Frigidaire FFU0912D User manual

Product No. FFU0912DW2
Series 134A
Color white
Volts 115
Wiring Diagram 297010200
Owner's Guide 216960000
Market North America
Energy Guide 216794707
P08F0009.EPS P08D0350.eps P08C0719.eps P08S0374.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995425922
05/01/06
(EN/SERVICE/)
365
UPRIGHT FREEZER
Model No.
FFU0912DW
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995425922 FFU0912DW2
01/05 2
DOOR

FFU0912DW2 Publication No: 5995425922
# Functional Parts 3 01/05
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216522300 Gasket-door
9 216527206 Panel-inner door, frzr
11 216564214 Panel-outer door, white
12A 216892802 Nameplate
13 08016354 Door Stop
14 5303313518 Washer, sealing
18 216140206 Handle, recessed, black
21A 08005520 Screw, door stop mtg, 4.0 x 0.7-19.7, flat hd, metric
22 216970800 Bearing, hinge, top
22A 216503200 Bearing, hinge, bottom
26 216524400 Gasket-secondary
27 5303212828 Clip, panel mtg
28 216951602 Rack-shelf, (4)
31 08009392 Gasket, white
32 5309950074 Valve, breather, door base
64 216403700 Plug-button, hole filler, door base
93 5303161215 Screw, ph truss head, 8-18AB x 0.500

Publication No: 5995425922 FFU0912DW2
01/05 4
CABINET
P08C0719
21
20
86
18
22
24
63
26
28
41
6
6
9
9
35
32
3
29
38
41
40
106

FFU0912DW2 Publication No: 5995425922
# Functional Parts 5 01/05
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
3 216502600 Plug, drain, interior
6 216604500 Breaker, hinge side
9 216603500 Breaker, top
18 216707200 Knob, temp control
20 297013800 Cover-control housing
21 # 216834500 Control-temperature
22 216823500 Clamp, cap tube, cold control
24 5300052943 Screw-clamp, truss hd cr, control
26 216503300 Ramp, door closer
28 216247400 Hinge, bottom
29 216313503 Hose-drain
32 5308005500 Drain
35 216273000 Clip, drain hose
38 216939100 Hinge-upper
40 216809000 Cover-hinge
41 216936800 Screw-hinge, 12-24x.700 HWH, btm
63 216396900 Screw, leveling foot, plastic, adjustable
86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
106 216926301 Plug, square
* 216794707 Energy Guide
* 297001701 Insulation, drain tube, 24"
* 5303305324 Paint, touch-up, white

Publication No: 5995425922 FFU0912DW2
01/05 6
SYSTEM
FRONT
BACK
11
7
3
6
3
36
13
12
1
4
35
5
P08S0374
86
29
27
34
43A
53
30
31

FFU0912DW2 Publication No: 5995425922
# Functional Parts 7 01/05
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 5303304537 Condenser
3 216847802 Trim-shelf, white, evap
4 # 216938600 Drier-filter
5 # 216987100 Harness-main
5* 216987800 Adapter-harness
6 297001600 Support-shelf, front LH
7 297001500 Support-shelf, front RH
11 216474600 Support-rear shelf
12 216225700 Grommet-spacer
13 216138900 Screw, hex sems, 8-18AB x 1.00, evap
27 5308002681 Grommet, compressor
29 216966800 Compressor, assy
30 216596800 Starter, relay
31 # 216100106 Overload Protector
34 5306594529 Sleeve-compressor
35 5303272328 Screw, Ind hex sems, 1/4-28 unfx, compressor
36 # 216940200 Evaporator, tubing assy, white
43A 216629700 Clip
53 216347800 Cover terminal, cover-comp term
86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
* 216502500 Sleeve, suction line
