Frigidaire FEB27T6D User manual

FEB27T6D.eps CGLEB27T9DSC.eps BUFEB27T6DSB.eps BLFEB27T6DSB.eps
DFEB30S5DSA.eps 318046121.eps
UPPEROVEN LOWEROVEN
Low er OvenUpperOven
Clock
Keep
warm
Controls
Clear
/Off
Bake
time
Start
time
Oven
light
Timer
On/Off
STAR T
Broil
Bake Speed
clean
Speed
bake
Clean
Speed Bake O vens
Keep
warm
Controls
Clear
/Off
Bake
time
Start
time
Oven
light
STAR T
Broil
Bake Speed
clean
Speed
bake
Clean
Product No. FEB27T6DBC FEB27T6DQC FEB27T6DSC
37054781E4063 37054781E4043 37054781E4013
Series 27" double 27" double 27" double
Color black bisque white
Market North America North America North America
Wiring Diagram 318046121 318046121 318046121
Owner's Guide 318200924 318200924 318200924
Installation Instructions 318201514 318201514 318201514
Service Data Sheet 318047306 318047306 318047306
Timer Guide 318200137 318200137 318200137
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995459319
06/01/23
(EN/SERVICE/ECL)
377
DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB27T6D
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995459319 FEB27T6D
01/06 2
CONTROL PANEL

FEB27T6D Publication No: 5995459319
# Functional Parts 3 01/06
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFEB27T6D (FEB27T6DSC)
BFEB27T6D (FEB27T6DBC)
CFEB27T6D (FEB27T6DQC)
POS. NO PART NO. DESCRIPTION
2A 318257301 A B C Shield, oven top
2B 318260101 A B C Cover, box
19 318342801 A - - Control Panel Assembly, glass, white, w/touch pad
19 318342803 - B - Control Panel Assembly, glass, black, w/touch pad
19 318342802 - - C Control Panel Assembly, glass, bisque, w/touch pad
20 # 316443801 A B C Control, electronic, ES610W2, dual oven
97 316443902 A B C Board, relay, dual oven
* 318231751 A B C Harness, wiring, control-relay
* 5303211311 A B C Screw, 8 x 0.500

Publication No: 5995459319 FEB27T6D
01/06 4
UPPER OVEN

FEB27T6D Publication No: 5995459319
# Functional Parts 5 01/06
* Non-Illustrated Parts
UPPER OVEN
Model Index: AFEB27T6D (FEB27T6DSC)
BFEB27T6D (FEB27T6DBC)
CFEB27T6D (FEB27T6DQC)
POS. NO PART NO. DESCRIPTION
1 318259210 A B C Back, main
2 318258910 A B C Shield, insulation, upper
6 318262602 A B C Rack, oven, (2)
9 5303317977 A B C Pan, broiler
10 5303317976 A B C Insert, broiler pan
12 # 318089917 A B C Switch, light
14 318224000 A B C Receptacle, oven light
14* 318268099 A B C Insulation, oven light
15 5303013071 A B C Bulb/Lamp, light
16 3201911 A B C Cover, oven light, glass
17 5304400195 A B C Retainer, light cover
29 318147411 A B C Bumper, (2)
37 # 316217002 A B C Probe, oven temp
41 5303310526 A B C Cover, hinge cutout
54 318222400 A B C Housing, oven light
58A 318285060 A B C Insulation, rear & bottom, oven wrapper
58B 318285059 A B C Insulation, top & sides, oven wrapper
58D 318285058 A B C Insulation, 1/2" thick, 43 x 9.5
59 318072560 A B C Duct, oven vent
59A 318261600 A B C Bracket, vent tube
66 # 318255601 A B C Element, broil, 3400W
67 # 318255103 A B C Element, bake, 2300W
68 5304403015 A B C Support, hanger, (2), broil element
70 318259100 A B C Shield, insulation, sides, (2)
71 318260001 A B C Panel, rear box
76 318056222 A B C Front, oven
80 5303320846 A B C Plate, oven mtg
* 318249401 A B C Tube, protector
81 318192400 A B C Spring, oven
82 318258710 A B C Shield, insulation, lower
83 318261503 A B C Liner, oven assy
86 5303310524 A B C Receptacle, hinge
89 # 318261211 A B C Motor, latch assy
* # 318231750 A B C Harness, wiring, main, latch
* # 318199744 A B C Wiring Harness, latch, BAS
* # 318199746 A B C Wiring Harness, latch, NO BAS
99 318252800 A B C Support, side
* 5303300265 A B C Screw, 8-18 X 1/2, (2)
107 318219401 A B C Cover, fan
108# 318073018 A B C Motor, blower
* 08016432 A B C Screw, truss head, 8-18 x 0.375
108A 318251300 A B C Bracket, fan support
109 316136400 A B C Blade, fan
111 316136600 A B C Nut, fan retainer
119# 318004900 A B C Switch, thermal
125# 316415800 A B C Motor, fan
125* 5303316994 A B C Insulation, 3.81 x 3.13
126 318142100 A B C Washer, motor, RH, convection

