Frigidaire FGF376CJBA User manual

© 2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
GAS RANGE
P.O. Box 212378
Augusta, Georgia 30917
PRODUCT NO. BASE MODEL NO. COLOR MARKET
FGF376CJBA FGF376CJ BLACK/BLACK USA
FGF376CJSA FGF376CJ WHITE/WHITE USA
FGF376CJTA FGF376CJ ALMOND/ALMOND USA
Publication No.
5995336079
000411
-EN/SERVICE/CML
369
WIRING DIAGRAM # - 316002180
OWNER’S GUIDE # - 316128207
INSTALLATION GUIDE # - 316105837 GAS - RANGE
FGF376CJBA
FGF376CJSA
FGF376CJTA

04/00 2
Publication number
5995336079 FGF376CJBA,FGF376CJSA,FGF376CJTA
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD

# - Fast Moving Parts
* - Non Illustrated Parts 3 6/98
Publication number
FGF376CJBA,FGF376CJSA,FGF376CJTA 5995336079
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
A = FGF376CJ (FGF376CJBA)
B = FGF376CJ (FGF376CJSA)
C = FGF376CJ (FGF376CJTA)
POS. NO PART NO DESCRIPTION
* 316002180 A B C Wiring diagram
* 316001475 A B C Harness-backguard
* 316105837 A B C Installation Instuctions
* 316128207 A B C Owner’s Guide
* 316112500 A B C Template, Anti-tip bracket
1 5303288505 A B C Shield-rear wall,backguard
2 316051600 A B C Shield-backguard, inner
2A 316053800 A B C Shield-backguard, inner/top
11 316083718 A - - Trim-wrapper, black, textured
11 316083722 - B - Trim-wrapper, white, textured
11 316083723 - - C Trim-wrapper, almond, textured
15 316023108 A B C Support-backguard, RH
15A 316023109 A B C Support-backguard, LH
19 316100581 - B - Panel-backguard, white
19 316100582 A - - Panel-backguard, black
19 316100583 - - C Panel-backguard, almond
20# 316080011 A B C Clock/Timer, slew
20A 316089306 - B - Overlay-clock, white
20A 316089307 A - - Overlay-clock, black
20A 316089308 - - C Overlay-clock, almond
23 316033204 A B C Bracket-mounting, clock/timer
24 # 316118100 A - - Switch-rocker, oven light, black
24# 316118101 - B - Switch-rocker, oven light, white
24# 316118102 - - C Switch-rocker, oven light, almond
36 316109502 A - - Knob-top valve, black (4)
36 316109503 - B - Knob-top valve, white (4)
36 316109504 - - C Knob-top valve, almond (4)
40 316009268 A - - Panel-manifold, black
40 316009285 - B - Panel-manifold, white
40 316009287 - - C Panel-manifold, almond
42 316055200 A - C Trim-vent (black)
42 316055201 - B - Trim-vent (clear)
56 316074907 A B C Deflector-flue, black

04/00 4
Publication number
5995336079 FGF376CJBA,FGF376CJSA,FGF376CJTA
CAUTION: Use the part number on all orders, not the position number.
BURNER

# - Fast Moving Parts
* - Non Illustrated Parts 5 04/00
Publication number
FGF376CJBA,FGF376CJSA,FGF376CJTA 5995336079
CAUTION: Use the part number on all orders, not the position number.
A = FGF376CJ (FGF376CJBA)
B = FGF376CJ (FGF376CJSA)
C = FGF376CJ (FGF376CJTA)
POS. NO PART NO DESCRIPTION
1 316113801 A B C Manifold-pipe (1)
2# 5303935168 A B C Valve-top burner, 9K (includes mounting screw) (2)
2A# 5303935169 A B C Valve-top burner, 11K (includes mounting screw) (1)
2B# 5303935175 A B C Valve-top burner, 5K sim (includes mounting screw) (1)
3 316001824 A B C Harness assembly-ignitor (1)
4# 316059612 A B C Tube-burner, marked red, RF
5# 316059613 A B C Tube-burner, marked green, LF
6# 316059614 A B C Tube-burner, marked no color, RR
7# 316059615 A B C Tube-burner, marked black, LR
8# 5303280394 A B C Spark module (1)
10# 5303935025 A B C Burner assembly-sealed, 9000 BTU (incls. 11, 37, 44 & 45)
10A# 5303935075 A B C Burner assembly-sealed,11,000 BTU (incls. 11,37, 44A & 45)
10B# 5303935176 A B C Burner assembly-sealed, 5,000 BTU (incls. 11A, 37, 44B & 45)
11 316011200 A B C Electrode-sealed burner w/mtg bracket (3)
11A 316011201 A B C Electrode-sealed burner w/mtg bracker (5K only)
13# 316065005 A B C Tube-aluminum, regulator to manifold w/fittings
14# 316091706 A B C Regulator-pressure (1)
14* 316021104 A B C Screw-regulator/bracket, hex, 8-18 x 3/8, nick
15 316091600 A B C Bracket-regulator
16# 316065003 A B C Tube-valve to regulator, 3/8
17# 5303208499 A B C Valve-safety, dual
18# 3131290 A B C Burner-oven
19# 5303935066 A B C Ignitor-oven
20 3131284 A B C Baffle-oven burner
21 5303013272 A B C Nut-hex head, sems
22# 316065002 A B C Tube-valve to mixer
23# 316087900 A B C Burner-broiler
24# 316070400 A B C Mixer Elbow
25 5303210379 A B C Baffle-broiler
26 316119302 A B C Ignitor-broil
37 316069301 A B C Screw-burner mounting (12)
44 5303210090 A B C Orifice-top burner, 9K (2)
44A 316010804 A B C Orifice-top burner, 11Km (1)
44B 316010809 A B C Orifice-top burner, 5K sim (1)
45 316011100 A B C Screw-ignitor mounting, self-tapping, M3x5.8 (4)
46 316074700 A B C Plate-burner tube
47 316039610 A B C Kit-LP Conversion
47* 316105838 A B C Installation Instructions-LP Kit (2+1+1)
BURNER

