Frigidaire FEB30T6DBB Instruction Manual

UPPER
OVENLOWE
R
OVEN
Low er OvenUpper Oven
Cl
ock
Keep
warm
Controls
Clear
/Of
f
Bake
tim e
Start
time
Oven
light
Timer
On/Off
STAR T
Broil
BakeSpeed
clean
Speed
bake
Clea n
Speed Bak e Ovens
Keep
warm
Controls
Clear
/Of
f
Bake
time
Start
time
Oven
light
STAR T
Broi
l
BakeSpeed
cl
ean
Speed
bake
Clean
Product No. FEB30T6DBB FEB30T6DQB FEB30T6DSB
37054381E4062 37054381E4042 37054381E4012
Series 30" double 30" double 30" double
Color black bisque white
Market North America North America North America
Wiring Diagram 318046119 318046119 318046119
Owner's Guide 318200924 318200924 318200924
Installation Instructions 318201514 318201514 318201514
Service Data Sheet 318047305 318047305 318047305
Timer Guide 318200132 318200132 318200132
FEB30T6D.eps CFEB30T5DSA.eps BUFEB30T6DSB.eps BLFEB30T6DSB.eps
DFEB30S5DSA.eps 318046119.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995443578
05/08/04
(EN/SERVICE/BJH)
377
DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB30T6D
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995443578 FEB30T6D
08/05 2
CONTROL PANEL

FEB30T6D Publication No: 5995443578
# Functional Parts 3 08/05
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFEB30T6D (FEB30T6DBB)
BFEB30T6D (FEB30T6DQB)
CFEB30T6D (FEB30T6DSB)
POS. NO PART NO. DESCRIPTION
2A 318257300 A B C Shield, oven top
2B 318260100 A B C Cover, box
19 318274617 A - - Control Panel Assembly, glass, black, w/touch pad
19 318274616 - B - Control Panel Assembly, glass, bisque, w/touch pad
19 318274615 - - C Control Panel Assembly, glass, white, w/touch pad
20 # 316429709 A B C Control, electronic, 5800W2, dual oven
23 318262900 A B C Bracket, control mtg., (2)
97 316429800 A B C Board, relay, dual oven
* 318231704 A B C Harness, wiring, control-relay
* 5303211311 A B C Screw, 8 x 0.500

Publication No: 5995443578 FEB30T6D
08/05 4
UPPER OVEN

FEB30T6D Publication No: 5995443578
# Functional Parts 5 08/05
* Non-Illustrated Parts
UPPER OVEN
Model Index: AFEB30T6D (FEB30T6DBB)
BFEB30T6D (FEB30T6DQB)
CFEB30T6D (FEB30T6DSB)
POS. NO PART NO. DESCRIPTION
1 318259202 A B C Back, main
2 318258900 A B C Shield, insulation, upper
6 318262502 A B C Rack, oven
9 5303317977 A B C Pan, broiler
10 5303317976 A B C Insert, broiler pan
12 # 318089917 A B C Switch, light
14 318224000 A B C Receptacle, oven light
14* 318268099 A B C Insulation, oven light
15 5303013071 A B C Bulb/Lamp, oven light
16 3201911 A B C Cover, oven light, glass
17 5304400195 A B C Retainer, light cover
29 318147411 A B C Bumper, (2)
37 # 316217002 A B C Probe, oven temp
41 5303310526 A B C Cover, hinge cutout
* 5303325980 A B C Screw, 10-32 x 0.437
54 318222400 A B C Housing, oven light
58A 318285055 A B C Insulation, oven wrapper
58B 318285056 A B C Insulation, oven back
58D 318285058 A B C Insulation, 1/2" thick, 43 x 9.5
59 318072560 A B C Duct, oven vent
59A 318261600 A B C Bracket, vent tube
66 # 318255600 A B C Element, broil, 2750W
67 # 318255401 A B C Element, bake, 3400W
68 5304403015 A B C Support, hanger, (2), broil element
70 318259100 A B C Shield, insulation, sides, (2)
71 318260007 A B C Panel, rear box
76 318056217 A B C Front, oven
80 5303320846 A B C Plate, oven mtg
81 318192400 A B C Spring, oven
82 318258707 A B C Shield, insulation, lower
83 318261404 A B C Liner, oven assy
86 5303310524 A B C Receptacle, hinge
89 # 318261202 A B C Motor, latch assy
* 318231705 A B C Harness, latch
99 318252800 A B C Support, side
* 5303300265 A B C Screw, 8-18 x 0.500, chrome, (3)
107 318219401 A B C Cover, fan
108# 318073018 A B C Motor, blower
108A 318251300 A B C Bracket, fan support
109 316136400 A B C Blade, fan
111 316136600 A B C Nut, fan retainer
119# 318004900 A B C Switch, thermal
125# 316415800 A B C Motor, fan
126 318142100 A B C Washer, motor, RH, convection
127 318317100 A B C Adapter Assembly, vent tube, w/converter
131 318272900 A B C Box, vent
132 318003000 A B C Plate, shield
142 318123910 A B C Deflector