Publication No: 5995459319 FEB27T6D
01/06 6
UPPER OVEN

FEB27T6D Publication No: 5995459319
# Functional Parts 7 01/06
* Non-Illustrated Parts
UPPER OVEN
Model Index: AFEB27T6D (FEB27T6DSC)
BFEB27T6D (FEB27T6DBC)
CFEB27T6D (FEB27T6DQC)
POS. NO PART NO. DESCRIPTION
127 318317100 A B C Adapter Assembly, vent tube, w/converter
131 318272900 A B C Box, vent
132 318003000 A B C Plate, shield
142 318123910 A B C Deflector
143 318172904 A B C Support, wire
163 318014111 A B C Spacer
185 318014700 A B C Spacer, oven shield, (4)
219# 318003614 A B C Thermostat, safety
263 316136500 A B C Washer, flat
264 318257711 A B C Trim, oven, black, front
310 5304440067 A B C Cabinet Mounting Kit
311 318246010 A B C Bracket, cabinet mtg, (2)
311* 5304438005 A B C Screw, 6 x 1, black
312 318246702 A B C Tool, cabinet bracket, RH
312 318246703 A B C Tool, cabinet bracket, LH
* 3201861 A B C Screw, 6 x 0.375, (4)
* 5303211311 A B C Screw, 8 x 0.500
* 5303323277 A B C Screw, 8-18 X 13/32
* 5304436875 A B C Screw, 8-18 X 1/2, black

Publication No: 5995459319 FEB27T6D
01/06 8
LOWER OVEN

FEB27T6D Publication No: 5995459319
# Functional Parts 9 01/06
* Non-Illustrated Parts
LOWER OVEN
Model Index: AFEB27T6D (FEB27T6DSC)
BFEB27T6D (FEB27T6DBC)
CFEB27T6D (FEB27T6DQC)
POS. NO PART NO. DESCRIPTION
1 318259210 A B C Back, main
2 318258910 A B C Shield, insulation, upper
6 318262602 A B C Rack, oven, (2)
12 # 318089917 A B C Switch, light
14 318224000 A B C Receptacle, oven light
14* 318268099 A B C Insulation, oven light
15 5303013071 A B C Bulb/Lamp, light
16 3201911 A B C Cover, oven light, glass
17 5304400195 A B C Retainer, light cover
29 318147411 A B C Bumper, (2)
37 # 316217002 A B C Probe, oven temp
41 5303310526 A B C Cover, hinge cutout
54 318222400 A B C Housing, oven light
56 318259912 A - - Trim, side filler, white, RH
56 318259914 - B - Trim, side filler, black, RH
56 318259916 - - C Trim, side filler, bisque, RH
56A 318259913 A - - Trim, side filler, white, LH
56A 318259915 - B - Trim, side filler, black, LH
56A 318259917 - - C Trim, side filler, bisque, LH
58A 318285060 A B C Insulation, rear & bottom, oven wrapper
58B 318285059 A B C Insulation, top & sides, oven wrapper
58D 318285058 A B C Insulation, 1/2" thick, 43 x 9.5
59 318072560 A B C Duct, oven vent
59A 318261600 A B C Bracket, vent tube
62 316056000 A B C Terminal Block
62* 5303323139 A B C Screw, 10-24 x 0.906
62* 5303323144 A B C Nut, 10-32
66 # 318255601 A B C Element, broil, 3400W
67 # 318255103 A B C Element, bake, 2300W
68 5304403015 A B C Support, hanger, (2), broil element
70 318259100 A B C Shield, insulation, sides, (2)
71 318260001 A B C Panel, rear box
71* 318340200 A B C Bracket, insul. panel
76 318056222 A B C Front, oven
80 5303320846 A B C Plate, oven mtg
* 318249401 A B C Tube, protector
81 318192400 A B C Spring, oven
82 318258710 A B C Shield, insulation, lower
83 318261503 A B C Liner, oven assy
86 5303310524 A B C Receptacle, hinge
87 318260601 A B C Bracket, cable mtg.
89 # 318261211 A B C Motor, latch assy
* # 318231750 A B C Harness, wiring, main, latch
* # 318199744 A B C Wiring Harness, latch, BAS
* # 318199746 A B C Wiring Harness, latch, NO BAS
90 318259710 A - - Trim, oven front, white, bottom
90 318259711 - B - Trim, oven front, black, bottom
90 318259712 - - C Trim, oven front, bisque, bottom

