Frigidaire FEB30T5DCC Instruction Manual

FEB30T5DC.eps CGLEB27T9DSC.eps BUFEB30T5DCB.eps BLFEB30T5DCB.eps
DFEB30S5DCA.eps 318046121.eps
UPPEROVEN LOWER OVEN
Low er OvenUpper Oven
Clea n Clea n
Clock
Keep
warm
Controls
Clear
/Off
Keep
warm
Controls
Clear
/Off
Bake
tim e
Start
tim e
Se lf-C lea n in g O v e n s
Oven
ligh t
Timer
On/Off
Bake
time
Oven
ligh t
STAR T STAR T
Broil
Bake
Start
tim e
Broil
Bake
Product No. FEB30T5DCC
37054341E40S3
Series 30" double
Color stainless
Market North America
Wiring Diagram 318046121
Owner's Guide 318200924
Installation Instructions 318201514
Service Data Sheet 318047306
Timer Guide 318200137
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995459426
06/01/24
(EN/SERVICE/ECL)
377
DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB30T5D
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995459426 FEB30T5DCC
01/06 2
CONTROL PANEL

FEB30T5DCC Publication No: 5995459426
# Functional Parts 3 01/06
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
2A 318257300 Shield, oven top
2B 318260100 Cover, box
19 318342901 Control Panel Assembly, glass, black, w/touch pad
20 # 316443803 Control, electronic, ES610W1, dual oven
97 316443903 Board, relay, dual oven
* 318231751 Harness, wiring, control-relay
* 5303211311 Screw, 8 x 0.500

Publication No: 5995459426 FEB30T5DCC
01/06 4
UPPER OVEN

FEB30T5DCC Publication No: 5995459426
# Functional Parts 5 01/06
* Non-Illustrated Parts
UPPER OVEN
POS. NO PART NO. DESCRIPTION
1 318259202 Back, main
2 318258902 Shield, insulation, upper
6 318262502 Rack, oven
9 5303317977 Pan, broiler
10 5303317976 Insert, broiler pan
12 # 318089917 Switch, light
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 3201911 Cover, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
54 318222400 Housing, oven light
58A 318285055 Insulation, oven wrapper
58B 318285056 Insulation, oven back
58D 318285058 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
66 # 318255600 Element, broil, 2750W
67 # 318255401 Element, bake, 3400W
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
76 318056217 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258707 Shield, insulation, lower
83 318261403 Liner, oven assy
86 5303310524 Receptacle, hinge
89 # 318261211 Motor, latch assy
* # 318231750 Harness, wiring, main, latch
* # 318199744 Wiring Harness, latch, BAS
* # 318199746 Wiring Harness, latch, NO BAS
99 318252800 Support, side
* 5303300265 Screw, 8-18 X 1/2, (2)
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
119# 318004900 Switch, thermal
127 318317100 Adapter Assembly, vent tube, w/converter
131 318272900 Box, vent
132 318003000 Plate, shield
142 318123910 Deflector
143 318172904 Support, wire
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
219# 318003614 Thermostat, safety
264 318257701 Trim, oven, black, front
310 5304440067 Cabinet Mounting Kit
311 318246010 Bracket, cabinet mtg, (2)
311* 5304438005 Screw, 6 x 1, black
312 318246702 Tool, cabinet bracket, RH
312 318246703 Tool, cabinet bracket, LH
* 3201861 Screw, 6 x 0.375, (4)
* 5303211311 Screw, 8 x 0.500
* 5303323139 Screw, 10-24 x 0.906
* 5303323277 Screw, 8-18 X 13/32
* 5303325980 Screw, 10-32 x 0.437
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995459426 FEB30T5DCC
01/06 6
LOWER OVEN

FEB30T5DCC Publication No: 5995459426
# Functional Parts 7 01/06
* Non-Illustrated Parts
LOWER OVEN
POS. NO PART NO. DESCRIPTION
1 318259202 Back, main
2 318258902 Shield, insulation, upper
6 318262502 Rack, oven
12 # 318089917 Switch, light
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 3201911 Cover, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
54 318222400 Housing, oven light
56 318259914 Trim, side filler, black, RH
56A 318259915 Trim, side filler, black, LH
58A 318285055 Insulation, oven wrapper
58B 318285056 Insulation, oven back
58D 318285058 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
62 316056000 Terminal Block
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
66 # 318255600 Element, broil, 2750W
67 # 318255401 Element, bake, 3400W
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
71* 318340200 Bracket, insul. panel
76 318056217 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258707 Shield, insulation, lower
83 318261403 Liner, oven assy
86 5303310524 Receptacle, hinge
87 318260600 Bracket, cable mtg.
89 # 318261211 Motor, latch assy
* # 318231750 Harness, wiring, main, latch
* # 318199744 Wiring Harness, latch, BAS
* # 318199746 Wiring Harness, latch, NO BAS
90 318259701 Trim, oven front, black, bottom
90A 318259704 Trim, oven front, black, bottom
99 318256200 Bracket, side, bottom, (2)
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
119# 318004900 Switch, thermal
127 318317100 Adapter Assembly, vent tube, w/converter
142 318123910 Deflector
143 318172904 Support, wire
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
219# 318003614 Thermostat, safety
264 318257801 Trim, oven, black, front
* # 318078543 Box & wires assy
* 318231746 Harness, wiring, main
* 5303323136 Screw ground
* 3201861 Screw, 6 x 0.375, (4)
* 5303211311 Screw, 8 x 0.500
* 5303323277 Screw, 8-18 X 13/32
* 5303325980 Screw, 10-32 x 0.437
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995459426 FEB30T5DCC
01/06 8
DOORS

