Frigidaire FEB30T5GCC User manual

FEB30T6FC.tif CPLEB30T9FCA.eps BUFEB30T5GCC.eps BLFEB30T5GCC.eps
DCFEB30S5GC2.eps 318046123.eps
Product No. FEB30T5GCC
37054343E70S3
Series 30" double
Color stainless
Market North America
Wiring Diagram 318046123
Owner's Guide 318205115
Installation Instructions 318201514
Service Data Sheet 318047309
Timer Guide 318200129
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995536165
09/03/24
(EN/SERVICE/ECL)
377
30” DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB30T5G
Copyright ©2009 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995536165 FEB30T5GCC
03/09 2
CONTROL PANEL

FEB30T5GCC Publication No: 5995536165
# Functional Parts 3 03/09
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
2A 318257300 Shield, oven top
2B 318260100 Cover, box
19 318271544 Control Panel Assembly, steel/glass, stainless/black, w/touch pad
20 # 316443833 Control, electronic, ES610W1, dual oven
20* 5303311306 Screw, 8-18 x 0.375, (6)
77 316247900 Spacer, power board
77A 316114100 Spacer
97 316443913 Board, relay, dual oven
* # 318370374 Wiring Harness, timer, to relay board
* 5303211311 Screw, 8 x 0.500

Publication No: 5995536165 FEB30T5GCC
03/09 4
UPPER OVEN
119
108
108A
70
185
71
81
163
163
81
1
80
58B
264
99
37
76
29
29 127
86
86
58A
82 BUFEB30T5GCC
99
185
70
2
12
83
59
59A
10
9
131
132
89
58D
143
67
66
68
54
14
15
16
17
142
6
6

FEB30T5GCC Publication No: 5995536165
# Functional Parts 5 03/09
* Non-Illustrated Parts
UPPER OVEN
POS. NO PART NO. DESCRIPTION
1 318259220 Back, main
2 318258902 Shield, insulation, upper
6 318345207 Rack, oven
9 5303317977 Pan, broilerOPTIONAL ACCESS0RY
10 5303317976 Insert, broiler panOPTIONAL ACCESS0RY
12 316445501 Switch, oven light, door frame
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 316517600 Spacer, oven door
37 # 316217002 Probe, oven temp
54 318222400 Housing, oven light
58A 318386100 Insulation, oven wrapper
58B 318133791 Insulation, oven back, back/bottom
58D 318372006 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
66 # 318255600 Element, broil, 2750W
67 # 318255401 Element, bake, 3400W
68 5304403015 Support, hanger, (4), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
71* 318340201 Bracket, insul. panel
76 318056292 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258707 Shield, insulation, lower
83 318261403 Liner, oven assy
86 318561100 Receptacle, hinge, (2)
89 # 318261215 Motor, latch assy
* # 318402206 Wiring Harness, main, latch
* # 318199746 Wiring Harness, latch, NO BAS
* # 318199768 Wiring Harness, latch, BAS
99 318252804 Support, side
108# 318073028 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
119# 318004900 Switch, thermal
127 318317100 Adapter Assembly, vent tube, w/converter
131 318272901 Box, vent
132 318003000 Plate, shield
142 318123910 Deflector
143 318172904 Support, wire
163 318531703 Spacer, (4)
185 318531800 Spacer, oven shield, (2)
264 318257701 Trim, oven, black, front
* 318165800 Spacer
* 5303211311 Screw, 8 x 0.500
* 5303300265 Screw, 8-18 X 1/2, (4)
* 5303323277 Screw, 8-18 X 13/32
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995536165 FEB30T5GCC
03/09 6
LOWER OVEN
143
119
108
108A
70
185
71
81
163
163
81
87
1
62
80
142
58B
264
99
56A
76
29
29 127
86 56
86
90
58A
82 BLFEB30T5GCC
99
185
70
2
12
83
59
59A
37
89
58D
67
66
68
54
14
15
16
17
6
6

FEB30T5GCC Publication No: 5995536165
# Functional Parts 7 03/09
* Non-Illustrated Parts
LOWER OVEN
POS. NO PART NO. DESCRIPTION
1 318259220 Back, main
2 318258902 Shield, insulation, upper
6 318345207 Rack, oven
12 316445501 Switch, oven light, door frame
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 316517600 Spacer, oven door
37 # 316217002 Probe, oven temp
54 318222400 Housing, oven light
56 318903604 Trim, side filler, black, RH
56A 318903605 Trim, side filler, black, LH
58A 318386100 Insulation, oven wrapper
58B 318133791 Insulation, oven back, back/bottom
58D 318372006 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
62 316056000 Terminal Block
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
66 # 318255600 Element, broil, 2750W
67 # 318255401 Element, bake, 3400W
68 5304403015 Support, hanger, (4), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
71* 318340201 Bracket, insul. panel
76 318056292 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258707 Shield, insulation, lower
83 318261403 Liner, oven assy
86 318561100 Receptacle, hinge, (2)
87 318260600 Bracket, cable mtg.
89 # 318261215 Motor, latch assy
* # 318402206 Wiring Harness, main, latch
* # 318199746 Wiring Harness, latch, NO BAS
* # 318199768 Wiring Harness, latch, BAS
90 318259701 Trim, oven front, black, bottom
99 318256201 Bracket, side, bottom, (2)
108# 318073028 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
119# 318004900 Switch, thermal
127 318317100 Adapter Assembly, vent tube, w/converter
142 318123910 Deflector
143 318172904 Support, wire
163 318531703 Spacer, (4)
185 318531800 Spacer, oven shield, (2)
264 318257801 Trim, oven, black, front
* # 318394442 Box & wires assy
* # 318370302 Wiring Harness, main
* 318165800 Spacer
* 5303211311 Screw, 8 x 0.500
* 5303323136 Screw ground
* 5303323277 Screw, 8-18 X 13/32
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995536165 FEB30T5GCC
03/09 8
DOORS
4142
56
56
56
56
3A
3A
24
13
6
3B
3B
7
7
7A
7A
9
64
12
17
17
23
23
39
40
40
64
8
8
16
DCFEB30S5GC2
56
10
10

FEB30T5GCC Publication No: 5995536165
# Functional Parts 9 03/09
* Non-Illustrated Parts
DOORS
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260522 Baffle, door
7 318372000 Insulation, door, (2)
7A 318372002 Insulation, door, (2)
8 316117500 Glass, oven door, heat barrier
9 318360108 Liner, oven door
10 5304452028 Screw, handle mtg, 10-14 x 1/2, (2)
12 318053121 Seal, oven door
13 318272183 Door Assy, glass, stainless steel, outer
16 318212210 Glass, oven door, heat barrier, lower door
17 318264710 Spacer, glass, lower, (2)
23 318567100 Hinge, oven door, (2)
24 318260301 Trim, door, black, lower
39 316270200 Handle, door, black
40 318242702 Bracket, glass holder, door, (2)
41 318370600 Bracket, glass retainer, (2)
42 318382301 Bracket, glass retainer, (4)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer
* 318163602 Cleaner, stainless steel
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303300265 Screw, 8-18 X 1/2, (4)
* 5303323277 Screw, 8-18 X 13/32

Publication No: 5995536165 FEB30T5GCC
03/09 10
WIRING DIAGRAM
