Frigidaire FEB30S6FCB Instruction Manual

FEB30S6FC.eps CFEB30S7DCA.eps BFEB30S7FCA.eps DFEB30S5DCA.eps
318046237.eps
Product No. FEB30S6FCB
38254383E60S2
Series 30" single
Color stainless
Market North America
Wiring Diagram 318046237
Owner's Guide 318200943
Installation Instructions 318201514
Service Data Sheet 318047413
Timer Guide 318200189
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995477451
06/10/25
(EN/SERVICE/BJH)
377
SINGLE ELECTRIC
WALL OVEN
Model No.
FEB30S6F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995477451 FEB30S6FCB
10/06 2
CONTROL PANEL

FEB30S6FCB Publication No: 5995477451
# Functional Parts 3 10/06
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
2A 318257300 Shield, oven top
2B 318260100 Cover, box
19 318271527 Control Panel Assembly, steel/glass, stainless/black, w/touch pad
20 # 316418523 Clock/Timer, electronic, ES350W2
* 5303211311 Screw, 8 x 0.500
* 5303311306 Screw, 8-18 x 0.375, (8)

Publication No: 5995477451 FEB30S6FCB
10/06 4
BODY

FEB30S6FCB Publication No: 5995477451
# Functional Parts 5 10/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 318259204 Back, main
2 318258902 Shield, insulation, upper
6 318345207 Rack, oven
9 5303317977 Pan, broiler
10 5303317976 Insert, broiler pan
12 # 318089917 Switch, light
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
54 318222400 Housing, oven light
56 318259904 Trim, side filler, black, RH
56A 318259905 Trim, side filler, black, LH
58A 318285055 Insulation, oven wrapper
58B 318285056 Insulation, oven back
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
62 316056000 Terminal Block
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
66 # 318255600 Element, broil, 2750W
67 # 318255401 Element, bake, 3400W
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
76 318056217 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258707 Shield, insulation, lower
83 318261404 Liner, oven assy
86 318342400 Receptacle, hinge
87 318260600 Bracket, cable mtg.
89 # 318261209 Motor, latch assy
90 318259701 Trim, oven front, black, bottom
99 318256200 Bracket, side, bottom, (2)
107 318219401 Cover, fan
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
109 316136400 Blade, fan
111 316136600 Nut, fan retainer
112# 318112701 Relay
119# 318004900 Switch, thermal
125* 5303316994 Insulation, 3.81 x 3.13
125# 316415800 Motor, fan
126 3016303 Clip, insulator
127 318317100 Adapter Assembly, vent tube, w/converter

Publication No: 5995477451 FEB30S6FCB
10/06 6
BODY

FEB30S6FCB Publication No: 5995477451
# Functional Parts 7 10/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
131 318272900 Box, vent
132 318003000 Plate, shield
142 318123910 Deflector
* 5303324184 Screw, 8-18 x 5/16, black, (4)
143 318172904 Support, wire
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
219# 318003614 Thermostat, safety
219A 318003613 Thermostat, safety, 1.375" mtg, 105/120
263 316136500 Washer, flat
264 318257701 Trim, oven, black, front
272 318249401 Tube, protector
310 5304440067 Cabinet Mounting Kit
311 318246010 Bracket, cabinet mtg, (2)
311* 5304438005 Screw, 6 x 1, black
312 318246702 Tool, cabinet bracket, RH
312 318246703 Tool, cabinet bracket, LH
* # 318078542 Box & wires assy
* 318231736 Harness, wiring, main
* 5303323136 Screw ground
* 318165800 Spacer
* 5303323277 Screw, 8-18 X 13/32
* 5304436875 Screw, 8-18 X 1/2, black
* 3201861 Screw, 6 x 0.375, (4)
* 5303211311 Screw, 8 x 0.500

Publication No: 5995477451 FEB30S6FCB
10/06 8
DOOR

FEB30S6FCB Publication No: 5995477451
# Functional Parts 9 10/06
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260520 Baffle, door
7 318372000 Insulation, door, (2)
7A 318372002 Insulation, door, (2)
8 316117500 Glass, oven door, heat barrier
9 318259605 Liner, door
10 5304452028 Screw, handle mtg, 10-14 x 1/2, (2)
12 318053130 Seal, oven door, upper
13 318272188 Door Assy, glass, stainless steel, outer
17 316402403 Spacer, door glass, (2)
23 318024714 Hinge, door, (2)
24 318260301 Trim, door, black, lower
39 316270200 Handle, door, black
40 318242700 Bracket, glass holder, (2)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303300265 Screw, 8-18 X 1/2, (2)
* 5303323277 Screw, 8-18 X 13/32

Publication No: 5995477451 FEB30S6FCB
10/06 10
WIRING DIAGRAM