FEB30T5DCC Publication No: 5995459426
# Functional Parts 9 01/06
* Non-Illustrated Parts
DOORS
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260500 Baffle, door
7 318285057 Insulation, oven door
7A 318285062 Insulation, oven door
8 316117500 Glass, oven door, heat barrier
9 318259605 Liner, door
10 5304452028 Screw, handle mtg, 10-14 x 1/2, (2)
12 318053120 Seal, door, upper oven
13 318272155 Door Assy, glass, stainless steel, outer
17 316402403 Spacer, door glass, (2)
23 318024714 Hinge, door, (2)
24 318260301 Trim, door, black, lower
39 316270200 Handle, door, black
40 318242700 Bracket, glass holder, (2)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer, (2)
* 318163602 Cleaner, stainless steel
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303300265 Screw, 8-18 X 1/2, (2)
* 5303323277 Screw, 8-18 X 13/32

Publication No: 5995459426 FEB30T5DCC
01/06 10
WIRING DIAGRAM
COLOR CODE/CODIGOS DE COLOR/CODE
DE COULEUR
G.-GREEN/VERDE/VERT
W.-WHITE/BLANCO/BLANC
R.-RED/ROJO/ROUGE
O.-ORANGE/NARANJA/ORANGE
Y.-YELLOW/AMARILLO/JAUNE
BR.-BROWN/MORENO/BRUN
BL.-BLUE/AZUL/BLEU
BK.-BLACK/NEGRO/NOIR
318046121 REV:B
CAUTION: DISCONNECT POWER BEFORE SERVICING UNIT.
ATENCION:CORTAR EL CORIENTE ANTES DE REALIZAR ELMANTENIMIENTO DEL ELECTRODOMESTICO.
ATTENTION:COUPEZ L`ALIMENTATION AVANT D`EFFECTUER LA REPARATION.
TERMINAL BLOCK
BLOQUE DE CONEXION
BLOC DE CONNECTION
L2
N
L1
BK-7
OR/O/OU
(BK-8)*
W-5
J3
ELECTRONIC OVEN CONTROL/CONTROL
DE HORNO ELECTRONICO/
COMMANDE FOUR ELECTRONIQUE
ES 610/615
DLB IN
DLB OUT
CONV.
BAKE
BROIL
J5
1
BROIL ELEMENT/
ELEMENTO DE
ASADO/ELEMENT
GRIL
BL-6 OR/O/OU (BL-8)*
BAKE ELEMENT/ELEMENTO
DE HORNO/ELEMENT
CUISSON
Y-6
Y-6
t
V-14
V-14
LATCH MOTOR/MOTOR DE
CERROJO/MOTEUR VERROU
BK-5
BR-5
DOOR SWITCH/INTERRUPTOR DE
PUERTA/INTERRUPTEUR DE PORTE
SW.A
SEE LEGEND/
VER LEYENDA/
VOIR LEGENDE
THERMAL CIRCUIT BREAKER
INTERRUPTOR DE CIRCUITO
TERMICO
DISJONCTEUR THERMIQUE
TEMPERATURE PROBE/
SONDA DETEMPERATURA/
SONDE THERMIQUE
BK-14
NO
W-5
BK-14
R/W-7 OR/O/OU (R/W-8)*
OVEN CIRCUIT // CIRCUITO DE HORNO // CIRCUIT DU FOUR
BR-5
COOLING FAN/VENTILADOR DE ENFRIAMIENTO/
VENTILATEUR REFROIDISSEMENT
BK-5
BK-5
R-5
W-5
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
W-5
HIGH SPEED/ALTA VELOCIDAD/HAUTE VITESSE
R-6
OR/O/OU
(R-7)*
CODE GAUGE TEMP. C CSA UL
CODIGO MEDIDA
CODE CALIBRE
1 18 125 CL1251 3173
2 16 125 CL1251 3173
3 14 125 CL1251 3173
4 12 125 CL1251 3173
5 18 150 EXL-150 3321
6 16 150 EXL-150 3321
7 14 150 EXL-150 3321
8 12 150 EXL-150 3321
9 10 150 EXL-150 3321
