Frigidaire FEC30C4ABD Instruction Manual

Product No. FEC30C4ABD FEC30C4ACD FEC30C4AQD FEC30C4ASD
3805421161064 38054211610C4 3805421161044 3805421161014
Series 30" elec 30" elec 30" elec 30" elec
Color black stainless bisque white
Market North America North America North America North America
Wiring Diagram 318046901 318046901 318046901 318046901
Owner's Guide 318200612 318200612 318200612 318200612
Installation Instructions 318201410 318201410 318201410 318201410
FEC30C4A.eps LA9923G29A.eps LA9923V32.eps 318046901.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995403044
04/02/02
(EN/SERVICE/ECL)
377
ELECTRIC COOK-TOP
RANGE
Model No.
FEC30C4A
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995403044 FEC30C4A
02/04 2
CONTROL PANEL

FEC30C4A Publication No: 5995403044
# Functional Parts 3 02/04
* Non-Ilustrated Parts
CONTROL PANEL
Model Index: AFEC30C4A (FEC30C4ASD)
BFEC30C4A (FEC30C4ABD)
CFEC30C4A (FEC30C4ACD)
DFEC30C4A (FEC30C4AQD)
POS. NO PART NO. DESCRIPTION
14 # 3200297 A B C D Light/Lamp, indicator
16 5303301457 A B C D Plate, instrument mtg
16A 5303301458 A B C D Cover, instrument mtg.
19 318242300 A - - - Panel, control, white
19 318242302 - B C - Panel, control, black
19 318242301 - - - D Panel, control, bisque
36 318196633 A - - - Knob, control, white
36 318196634 - B C - Knob, control, black
36 318196635 - - - D Knob, control, bisque
46 5303299764 A B C D Lens, indicator light
54 # 318220014 A B C D Switch, surface unit, small
54A# 318220015 A B C D Switch, surface unit, large
69 5303305528 A B C D Screw, 8-32 x 1/4
74 318146010 A B C D Bushing, switch
* 5304410665 A B C D Screw, 10-32 x 5/8

Publication No: 5995403044 FEC30C4A
02/04 4
MAIN TOP/SURFACE UNITS

FEC30C4A Publication No: 5995403044
# Functional Parts 5 02/04
* Non-Ilustrated Parts
MAIN TOP/SURFACE UNITS
Model Index: AFEC30C4A (FEC30C4ASD)
BFEC30C4A (FEC30C4ABD)
CFEC30C4A (FEC30C4ACD)
DFEC30C4A (FEC30C4AQD)
POS. NO PART NO. DESCRIPTION
15 # 5308011964 A B C D Element, surface, large/8 inch, (2), medallion incl
15A# 5304437241 A B C D Element, surface, small/6 inch, 1250W, medallion incl
16 318159021 A - - - Main Top, white
16 5303324148 - B - - Main Top, black
16 318159023 - - C - Main Top, stainless
16 318159025 - - - D Main Top, bisque
17 3016817 A B C D Rod, maintop support
18 318074310 A B C D Hinge, maintop, (2)
19 # 318067056 A B C D Pan, surface element, large, chrome
19A# 318067046 A B C D Pan, surface element, small, chrome
27 # 318223407 A B C D Terminal Block, surface element, 21", white leads
27 # 318223409 A B C D Terminal Block, surface element, 24", yellow leads
27 # 318223423 A B C D Terminal Block, surface element, 36", brown leads
27 # 318223424 A B C D Terminal Block, surface element, 36", orange leads
28 5303301461 A B C D Medallion, surface element
46 318077401 A B C D Burner Box
93 318122500 A B C D Support, terminal block, (4)
136 5303935029 A B C D Support
137 5303323138 A B C D Screw, 10-24x1/2
140 318216000 A B C D Spacer, installation
183 5304410665 A B C D Screw, 10-32 x 5/8
* # 318078525 A B C D Box & wires assy
* 5303308449 A B C D Fastener, wire tie
* 5303300195 A B C D Screw, 10-32 x 0.375, terminal block, (2)
* 5303311532 A B C D Screw, 6-32 x 1/4", back

Publication No: 5995403044 FEC30C4A
02/04 6
WIRING DIAGRAM