Publication No: 5995443578 FEB30T6D
08/05 6
UPPER OVEN

FEB30T6D Publication No: 5995443578
# Functional Parts 7 08/05
* Non-Illustrated Parts
UPPER OVEN
Model Index: AFEB30T6D (FEB30T6DBB)
BFEB30T6D (FEB30T6DQB)
CFEB30T6D (FEB30T6DSB)
POS. NO PART NO. DESCRIPTION
143 318172904 A B C Support, wire/glass
163 318014111 A B C Spacer
185 318014700 A B C Spacer, oven shield, (4)
219# 318003614 A B C Thermostat, safety
263 316136500 A B C Washer, fan motor
264 318257701 A B C Trim, oven, black, front
272 318249401 A B C Tube, protector
310 5304440067 A B C Cabinet Mounting Kit
311 318246010 A B C Bracket, cabinet mtg, (2)
311* 5304438005 A B C Screw, 6 x 1, black
312 318246702 A B C Tool, cabinet bracket, RH
312 318246703 A B C Tool, cabinet bracket, LH
* 3201861 A B C Screw, 6 x 0.375, (4)
* 08016432 A B C Screw, truss head, 8-18 x 0.375
* 5303211311 A B C Screw, 8 x 0.500
* 5303323277 A B C Screw, 8-18 X 13/32
* 5304436875 A B C Screw, 8-18 X 1/2, black

Publication No: 5995443578 FEB30T6D
08/05 8
LOWER OVEN

FEB30T6D Publication No: 5995443578
# Functional Parts 9 08/05
* Non-Illustrated Parts
LOWER OVEN
Model Index: AFEB30T6D (FEB30T6DBB)
BFEB30T6D (FEB30T6DQB)
CFEB30T6D (FEB30T6DSB)
POS. NO PART NO. DESCRIPTION
1 318259202 A B C Back, main
2 318258900 A B C Shield, insulation, upper
6 318262502 A B C Rack, oven
12 # 318089917 A B C Switch, light
14 318224000 A B C Receptacle, oven light
14* 318268099 A B C Insulation, oven light
15 5303013071 A B C Bulb/Lamp, oven light
16 3201911 A B C Cover, oven light, glass
17 5304400195 A B C Retainer, light cover
29 318147411 A B C Bumper, (2)
37 # 316217002 A B C Probe, oven temp
41 5303310526 A B C Cover, hinge cutout
* 5303325980 A B C Screw, 10-32 x 0.437
54 318222400 A B C Housing, oven light
56 318259914 A - - Trim, side filler, black, RH
56 318259916 - B - Trim, side filler, bisque, RH
56 318259912 - - C Trim, side filler, white, RH
56A 318259915 A - - Trim, side filler, black, LH
56A 318259917 - B - Trim, side filler, bisque, LH
56A 318259913 - - C Trim, side filler, white, LH
58A 318285055 A B C Insulation, oven wrapper
58B 318285056 A B C Insulation, oven back
58D 318285058 A B C Insulation, 1/2" thick, 43 x 9.5
59 318072560 A B C Duct, oven vent
59A 318261600 A B C Bracket, vent tube
62 316056000 A B C Terminal Block
62* 5303323139 A B C Screw, 10-24 x 0.906
62* 5303323144 A B C Nut, 10-32
66 # 318255600 A B C Element, broil, 2750W
67 # 318255401 A B C Element, bake, 3400W
68 5304403015 A B C Support, hanger, (2), broil element
70 318259100 A B C Shield, insulation, sides, (2)
71 318260007 A B C Panel, rear box
76 318056217 A B C Front, oven
80 5303320846 A B C Plate, oven mtg
81 318192400 A B C Spring, oven
82 318258707 A B C Shield, insulation, lower
83 318261404 A B C Liner, oven assy
86 5303310524 A B C Receptacle, hinge
87 318260600 A B C Bracket, cable mtg.
89 # 318261202 A B C Motor, latch assy
* 318231705 A B C Harness, latch
90 318259701 A - - Trim, oven front, black, bottom
90 318259702 - B - Trim, oven front, bisque, bottom
90 318259700 - - C Trim, oven front, white, bottom
90A 318259704 A - - Trim, oven front, black, bottom
90A 318259705 - B - Trim, oven front, bisque, bottom
90A 318259703 - - C Trim, oven front, white, bottom

