Frigidaire FFC20G4AW2 User manual

CHEST FREEZER
Model number
FFC20G4AW2
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216804000
OWNER’S GUIDE - # 216802800
SERVICE DATA SHEET - #216804000
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC20G4AW2 FFC20G4AW 134A white 115
MARKET
North America
Publication No.
5995376851
020814
-EN/SERVICE /MLR
08 / 365
ELECTROLUX HOME PRODUCTS INC.
P.O BOX 212378, AUGUSTA , GA 30917

08/02 2
Publication No FFC20G4AW2
5995376851
DOOR

# = Fast-moving Parts 3 08/02
* = Non-Illustrated Parts
FFC20G4AW2 Publication No.
5995376851
DOOR
POS. NO PART NO DESCRIPTION
1 216481401 Gasket-door,white
2 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216829504 Panel-inner door,frzr
10 216141101 Plug button,white
11 216130114 Lid,white
14 # 216822900 Switch,light/lamp ,ramp
15 216846400 Light Bulb/Lamp
16 # 216817600 Socket,light/lamp ,25 W
18 216205004 Handle,white
23 216212700 Light-signal,amber
27 5303212828 Clip,panel mtg
34 5303296969 Shield-light
35 5303297015 Washer,signal light
36 5306599968 Plate,backup ,light switch
40 5309948647 Fastener,handle
44 # 216823300 Switch,rocker
46 08037851 Screw,PH type AB ,8-32x1/2 ,wiring harness
47 # 216792400 Harness-lid
53 # 216713600 Buzzer,alarm
55 216164000 Housing,switch
56 216694200 Cap,sig light seal
92 5303161215 Screw,ph truss head ,8-18AB x 0.500
* 5303925098 Insulation

08/02 4
Publication No FFC20G4AW2
5995376851
CABINET

# = Fast-moving Parts 5 08/02
* = Non-Illustrated Parts
FFC20G4AW2 Publication No.
5995376851
POS. NO PART NO DESCRIPTION
1 5303208488 Latch-door
1A 216818900 support-lock
3 216502600 Plug-drain,interior
4 216073905 Plug-drain,exterior
6 216111200 Breaker,hinge side
7 216111800 Breaker,lock side
11 216110800 Breaker,white ,ends
12A 240449701 Nameplate,white
18 216707200 Knob,temp control
21 # 216714700 Control-temperature
27 216629600 Screw-hinge
28 216035300 Hinge
30 216110700 Breaker,white ,corners
59 216080300 Basket
71 5303302714 Screw,8-18x3/4 ,(2)
75 216034301 Panel-access,white
* 5303305324 Paint,touch-up ,white
* 216269500 Adapter,drain hose
CABINET

08/02 6
Publication No FFC20G4AW2
5995376851
SYSTEM

# = Fast-moving Parts 7 08/02
* = Non-Illustrated Parts
FFC20G4AW2 Publication No.
5995376851
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5303280307 Condenser
4 # 216634500 Drier-filter
5 # 216792500 Harness,electrical
22 216056400 Clip-spring mtg
27 5308002681 Grommet,compressor
28 5303212615 Support-compressor
29 # 216851800 Compressor,w/o electricals
30 216649318 Controller
32 216649100 Clamp,elec cont mtg ,compressor
42 216232700 Washer-flat
43A 5303212614 Clip-harness
47 216629600 Screw-hinge
55 # 216787800 Capacitor-run
86 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming
