FACTORY PARTS CATALOG
ELECTRIC RANGE
P.O. Box 212378
Augusta, Georgia 30917
PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF358BFWD FEF358BF WHITE USA
FEF358BFDD FEF358BF ALMOND/ALMOND USA
Publication No.
5995320008
980731
-EN/SERVICE /VLM
369
WIRING DIAGRAM # - 316002651
OWNER’S GUIDE # - 316000268
INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE
FEF358BFWD
FEF358BFDD

03/99 2
Publication number
5995320008 FEF358BFWD, FEF358BFDD
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD

# - Fast Moving Parts
* - Non Illustrated Parts 3 6/98
Publication number
FEF358BFWD, FEF358BFDD 5995320008
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
A = FEF358BF (FEF358BFWD)
B = FEF358BF (FEF358BFDD)
POS. NO PART NO DESCRIPTION
* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B Screw-8-18x1/2 Tr Sqd black
* 316071902 A B Gasket-edge
* 316085600 A B Insulator-shield thermostt
* 316112500 A B Template, Anti-tip bracket
1 316081601 A B Shield-backguard,rear wall
2 316015905 A B Shield-backguard,inner
11 316083719 A B Trim-wrapper,textured ,black
13A# 316095500 A B Switch-warmer,infinite ,drawer/zone
14 316022504 A B Light-indicator,250v
14A 316022500 A B Light/Lamp, warmer,, indicator ,
drawer/zone,125 V
15 316023108 A B Support-backguard,RH
15A 316023109 A B Support-backguard,LH
19 316100503 A B Panel-control,metal ,black
20 # 316101001 A B Clock/Timer,electronic
20* 316101503 A B Overlay-clock
23 316100300 A B Bracket-clock mtg
24 # 316005602 A B Switch-rocker,oven light ,black
24B# 316083100 A B Switch-rocker,dual element ,black ,LH ,
(2)
31A 316095603 A B Knob-warmer,black
36 316025100 A B Knob-control,infinite sw
39* 5303292005 A B Screw-switch/handle,8-32 x 5/32
40 316025800 A B Panel-manifold
46 316040201 A B Lens-light/lamp,indicator ,red
54 # 316021500 A B Switch-infinite, 6" element
54B# 316049800 A B Switch, infinite , dual element
60 316021105 A B Screw,hex ,8-18 x 3/8 ,back\bodyside

03/99 4
Publication number
5995320008 FEF358BFWD, FEF358BFDD
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 5 03/99
Publication number
FEF358BFWD, FEF358BFDD 5995320008
CAUTION: Use the part number on all orders, not the position number.
BODY
A = FEF358BF (FEF358BFWD)
B = FEF358BF (FEF358BFDD)
POS. NO PART NO DESCRIPTION
* 3203550 A B Plug-button
* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316045000 A B Clip-wire,harness ,main top
* 316101600 A B Shield-vent,smoothtop
* 5303051099 A B Nut,hex ,#10-32
1 316080804 A B Back-main, short,dipped ,black
3 316081034 A - Panel-bodyside,white ,RH
3 316081035 A - Panel-bodyside,white ,LH
3 316081036 - B Panel-bodyside,almond ,RH
3 316081037 - B Panel-bodyside,almond ,LH
5 316107300 A B Screw-leveling
6 316067902 A B Rack-oven
7 316007002 A B Hinge-oven door,(2)
8 3203540 A B Panel-oven bottom
9 316073800 A B Pan-broiler
10 3205234 A B Insert-broiler pan
12 # 316027701 A B Switch-oven light
13 316026800 A B Rod-light switch /door
14 316116400 A B Socket-light
15 5303013071 A B Light Bulb/Lamp
16 08011086 A B Lens-light/lamp,glass ,oven
17 316087500 A B Retainer-lens
18 # 316036300 A B Latch-door
21 3014099 A B Spacer-bodyside,(8)
25 3200848 A B Shield-heat,lower
29 3051162 A B Glide-drawer,front
30 5303283574 A B Bracket-hinge,main top RH
30A 5303283575 A B Bracket-hinge,main top LH
37 # 316111200 A B Probe-oven temp
41 3131570 A B Cover-hinge cutout
44 3131903 A B Bumper-door/drawer,rubber
45 316066100 A B Shield-wire, s/t vent
57 316081101 A B Cover-access
58 3200847 A B Insulation,oven bottom
58A 316047708 A B Insulation, 2" ,oven wrapper
58B 316054200 A B Insulation, 2" ,oven back
59 316073602 A B Tube-oven vent
59A 316023601 A B Tube-oven vent,upper
59B 316040100 A B Bracket-mounting,vent tube
62 # 5303935061 A B Terminal Block
63 5301145190 A B Plate-ground strap
66 # 5303051140 A B Element-broil
67 # 316075102 A B Element-bake,lower oven
68 316075300 A B Support-element, broil
71 316015805 A B Shield-rear wall
72 5303285692 A B Cover-light/switch rod
82 5303289913 A B Shield-insulation
87 316081200 A B Bracket-cable mtg
88 316026400 A B Rod-latch,auto
89 # 316028101 A B Motor-latch/lock
170 316107200 A B Anti-tip bracket
170* 316116000 A B Screw-Anti tip, 1.75" concrete