10 18 200 SEW-1 3122
11 16 200 SEW-1 3122
12 12 250 3252
13 16 250 3252
14 20 150 EXL-150 3321
15 8 150 EXL-150 3321
16 8 60
17 10 60
18 10 200 SEW-1 3122
19 20 125 CL1251 3173
20 20 200 SEW-1 3122
21 22 125 CL-1251 3173
22 22 150 EXL-150 3321
23 18 200 3573
12v 12v
120v
HALOGEN/HALOGENO/
HALOGENE
SW.A
SW.A
LATCH MOTOR
MOTOR DE CERROJO
MOTEUR VERROU
W-5
1
UPPER OVEN
J7
1J2
1
J6
1
1
J1
1
DLB IN
DLB OUT
CONV.
BAKE BROIL
L1L1
LOWER OVEN J4
P6
J3
1
1
J4
1
J5
1
P10
1
P8
1
J2
1
1
P1
1
P2
C
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
CONVECTION FAN/VENTILADOR DE CONVECCION/
CONVECTION VENTILATEUR
BK-5 BK-5
BK-14
BK-14
BK-14
t
V-14
TEMPERATURE PROBE/
SONDA DETEMPERATURA/
SONDE THERMIQUE
DOOR SWITCH/INTERRUPTOR DE
PUERTA/INTERRUPTEUR DE PORTE
SW.A
SEE LEGEND/
VER LEYENDA/
VOIR LEGENDE
BK-14
NO
BK-14
C
BK-14
BK-14
LATCH MOTOR/MOTOR DE
CERROJO/MOTEUR VERROU
BK-5
BR-5
BR-5
BK-5
BK-5
R-5
W-5
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
W-5
W-5
OVEN LAMP/LUZ DE HORNO/
LAMPE DE FOUR
CONVECTION FAN/VENTILADOR DE CONVECCION/
CONVECTION VENTILATEUR
BK-5 BK-5
BROIL ELEMENT/
ELEMENTO DE
ASADO/ELEMENT
GRIL
BAKE ELEMENT/ELEMENTO
DE HORNO/ELEMENT
CUISSON
THERMAL CIRCUIT BREAKER/
INTERRUPTOR DE CIRCUITO
TERMICO/
DISJONCTEUR THERMIQUE
CONVECTION ELEMENT/
ELEMENTO DE CONVECCION/
ELEMENT CONVECTION
V-14
OPTION
OPCION
OPTION
OPTION
OPCION
OPTION
OPTION
OPCION
OPTION
UPPER OVEN/HORNO SUPERIOR/FOUR SUPERIEUR
LOWER OVEN /HORNO INFERIOR/FOUR INFERIEUR
EXAMPLE/EJEMPLO/EXAMPLE: (R-8)*
* WHEN USING 4000 W. BROIL ELEMENT
* CUANDO SE USA 4000 W. ELEMENTO DE ASADO
* QUAND UTILISE AVEC 4000 W. ELEMENT GRILLAGE
Y-6
BL-6 OR/O/OU (BL-8)*
BL-6
OR/O/OU
(BL-7)*
R-6
OR/O/OU
(R-7)*
LOW SPEED/BAJA VELOCIDAD/BASSE VITESSE
HIGH SPEED/ALTA VELOCIDAD/HAUTE VITESSE
LOW SPEED/BAJA VELOCIDAD/BASSE VITESSE
BK-14
R-7
OR/O/OU
(R-8)*
W-5
3
C
NO
BK-8
W-6
R-8
G-8
GND
BX
OUTSIDE
EXTERIOR
EXTERIEUR
INTSIDE
INTERIOR
INTERIEUR
AUX.
Y-6
BL-6
OR/O/OU
(BL-8)*
BK-5
OPTION
OPCION
OPTION
N
AUX.
RELAY
RELE
RELAIS
TMR
DLB OUT
REL
BD
THERMAL CIRCUIT BREAKER/
INTERRUPTOR DE CIRCUITO
TERMICO/
DISJONCTEUR THERMIQUE
LEGEND/LEYENDA/LEGENDE
CONVECTION ELEMENT/ELEMENTO DE
CONVECCION/ELEMENT CONVECTION
O-6 O-6
CONVECTION ELEMENT/
ELEMENTO DE CONVECCION/
ELEMENT CONVECTION
2500 W.
350 W.
O-6
O-6
SEE LEGEND
VER LEYENDA
VOIR LEGENDE
SEE LEGEND
VER LEYENDA
VOIR LEGENDE
REL BD
COOLING FAN/VENTILADOR DE ENFRIAMIENTO/
VENTILATEUR REFROIDISSEMENT
BK/W-5
BK-5 W-5
W-5
BK-5
LOW
OV
UPR
OV
L2
IN
R-6
OR/O/OU
(R-8)*
R-6
OR/O/OU
(R-8)*
R/W-5
BK-5
