Frigidaire FEF354BJWA User manual

© 2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ELECTRIC RANGE
P.O. Box 212378
Augusta, Georgia 30917
PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF354BJWA FEF354BJ WHITE USA
FEF354CJSA FEF354CJ WHITE/WHITE USA
FEF354CJTA FEF354CJ ALMOND/ALMOND USA
Publication No.
5995340469
000705
-EN/SERVICE /CML
369
WIRING DIAGRAM # - 316002622
OWNER’S GUIDE # - 316135906
INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE
FEF354BJWA
FEF354CJSA
FEF354CJTA
07/00 2
Publication number
5995340469 FEF354BJWA,FEF354CJSA,FEF354CJTA
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
# - Fast Moving Parts
* - Non Illustrated Parts 3 6/98
Publication number
FEF354BJWA,FEF354CJSA,FEF354CJTA 5995340469
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
A = FEF354BJ (FEF354BJWA)
B = FEF354CJ (FEF354CJSA)
C = FEF354CJ (FEF354CJTA)
POS. NO PART NO DESCRIPTION
* 316021105 A B C Screw,hex ,8-18 x 0.375 ,back\bodyside
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B C Screw,semi gim ,8-18 X 1/2 ,black
* 316112500 A B C Template, Anti-tip bracket
* 5303292005 A B C Screw-switch/handle,8-32 x 5/32
1 316081600 A B C Shield-backguard,rear wall
2 316015907 A B C Shield-backguard,inner
11 316083719 A - - Trim-wrapper,textured ,black
11 316083721 - B - Trim-wrapper, textured,white
11 316083720 - - C Trim-wrapper,textured,almond
14 316022503 A B C Light/Lamp, indicator , surface ,250 V
15 316023108 A B C Support-backguard,RH
15A 316023109 A B C Support-backguard,LH
19 316024494 A - - Panel-control,metal
19 316024495 - B - Panel-control,metal
19 316024496 - - C Panel-control,metal
20 # 316101001 A B C Clock/Timer,electronic
20* 316101502 - B - Overlay-clock
20* 316101503 A - - Overlay-clock
20* 316101504 - - C Overlay-clock
23 316100301 A B C Bracket-timer
24 # 316118100 A - - Switch-rocker, black
24# 316118101 - B - Switch-rocker,white
24# 316118102 - - C Switch-rocker,almond
36 316025106 - B - Knob-control,infinite sw ,white
36 316025108 A - - Knob-control, infinite sw, black
36 316025107 - - C Knob-control,infinite sw,gray
40 316025800 A - - Panel-manifold,black
40 316025808 - B - Panel-manifold,white
40 316025809 - - C Panel-manifold,almond
46 316040201 A B C Lens-light/lamp,indicator ,red
54 # 316021500 A B C Switch-infinite, 6" element
54A# 316021501 A B C Switch-infinite, 8" element
69 5303292005 A B C Screw-switch mtg, 8-32 x5/32
07/00 4
Publication number
5995340469 FEF354BJWA,FEF354CJSA,FEF354CJTA
CAUTION: Use the part number on all orders, not the position number.
BODY
# - Fast Moving Parts
* - Non Illustrated Parts 5 07/00
Publication number
FEF354BJWA,FEF354CJSA,FEF354CJTA 5995340469
CAUTION: Use the part number on all orders, not the position number.
BODY
A = FEF354BJ (FEF354BJWA)
B = FEF354CJ (FEF354CJSA)
C = FEF354CJ (FEF354CJTA)
POS. NO PART NO DESCRIPTION
* 316021105 A B C Screw,hex ,8-18 x 0.375 ,back\bodyside
* 316021108 A B C Screw,cup pt ,8-18 x 0.375,hinge,ind lght brkt,manifold pnl
* 5303051099 A B C Nut,hex ,#10-32
* 5308014215 A B C Screw
3 316081034 A B - Panel-bodyside,white ,RH
3* 316081035 A B - Panel-bodyside,white ,LH
3 316081036 - - C Panel-bodyside,almond,RH
3* 316081037 - - C Panel-bodyside,almond,LH
4 5303271756 A B C Burner Box
5 316129200 A B C Leg-leveling(plastic) w/stop
6 316067902 A B C Rack-oven
7 316007002 A B C Hinge-oven door,(2)
8 3203540 A B C Panel-oven bottom
9 316081900 A B C Pan-broiler
10 316082000 A B C Insert-broiler pan
12 # 316027701 A B C Switch-oven light
13 316026800 A B C Rod-light switch /door
14 316116400 A B C Socket-light
15 5303013071 A B C Light Bulb/Lamp
16 08011086 A B C Lens-light/lamp, glass , oven
17 316087500 A B C Retainer-lens
18 # 316036300 A B C Latch-door
21 3014099 A B C Spacer-bodyside, (8)
25 3200848 A B C Shield-heat,lower
29 3051162 A B C Glide-drawer,front
37 # 316111202 A B C Probe-oven temp
41 3131570 A B C Cover-hinge cutout
57 316081101 A B C Cover-access
58 3200847 A B C Insulation,oven bottom
58A 316047708 A B C Insulation, 2" ,oven wrapper
58B 316054200 A B C Insulation, 2" ,oven back
59 316073600 A B C Tube-oven vent
62 # 5303935061 A B C Terminal Block