03/99 6
Publication number
5995320008 FEF358BFWD, FEF358BFDD
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER

# - Fast Moving Parts
* - Non Illustrated Parts 7 03/99
Publication number
FEF358BFWD, FEF358BFDD 5995320008
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER
A = FEF358BF (FEF358BFWD)
B = FEF358BF (FEF358BFDD)
POS. NO PART NO DESCRIPTION
* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B Screw-8-18x1/2 Tr Sqd black
* 316021112 A - Screw-8-18x1/2 Tr Sqd White
* 316021113 - B Screw-8-18x1/2 Tr Sqd Almond
* 316045000 A B Clip-wire,harness ,main top
* 316089600 A B Spacer-drawer,(2)
* 5303280311 A B Screw,waf hd sdr ,10-32 x 5/16 ,(2)
* 5309951550 A B Cleaner-cooktop
1 316011501 A B Drawer-utility
2 3131975 A B Shield-panel
4 316084405 A - Panel-drawer,white
4 316084406 - B Panel-drawer,almond
4* 08067785 - B Screw,hex washer head ,8-18AB x 1/2
7 3051163 A B Glide-drawer,rear
15A# 316010203 A B Element-surface,radiant , small/6 inch ,
1200W,limit sw incl
15B# 316049703 A B Element-surface,radiant ,dual ,
2100W/1000W,limit sw incl
15C# 316098200 A B Element-warmer,120V/100W
16 316098127 A - Main Top,glass ,white
16 316098128 - B Main Top,glass ,almond
18 5303273062 A B Hinge-main top,RH
18A 5303273063 A B Hinge-main top,LH
26 316099101 A B Channel-support,element ,(2)
26A 316099201 A B Bracket-support, chassis
44 3131903 A B Bumper-door/drawer,rubber
48 316100200 A B Shield-wire,main top
52 316099400 A B Clip-spring, element mtg,(8)
53 316099300 A B Bracket-indicator light,hot surface ,
4 hole
88 316099500 A B Pin-guide,(2)

03/99 8
Publication number
5995320008 FEF358BFWD, FEF358BFDD
CAUTION: Use the part number on all orders, not the position number.
DOOR

# - Fast Moving Parts
* - Non Illustrated Parts 9 03/99
Publication number
FEF358BFWD, FEF358BFDD 5995320008
CAUTION: Use the part number on all orders, not the position number.
DOOR
A = FEF358BF (FEF358BFWD)
B = FEF358BF (FEF358BFDD)
POS. NO PART NO DESCRIPTION
* 3203618 A B Rivet-pop,warning-plate
* 316021110 A B Screw-8-18x1/2 Tr Sqd black
* 316065301 A B Plate warning/caution
* 5303212762 - B Screw,8-18 X 1/2
* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 1/2
* 5303280311 A B Screw,waf hd sdr ,10-32 x 5/16 ,(2)
3 316067802 A B Trim-oven door,black
4 316089000 A B Glass-oven door,black ,outer
5 316088700 A B Glass-oven door,airwash
6 316088401 A B Shield-wool
7 316076403 A B Insulation-door
8 316088600 A B Glass-oven door,inner
9 316066610 A B Liner-oven door
10 5303280308 A B Screw-handle mtg,wafer head ,10-24T x 2
12 # 5303131601 A B Seal-oven door
14 5303208656 A B Reflector,aluminum foil
14A 5303208655 A B Reflector,aluminum foil
15 316081403 A B Bracket-glass mtg
16 316085701 A B Glass-oven door,heat barrier
39 316091114 A B Handle-door,black ,oven
39* 316008401 A B Washer,3/4 x 1/4 ,steel
39* 5303292005 A B Screw-switch/handle,8-32 x 5/32
52 316081303 A B Shield-oven door,black ,top

03/99 10
Publication number
5995320008 FEF358BFWD, FEF358BFDD
CAUTION: Use the part number on all orders, not the position number.
WIRING DIAGRAM
