Frigidaire FEB30T5DCA Instruction Manual

FEB30T5DC.eps CFEB30T5DSA.eps BUFEB30T5DSA.eps BLFEB30T5DSA.eps
DFEB30S5DCA.eps 318046116.eps
UPPEROVEN LOWER OVEN
Low er OvenUpper Oven
Clea n Clea n
Clock
Keep
warm
Controls
Clear
/Off
Keep
warm
Controls
Clear
/Off
Bake
tim e
Start
tim e
Se lf-C lea n in g O v e n s
Oven
ligh t
Timer
On/Off
Bake
time
Oven
ligh t
STAR T STAR T
Broil
Bake
Start
tim e
Broil
Bake
Product No. FEB30T5DCA
37054341E40S1
Series 30" double
Color stainless
Market North America
Wiring Diagram 318046116
Owner's Guide 318200924
Installation Instructions 318201514
Service Data Sheet 318047305
Timer Guide 318200132
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995420527
04/11/01
(EN/SERVICE/ECL)
377
DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB30T5D
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995420527 FEB30T5DCA
11/04 2
CONTROL PANEL

FEB30T5DCA Publication No: 5995420527
# Functional Parts 3 11/04
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
2A 318257300 Shield, oven top
2B 318260100 Cover, box
19 318274613 Control Panel Assembly, glass, black, w/ touch pad
20 # 316429706 Control, electronic, 5800W1, dual oven
* 316021107 Screw, hex head, 8-32, silver
23 318262900 Bracket, control mtg., (2)
97 316429800 Board, relay, dual oven
* 318231704 Harness, wiring, control-relay
* 5303211311 Screw, 8 x 0.500

Publication No: 5995420527 FEB30T5DCA
11/04 4
UPPER OVEN

FEB30T5DCA Publication No: 5995420527
# Functional Parts 5 11/04
* Non-Illustrated Parts
UPPER OVEN
POS. NO PART NO. DESCRIPTION
1 318259200 Back, main
2 318258900 Shield, insulation, upper
6 318262502 Rack, oven
9 5303317977 Pan, broiler
10 5303317976 Insert, broiler pan
12 # 318089917 Switch, light
* 3015722 Clip, wire retainer
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, oven light
16 3201911 Cover, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, door, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
* 5303325980 Screw, 10-32 x 0.437
54 318222400 Housing, oven light
58A 318133791 Insulation, oven wrapper, back/bottom
58B 318133790 Insulation, oven wrapper, top/sides
58D 318133793 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
66 # 318255600 Element, broil, 2750W
67 # 318255401 Element, bake, 3400W
68 5304403015 Support, element hanger
70 318259100 Shield, insulation, sides, (2)
71 318260004 Panel, rear box
76 318056217 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258700 Shield, insulation, lower
83 318261403 Liner, oven assy
86 5303310524 Receptacle, hinge
89# 318261200 Motor, latch assy
* 318231705 Harness, latch
99 318252800 Support, side
* 5303300265 Screw, 8-18 x 0.500, chrome, (3)
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
112# 318112701 Relay
119# 318004900 Switch, thermal
127 5303310542 Adapter, vent tube, with converter
131 318272900 Box, vent
132 318003000 Plate, shield
142 318123910 Deflector
143 318172904 Support, wire/glass
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
219# 318003606 Thermostat, safety
264 318257701 Trim, oven, black, front
310 5304440067 Cabinet Mounting Kit
311 318246010 Bracket, cabinet mtg, (2)
311* 5304438005 Screw, 6 x 1, black
312 318246702 Tool, cabinet bracket, RH
312 318246703 Tool, cabinet bracket, LH
* 3201861 Screw, 6 x 0.375, (4)
* 5303211311 Screw, 8 x 0.500
* 5303323139 Screw, 10-24 x 0.906
* 5303323277 Screw, 8-18 X 13/32
* 5304415832 Screw, 8-18 x 0.406
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995420527 FEB30T5DCA
11/04 6
LOWER OVEN

FEB30T5DCA Publication No: 5995420527
# Functional Parts 7 11/04
* Non-Illustrated Parts
LOWER OVEN
POS. NO PART NO. DESCRIPTION
1 318259200 Back, main
2 318258900 Shield, insulation, upper
6 318262502 Rack, oven
12 # 318089917 Switch, light
* 3015722 Clip, wire retainer
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, oven light
16 3201911 Cover, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, door, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
* 5303325980 Screw, 10-32 x 0.437
54 318222400 Housing, oven light
56 318259914 Trim, side filler, black, RH
56A 318259915 Trim, side filler, black, LH
58A 318133791 Insulation, oven wrapper, back/bottom
58B 318133790 Insulation, oven wrapper, top/sides
58D 318133793 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
62 316056000 Terminal Block
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
66 # 318255600 Element, broil, 2750W
67 # 318255401 Element, bake, 3400W
68 5304403015 Support, element hanger
70 318259100 Shield, insulation, sides, (2)
71 318260004 Panel, rear box
76 318056217 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258700 Shield, insulation, lower
83 318261403 Liner, oven assy
86 5303310524 Receptacle, hinge
87 318260602 Bracket, cable mtg.
89# 318261201 Motor, latch assy
* 318231705 Harness, latch
90 318259701 Trim, oven front, black, bottom
90A 318259704 Trim, oven front, black, bottom
99 318256200 Bracket, side, bottom, (2)
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
112# 318112701 Relay
119# 318004900 Switch, thermal
127 5303310542 Adapter, vent tube, with converter
142 318123910 Deflector
143 318172904 Support, wire/glass
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
219# 318003606 Thermostat, safety
264 318257801 Trim, oven, black, front
* # 318078543 Box & wires assy
* 318231708 Harness, wiring, main
* 5303323136 Screw ground
* 3201861 Screw, 6 x 0.375, (4)
* 5303211311 Screw, 8 x 0.500
* 5303323277 Screw, 8-18 X 13/32
* 5304415832 Screw, 8-18 x 0.406
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995420527 FEB30T5DCA
11/04 8
DOOR

FEB30T5DCA Publication No: 5995420527
# Functional Parts 9 11/04
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260500 Baffle, door
7 318133792 Insulation, oven door
7A 318133797 Insulation, oven door, cavity
8 316117500 Glass, oven door, heat barrier
9 318259605 Liner, oven door, upper
10 5303311174 Screw, 10-24 x 3/8
12 318053120 Seal, oven door
13 318272151 Door Assy, stainless steel, outer, w/tape & foil
17 316402403 Spacer, door glass, (2)
23 318024714 Hinge, oven door
24 318260301 Trim, door, black, lower
39 318231200 Handle, black
40 318242700 Bracket, glass holder, (2)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer, (4)
* 318163602 Cleaner, stainless steel
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303300265 Screw, 8-18 x 0.500, chrome, (3)
* 5303323277 Screw, 8-18 X 13/32

Publication No: 5995420527 FEB30T5DCA
11/04 10
WIRING DIAGRAM