Publication No: 5995443578 FEB30T6D
08/05 10
LOWER OVEN

FEB30T6D Publication No: 5995443578
# Functional Parts 11 08/05
* Non-Illustrated Parts
LOWER OVEN
Model Index: AFEB30T6D (FEB30T6DBB)
BFEB30T6D (FEB30T6DQB)
CFEB30T6D (FEB30T6DSB)
POS. NO PART NO. DESCRIPTION
99 318256200 A B C Bracket, side, bottom, (2)
107 318219401 A B C Cover, fan
108# 318073018 A B C Motor, blower
* 08016432 A B C Screw, truss head, 8-18 x 0.375
108A 318251300 A B C Bracket, fan support
109 316136400 A B C Blade, fan
111 316136600 A B C Nut, fan retainer
119# 318004900 A B C Switch, thermal
125# 316415800 A B C Motor, fan
126 318142100 A B C Washer, motor, RH, convection
127 318317100 A B C Adapter Assembly, vent tube, w/converter
142 318123910 A B C Deflector
143 318172904 A B C Support, wire/glass
163 318014111 A B C Spacer
185 318014700 A B C Spacer, oven shield, (4)
219# 318003614 A B C Thermostat, safety
263 316136500 A B C Washer, fan motor
264 318257801 A B C Trim, oven, black, front
272 318249401 A B C Tube, protector
* # 318078543 A B C Box & wires assy
* 318231741 A B C Harness, wiring, main
* 5303323136 A B C Screw ground
* 3201861 A B C Screw, 6 x 0.375, (4)
* 5303211311 A B C Screw, 8 x 0.500
* 5303323277 A B C Screw, 8-18 X 13/32
* 5304436875 A B C Screw, 8-18 X 1/2, black

Publication No: 5995443578 FEB30T6D
08/05 12
DOORS

FEB30T6D Publication No: 5995443578
# Functional Parts 13 08/05
* Non-Illustrated Parts
DOORS
Model Index: AFEB30T6D (FEB30T6DBB)
BFEB30T6D (FEB30T6DQB)
CFEB30T6D (FEB30T6DSB)
POS. NO PART NO. DESCRIPTION
3 318260201 A B C Trim, oven door, black, upper
3A 318260401 A B C Trim, oven door, side, (2)
4 318261300 A - - Glass Assy., oven door, black, outer, w/trim
4 318261302 - B - Glass Assy., oven door, bisque, outer, w/trim
4 318261301 - - C Glass Assy., oven door, white, outer, w/trim
6 318260500 A B C Baffle, door
7 318285057 A B C Insulation, oven door
7A 318285062 A B C Insulation, oven door
8 316117500 A B C Glass, oven door, heat barrier
9 318259601 A B C Liner, oven door
10 5304416408 A B C Screw, 10-24 x 1.750, handle mtg
12 318053130 A B C Seal, oven door
17 316402403 A B C Spacer, door glass, (2)
23 5303310828 A B C Hinge, oven door, (2)
29 318014402 A B C Spacer, door
39 318231200 A - - Handle, black
39 316203003 - B - Handle, door, bisque
39 316203001 - - C Handle, door, white
40 318242700 A B C Bracket, glass holder, (2)
56 5304436875 A B C Screw, 8-18 X 1/2, black
64 318165800 A B C Spacer, (2)
* 5303323277 A B C Screw, 8-18 X 13/32

Publication No: 5995443578 FEB30T6D
08/05 14
WIRING DIAGRAM
