Frigidaire GLEB27M9F User manual

GLEB27M9F.tif CGLEB27M9ESA.eps MGLEB27M9ESA.eps BGLEB30M9ESB.eps
DGLEB27M9FSA.eps 318046238.eps
Product No. GLEB27M9FBA GLEB27M9FQA GLEB27M9FSA
39256761G6061 39256761G6041 39256761G6011
Series 27" elec 27" elec 27" elec
Color black bisque white
Market North America North America North America
Wiring Diagram 318046238 318046238 318046238
Owner's Guide 318200941 318200941 318200941
Installation Instructions 318201521 318201521 318201521
Service Data Sheet 318047418 318047418 318047418
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995475125
06/09/27
(EN/SERVICE/ECL)
377
MICROWAVE/ WALL
OVEN COMBO
Model No.
GLEB27M9F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995475125 GLEB27M9F
09/06 2
CONTROL PANEL

GLEB27M9F Publication No: 5995475125
# Functional Parts 3 09/06
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AGLEB27M9F (GLEB27M9FSA)
BGLEB27M9F (GLEB27M9FBA)
CGLEB27M9F (GLEB27M9FQA)
POS. NO PART NO. DESCRIPTION
1 318331301 A - - Control Panel Assembly, glass, white, w/touch pad
1 318331300 - B - Control Panel Assembly, glass, black, w/touch pad
1 318331302 - - C Control Panel Assembly, glass, bisque, w/touch pad
2 # 316418721 A B C Clock/Timer, electronic, ES510W1
3 318295703 A B C Deflector, timer
16 # 5304440820 A B C Control Board, printed circuit
17 5304442127 A - - Frame, control panel, white
17 5304440821 - B - Frame, control panel, black
17 5304440823 - - C Frame, control panel, bisque
18 # 5304452254 A - - Switch Assy, touch control, white, w/touch pad
18 # 5304440824 - B - Switch Assy, touch control, black
18 # 5304440826 - - C Switch Assy, touch control, bisque
19 5304442133 A - - Push Button, door opener, white
19 5304440827 - B - Push Button, door opener, black
19 5304440829 - - C Push Button, door opener, bisque
20 5304442134 A B C Spring, button
21 5304440282 A B C Screw, control board, 3mm x 10mm
22 5304440832 A B C Connector, rubber, control board
23 5304440833 A B C Panel, touch pad mount
24 # 5304440834 A B C LED Sheet, backlight
25 # 5304440835 A B C LCD, display
26 5304440836 A B C Bracket, PCB support
* 5303211311 A B C Screw, 8 x 0.500

Publication No: 5995475125 GLEB27M9F
09/06 4
MICROWAVE

GLEB27M9F Publication No: 5995475125
# Functional Parts 5 09/06
* Non-Illustrated Parts
MICROWAVE
Model Index: AGLEB27M9F (GLEB27M9FSA)
BGLEB27M9F (GLEB27M9FBA)
CGLEB27M9F (GLEB27M9FQA)
POS. NO PART NO. DESCRIPTION
1 5304440777 A B C Capacitor, high voltage
2 # 5304440778 A B C Rectifier, high voltage
3 # 5304440779 A B C Lamp Assy, with socket
4 # 5304448490 A B C Motor, cooling fan
5 # 5303319559 A B C Switch, monitor, w/ceramic fuse
6 # 5304440026 A B C Switch, interlock, door sensor
7 # 5304440780 A B C Fuse, cavity temp, 20 Amp, 250 V
8 # 5304440781 A B C Magnetron
9 # 5304448832 A B C Motor, turntable
10 # 5304440783 A B C Transformer, power
11 # 5304440784 A B C Power Cord, electric
12 # 5304440785 A B C Sensor, humidity, cook control
13 5304440814 A B C Base, unit chassis
14 5304442125 A B C Insert, threaded, (4)
15 5304440817 A - - Cabinet, outer casing, white
15 5304440816 - B - Cabinet, outer casing, black
15 5304440818 - - C Cabinet, outer casing, bisque
28 5304440838 A B C Retainer, capacitor strap
29 5304440839 A B C Bracket, chassis support
30 5304440840 A B C Latch Hook
31 5304440841 A B C Lever, door release
32 5304442135 A B C Duct, magnetron
33 # 5304440843 A B C Fan Blade, cooling fan
34 5304440844 A B C Duct, cooling fan
36 5304440845 A B C Cover, waveguide
37 5304440288 A B C Bushing, motor shaft, turntable
38 5304441909 A B C Cushion, base plate pad
39 5304440847 A B C Duct, AH sensor
40 5304441910 A B C Cushion, magnetron pad
52 5304452260 A B C Wiring Harness, main
53 5304440284 A B C Support Assy, turntable
54 5304440868 A B C Tray, turntable, glass
55 5304440334 A B C Label, Caution-monitor
56 5304440333 A B C Label, Caution-DHHS
58 # 5304440870 A B C Wire, high voltage-A
59 5303319636 A B C Screw
60 5303319641 A B C Screw
61 5304440871 A B C Screw, 4mm x 12mm, ground
62 5304440340 A B C Screw, 4mm x 12mm
62 5304452261 A B C Screw, outer casing
63 5303319633 A B C Screw, 3mm x 8mm
64 5304440872 A B C Screw, 4mm x 8mm
65 5304440873 A B C Screw, torx head, tamper proof
66 5304440874 A B C Screw
67 # 5304451818 A B C Filter, noise, electronic
68 5303322975 A B C Bracket, noise filter, angle

