Drop-In Cooktop
FPEC3085K S 30" Electric
Signature Features
Product Dimensions
Height 30-3/4"
Width 23-7/8"
Depth 25-3/8"
More Easy-To-Use Features
Large Window
Our large oven window lets you easily
see what’s inside.
Bright Oven Lighting
Our bright lighting makes it easy to see
what’s inside.
Delay Bake
Timer Function
Timed Cook Option
Auto Shut-O
As an extra safety measure, the oven
will automatically shut off after 12 hours.
Sabbath Mode (Star-K® Certified)
Available in:
Single Wall Ovens
FEB24S5A S / B 24" Electric
White
(S)
Black
(B)
Self-Cleaning
Ovens clean themselves — so you don’t
have to.
Vari-Broil™ Option
Allows you to choose between two
heat levels.
Even Baking Technology
Our latest technology ensures even
baking every time.
Ready-Select™ Controls
Easily select options or control
cooking temperature with our
easy-to-use controls.

Accessories information available
on the web at frigidaire.com
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FEB24S5A 07/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Specifications
subject to change.
Single Wall Ovens
FEB24S5A S / B 24" Electric
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
E
D
B
C
A
Spacer
Single Electric Wall Ovens
Frigidaire Baseline
Cutout Dimensions
Height (Min.)
Height (Max.)
Width (Min.)
Width (Max.)
Depth (Min.)
28-1/8"
30-1/8"
22"
22-1/4"
23-1/2"
Product Dimensions
A - Height
B - Width
C - Depth
D - Height (Wrapper)
E - Width (Wrapper)
Depth with Door Open 90˚
30-3/4"
23-7/8"
25-3/8"
28-3/32"
21-11/16"
43-3/4"
1Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC
only electrical supply with ground required on separate circuit fused on
both sides of line.
Features
Oven Control / Timing System
Window
Exterior Door Finish
Handle Design
Oven Cleaning System
Oven Controls
Bake / Broil
Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
PowerPlus™ / Quick Preheat
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Bake
Self-Clean
Rapid / Quick Clean Option
Delay Clean
Kitchen Timer
Timed Cook Option
Control Lock
Auto Oven Shuto
Oven Lock-Out
Oven Features
Capacity (Cu. Ft.)
Convection System
Oven Light
Hidden Bake Element
Rack Configuration
Baking System
Broiling System
Bake / Broil Element (Watts)
Certifications
A.D.A. Compliant
Sabbath Mode (Star-K® Certified)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 240 / 208 Volts1
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Approved for Under-Counter
Installation
Shipping Weight (Approx.)
Ready-Select™
Large
Color-Coordinated
Color-Coordinated
Self Clean
Yes /
Variable (Hi - Lo)
Yes
Yes
Yes
Yes
12 Hours
2.9
1
2 Handle Racks
Even Baking Technology
Vari-Broil™
2,100 / 3,400
Yes
16" x 17" x 18-1/2"
Left Bottom Rear
240V / 208V / 60Hz
3.4 /2.6
14.5 / 12.5
20
130 Lbs.