Publication No: 5995459319 FEB27T6D
01/06 10
LOWER OVEN

FEB27T6D Publication No: 5995459319
# Functional Parts 11 01/06
* Non-Illustrated Parts
LOWER OVEN
Model Index: AFEB27T6D (FEB27T6DSC)
BFEB27T6D (FEB27T6DBC)
CFEB27T6D (FEB27T6DQC)
POS. NO PART NO. DESCRIPTION
99 318256200 A B C Bracket, side, bottom, (2)
107 318219401 A B C Cover, fan
108# 318073018 A B C Motor, blower
* 08016432 A B C Screw, truss head, 8-18 x 0.375
108A 318251300 A B C Bracket, fan support
109 316136400 A B C Blade, fan
111 316136600 A B C Nut, fan retainer
119# 318004900 A B C Switch, thermal
125# 316415800 A B C Motor, fan
125* 5303316994 A B C Insulation, 3.81 x 3.13
126 318142100 A B C Washer, motor, RH, convection
127 318317100 A B C Adapter Assembly, vent tube, w/converter
142 318123910 A B C Deflector
143 318172904 A B C Support, wire
163 318014111 A B C Spacer
185 318014700 A B C Spacer, oven shield, (4)
219# 318003614 A B C Thermostat, safety
263 316136500 A B C Washer, flat
264 318257811 A B C Trim, oven, black, front
* # 318078543 A B C Box & wires assy
* 318231747 A B C Harness, wiring, main
* 3201861 A B C Screw, 6 x 0.375, (4)
* 5303211311 A B C Screw, 8 x 0.500
* 5303323277 A B C Screw, 8-18 X 13/32
* 5304436875 A B C Screw, 8-18 X 1/2, black

Publication No: 5995459319 FEB27T6D
01/06 12
DOORS

FEB27T6D Publication No: 5995459319
# Functional Parts 13 01/06
* Non-Illustrated Parts
DOORS
Model Index: AFEB27T6D (FEB27T6DSC)
BFEB27T6D (FEB27T6DBC)
CFEB27T6D (FEB27T6DQC)
POS. NO PART NO. DESCRIPTION
3 318260211 A B C Trim, oven door, black, upper
3A 318260401 A B C Trim, oven door, side, (2)
4 318261351 A - - Glass Assy., oven door, white, outer, w/trim
4 318261350 - B - Glass Assy., oven door, black, outer, w/trim
4 318261352 - - C Glass Assy., oven door, bisque, outer, w/trim
6 318260510 A B C Baffle, door
7 318285057 A B C Insulation, oven door
7A 318285061 A B C Insulation, (2)
8 318212200 A B C Glass, oven door, heat barrier
9 318259611 A B C Liner, oven door, upper
10 5304416408 A B C Screw, 10-24 x 1.750, handle mtg
12 318053125 A B C Seal, door
17 318264700 A B C Spacer, glass, (2)
23 318024722 A B C Hinge, door, (2)
29 318014402 A B C Spacer, door
39 318264501 A - - Handle, oven door, white
39 318264500 - B - Handle, oven door, black
39 318264502 - - C Handle, oven door, bisque
40 318242700 A B C Bracket, glass holder, (2)
56 5304436875 A B C Screw, 8-18 X 1/2, black
64 318165800 A B C Spacer, (2)
* 5303323277 A B C Screw, 8-18 X 13/32