Publication No: 5995475125 GLEB27M9F
09/06 6
LOWER OVEN
70
185
99
310
311
143
219
119
312
108
112
108A
71
81
163
163
81
87
1
62
80
142
58B
264
37
76
29
29 127
86
86
41
41
90
54
54
14
14
15
15
16
16
17
17
58A
82 BGLEB30M9ESB
99
185
70
2
84
412
411
12
83
59
59A
89
56A
56
131
400
402
410
401
403
409
Microwave
Parts
406
132
219A
10
9
6
6
66
68
8
8A
6A
67
107
161
111
109
263
125
272

GLEB27M9F Publication No: 5995475125
# Functional Parts 7 09/06
* Non-Illustrated Parts
LOWER OVEN
Model Index: AGLEB27M9F (GLEB27M9FSA)
BGLEB27M9F (GLEB27M9FBA)
CGLEB27M9F (GLEB27M9FQA)
POS. NO PART NO. DESCRIPTION
1 318259212 A B C Back, main
2 318258910 A B C Shield, insulation, upper
6 318345210 A B C Rack, oven, (3)
6A 318219500 A B C Rack, broiler pan
8 318262011 A B C Cover, element
8A 318318600 A B C Bracket, element, hidden bake
9 5303317977 A B C Pan, broiler
10 5303317976 A B C Insert, broiler pan
12 # 318089917 A B C Switch, light
14 318224000 A B C Receptacle, oven light
14* 318268099 A B C Insulation, oven light
15 5303013071 A B C Bulb/Lamp, light
16 08011086 A B C Lens, oven light, glass
17 5304400195 A B C Retainer, light cover
29 318147411 A B C Bumper, (2)
37 # 316217002 A B C Probe, oven temp
41 5303310526 A B C Cover, hinge cutout
* 5303325980 A B C Screw, 10-32 x 0.437
54 318222400 A B C Housing, oven light
56 318276302 A - - Trim, side filler, white, RH
56 318276304 - B - Trim, side filler, black, RH
56 318276306 - - C Trim, side filler, bisque, RH
56A 318276303 A - - Trim, side filler, white, LH
56A 318276305 - B - Trim, side filler, black, LH
56A 318276307 - - C Trim, side filler, bisque, LH
58A 318285060 A B C Insulation, rear & bottom, oven wrapper
58B 318285059 A B C Insulation, top & sides, oven wrapper
59 318072560 A B C Duct, oven vent
59A 318261600 A B C Bracket, vent tube
62 316056000 A B C Terminal Block
62* 5303323139 A B C Screw, 10-24 x 0.906
62* 5303323144 A B C Nut, 10-32
66 # 318255601 A B C Element, broil, 3400W
67 318254902 A B C Element, bake, 2700W, 6 pass
68 5304403015 A B C Support, hanger, (2), broil element
70 318259100 A B C Shield, insulation, sides, (2)
71 318260001 A B C Panel, rear box
76 318056222 A B C Front, oven
80 5303320846 A B C Plate, oven mtg
81 318192400 A B C Spring, oven
82 318258710 A B C Shield, insulation, lower
83 318261500 A B C Liner, oven assy
84 # 318146833 A B C Outlet-electrical, miniature, black-glossy
86 5303310524 A B C Receptacle, hinge
87 318260601 A B C Bracket, cable mtg.
89 # 318261209 A B C Motor, latch assy
90 318259710 A - - Trim, oven front, white, bottom
90 318259711 - B - Trim, oven front, black, bottom

Publication No: 5995475125 GLEB27M9F
09/06 8
LOWER OVEN
70
185
99
310
311
143
219
119
312
108
112
108A
71
81
163
163
81
87
1
62
80
142
58B
264
37
76
29
29 127
86
86
41
41
90
54
54
14
14
15
15
16
16
17
17
58A
82 BGLEB30M9ESB
99
185
70
2
84
412
411
12
83
59
59A
89
56A
56
131
400
402
410
401
403
409
Microwave
Parts
406
132
219A
10
9
6
6
66
68
8
8A
6A
67
107
161
111
109
263
125
272