63 5301145190 A B C Plate-ground strap
66 # 5303051140 A B C Element-broil
67 # 316075103 A B C Element-bake
68 316075300 A B C Support-element, broil
72 5303285692 A B C Cover-light/switch rod
82 5303289913 A B C Shield-insulation
87 316081200 A B C Bracket-cable mtg
88 316026400 A B C Rod-latch,auto
89 # 316028101 A B C Motor-latch/lock
135* 3131903 A B C Bumper-door/drawer, rubber
170 316107200 A B C Anti-tip bracket
170* 316116000 A B C Screw-Anti tip, 1.75" concrete
170* 5303935180 A B C Kit-Anti-Tip (complete w/template & screws)
07/00 6
Publication number
5995340469 FEF354BJWA,FEF354CJSA,FEF354CJTA
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER
# - Fast Moving Parts
* - Non Illustrated Parts 7 07/00
Publication number
FEF354BJWA,FEF354CJSA,FEF354CJTA 5995340469
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER
A = FEF354BJ (FEF354BJWA)
B = FEF354CJ (FEF354CJSA)
C = FEF354CJ (FEF354CJTA)
POS. NO PART NO DESCRIPTION
* 316001725 A B C Wiring Harness,surface element
* 316021105 A B C Screw,hex ,8-18 x 0.375 ,back\bodyside
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B C Screw,semi gim ,8-18 X 1/2 ,black
* 316089600 A B C Spacer-drawer,(2)
* 5303280311 A B C Screw, waf hd sdr , 10-32 x 5/16 , (2)
* 5308014215 A B C Screw
1 316011501 A B C Drawer-utility
2 3131975 A B C Shield-panel
4 316084405 A B - Panel-drawer,white
4 316084406 - - C Panel-drawer,almond
7 3051163 A B C Glide-drawer,rear
15 # 5303012223 A B C Element-surface,large-8"
15A# 08067762 A B C Element-surface,small-6"
16 316020907 A B - Main Top,white
16 316020908 - - C Main Top,almond
17 316057601 A B C Rod-maintop support
18 5303273062 A B C Hinge-main top,RH
18A 5303273063 A B C Hinge-main top,LH
19 318067051 A - - Pan-surface element,large/8 inch
19 5303935054 - B C Pan-surface element,large/8 inch
19A 318067041 A - - Pan-surface element,small/6 inch
19A 5303935057 - B C Pan-surface element,small/6 inch
27 # 5301167733 A B C Terminal Block Kit,surface element
28 3017801 - B C Medallion,stainless steel ,surf elem
28 5303017715 A - - Medallion,1 1/2"dia ,black ,surface element
07/00 8
Publication number
5995340469 FEF354BJWA,FEF354CJSA,FEF354CJTA
CAUTION: Use the part number on all orders, not the position number.
DOOR
# - Fast Moving Parts
* - Non Illustrated Parts 9 07/00
Publication number
FEF354BJWA,FEF354CJSA,FEF354CJTA 5995340469
CAUTION: Use the part number on all orders, not the position number.
DOOR
A = FEF354BJ (FEF354BJWA)
B = FEF354CJ (FEF354CJSA)
C = FEF354CJ (FEF354CJTA)
POS. NO PART NO DESCRIPTION
* 316065306 A B C Plate-warning/caution
* 3203618 A B C Rivet-pop,warning-plate
* 316021110 A B C Screw,semi gim ,8-18 X 1/2 ,black
* 5303271648 A B C Burner Box, wafer hd sq dr,8-18AB x 1/2
* 5303280311 A B C Screw, waf hd sdr , 10-32 x 5/16 , (2)
* 5303292005 A B C Screw-switch/handle,8-32 x 5/32
* 316132100 A B C Spacer-sponge pad
3 316067802 A - - Trim-oven door,black
3 316067804 - B - Trim-oven door,white
3 316067803 - - C Trim-oven door,almond
4 316089000 A - - Glass-oven door,black ,outer
4 316089005 - B - Glass-oven door,white ,outer
4 316089004 - - C Glass-oven door,almond,outer
5 316088700 A B C Glass-oven door,airwash
6 316088401 A B C Shield-wool
7 316076403 A B C Insulation-door
8 316088600 A B C Glass-oven door,inner
9 316066610 A B C Liner-oven door
10 5303280308 A B C Screw-handle mtg,wafer head ,10-24T x 2
10* 316008401 A B C Washer,3/4 x 1/4 ,steel
12 # 5303131601 A B C Seal-oven door
14 3131361 - B C Reflector,aluminum foil
14 5303208656 A - - Reflector,aluminum foil
14A 3131360 - B C Reflector,aluminum foil
14A 5303208655 A -- - Reflector,aluminum foil
15 316081403 A B C Bracket-glass mtg
16 316085701 A B C Glass-oven door,heat barrier
39 316091114 A - - Handle-door,black ,oven
39 316091115 - B - Handle-door,white ,oven
39 316091116 - - C Handle-door,almond,oven
52 316081301 - B - Shield-oven door,white ,top
52 316081303 A - - Shield-oven door,black ,top
52 316081302 - - C Shield-oven door,almond,top
07/00 10
Publication number
5995340469 FEF354BJWA,FEF354CJSA,FEF354CJTA
CAUTION: Use the part number on all orders, not the position number.
WIRING DIAGRAM