04/00 6
Publication number
5995336079 FGF376CJBA,FGF376CJSA,FGF376CJTA
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 7 04/00
Publication number
FGF376CJBA,FGF376CJSA,FGF376CJTA 5995336079
CAUTION: Use the part number on all orders, not the position number.
BODY
A = FGF376CJ (FGF376CJBA)
B = FGF376CJ (FGF376CJSA)
C = FGF376CJ (FGF376CJTA)
POS. NO PART NO DESCRIPTION
1 316029416 A B C Back-main, long
2 3131314 A B C Shield-oven top
3 316081038 A - - Panel-bodyside, black, RH
3 316081039 A - - Panel-bodyside, black, LH
3 316081035 - B - Panel-bodyside, white, LH
3 316081034 - B - Panel-bodyside, white, RH
3 316081037 - - C Panel-bodyside, almond, LH
3 316081036 - - C Panel-bodyside, almond, RH
4 316011917 A B C Burner box
5 316129200 A B C Leg-leveling, plastic w/stops (4)
6 316067902 A B C Rack-oven (2)
7 316007005 A B C Hinge-oven door (2)
8 5303212540 A B C Panel-oven bottom
9 316081900 A B C Pan-broiler
10 316082000 A B C Insert-broiler pan
12 # 316027701 A B C Switch-oven light
13 316026800 A B C Rod-light switch/door
14 316116400 A B C Socket-light
15 5303013071 A B C Light bulb/lamp
16 08011086 A B C Lens-light/lamp, glass, oven
17 316087500 A B C Retainer-lens
18 # 316036300 A B C Latch-door
21 3014099 A B C Spacer-bodyside (8)
25 5303288580 A B C Shield-bake lower
26 08067757 A B C Cover plate
28 3011813 A B C Clip-wire, bodyside
29 3051162 A B C Glide-drawer, front
30 316059200 A B C Bracket-main top, RH
30A 316059201 A B C Bracket-main top, LH
33 5303288495 A B C Shield-rear wall
35 316116600 A B C Gasket-flue
36 5303272844 A B C Flue-oven
37 # 316111202 A B C Probe-oven temp
38 316051700 A B C Shield-heat
39 3202006 A B C Cord-electric power
40 3200836 A B C Shield-heat baffle
40* 5303288570 A B C Screw-heat shield, shoulder, sq. Drive, 8-18x1/2
41 3131570 A B C Cover-hinge cutout
42 5303288578 A B C Shield-bake burner
43 3131732 A B C Screw-oven bottom, 8-18 x 1.438
44 3131903 A B C Bumper-door/drawer, rubber
49 3051124 A B C Clip-spring mounting
55 316107800 A B C Shield-flue
58A 316047708 A B C Insulation, 2", oven wrapper
58B 316054200 A B C Insulation, 2", oven back
58G 08067973 A B C Insulation-main, front

04/00 8
Publication number
5995336079 FGF376CJBA,FGF376CJSA,FGF376CJTA
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 9 04/00
Publication number
FGF376CJBA,FGF376CJSA,FGF376CJTA 5995336079
CAUTION: Use the part number on all orders, not the position number.
BODY
POS. NO PART NO DESCRIPTION
69 5303288579 A B C Shield-main front
72 5303285692 A B C Cover-light/switch rod
88 316026400 A B C Rod-latch,auto
89# 316028101 A B C Motor-latch/lock
170 5303935180 A B C Kit-AntiTiip bracket installation (complete w/template & screws)
170* 316116000 A B C Screw-anti-tip bracket, 1.75” concrete (2)