GLEB27M9F Publication No: 5995475125
# Functional Parts 9 09/06
* Non-Illustrated Parts
LOWER OVEN
Model Index: AGLEB27M9F (GLEB27M9FSA)
BGLEB27M9F (GLEB27M9FBA)
CGLEB27M9F (GLEB27M9FQA)
POS. NO PART NO. DESCRIPTION
90 318259712 - - C Trim, oven front, bisque, bottom
99 318256200 A B C Bracket, side, bottom, (2)
107 318219401 A B C Cover, fan
108# 318073018 A B C Motor, blower
* 08016432 A B C Screw, truss head, 8-18 x 0.375
108A 318251300 A B C Bracket, fan support
109 316136400 A B C Blade, fan
111 316136600 A B C Nut, fan retainer
112# 318112701 A B C Relay
119# 318004900 A B C Switch, thermal
125# 316415800 A B C Motor, fan
125* 5303316994 A B C Insulation, 3.81 x 3.13
127 318317100 A B C Adapter Assembly, vent tube, w/converter
131 318272900 A B C Box, vent
132 318003000 A B C Plate, shield
142 318123910 A B C Deflector
143 318172904 A B C Support, wire
161# 318255503 A B C Element, convection, 350 W
163 318014111 A B C Spacer
185 318014700 A B C Spacer, oven shield, (4)
219# 318003614 A B C Thermostat, safety
* 3201861 A B C Screw, 6 x 0.375, (4)
219A 318003613 A B C Thermostat, safety, 1.375" mtg, 105/120
263 316136500 A B C Washer, flat
264 318257711 A B C Trim, oven, black, front
272 318249401 A B C Tube, protector
310 5304440067 A B C Cabinet Mounting Kit
311 318246010 A B C Bracket, cabinet mtg, (2)
311* 5304438005 A B C Screw, 6 x 1, black
312 318246702 A B C Tool, cabinet bracket, RH
312 318246703 A B C Tool, cabinet bracket, LH
400 318275601 A - - Trim Assembly, microwave, 27", white
400 318275600 - B - Trim Assembly, microwave, 27", black
400 318275602 - - C Trim Assembly, microwave, 27", bisque
401 318297202 A B C Plate, support, microwave, 27"
402 318276202 A B C Bracket, base pad, RH
403 318276203 A B C Bracket, base pad, LH
406 318277200 A B C Shield, microwave rear
409 318295300 A B C Bracket, top trim
410 318297101 A B C Flue, black
411# 5304442354 A B C Holder, fuse
412# 5304442353 A B C Fuse, 20 Amp
* # 318078543 A B C Box & wires assy
* 318231737 A B C Harness, wiring, main
* 5303323136 A B C Screw ground
* 5303211311 A B C Screw, 8 x 0.500
* 5303323277 A B C Screw, 8-18 X 13/32
* 5303324184 A B C Screw, 8-18 x 5/16, black, (4)
* 5304436875 A B C Screw, 8-18 X 1/2, black

Publication No: 5995475125 GLEB27M9F
09/06 10
DOORS

GLEB27M9F Publication No: 5995475125
# Functional Parts 11 09/06
* Non-Illustrated Parts
DOORS
Model Index: AGLEB27M9F (GLEB27M9FSA)
BGLEB27M9F (GLEB27M9FBA)
CGLEB27M9F (GLEB27M9FQA)
POS. NO PART NO. DESCRIPTION
3 318260211 A B C Trim, oven door, black, upper
3A 318260401 A B C Trim, oven door, side, (2)
4 318261351 A - - Glass Assy., oven door, white, outer, w/trim
4 318261350 - B - Glass Assy., oven door, black, outer, w/trim
4 318261352 - - C Glass Assy., oven door, bisque, outer, w/trim
6 318260510 A B C Baffle, door
7 318285057 A B C Insulation, oven door
7A 318285061 A B C Insulation, (2)
8 318212200 A B C Glass, oven door, heat barrier
9 318259611 A B C Liner, oven door, upper
10 5304400794 A B C Screw, handle mtg, 10-32 x 3/4
12 318053135 A B C Seal, oven door, upper
17 318264700 A B C Spacer, glass, (2)
23 318024724 A B C Hinge, door, (2)
29 318014402 A B C Spacer, door
39 5304457046 A - - Handle, door, white, w/spacer
39 5304457045 - B - Handle, door, black, w/spacer
39 5304457047 - - C Handle, door, bisque, w/spacer
40 318242700 A B C Bracket, glass holder, (2)
41 5304452255 A - - Door Assembly, complete, white
41 5304452257 - B - Door Assembly, complete, black
41 5304452256 - - C Door Assembly, complete, bisque
43 5304440856 A B C Latch, door
44 5304440316 A B C Spring, door latch
45 5304442144 A - - Panel, inner door, white
45 5304440857 - B C Panel, inner door, black
45 5304440859 - B C Panel, inner door, bisque
46 5304440860 A B C Seal, door, film
47 5304440861 A B C Frame, choke cover, inner door
48 5304442145 A B C Door Stop
50 5304440862 A B C Door Stop
51 5304452259 A B C Screw
56 5304436875 A B C Screw, 8-18 X 1/2, black
64 318165800 A B C Spacer
* 5303323277 A B C Screw, 8-18 X 13/32

Publication No: 5995475125 GLEB27M9F
09/06 12
WIRING DIAGRAM