Publication No: 5995459319 FEB27T6D
01/06 14
WIRING DIAGRAM
COLOR CODE/CODIGOS DE COLOR/CODE
DE COULEUR
G.-GREEN/VERDE/VERT
W.-WHITE/BLANCO/BLANC
R.-RED/ROJO/ROUGE
O.-ORANGE/NARANJA/ORANGE
Y.-YELLOW/AMARILLO/JAUNE
BR.-BROWN/MORENO/BRUN
BL.-BLUE/AZUL/BLEU
BK.-BLACK/NEGRO/NOIR
318046121 REV:B
CAUTION: DISCONNECT POWER BEFORE SERVICING UNIT.
ATENCION:CORTAR EL CORIENTE ANTES DE REALIZAR ELMANTENIMIENTO DEL ELECTRODOMESTICO.
ATTENTION:COUPEZ L`ALIMENTATION AVANT D`EFFECTUER LA REPARATION.
TERMINAL BLOCK
BLOQUE DE CONEXION
BLOC DE CONNECTION
L2
N
L1
BK-7
OR/O/OU
(BK-8)*
W-5
J3
ELECTRONIC OVEN CONTROL/CONTROL
DE HORNO ELECTRONICO/
COMMANDE FOUR ELECTRONIQUE
ES 610/615
DLB IN
DLB OUT
CONV.
BAKE
BROIL
J5
1
BROIL ELEMENT/
ELEMENTO DE
ASADO/ELEMENT
GRIL
BL-6 OR/O/OU (BL-8)*
BAKE ELEMENT/ELEMENTO
DE HORNO/ELEMENT
CUISSON
Y-6
Y-6
t
V-14
V-14
LATCH MOTOR/MOTOR DE
CERROJO/MOTEUR VERROU
BK-5
BR-5
DOOR SWITCH/INTERRUPTOR DE
PUERTA/INTERRUPTEUR DE PORTE
SW.A
SEE LEGEND/
VER LEYENDA/
VOIR LEGENDE
THERMAL CIRCUIT BREAKER
INTERRUPTOR DE CIRCUITO
TERMICO
DISJONCTEUR THERMIQUE
TEMPERATURE PROBE/
SONDA DETEMPERATURA/
SONDE THERMIQUE
BK-14
NO
W-5
BK-14
R/W-7 OR/O/OU (R/W-8)*
OVEN CIRCUIT // CIRCUITO DE HORNO // CIRCUIT DU FOUR
BR-5
COOLING FAN/VENTILADOR DE ENFRIAMIENTO/
VENTILATEUR REFROIDISSEMENT
BK-5
BK-5
R-5
W-5
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
W-5
HIGH SPEED/ALTA VELOCIDAD/HAUTE VITESSE
R-6
OR/O/OU
(R-7)*
CODE GAUGE TEMP. C CSA UL
CODIGO MEDIDA
CODE CALIBRE
1 18 125 CL1251 3173
2 16 125 CL1251 3173
3 14 125 CL1251 3173
4 12 125 CL1251 3173
5 18 150 EXL-150 3321
6 16 150 EXL-150 3321
7 14 150 EXL-150 3321
8 12 150 EXL-150 3321
9 10 150 EXL-150 3321
10 18 200 SEW-1 3122
11 16 200 SEW-1 3122
12 12 250 3252
13 16 250 3252
14 20 150 EXL-150 3321
15 8 150 EXL-150 3321
16 8 60
17 10 60
18 10 200 SEW-1 3122
19 20 125 CL1251 3173
20 20 200 SEW-1 3122
21 22 125 CL-1251 3173
22 22 150 EXL-150 3321
23 18 200 3573
12v 12v
120v
HALOGEN/HALOGENO/
HALOGENE
SW.A
SW.A
LATCH MOTOR
MOTOR DE CERROJO
MOTEUR VERROU
W-5
1
UPPER OVEN
J7
1J2
1
J6
1
1
J1
1
DLB IN
DLB OUT
CONV.
BAKE BROIL
L1L1
