Frigidaire FEB756CE User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FEB756CESE 38254731E6015 WHITE U.S.A.
FEB756CESF 38254731E6016 WHITE U.S.A.
FEB756CEBE 38254731E6065 BLACK U.S.A.
FEB756CEBF 38254731E6066 BLACK U.S.A.
FEB756CETE 38254731E6035 ALMOND U.S.A.
FEB756CETF 38254731E6036 ALMOND U.S.A.
ELECTRIC WALL OVEN
Model No.
FEB756CE
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ELECTRIC WALL OVEN
WIRING DIAGRAM MODELS A, C, E #- 318046002
WIRING DIAGRAM MODELS B, D, F #-318046207
OWNER’S GUIDE MODELS #- 318008802
INSTALLATION INSTR. # - 318064300
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA, L5T 1K6
TEL: [phone]
Publication No.
5995317194
990121
-EN/SERVICE
377

Publication No. FEB756CE
5995317194
01/99 2
CONTROL PANEL
80
20
68
23
101
101
65
LAP23G0039A
42
21
19
18
15
15A
18A
78
99

FEB756CE Publication No.
5995317194
# = Functional Part 301/99
* = Non-Illustrated Part
CONTROL PANEL
A=FEB756CE (FEB756CESE)
B=FEB756CE (FEB756CESF)
C=FEB756CE (FEB756CEBE)
D = FEB756CE (FEB756CEBF)
E = FEB756CE (FEB756CETE)
F = FEB756CE (FEB756CETF)
POS. NO PART NO DESCRIPTION
15 5303302286 A B CD E F Support backguard RH
15A 5303302287 A B CD E F Support backguard LH
18 5303311208 A B End Cap RH white
18 5303311231 C D End Cap RH black
18 5303311225 E F End Cap RH almond
18A 5303311209 A B End Cap LH white
18A 5303311232 C D End Cap LH black
18A 5303311226 E F End Cap LH almond
19 318030013 A B Panel-control white
19 318030012 C D Panel-control black
19 318030018 E F Panel-control almond
20 # 318010900 A B C D E F Clock/Timer
21 5303311212 A B Trim-canopy white
21 5303301310 C D Trim-canopy black
21 5303311227 E F Trim-canopy almond
23 318111602 A B CD E F Bracket timer
42 5303318709 A B Trim-vent white
42 5303316983 C DTrim-vent black
42 5303318712 E F Trim-vent almond
65 5303302386 ACE Cover-control housing
65 318038800 BD F Cover-control housing
68 5303302285 A B CD E F Housing control
78 5303302394 A B Cover, oven vent white
78 5303302396 C D Cover, oven vent black
78 5303302395 E F Cover, oven vent almond
80 318111500 A B CD E F Relay (9 Volts)
99 5303316956 A B Screw, 6-32 X 3/8, white
99 5303307406 C DScrew, 6-32 X 3/8, black
99 5303317307 E F Screw, 6-32 X 3/8, almond
101 5303302412 A B CD E F Shield backsplash
*5303211311 A B CScrew #8 X ½
*3201861 A B CScrew, 6 X 3/8

FEB756CE Publication No.
5995317194
01/99 4
CAVITY / ELEMENTS
118
58B
59
126
58C
89A 62
LA9923V04
6
6B
67
98
98A
56
56
68
103
101
66
83
127
99
141
99231
14 15 16
17
80
80
71
76
88
2
97 18
91
91A
92
89
10
41
54
41
81
86
86
9
37
12
189
82
121
123
58A

