Frigidaire FEF358BFDB User manual

© 1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ELECTRIC RANGE
P.O. Box 212378
Augusta, Georgia 30917
PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF358BFWB FEF358BF WHITE USA
FEF358BFDB FEF358BF ALMOND USA
FEF358CFSB FEF358BF WHITE/WHITE USA
FEF358BFWC FEF358BF WHITE USA
FEF358BFDC FEF358BF ALMOND USA
FEF358CFSC FEF358BF WHITE/WHITE USA
Publication No.
59953299178
990407
-EN/SERVICE /VLM
369
WIRING DIAGRAM # - 316002651
OWNER’S GUIDE # - 316000268
INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE
FEF358BFWB
FEF358BFDB
FEF358CFSB
FEF358BFWC
FEF358BFDC
FEF358CFSC

04/99 2
Publication number
5995320016 FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD

# - Fast Moving Parts
* - Non Illustrated Parts 3 4/99
Publication number
FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC 5995320016
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
A = FEF358BF (FEF358BFDB)
B = FEF358BF (FEF358BFWB)
C = FEF358CF (FEF358CFSB)
D = FEF358BF (FEF358BFDC)
E = FEF358BF (FEF358BFWC)
F = FEF358CF (FEF358CFSC)
POS. NO PART NO DESCRIPTION
1 316081601 A B C D E F Shield-backguard,rear wall
2 316015905 A B C D E F Shield-backguard,inner
11 316083705 A B - D E - Trim-wrapper,black
11 316083700 - - C - - F Trim-wrapper,white
13A# 316095500 A B C D E F Switch-warmer,infinite ,drawer/zone
14 316022503 A B C D E F Light/Lamp, indicator , surface ,250 V
14A 316022500 A B C D E F Light/Lamp, warmer,, indicator ,
drawer/zone,125 V
15 316023108 A B C D E F Support-backguard,RH
15A 316023109 A B C D E F Support-backguard,LH
19 316100503 A B - D E Panel-control,metal ,black
19 316100504 - - C - - F Panel-control,metal ,white
20 # 316101001 A B C D E F Clock/Timer,electronic
20* 316101503 A B - D E - Overlay-clock
20* 316101502 - - C - - F Overlay-clock
23 316100300 A B C D E F Bracket-clock mtg
24 # 316005602 A B - D E - Switch-rocker,oven light ,black
24 # 316005607 - - C - - F Switch-rocker,oven light ,white
24B# 316083100 A B - D E - Switch-rocker,dual element ,black ,LH ,
(2)
24B# 316086901 - - C - - F Switch-rocker,dual element ,white
31A 316095603 A B - D E - Knob-warmer,black
31A 316095601 - - C - - F Knob-warmer,white
36 316025100 A B - D E - Knob-control,infinite sw
36 316025106 - - C - - F Knob-control,infinite sw ,white
40 316025800 A B - D E - Panel-manifold
40 316025808 - - C - - F Panel-manifold,white
46 316040201 A B C D E F Lens-light/lamp,indicator ,red
54 # 316021500 A B C D E F Switch-infinite, 6" element
54C# 316049800 A B C D E F Switch, infinite , dual element
60 316021105 A B C D E F Screw,hex ,8-18 x 3/8 ,back\bodyside
69 5303292005 A B C D E F Screw-switch/handle,8-32 x 5/32
71 316071902 A B C D E F Gasket-edge
* 316021108 A B C D E F Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl

04/99 4
Publication number
5995320016 FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 5 04/99
Publication number
FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC 5995320016
CAUTION: Use the part number on all orders, not the position number.
BODY
A = FEF358BF (FEF358BFDB)
B = FEF358BF (FEF358BFWB)
C = FEF358CF (FEF358CFSB)
D = FEF358BF (FEF358BFDC)
E = FEF358BF (FEF358BFWC)
F = FEF358CF (FEF358CFSC)
POS. NO PART NO DESCRIPTION
1 316080801 A B C D E F Back-main
3 316081030 A - - D - - Panel-bodyside,almond ,RH
3 316081028 - B C - E F Panel-bodyside,white ,RH
3* 316081031 A - - D - - Panel-bodyside,almond ,LH
3* 316081029 - B C - E F Panel-bodyside,white ,LH
5 5303203397 A B C D E F Screw-leveling
5* 3934058 A B C D E F Anti-tip Kit
5* 316078600 A B C D E F Screw,anti-tip ,(4)
5* 5303288460 A B C D E F Nut,T-type ,leveling screw
6 316067902 A B C D E F Rack-oven
7 316007002 A B C D E F Hinge-oven door,(2)
8 3203540 A B C D E F Panel-oven bottom
9 316073800 A B C D E F Pan-broiler
10 3205234 A B C D E F Insert-broiler pan
12 # 316027701 A B C D E F Switch-oven light
13 316026800 A B C D E F Rod-light switch /door
14 3014073 A B C D E F Socket-light/lamp,oven
15 5303013071 A B C D E F Light Bulb/Lamp
16 08011086 A B C D E F Lens-light/lamp,glass ,oven
17 316087500 A B C D E F Retainer-lens
18 # 316036300 A B C D E F Latch-door
21 3014099 A B C D E F Spacer-bodyside,(8)
25 3200848 A B C D E F Shield-heat,lower
28 316045000 A B C D E F Clip-wire,harness ,main top
29 3051162 A B C D E F Glide-drawer,front
30 5303283574 A B C D E F Bracket-hinge,main top RH
30A 5303283575 A B C D E F Bracket-hinge,main top LH
37 # 316111200 A B C D E F Probe-oven temp
41 3131570 A B C D E F Cover-hinge cutout
44 3131903 A B C D E F Bumper-door/drawer,rubber
45 316066100 A B C D E F Shield-wire, s/t vent
57 316081101 A B C D E F Cover-access
58 3200847 A B C D E F Insulation,oven bottom
58A 316047708 A B C D E F Insulation, 2" ,oven wrapper
58B 316054200 A B C D E F Insulation, 2" ,oven back
58C 3131304 A B C D E F Insulation,oven top
59 316073602 A B C D E F Tube-oven vent
59* 316040100 A B C D E F Bracket-mounting,vent tube
59A 316023601 A B C D E F Tube-oven vent,upper
62 # 5303935061 A B C D E F Terminal Block
63 5301145190 A B C D E F Plate-ground strap
66 # 5303051140 A B C D E F Element-broil
67 # 316075102 A B C D E F Element-bake,lower oven
68 316075300 A B C D E F Support-element, broil
71 316015805 A B C D E F Shield-rear wall
72 5303285692 A B C D E F Cover-light/switch rod
82 5303289913 A B C D E F Shield-insulation
87 316081200 A B C D E F Bracket-cable mtg
88 316026400 A B C D E F Rod-latch,auto
89 # 316028101 A B C D E F Motor-latch/lock

04/99 6
Publication number
5995320016 FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 7 04/99
Publication number
FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC 5995320016
CAUTION: Use the part number on all orders, not the position number.
BODY
* 3203550 A B C D E F Plug-button
* 316021108 A B C D E F Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316101600 A B C D E F Shield-vent,smoothtop
* 5303051099 A B C D E F Nut,hex ,#10-32

04/99 8
Publication number
5995320016 FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER

# - Fast Moving Parts
* - Non Illustrated Parts 9 04/99
Publication number
FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC 5995320016
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER
A = FEF358BF (FEF358BFDB)
B = FEF358BF (FEF358BFWB)
C = FEF358CF (FEF358CFSB)
D = FEF358BF (FEF358BFDC)
E = FEF358BF (FEF358BFWC)
F = FEF358CF (FEF358CFSC)
POS. NO PART NO DESCRIPTION
1 316011501 A B C D E F Drawer-utility
2 3131975 A B C D E F Shield-panel
4 316084406 A - - D - - Panel-drawer,almond
4 316084405 - B C - E F Panel-drawer,white
4* 316021113 A - - D - - Screw-8-18x1/2 Tr Sqd Almond
4* 316021112 - B C - E F Screw-8-18x1/2 Tr Sqd White
4* 08067785 A B C D E F Screw,hex washer head ,8-18AB x 1/2
7 3051163 A B C D E F Glide-drawer,rear
15 # 316010203 A B C D E F Element-surface,radiant , small/6 inch ,
1200W,limit sw incl
15A# 316049703 A B C D E F Element-surface,radiant ,dual ,
2100W/1000W,limit sw incl
15C# 316098200 A B C D E F Element-warmer,120V/100W
16 316098128 A - - D - - Main Top,glass ,almond
16 316098127 - B - E Main Top,glass ,white
16 316098129 - - C F Main Top,glass ,white
18 5303273062 A B C D E F Hinge-main top,RH
18A 5303273063 A B C D E F Hinge-main top,LH
26 316099101 A B C D E F Channel-support,element ,(2)
26A 316099201 A B C D E F Bracket-support, chassis
44 3131903 A B C D E F Bumper-door/drawer,rubber
48 316100200 A B C D E F Shield-wire,main top
52 316099400 A B C D E F Clip-spring, element mtg,(8)
51 316105103 A B C D E F Hot surface indicator light
53 316099300 A B C D E F Bracket-indicator light,hot surface ,
4 hole
88 316099500 A B C D E F Pin-guide,(2)
* 3203618 A B C D E F Rivet-pop,warning-plate
* 316021105 A B C D E F Screw,hex ,8-18 x 3/8 ,back\bodyside
* 316021108 A B C D E F Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 5303280311 A B C D E F Screw,waf hd sdr ,10-32 x 5/16 ,(2)
* 316089600 A B C D E F Spacer-drawer,(2)
* 5309951550 A B C D E F Cleaner-cooktop
* 316045000 A B C D E F Clip-wire,harness ,main top
* # 316001748 A B C D E F Harness-top elements,incl ind. light

04/99 10
Publication number
5995320016 FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC
CAUTION: Use the part number on all orders, not the position number.
DOOR

# - Fast Moving Parts
* - Non Illustrated Parts 11 04/99
Publication number
FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC 5995320016
CAUTION: Use the part number on all orders, not the position number.
DOOR
A = FEF358BF (FEF358BFDB)
B = FEF358BF (FEF358BFWB)
C = FEF358CF (FEF358CFSB)
D = FEF358BF (FEF358BFDC)
E = FEF358BF (FEF358BFWC)
F = FEF358CF (FEF358CFSC)
POS. NO PART NO DESCRIPTION
3 316067802 A B - D E F Trim-oven door,black
3 316067804 - - C - - F Trim-oven door, white
4 316089000 A B - D E - Glass-oven door,black ,outer
4 316089005 - - C - - F Glass-oven door, white, outer
5 316088700 A B C D E - Glass-oven door,airwash
6 316088401 A B C D E - Shield-wool
7 316076403 A B C D E - Insulation-door
8 316088600 A B C D E - Glass-oven door,inner
9 316066610 A B C D E - Liner-oven door
10 5303280308 A B C D E - Screw-handle mtg, wafer head ,10-24T x 2
12 5303131601 A B C D E - Seal-oven door
14 5303208656 A B C D E - Reflector, aluminum foil
14A 5303208655 A B C D E - Reflector, aluminum foil
15 316081401 A B C - - - Bracket-glass mtg
15 316081403 ---DEF Bracket-glass mtg
16 316085700 A B C - - - Glass-oven door, heat barrier
16 316085701 ---DEF Glass-oven door, heat barrier
39 316091114 A B - D E - Handle-door, black ,oven
39 316091115 - - C - - F Handle-door, white, oven
39* 316008401 A B C D E F Washer,3/4 x 1/4 , steel
52 316081303 A B C D E F Shield-oven door, black ,top
* 316065301 A B C D E F Plate warning/caution
* 5303212671 A B C D E F Screw,cr pan hd sems , 8-32BP x 1.00
* 5303271648 A B C D E F Screw,wafer hd sq dr, 8-18AB x 1/2
* 5303280311 A B C D E F Screw,waf hd sdr, 10-32 x 5/16 ,(2)
* 5303285179 A B C D E F Screw-oven door,wafer head, 8-32T x 1/2

04/99 12
Publication number
5995320016 FEF358BFWB, FEF358BFDB, FEF358CFSB, FEF358BFWC, FEF358BFDC, FEF358CFSC
CAUTION: Use the part number on all orders, not the position number.
WIRING DIAGRAM
