Frigidaire FEB27T5ABB Instruction Manual

PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET
FEB27T5ABB FEB27T5A 37054732D1062 black North America
FEB27T5ASB FEB27T5A 37054732D1012 white North America
Publication No.
5995366357
020220
-EN/SERVICE /ECL
377
ELECTRIC
WALL OVEN
Model No.
FEB27T5A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318046112
OWNER’S GUIDE - # 318200919
TIMER INSTRUCTION SHEET - # 318200181
INSTALLATION INSTRUCTIONS - # 318201509
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917

02/02 2
Publication No. FEB27T5A
5995366357
CONTROL PANEL

# = Functional Parts 3 02/02
* = Non-Illustrated Parts
FEB27T5A Publication No.
5995366357
CONTROL PANEL
A = FEB27T5A (FEB27T5ASB)
B = FEB27T5A (FEB27T5ABB)
POS. NO PART NO DESCRIPTION
12 # 318058200 A B Thermostat,oven/non s/c ,lower
14 5303320497 A B Light/Lamp,indicator ,red ,250 V
15 5303302286 A B Support,backguard ,RH
15A 5303302287 A B Support,backguard ,LH
18 5303311208 A - End Cap,white ,RH
18 5303311231 - B End Cap,black ,RH
18A 5303311209 A - End Cap,white ,LH
18A 5303311232 - B End Cap,black ,LH
19 318179809 A - Panel,control ,white
19 318179810 - B Panel,control ,black
20 # 318012953 A - Clock/Timer,electronic ,white
20 # 318012954 - B Clock/Timer,electronic ,black
21 5303302283 A - Trim,canopy ,white ,top
21 5303300968 - B Trim,canopy ,black ,top
23 318015725 A B Bracket,clock mtg
24 # 316005607 A - Switch,rocker ,white
24 # 316005602 - B Switch,rocker ,black
32 318196644 A - Knob,thermostat ,white
32 318196645 - B Knob,thermostat ,black
42 5303318709 A - Trim,vent ,white
42 5303316983 - B Trim,vent ,black
65 318038803 A B Cover,control housing
68 5303302285 A B Housing,control
69 5303323134 A B Screw,switch mtg. ,8-32 x 0.188
78 318036900 - B Cover,oven vent ,black
78 318036901 A - Cover,oven vent ,white
99 5303316956 A - Screw,6-32 x 3/8 ,white ,(2)
99 5303307406 - B Screw,6-32 x 3/8 ,black ,(2)
100 318112200 A B Plate,mounting ,rocker switch
* 3201861 A B Screw,6 x 0.375

02/02 4
Publication No. FEB27T5A
5995366357
UPPER OVEN

# = Functional Parts 5 02/02
* = Non-Illustrated Parts
FEB27T5A Publication No.
5995366357
UPPER OVEN
A = FEB27T5A (FEB27T5ASB)
B = FEB27T5A (FEB27T5ABB)
POS. NO PART NO DESCRIPTION
2 5303300093 A B Wrapper,oven top
6 5303296873 A B Rack,oven
6B 5303299271 A B Shelf,oven
9 5303317977 A B Pan,broiler
10 5303317976 A B Insert,broiler pan
12 318089910 A B Switch,oven light ,door frame
14 # 5308011085 A B Receptacle,oven light
15 # 3201908 A B Light,oven
16 3201911 A B Cover,oven light ,glass
17 5304400195 A B Retainer,light cover
27 5303284616 A B Clip,thermo bulb mtg
37 # 316111203 A B Sensor,oven temp probe
41 5303310526 A B Cover,hinge cutout
54 5303310514 A B Housing,oven light
58A 318133738 A B Insulation,oven wrapper
58B 318133737 A B Insulation,oven back
58C 5303317714 A B Insulation,oven vent
59 5303300951 A B Tube,oven vent
62 # 5303310518 A B Terminal Block
62* 5303323144 A B Nut,10-32
66 # 5303322963 A B Element,broil
67 # 5303323865 A B Element,bake
68 5304403015 A B Support,element hanger
76 318124212 A B Front,oven
80 318192400 A B Spring,oven
81 5303323710 A B Bracket,oven
83 318089520 A B Liner,oven
86 5303310524 A B Receptacle,hinge
88 5303311222 A B Rod,latch
89 # 318095932 A B Motor,latch assy ,w/brkt & switch
89* 318120711 A B Switch
97 318066500 A B Wrapper,back & sides
123 318071442 A B Shield,insulation ,top & sides
126 3016303 A B Clip,insulator
127 5303310542 A B Adapter,vent tube ,with converter
128 5303311163 A B Bushing
129 5303311164 A B Spring
187 318013501 A B Tube,latch rod
* 08002868 A B Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
* 5303308449 A B Fastener
* 5303323136 A B Screw ground

