOL DOWN PERIOD
For proper operation, allow the unit to operate with the door closed for at least 12 hours before
placing the keg inside.
KEG COOLER CONTROLS
Temperature control
This rotary control is the primary control for the refrigerated compartment temperature. If the
unit is too warm, adjust this control in the “Max” direction. If the unit is too cold, adjust this
control in the “Min” direction.
TEMPERATURE SETTING AND ADJUSTMENT
For beer storage, the recommended initial setting is “Med.” Under most conditions,
this setting will provide for dispensed beer between 1-3 ºC (34-38 ºF) You may adjust as
required to suit your individual taste and the keg cooler operating conditions. After a control
adjustment, always allow 24 hours for the beer to stabilize at the new temperature before
making additional adjustments.
NOTE: When purchasing a beer keg, always purchase a keg cold ( <3 ºC (38 ºF)),
transport as quickly as possible, and get it installed in the cold unit within two (2)
hours. Under most conditions, these guidelines will allow serving of properly
cooled beerwithin 24 hours. Purchasing a keg at a temperature above 3 ºC (38 ºF),
and/or exposure to elevated temperatures longer than two (2) hours will require
additional time for the beer to be cooled to optimum serving temperature.
IMPORTANT: Turning the unit temperature control to “OFF” turns off the
compressor, but does not disconnect the power to the light bulb and other electrical
components. To turn off power to your unit, you must unplug the power cord from
the wall outlet.
13

HELPFUL HINTS
PARTS OF A CO2 REGULATOR
(A) Low Pressure Gauge
(B) Adjustment Knob
(C) Adjustment Lock Set Screw
(D) Shut-off Valve
(E) CO2 Nut (used to connect to CO2 canister)
(F) High Pressure Gauge
BEER STORAGE TEMPERATURE
• Draft beer is not pasteurized, so it must be kept cold, preferably at 3 ºC (38 ºF). Temperatures
above 3 ºC (38 ºF) may cause the beer to become wild, turn sour and cloudy.
RECOMMENDED KEG HANDLING
• Be sure the keg is cold when you purchase it.
• Transfer keg from place of purchase and install in keg cooler in two (2) hours or less.
• After the keg is installed in the keg cooler, allow 24 hours for beverage to reach recommended
temperature.
• If the keg is exposed to ambient temperatures longer than two (2) hours, additional cooling
time will be required before beverage will reach recommended temperature.
CAUTION: DO NOT attempt to move or relocate this keg cooler with a keg inside.
14
TYPICAL BEER SERVING EQUIVALENTS
¼ Keg ½ Keg
Grams/Ounces 28123g/992
37 kg / 82.5 lb. 75 kg / 165 lb
56245g/1984
Litres/Gallons
Cases (355 mL
(12 oz.) bottles)
Weight (full)
3 3/8 (82 bottles)
29 L / 7.75 gal
6 3/4 (165 bottles)
58 L / 15.5 gal.

ENERGY SAVING TIPS
VACATION AND MOVING TIPS
NORMAL OPERATING SOUNDS AND SIGHTS
UNDERSTANDING THE SOUNDS YOU MAY HEAR
Your new, high-efficiency keg cooler may introduce unfamiliar sounds. These sounds normally
indicate your keg cooler is operating correctly. Some surfaces on floors, walls, and kitchen
cabinets may make these sounds more noticeable.
NOTE: Rigid foam insulation is very energy efficient, but is not a sound insulator.
15
• Install the keg cooler in the coolest part of the room, out of direct
sunlight and away from heating ducts or registers. Do not place the keg
cooler next to heat-producing appliances such as a range, oven, or
dishwasher.
• Do not overcrowd the keg cooler or block cold air vents. Doing so
causes the keg cooler to run longer and use more energy.
• Organize the keg cooler to reduce door openings. Remove as many
items as needed at one time and close the door as soon as possible.
Vacation and Moving Tips
Short Vacations •Leave keg cooler operating during vacations of three (3) weeks or less.
•Use all perishable items from keg cooler compartment.
Long Vacations •Remove all food and ice if you will be gone one month or more.
•Turn controls to the OFF position and disconnect power.
•Clean interior thoroughly.
•Leave door open to prevent odours and mould build-up. Block door open if necessary.
Moving •NEVER MOVE KEG COOLER WITH KEG INSIDE.
•If using handcart, load from side.
•Adjust leveling legs all the way up to protect surface during sliding or moving.
•Pad cabinet to avoid scratching surface.
Following is a list of major components in your keg cooler and the sounds they can cause:
Evaporator Refrigerant through the evaporator may create a boiling or gurgling sound.
Electronic control and automatic defrost control These parts can produce a snapping or
clicking sound when turning the cooling system on and off.
Compressor Modern, high-efficiency compressors run much faster than in the past. The
compressor may have a high-pitched hum or pulsating sound.
Drain pan (not removable) You may hear water dripping into the drain pan during the defrost
cycle.