LOWER OVEN J4
P6
J3
1
1
J4
1
J5
1
P10
1
P8
1
J2
1
1
P1
1
P2
C
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
CONVECTION FAN/VENTILADOR DE CONVECCION/
CONVECTION VENTILATEUR
BK-5 BK-5
BK-14
BK-14
BK-14
t
V-14
TEMPERATURE PROBE/
SONDA DETEMPERATURA/
SONDE THERMIQUE
DOOR SWITCH/INTERRUPTOR DE
PUERTA/INTERRUPTEUR DE PORTE
SW.A
SEE LEGEND/
VER LEYENDA/
VOIR LEGENDE
BK-14
NO
BK-14
C
BK-14
BK-14
LATCH MOTOR/MOTOR DE
CERROJO/MOTEUR VERROU
BK-5
BR-5
BR-5
BK-5
BK-5
R-5
W-5
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
W-5
W-5
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
CONVECTION FAN/VENTILADOR DE CONVECCION/
CONVECTION VENTILATEUR
BK-5 BK-5
BROIL ELEMENT/
ELEMENTO DE
ASADO/ELEMENT
GRIL
BAKE ELEMENT/ELEMENTO
DE HORNO/ELEMENT
CUISSON
THERMAL CIRCUIT BREAKER/
INTERRUPTOR DE CIRCUITO
TERMICO/
DISJONCTEUR THERMIQUE
CONVECTION ELEMENT/
ELEMENTO DE CONVECCION/
ELEMENT CONVECTION
V-14
OPTION
OPCION
OPTION
OPTION
OPCION
OPTION
OPTION
OPCION
OPTION
UPPER OVEN/HORNO SUPERIOR/FOUR SUPERIEUR
LOWER OVEN /HORNO INFERIOR/FOUR INFERIEUR
EXAMPLE/EJEMPLO/EXAMPLE: (R-8)*
* WHEN USING 4000 W. BROIL ELEMENT
* CUANDO SE USA 4000 W. ELEMENTO DE ASADO
* QUAND UTILISE AVEC 4000 W. ELEMENT GRILLAGE
Y-6
BL-6 OR/O/OU (BL-8)*
BL-6
OR/O/OU
(BL-7)*
R-6
OR/O/OU
(R-7)*
LOW SPEED/BAJA VELOCIDAD/BASSE VITESSE
HIGH SPEED/ALTA VELOCIDAD/HAUTE VITESSE
LOW SPEED/BAJA VELOCIDAD/BASSE VITESSE
BK-14
R-7
OR/O/OU
(R-8)*
W-5
3
C
NO
BK-8
W-6
R-8
G-8
GND
BX
OUTSIDE
EXTERIOR
EXTERIEUR
INTSIDE
INTERIOR
INTERIEUR
AUX.
Y-6
BL-6
OR/O/OU
(BL-8)*
BK-5
OPTION
OPCION
OPTION
N
AUX.
RELAY
RELE
RELAIS
TMR
DLB OUT
REL
BD
THERMAL CIRCUIT BREAKER/
INTERRUPTOR DE CIRCUITO
TERMICO/
DISJONCTEUR THERMIQUE
LEGEND/LEYENDA/LEGENDE
CONVECTION ELEMENT/ELEMENTO DE
CONVECCION/ELEMENT CONVECTION
O-6 O-6
CONVECTION ELEMENT/
ELEMENTO DE CONVECCION/
ELEMENT CONVECTION
2500 W.
350 W.
O-6
O-6
SEE LEGEND
VER LEYENDA
VOIR LEGENDE
SEE LEGEND
VER LEYENDA
VOIR LEGENDE
REL BD
COOLING FAN/VENTILADOR DE ENFRIAMIENTO/
VENTILATEUR REFROIDISSEMENT
BK/W-5
BK-5 W-5
W-5
BK-5
LOW
OV
UPR
OV
L2
IN
R-6
OR/O/OU
(R-8)*
R-6
OR/O/OU
(R-8)*
R/W-5
BK-5
