Frigidaire CGMV174KF User manual

frigidaire.ca
30" Over-The-Range
Microwaves
CGMV174KF
Product Dimensions
Height 16-3/8"
Width 29-15/16"
Depth 16-3/16"
More Easy-To-Use Features
Real Stainless Steel1
Real stainless steel with a protective
coating that reduces fingerprints and
smudges so it's easy to clean.
Sensor Cooking
Microwave automatically adjusts power
levels and cooking times to perfectly cook
a variety of items, eortlessly.
Available in:
1
Select models only.
Signature Features
Stainless
(F)
SpaceWise® Rack
Our SpaceWise® Rack creates more
room so you can cook multiple dishes
at once.
One-Touch Options
Our microwaves feature easy-to-use
one-touch buttons so you can cook
chicken nuggets, baked potatoes or
popcorn with the touch of a button.
Eortless™ Reheat
Reheat almost anything with the
touch of a button.
Over 30 Options
Versatile settings include: Chicken
nuggets and snacks.

Microwaves
CGMV174KF 30" Over-The-Range
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
CGMV174K 06/11 © 2011 Electrolux Major Appliances, NA Printed in Canada
Specifications subject to change.
Accessories information available
on the web at frigidaire.ca
Features
Control/Timing System
Exterior Door Finish
Handle Design
Microwave Capacity (Cu. Ft.)
Convection
Watts (IEC-705 Test Procedure)
Interior Light
Interior Colour
Turntable Diameter
Turntable On/O
Control Lock
Clock
Touch Pad Buttons
Power Levels
Accessory Metal Rack
Microwave Control Options
Popcorn Button
Chicken Nugget Button
Baked Potato Button
Sensor Reheat Button
Snack Button
Beverage
Melt & Soften Options
Auto Reheat Options
Snack Menu Options
Auto Cook Options
Auto Defrost Options
Multi-Stage Cooking Option
Keep Warm
Add-30-Seconds
Sensor Cooking Options
Vegetable Cook Sensor
Delay Start
User Preferences
Ventilation System
Ducted/Ductless
Installation Option
Exhaust Fan (CFM)
Cooktop Light
Auto-Start Heat Sensor
Dishwasher-Safe Vent Filter
(Ductless Installation)
Power Ratings
Frequency (MHz)
Watts @ 120 Volts
Amps @ 120 Volts
Optional Accessories
36" Stainless Steel Filler Panel Kit
Specifications
Oven Interior (HxWxD)
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 120 Volts1
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
Product Dimensions
A - Height
B - Width
C - Depth
Express-Select®
Real Stainless Steel (F)
Stainless Steel
1.7
1,000
Yes
White
13"
Yes
Yes
Yes
28
High (1-9)
Yes (1)
Yes
Yes
Yes
Yes
Yes
5
8
6
Yes
Yes
Yes
5
Yes
Yes
Yes
2-Speed 180/300
2
Yes
Yes
2,450
1,640
14.2
PN # MWFILKTSS
8-7/8"x 21"x14-7/16"
Right Top Rear
120V/60Hz/15A
1.64
15
63 Lbs.
NOTE: For planning purposes only. Always consult local and national electric codes. Refer to
Product Installation Guide for detailed installation instructions on the web at frigidaire.ca.
Specifications
subject to change.
FRIGIDAIRE®
USA
•
250 Bobby Jones Expressway
•
Martinez, GA 30907
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGMV173K 12/09 © 2009 Electrolux Home Products, Inc. Printed in the U.S.A.
Microwaves
FGMV173K W/B/Q Over-The-Range
Ducted Option Specifications
• For outside ventilation.
• Exhaust duct adapter will be needed for outside ventilation, to mate
rectangular-to-round transition adapter will be needed with no less
than 6" diameter.
• For most efficient airflow exhaust, use a straight run or as few elbows
6" diameter round duct, not to exceed 140 equivalent feet.
• For horizontal installation, be sure to allow enough space between
wall studs to accommodate exhaust.
• Refer to installation instructions on web for detailed duct
preparation and converting exhaust vent blower system for exterior
exhaust ventilation.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Optional Accessories
•
•
Microwave Specifications
• Product Shipping Weight (approx.) – 60 Lbs.
•
•
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
• Amps @ 120 Volts = 14.2 Amps
• Always consult local and national electric codes.
• Grounded outlet should be located in cabinet above, with hole in base
to route power cord. Carefully follow top template instructions for
power cord clearance when installing beneath smooth, flat cabinets.
• Microwave’s exhaust ventilation system is preset to recirculate air
inside with no ducting system required. Exhausting air outside is
optional, using either vertical or horizontal ducting system. (Refer to
Ducted Option Specifications for outside ventilation.)
•
For safe and proper installation, microwave MUST be mounted to
BOTH a top cabinet AND a wall, and connected to at least one wall
stud. Can NOT be installed in island or peninsula cabinet arrangements.
• Cabinet bottom MUST be level to insure proper installation.
• Cabinet MUST be capable of supporting a total load of 110 lbs.
• Filler blocks recommended for installation when cabinet front hangs
below recessed bottom shelf.
• Minimum distance of 30" required from cooking surface to bottom
edge of top cabinet.
• Minimum distance of 66" required from floor to top of microwave.
•
Opening between cabinets MUST be 30" wide and free of obstructions.
For openings up to 36" wide, order optional 36" Filler Panel Kit to fill
in gap between unit and cabinets.
• Allow 26" minimum clearance for 90° door swing.
30" Over-the-Range Microwave w/ Side Controls
Gallery (1.7 Cu. Ft.)
C
B
A
Cutout Dimensions
Height (Min. from floor to top of unit)
Width (Min.)
Depth (Min.)
Depth (Max.)
1 For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded for
safe operation.
16-3/8"
29-15/16"
16-3/16"
66"
30"
12"
13"

Microwaves
CGMV174KF 30" Over-The-Range
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
CGMV174K 06/11 © 2011 Electrolux Major Appliances, NA Printed in Canada
Ducted Option Specifications
• For outside ventilation.
• Exhaust duct adapter will be needed for outside ventilation, to mate
with standard 3-1/4" x 10" rectangular duct. If round duct required,
rectangular-to-round transition adapter will be needed with no less
than 6" diameter.
• For most efficient airflow exhaust, use a straight run or as few elbows
as possible with a maximum duct length of 3-1/4" x 10" rectangular or
6" diameter round duct, not to exceed 140 equivalent feet.
• For horizontal installation, be sure to allow enough space between
wall studs to accommodate exhaust.
• Refer to installation instructions on web for detailed duct
preparation and converting exhaust vent blower system for exterior
exhaust ventilation.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.ca for detailed instructions.
Optional Accessories
• 36" Stainless Steel Filler Panel Kit – (PN # MWFILKTSS).
Microwave Specifications
• Product Shipping Weight (approx.) – 63 Lbs.
• Voltage Rating – 120V / 60 Hz / 15 Amps
• Connected Load (kW Rating) @ 120 Volts = 1.64 kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
• Amps @ 120 Volts = 14.2 Amps
• Always consult local and national electric codes.
• Grounded outlet should be located in cabinet above, with hole in base
to route power cord. Carefully follow top template instructions for
power cord clearance when installing beneath smooth, flat cabinets.
• Microwave’s exhaust ventilation system is preset to recirculate air
inside with no ducting system required. Exhausting air outside is
optional, using either vertical or horizontal ducting system. (Refer to
Ducted Option Specifications for outside ventilation.)
•
For safe and proper installation, microwave MUST be mounted to
BOTH a top cabinet AND a wall, and connected to at least one wall
stud. Can NOT be installed in island or peninsula cabinet arrangements.
• Cabinet bottom MUST be level to insure proper installation.
• Cabinet MUST be capable of supporting a total load of 110 lbs.
• Filler blocks recommended for installation when cabinet front hangs
below recessed bottom shelf.
• Minimum distance of 30" required from cooking surface to bottom
edge of top cabinet.
• Minimum distance of 66" required from floor to top of microwave.
•
Opening between cabinets MUST be 30" wide and free of obstructions.
For openings up to 36" wide, order optional 36" Filler Panel Kit to fill
in gap between unit and cabinets.
• Allow 26" minimum clearance for 90° door swing.
Specifications subject to change.
Accessories information available
on the web at frigidaire.ca
30" Over-the-Range Microwave w/ Side Controls
Gallery (1.7 Cu. Ft.)
16 ¾"
13
16 3/16
rear
extrusion