PROTECTING YOUR INVESTMENT
Keeping your keg cooler clean maintains appearance and prevents odour build-up. Wipe up any
spills immediately and clean the keg cooler at least twice a year. When cleaning, take the
following precautions:
• Never use CHLORIDE or cleaners with bleach to clean stainless steel.
• Do not wash any removable parts in a dishwasher.
• Always unplug the electrical power cord from the wall outlet before cleaning.
• Remove adhesive labels by hand. Do not use razor blades or other sharp instruments which
can scratch the appliance surface.
• Do not remove the serial plate.
Do not use abrasive cleaners such as window sprays, scouring cleansers, brushes, flammable
fluids, cleaning waxes, concentrated detergents, bleaches or cleansers containing petroleum
products on plastic parts, interior doors, gaskets or cabinet liners. Do not use paper towels,
metallic scouring pads, or other abrasive cleaning materials or strong alkaline solutions.
CARE and CLEANING
16
NOTE: If you set your temperature controls to turn off cooling, power to lights and
other electrical components will continue until you unplug the power cord from the
wall outlet.
CAUTION: 1.Pull the keg cooler straight out to move it. Shifting it from side to side
may damage flooring. Be careful not to move the keg cooler beyond the plumbing
connections. 2.Damp objects stick to cold metal surfaces. Do not touch refrigerated
surfaces with wet or damp hands.
IMPORTANT: If you store or move your keg cooler in freezing temperatures, be sure
to completely drain the water supply system. Failure to do so could result in water
leaks when the keg cooler is put back into service. Contact a service representative
to perform this operation.
Care and Cleaning Tips
Part What To Use Tips and Precautions
Interior and Door
Liners • Soap and water • Baking soda and water
Use 30 mL (2 tbsp) of baking soda in 945 mL (1 qt.) of warm water. Be sure
to wring excess water out of sponge or cloth before cleaning around
controls, light bulb or any electrical part.
Door Gaskets • Soap and water Wipe gaskets with a clean soft cloth.
Drawers and Bins • Soap and water Use a soft cloth to clean drawer runners and tracks.
Exterior and
Handles • Soap and water • Non-abrasive glass cleaner Do not use commercial household cleaners containing ammonia, bleach or alcohol to clean handles. Use a soft cloth to clean smooth handles. DO
NOT use a dry cloth to clean smooth doors.
Exterior and
Handles
(Stainless Steel
Models Only)
• Soap and water
• Stainless steel cleaners
Never use CHLORIDE or cleaners with bleach to cleanstainless steel.
Clean stainless steel front and handles with non-abrasive soapy water and
a dishcloth. Rinse with clean water and a soft cloth. Use a non-abrasive
stainless steel cleaner. These cleaners can be purchased at most home
improvement or major department stores. Always follow manufacturer’s
instructions. Do not use household cleaners containing ammonia or bleach.
NOTE: Always clean, wipe and dry with the grain to prevent
scratching. Wash the rest of the cabinet with warm water and mild liquid
detergent. Rinse well, and wipe dry with a clean soft cloth.

BEFORE YOU CALL
17
CONCERN POTENTIAL CAUSE COMMON SOLUTION
RUNNING OF KEG COOLER
Keg cooler does not
run. • Keg cooler is plugged into a circuit that has a ground fault
interrupt.
• Temperature control is in the
“O” position.
• Keg cooler may not be plugged
in, or plug may be loose.
• House fuse blown or tripped
circuit breaker.
• Power outage.
• Use another circuit. If you are unsure about the outlet,
have it checked by a technician.
• See SETTING THE TEMPERATURE CONTROL section.
• Ensure plug is tightly pushed into outlet.
• Check/replace fuse with a 15 amp time-delay fuse. Reset
circuit breaker.
• Check house lights. Call local electric company.
Keg cooler runs too
much or too long. • Room or outside weather is hot.
•Keg cooler has recently been
disconnected for a period of time.
• Doors are opened too frequently
or too long.
• Keg cooler door may be slightly
open.
• Temperature control is set too
low.
• Keg cooler gasket is dirty,worn,
cracked, or poorly
• It’s normal for the keg cooler to work longer under these
conditions.
• It takes four (4) hours for the keg cooler to cool down
completely.
• Warm air entering the keg cooler causes it to run more.
Open door less often.
• See DOOR PROBLEMS section.
• Adjust temperature control to warmer setting. Allow
several hours for temperature to stabilize.
•Clean or change gasket.Leaks in door seal will cause keg
cooler torun longer in order to maintain desired temperatures.
Interior keg cooler tem -
perature is too cold. • Temperature control is set too
low.
• Adjust temperature control to a warmer setting. Allow
several hours for temperature to stabilize.
Interior keg cooler
temperature is too
warm.
• Temperature control is set too
warm.
• Door is kept open too long or is
opened too frequently.
•Door may not be seating properly.
•Keg cooler has recently been
disconnected for a period of time.
• Adjust temperature control to a colder setting. Allow
several hours for the temperature to stabilize.
• Warm air enters the keg cooler every time the door is
opened. Open the door less often.
• See DOOR PROBLEMS section.
• It takes four (4) hours for the keg cooler to cool down
completely.
Keg cooler external
surface temperature is
warm.
• The external walls can be as
much as -1 OC (30 OF) warmer
than room temperature.
• This is normal while the compressor works to transfer heat
from inside the keg cooler.
WATER/MOISTURE/FROST INSIDE KEG COOLER
Moisture collects on
inside of keg cooler
walls.
• Weather is hot and humid.
• Door may not be seating
properly.
• Door is kept open too long or
opened too frequently.
• This is normal.
• See DOOR PROBLEMS section.
• Open the door less often.
WATER/MOISTURE/FROST OUTSIDE KEG COOLER
Moisture collects on
outside of keg cooler
walls.
• Door may not be seating
properly, causing the cold air
from inside the keg cooler to
meet warm moist air from the
outside.
• See DOOR PROBLEMS section.
ODOUR IN KEG COOLER
Unpleasant odours. • Interior needs to be cleaned. • Clean interior with sponge, warm water, and baking soda .
DOOR PROBLEMS
Door will not close. • Keg cooler is not level. • This condition can force the cabinet out of square and
misalign the door. Level the unit .
certified
fitted.

