Frigidaire FFEW2425LS User manual

frigidaire.com
Drop-In Cooktop
FPEC3085K S 30" Electric
Signature Features
24" Electric
Single Wall Oven
FFEW2425L S
Product Dimensions
Height 30-3/4"
Width 23-7/8"
Depth 25-3/8"
More Easy-To-Use Features
Large Window
Our large oven window lets you easily
see what’s inside.
Bright Oven Lighting
Our bright lighting makes it easy to see
what’s inside.
Delay Bake
Timer Function
Timed Cook Option
Auto Shut-O
As an extra safety measure, the oven
will automatically shut off after 12 hours.
Attractive Stainless Steel
Exterior
Available in:
Stainless
(S)
Self-Cleaning
Ovens clean themselves — so you don’t
have to.
Vari-Broil™ Option
Allows you to choose between two
heat levels.
Even Baking Technology
Our latest technology ensures even
baking every time.
Ready-Select® Controls
Easily select options or control
cooking temperature with our
easy-to-use controls.

Accessories information available
on the web at frigidaire.com
Single Wall Oven
FFEW2425L S 24" Electric
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFEW2425L 01/11 © 2011 Electrolux Home Products, Inc. Printed in the U.S.A.
Specifications
subject to change.
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
E
D
B
C
A
Spacer
Single Electric Wall Ovens
Frigidaire Baseline
Cutout Dimensions
Height (Min.)
Height (Max.)
Width (Min.)
Width (Max.)
Depth (Min.)
28-1/8"
30-1/8"
22"
22-1/4"
23-1/2"
Product Dimensions
A - Height
B - Width
C - Depth
D - Height (Wrapper)
E - Width (Wrapper)
Depth with Door Open 90˚
30-3/4"
23-7/8"
25-3/8"
28-3/32"
21-11/16"
43-3/4"
1Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC
only electrical supply with ground required on separate circuit fused on
both sides of line.
Features
Oven Control / Timing System
Window
Exterior Door Finish
Handle Design
Oven Cleaning System
Oven Controls
Bake / Broil
Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
PowerPlus™ / Quick Preheat
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Bake
Self-Clean
Rapid / Quick Clean Option
Delay Clean
Kitchen Timer
Timed Cook Option
Control Lock
Auto Oven Shuto
Oven Lock-Out
Oven Features
Capacity (Cu. Ft.)
Convection System
Oven Light
Hidden Bake Element
Rack Configuration
Baking System
Broiling System
Bake / Broil Element (Watts)
Certifications
A.D.A. Compliant
Sabbath Mode (Star-K® Certified)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 240 / 208 Volts1
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Approved for Under-Counter
Installation
Shipping Weight (Approx.)
Ready-Select®
Large
Stainless Steel
Black
Self Clean
Yes /
Variable (Hi - Lo)
Yes
Yes
2, 3 Hours
Yes
Yes
12 Hours
2.9
1
2 Handle Racks
Even Baking Technology
Vari-Broil™
2,100 / 3,400
16" x 17" x 18-1/2"
Left Bottom Rear
240V / 208V / 60Hz
3.4 /2.6
14.5 / 12.5
20
130 Lbs.

Accessories information available
on the web at frigidaire.com
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE •frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFEW2425L 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Specifications
subject to change.
24" Single Electric Wall Ovens
Baseline
Single Wall Oven
FFEW2425L S 24" Electric
Single Wall Oven Specifications
•Product Shipping Weight (approx.) – 130 Lbs.
•Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit
fused on both sides of line.
•Connected Load (kW Rating) @ 240 / 208 Volts = 3.4 / 2.6 kW
•Amps @ 240 / 208 Volts = 14.5 / 12.5 Amps
•Recommended Circuit Breaker – 20 Amps
•Always consult local and national electric codes.
•Minimum 19-3/8" clearance for oven door depth when open.
•Minimum required distance from floor is 31".
•Minimum 23-1/2" deep cutout dimension is critical for proper
installation, to ensure that oven’s faceplate will fit flush against
cabinet front.
•To adapt oven to fit cutout height greater than 28-1/8", add one
2"-wide wood shim of appropriate height to each side of opening
under oven side rails. Lifting oven will hide larger cutout opening at
top and oven’s bottom trim will hide shims at bottom.
•Full oven base of solid plywood or similar material required,
capable of supporting 150 Lbs.
•Base must be level and cabinet front must be square.
•Single Wall Oven is NOT approved to be used in stackable or
side-by-side installation.
•Single Wall Oven is NOT approved to be used in under-counter
installation.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_TMR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with Top Mount Refrigerator

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_SSR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
General Installation Guidelines
with Side-by-Side Refrigerator
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
