OVEN CONTROL
1
OVEN CONTROL GUIDE
318200107 (9901) Rev. A
Versión en español, Si desea obtener una copia en español de este Manual,
sírvase escribir a la dirección que se incluye a continuación. Solicite la P/N
318201137.
Spanish Owner’s Guides
Frigidaire Company
P.O. Box 9061
Setting the Clock and
Minute Timer
To Set the Clock
Whentheapplianceisfirstpluggedin,orwhenthepowersupplytotheappliance
has been interrupted, "12:00" will flash in the display window.
1. Press pad C(CLOCK).
2. PressandholdpadA(HOUR)untilthecorrecthourappearsinthedisplay.(The
numbers will only count forward.)
3. Pressand hold pad B(MINUTE)untilthecorrectminutes appear inthedisplay.
To Set the Minute Timer
1. Press pad D(TIMER), "0:59" (59 MINUTES) will appear. The timer can be set
for any amount of time from 1 minute to 1 hour and 59 minutes.
2. Tosetatimemorethan59minutes,pressandreleasepadA(HOUR).Thetimer
willjumpinatthemaximum1hourand59minutes.Adjustthetimebypressing
and holding pad B(MINUTE) until the correct time appears in the display. The
minute timer will automatically start when the pad is released.
3. When the set time has passed, the control will display "0:00" and beep
continuously. Press pad C(CLOCK) to cancel the timer and return to the clock
mode.

OVEN CONTROL
2
Setting Oven Controls
Temperature Control Knob
To Bake
1. Arrange oven racks while the oven is still cool.
2. PushinandturntheTemperatureControlknobtothedesiredoventemperature.When
theovenisfirstturnedon,theovenindicatorlight(somemodels)undertheTemperature
Control knob will glow.
3. Preheattheoven for10 to12 minutesbefore baking.Preheating isnot necessarywhen
roasting, cooking casseroles or broiling most foods. When the desired temperature is
reached, the oven indicator light will go out.
4. When cooking is finished, turn the Temperature Control knob to OFF.
To Broil
1. Pull out broiler drawer.
2. Arrange oven rack while broiler is
stillcool.Forraremeats,positionthe
broiler pan closer to the burner
(upperposition).Forwell-donefoods
suchas chicken,lobstertailsorthick
cutsofmeat,positionthepanfurther
from the burner (lower position).
3. Push in and turn the Temperature
Control knob to BROIL. You may
adjusttheTemperatureControlknobdowntoavoidexcessbrowningordryingoffoods
that should be cooked to the well-done stage.
4. Place the grid on the broiler pan, and then placethe meat on the grid. DO NOT usethe
broilerpan withoutthegrid orcoverthe gridwith aluminumfoil.The exposedfatcould
ignite.
5. Push in the drawer and close the door.
6. Broil on one side until food is browned; turn and cook on the second side. Season and
serve.Note: Alwayspullthedrawerouttothestoppositionbefore turningorremoving
food.
7. When broiling is finished, turn the Temperature Control knob to OFF.
Shouldanovenfireoccur,leavetheovendoorclosedandturntheovenoff.
If the fire continues, throw baking soda on the fire or use a fire extinguisher. DO NOT put
water or flour on the fire. Flour may be explosive.
The broiler pan and its grid allow dripping
grease to drain and be kept away from the
highheatof thebroiler. DO NOT usethe pan
without its grid. DO NOT cover the grid with
foil. The exposed grease could ignite.
The temperature in the oven has been set at the factory. When first using the oven, be sure
to follow recipe times and temperatures. If you think the oven is too hot or too cool, the
temperature in the oven can be adjusted. Before adjusting, test a recipe by using a higher
or lower temperature than the recommended temperature. The baking results should help
you to decide how much of an adjustment is needed.
To Adjust Oven Temperature:
1. Check to be sure the Temperature control knob is in the OFF position.
2. Pull Temperature control knob straight off the shaft.
3. Loosen,but donotremove, thetwoscrews attheback oftheknob.Note: Ifknobdoes
not have 2 screws, it is not adjustable. There is a series of small indicator grooves. One
of these grooves is positioned next to a tiny pointer. Note the position of the pointer.
4. Toincreasethetemperature,movethepointer ina clockwisedirection. Todecrease the
temperature,movethepointerinacounterclockwisedirection.Thetemperaturecanbe
adjusted in increments of 10°F.
5. When the desired adjustment is reached, tighten both screws.
6. Toreplacetheknob, lineup theflat sidesof boththe knoband theshaft. Pushthe knob
into place. DO NOT force the Temperature Control knob onto the shaft or you may
damage the back of the knob.
Note: Once an adjustment is made, the OFF position will vary from the reference mark on
the backguard depending on the amount of adjustment.
Adjusting Oven
Temperature
Back of Control Knob