FEB756CE Publication No.
5995317194
# = Functional Part 501/99
* = Non-Illustrated Part
CAVITY / ELEMENTS
A=FEB756CE (FEB756CESE)
B=FEB756CE (FEB756CESF)
C=FEB756CE (FEB756CEBE)
D = FEB756CE (FEB756CEBF)
E = FEB756CE (FEB756CETE)
F = FEB756CE (FEB756CETF)
POS. NO PART NO DESCRIPTION
2 5304402380 A B CD E F Cover-top
6 5303296873 A B CD E F Rack-oven
6B 5303299271 A B CD E F Shelf-oven
95303317977 A B CD E F Pan-broiler
10 5303317976 A B CD E F Insert broiler pan
12# 318089900 ACE Switch-light
12 318089910 BD F Switch-light
14 08011171 AC E Socket-light/lamp
14 5308011085 BD F Socket-light/lamp
15 3201908 A B CD E F Lamp-oven light
16 3201911 A B CD E F Glass-oven light lens
17 5304400195 A B CD E F Retainer-lens
18 3051648 A B CD E F Latch door
37# 316111201 A B CD E F Probe-oven temp
41 3019063 A B CD E F Retainer door
54 5303310514 BD F Housing-oven light
56 5303302711 A B Trim-bodyside white
56 5303298951 C D Trim-bodyside black
56 5303302712 E F Trim-bodyside almond
58A 5304400957 A B CD E F Insulation wrapper
58B 3019048 A B CD E F Insulation oven back
58C 5303311220 A B CD E F Insulation oven vent
59 318072507 A B CD E F Tube-oven vent
62# 5303310518 A B CD E F Terminal block
66# 5303322963 A B CD E F Element-broil
67# 5303323865 A B CD E F Element-bake
68 5304403015 A B CD E F Support-element
71 5303304701 A B CD E F Shield-wire
76 318124200 A B CD E F Front-oven
80 5303301261 A B CD E F Spring-oven
81 5303323710 A B CD E F Bracket-oven
82 5303304699 A B CD E F Shield-insulation bottom
83 318089518 A B CD E F Liner-oven assy
86 3201631 A B CD E F Channel-hinge
88 3016241 A B CD E F Rod-latch
89# 5303269766 ACE Motor-latch/lock
89# 318095800 BD F Motor-latch/lock
89A 3016296 A B CD E F Cover-Motor
91 3019069 A B CD E F Housing-latch
91A 3051647 A B CD E F Housing-latch
92 5308012004 A B CD E F Stud-axle
97 5303300980 ACE Wrapper-back & sides
97 318066701 B D F Wrapper-back & sides
98 5303298952 AC E Trim side inner RH
98 318029322 BD F Trim side inner RH
98A 5303298953 AC E Trim side inner LH
98A 318029323 BD F Trim side inner LH
99 5303299686 A B CD E F Support-adjustable
101 318039512 A B Bracket-trim
101 318039511 C D Bracket-trim
101 318039513 E F Bracket-trim
103 318028701 A B Trim-base white
103 318028700 C D Trim-base black
103 318028702 E F Trim-base almond
118 5303308461 A B CD E F Bracket-latch
121 318145002 A B CD E F Wrapper-base
123 5303299270 AC E Shield-insulation top & sides
123 318071430 BD F Shield-insulation top & sides
126 3016303 A B CD E F Clip-insulator retainer
127 5303310542 A B CD E F Adapter assy
141# 5303302280 A B CD E F Thermostat-safety
189 318042500 A B CD E F Retainer plate
231 5303300421 A B CD E F Cover-capillary
*08002868 A B CD E F Screw, 10-24 X ½
*5303320422 A B CD E F Screw, 6-20 X 5/16
*5303211311 A B CD E F Screw, #8 X ½
*5303308456 A B CD E F Screw, 8-18 X 0.531
*5303935083 A B Screw, 10-16 X 1 ¼, white
*5303302745 A B CD E F Screw, 10-16 X 1 1/8. Black
*5303325188 E F Screw, 10-16 X 1 ¼, almond

FEB756CE Publication No.
5995317194
01/99 6
DOOR
3
23
17
19
16
16 23
9
25
6
7
39
LA9923D03
20
4
20
29
29
12
18
11
10

FEB756CE Publication No.
5995317194
# = Functional Part 701/99
* = Non-Illustrated Part
DOOR
A=FEB756CE (FEB756CESE)
B=FEB756CE (FEB756CESF)
C=FEB756CE (FEB756CEBE)
D = FEB756CE (FEB756CEBF)
E = FEB756CE (FEB756CETE)
F = FEB756CE (FEB756CETF)
POS. NO PART NO DESCRIPTION
3 318026110 A B Trim-oven door white
3318026600 C D Trim-oven door black
3318026111 E F Trim-oven door almond
4 5303302279 A B Glass-oven door white
4 5304401679 C D Glass-oven door black
45303303595 E F Glass-oven door almond
6 318073600 A B CD E F Shield-air wash
7 5303308470 A B CD E F Insulation oven door
9318038601 A B CD E F Liner-door baffle
10 5303311217 A B CD E F Screw-handle door
11 5303294969 A B CD E F Strike plate
12# 3206270 A B CD E F Seal-oven door
16 5303324250 A B CD E F Glass-oven door
17 318139100 A B CD E F Spacer-glass upper
18 3016263 A B CD E F Seal-rope upper oven
19 318139201 A B CD E F Collar glass mtg
20 318014301 A B Spacer-handle white
20 318014300 C D Spacer-handle black
20 318014302 E F Spacer-handle almond
23 318074101 A B CD E F Hinge-oven door
25 318048301 A B CD E F Liner-oven door
29 5303210003 A B CD E F Spacer-handle mtg (2)
39 316091107 A B Handle-door white
39 316091106 C D Handle-door black
39 316091108 E F Handle-door almond
*3202113 A B CD E F Button plug
*5303308456 A B CD E F Screw, 8-18 X 0.531
*5303325981 A B CD E F Screw, 10-16 X 1 ½
*5303211311 A B CD E F Screw, #8 X ½
*3051070 A B CD E F Screw, 10-24 X 7/16
*5303323277 A B CD E F Screw, 8-18 X 13/32

Publication No. FEB756CE
5995317194
01/99 8
WIRING DIAGRAM