02/02 6
Publication No. FEB27T5A
5995366357
LOWER OVEN

# = Functional Parts 7 02/02
* = Non-Illustrated Parts
FEB27T5A Publication No.
5995366357
LOWER OVEN
A = FEB27T5A (FEB27T5ASB)
B = FEB27T5A (FEB27T5ABB)
POS. NO PART NO DESCRIPTION
6 5303296873 A B Rack,oven
12 # 5301314211 A B Switch,oven light ,sm door frame
14 # 5308011085 A B Receptacle,oven light
15 # 3201908 A B Light,oven
16 3201911 A B Cover,oven light ,glass
17 5304400195 A B Retainer,light cover
27 5303284616 A B Clip,thermo bulb mtg
41 5303310526 A B Cover,hinge cutout
54 5303310514 A B Housing,oven light
56 5303302282 A - Trim,bodyside ,white ,(2)
56 5303300956 - B Trim,bodyside ,black ,(2)
58A 318133710 A B Insulation,oven wrapper
58B 318133704 A B Insulation,oven back
58C 5303317714 A B Insulation,oven vent
59 318072507 A B Tube,oven vent
66 # 5303322963 A B Element,broil
67 # 5303323865 A B Element,bake
68 5304403015 A B Support,element hanger
71 318071120 A B Shield,rear wall
76 318124206 A B Front,oven
80 318192400 A B Spring,oven
81 5303323710 A B Bracket,oven
82 5303304699 A B Shield,insulation
83 318089522 A B Liner,oven
86 5303310524 A B Receptacle,hinge
96 5303317197 A B Duct,oven vent ,assy
96A 3016325 A B Duct,oven vent ,center
96B 3016327 A B Duct,vent pipe
97 318066702 A B Wrapper,back and sides
98 318029334 A B Trim,side ,inner,RH
98A 318029335 A B Trim,side ,inner,LH
99 5303299686 A B Support,adjustable
101 318039512 A - Bracket,trim ,white
101 318039511 - B Bracket,trim ,black
103 318028701 A - Trim,base ,white
103 318028700 - B Trim,base ,black
121 318145002 A B Wrapper,base
123 318071442 A B Shield,insulation ,top & sides
126 3016303 A B Clip,insulator
127 318072800 A B Adaptor assy
141# 5303302280 A B Thermostat,safety
156 5303317198 A B Bracket,oven vent
227 5303323955 A B Clip,retainer
* # 5303320505 A B Box & wires assy
* 08002868 A B Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
* 5303211311 A B Screw,8 x 0.500
* 5303302745 A B Screw,10-16x1-1/8 ,square drive

02/02 8
Publication No. FEB27T5A
5995366357
DOOR

# = Functional Parts 9 02/02
* = Non-Illustrated Parts
FEB27T5A Publication No.
5995366357
DOOR
A = FEB27T5A (FEB27T5ASB)
B = FEB27T5A (FEB27T5ABB)
POS. NO PART NO DESCRIPTION
3 318026110 A - Trim,oven door ,white
3 318026600 - B Trim,oven door ,black
4 318210502 A - Glass,oven door ,white ,outer
4 318210503 - B Glass,oven door ,black ,outer
6 318073600 A B Shield,air wash
7 318133740 A B Insulation,oven door
8 318211700 A B Glass,oven door ,inner
9 318038601 A B Liner,door baffle ,upper oven
10 5303311217 A B Screw,handle ,door
12 318178800 A B Seal,oven door
12A# 5303316768 A B Seal,oven door
16 5303324250 A B Glass,door ,13 1/2x61/2
17 318139100 A B Spacer,glass ,upper oven
17A 318162601 A B Support,glass
18 3016263 A B Seal,rope ,upper oven
18A 318053204 A B Seal,rope ,lower oven
19 318139201 A B Collar,glass mtg
20 318014301 A - Spacer,handle ,white ,(2)
20 318014300 - B Spacer,handle ,black ,(2)
23 5303311259 A B Hinge,oven door ,(2)
23A 318024702 A B Hinge,oven door
25 318048308 A B Liner,door baffle
25A 318156606 A B Liner,oven door ,lower door
29 318014400 A B Spacer,door
31 318065102 A B Latch,door
39 316091107 A - Handle,door ,white ,oven
39 316091106 - B Handle,door ,black ,oven
54 5303308456 A B Screw,8-18 x 0.531 ,black ,door frame
59 3202113 A B Plug,button
61 5303300414 A B Spacer,cork & rubber
* 5303316982 A B Foam seal,(3)
* 08002868 A B Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box

02/02 10
Publication No. FEB27T5A
5995366357
WIRING DIAGRAM