18
CONCERN POTENTIAL CAUSE COMMON SOLUTION
SOUND AND NOISE
Louder sound levels
whenever keg cooler
is on.
• Modern keg coolers have in-
creased storage capacity and
more stable temperatures. They
require a high-efficiency compres-
sor.
•This is normal. When the surrounding noise level is low,you
mighthear the compressor running while it cools the interior.
Longer sound levels
when compressor
comes on.
• Keg cooler operates at high
pressure during the start of the
“ON” cycle.
• This is normal. Sound will level off or disappear as the keg
cooler continues to run.
Popping or cracking
sound when compres-
sor comes on.
• Metal parts undergo expansion
and contraction, as in hot water
pipes.
• This is normal. Sound will level off or disappear as the keg
cooler continues to run.
Bubbling or gurgling
sound like water boil -
ing.
• Refrigerant (used to cool keg
cooler) is circulating throughout
the system.
• This is normal.
Vibrating or rattling
noise. •Keg cooler is touching the wall. • Move keg cooler slightly away from the wall.
Snapping noise. •Temperature control turning keg
cooler on and off.
• This is normal.
COMMON DRAFT PROBLEMS
WILD BEER - Beer,
when drawn, is all
foam, or too much
foam and not enough
liquid beer.
•Beer drawn improperly.
• Creeping regulator.
• Applied pressure is set too high.
• Hot spots in line.
• Tapped into a warm keg (should
be 1.1°C-3.5°C（34°F-38°F）
• Centre malfunctioning.
• Faucet is in bad, dirty or worn
condition.
• Make sure faucet is opened all the way. Close quickly when
done.
• Replace with a new regulator.
• Readjust regulator to a lower pressure until foam subsides.
When pressure is properly set, you should be able to pour 10
oz. of beer in (5)five seconds.
• Make sure beer delivery line is not pinched and is fully inside
the interior of the keg cooler.
• Wait until keg cools down to proper temperature.
• Have keg cooler serviced to return it to proper operating
condition.
• Thoroughly clean faucet with recommended cleaning kit.
Replace all worn seals.
FLAT BEER - Foamy
head disappears
quickly; beer lacks
usual zestful brewery
• Dirty glasses.
•Applied pressure is set too low.
•CO2
is cut off.
•Beer too cold.
•Loose tap or vent connections.
•Sluggish regulator.
• Wash glasses using soap-free detergent.
• Increase pressure until beer at a rate of 2 oz. per
second.
• Do not turn off CO2supply line to keg until keg is empty and
ready to be removed.
• Increase temperature of keg cooler. See SETTING THE
TEMPERATURE CONTROLsection.
• Check that coupler is properly installed in keg.
• Replace regulator.
CLOUDY BEER - When
beer in glass appears
hazy, not clear.
•Frozen or near frozen beer.
•Unrefrigerated beer for long periods
of time.
•Dirty glasses.
•Dirty faucet.
•Unrefrigerated foods placed on top
of cold keg.
• Return keg to place of purchase and exchange for one that
has been properly refrigerated.
• Exchange keg for fresh one.
• Wash glasses using soap-free detergent.
• Clean faucet with recommended cleaning kit.
• Remove items from atop keg and place in a separate refrig-
erator.
fresh flavour.
flows

19
DANGER – Risk Of Fire Or Explosion. Flammable Refrigerant
Used. To Be Repaired Only By Trained Service Personnel.
Do Not Puncture Refrigerant Tubing
CAUTION – Risk Of Fire Or Explosion. Flammable Refrigerant
Used. Consult Repair Manual/Owner’s Guide Before Attempting
To Service This Product. All Safety Precautions Must be Followed
CAUTION – Risk Of Fire Or Explosion. Dispose Of Property In
Accordance With Federal Or Local Regulations. Flammable
Refrigerant Used
CAUTION – Risk Of Fire Or Explosion Due To Puncture Of
Refrigerant Tubing; Follow Handling Instructions Carefully.
Flammable Refrigerant Used