04/00 10
Publication number
5995336079 FGF376CJBA,FGF376CJSA,FGF376CJTA
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER

# - Fast Moving Parts
* - Non Illustrated Parts 11 04/00
Publication number
FGF376CJBA,FGF376CJSA,FGF376CJTA 5995336079
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER
A = FGF376CJ (FGF376CJBA)
B = FGF376CJ (FGF376CJSA)
C = FGF376CJ (FGF376CJTA)
POS. NO PART NO DESCRIPTION
* 316089600 A B C Spacer-drawer (2)
* 5303280311 A B C Screw, waf hd sdr , 10-32 x 5/16 (2)
1 316011501 A B C Drawer-utility
2 3131975 A B C Shield-panel
4 316084405 - B - Panel-drawer, white
4 316084406 - - C Panel-drawer, almond
4 316084407 A - - Panel-drawer, black
4* 08067785 - - C Screw-hex washer head, 8-18AB x 1/2
7 3051163 A B C Glide-drawer, rear
16 316114803 A - - Maintop, black
16 316114801 - B - Maintop, white
16 316114802 - - C Maintop, almond
19 316011419 A - - Pan-burner, 11K, black (1)
19 316011417 - B - Pan-burner, 11K, light gray (1)
19 316011418 - - C Pan-burner, 11K, almond (1)
19A 316011401 A - - Pan-burner, 9K/5K, black (3)
19A 316011409 - B - Pan-burner, 9K/5K, light gray (3)
19A 316011410 - - C Pan-burner, 9K/5K, almond (3)
20 316085304 - B C Grate-burner, light gray (4)
20 316085305 A - - Grate-burner, black (4)
22A 316098505 A - - Cap-burner, 11K, black (1)
22A 316098509 - B C Cap-burner, 11K, light gray (1)
22 316122100 A - - Cap-burner, 9K, black (2)
22 316122101 - B C Cap-burner, 9K, gray (2)
22B 316118800 A - - Cap-burner, 5K, black (1)
22B 316118801 - B C Cap-burner, 5K, light gray (1)
48 316077401 A B C Shield-maintop (2)

04/00 12
Publication number
5995336079 FGF376CJBA,FGF376CJSA,FGF376CJTA
CAUTION: Use the part number on all orders, not the position number.
DOOR

# - Fast Moving Parts
* - Non Illustrated Parts 13 04/00
Publication number
FGF376CJBA,FGF376CJSA,FGF376CJTA 5995336079
CAUTION: Use the part number on all orders, not the position number.
DOOR
A = FGF376CJ (FGF376CJBA)
B = FGF376CJ (FGF376CJSA)
C = FGF376CJ (FGF376CJTA)
POS. NO PART NO DESCRIPTION
3 316067802 A - - Trim-oven door, black
3 316067803 - - C Trim-oven door, almond
3 316067804 - B - Trim-oven door, white
4 316089012 A - - Glass-oven door, front, black
4 316089013 - B - Glass-oven door, front, white
4 316089014 - - C Glass-oven door, front, black
5 316117601 A B C Glass-door airwash, large visualite, 4mm
6 316091404 A B C Shield-heat/wool
8 316117500 A B C Glass-oven door, inner (2)
10 5303280308 A B C Screw-handle mounting, wafer head, 10-24T x 2
10B 316008401 A B C Washer-handle mounting, steel, ¾ x ¼ (2)
12# 5303131601 A B C Seal-oven door
14 316102204 A - - Foil-aluminum (black door only) (1)
14A 316102205 A - - Foil-aluminum (black door only) (2)
14 316102202 - B C Foil-aluminum (1)
14A 316102203 - B C Foil-aluminum (2)
15 316081405 A B C Bracket-glass, (2)
17 316117701 A B C Spacer-glass, (2)
39 316091115 - B - Handle-door, white
39 316091116 - - C Handle-door, almond
39 316091117 A - - Handle-door, black
52 316081301 - B - Shield-oven door, top, white
52 316081303 A - - Shield-oven door, top, almond
52 316081302 - - C Shield-oven door, top, almond
60B 316021110 A - - Screw, 8-18x1/2 Tr Sqd Black
60B 316021112 - B - Screw-8-18x1/2 Tr Sqd White
60B 316021113 - - C Screw-8-18x1/2 Tr Sqd Almond
* 316065306 A B C Plate-warning/caution
* 3203618 A B C Rivet-pop, warning-plate

04/00 14
Publication number
5995336079 FGF376CJBA,FGF376CJSA,FGF376CJTA
CAUTION: Use the part number on all orders, not the position number.
WIRING DIAGRAM
